Motorola MOTOKRZR maxx K3 User manual

Level 1 and 2 Service Manual
6809509A88-O
Wireless Telephone
UMTS 2100, GSM 900/1800/1900 GPRS
MOTOKRZRTM
K3

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.
All other product or service names are the property of their respective owners.
The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license.
© Motorola, Inc. 2007.
All rights reserved.
Mobile Devices Business,
Sawgrass International Concourse
789 International Parkway
Room S2C
Sunrise, FL 33325-6220

6809509A88-O February 02, 2007 3
Level 1 and 2 Service Manual Contents
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Regulatory Agency Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Computer Program Copyrights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
About This Service Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Warranty Service Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Parts Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
General Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Controls, Indicators, and Input / Output (I/O) Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Alert Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Battery Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Tools and Test Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Removing and Replacing the Battery Door and Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Removing and Replacing the Trans Flash Memory Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Removing and Replacing the Subscriber Identity Module (SIM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Removing and Replacing the Rear Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Removing and Replacing the Transceiver Board Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Removing and Replacing the Daughter Board Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Removing and Replacing the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Removing and Replacing the Antenna Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Removing and Replacing the Keypad Mylar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Removing and Replacing the Flip Assembly Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Removing and Replacing the Display Module Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Removing and Replacing the VGA Camera Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Removing and Replacing the Main Camera Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Removing and Replacing the Flip Hinge and Flex Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Replacing the CLI and Main Display Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Subscriber Identity Module (SIM) and Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
USIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Personality Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Manual Test Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Manual Test Mode Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Programming: Software Upgrade and Flexing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Part Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Exploded View Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Exploded View Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
1 and 2
Contents
K3
6809509A88-O

4 February 02, 2007 6809509A88-O
Contents K3

6809509A88-O February 02, 2007 5
Level 1 and 2 Service Manual Introduction
Introduction
Motorola
®
Inc. maintains a worldwide organization that is dedicated to provide
responsive, full-service customer support. Motorola products are serviced by an
international network of company-operated product-care centers as well as
authorized independent service firms.
Available on a contract basis, Motorola Inc. offers comprehensive maintenance and
installation programs that allow customers to meet requirements for reliable,
continuous communications.
To learn more about the wide range of Motorola service programs, contact your local
Motorola products representative or the nearest Customer Service Manager.
Product Identification
Motorola products are identified by the model number on a label usually located
under the battery. Use the entire model number when inquiring about the product.
Numbers are also assigned to chassis and kits. Use these numbers when requesting
information or ordering replacement parts.
Product Names
Product names are listed on the front cover. Product names are subject to change
without notice. Some product names, as well as some frequency bands, are available
only in certain markets.
Product Changes
When electrical, mechanical or production changes are incorporated into Motorola
products, a revision letter is assigned to the chassis or kit affected, for example;
-A, -B, or -C, and so on.
The chassis or kit number, complete with revision number, is imprinted during
production. The revision letter is an integral part of the chassis or kit number and
is also listed on schematic diagrams and printed-circuit board layouts.
Regulatory Agency Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following conditions:
• This device may not cause any harmful interference
• This device must accept interference received, including interference that may
cause undesired operation
This class B device also complies with all requirements of the Canadian
Interference-Causing Equipment Regulations (ICES-003).
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement
sur le matériel brouilleur du Canada.
1 and 2
MOTOKRZR K3
6809509A88-O

6 February 02, 2007 6809509A88-O
Introduction MOTOKRZR K3
Computer Program Copyrights
The Motorola products described in this manual may include Motorola computer
programs stored in semiconductor memories or other media that are copyrighted
with all rights reserved worldwide to Motorola. Laws in the United States and other
countries preserve for Motorola, Inc. certain exclusive rights to the copyrighted
computer programs, including the exclusive right to copy, reproduce, modify,
decompile, disassemble, and reverse-engineer the Motorola computer programs in
any manner or form without Motorola's prior written consent. Furthermore, the
purchase of Motorola products shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any license or rights under the copyrights,
patents, or patent applications of Motorola, except for a nonexclusive license to use
the Motorola product and the Motorola computer programs with the Motorola
product.
About This Service Manual
Use of this manual assures proper installation, operation, and maintenance of
Motorola products and equipment. It contains all service information required for
the equipment described and is current as of the printing date. Refer questions
about this manual to the nearest Customer Service Manager.
Audience
This manual aids service personnel in testing and repairing K3 telephones. Service
personnel should be familiar with electronic assembly, testing, and troubleshooting
methods, and with the operation and use of associated test equipment.
Scope
This manual provides basic information relating to K3 telephones, and also provides
procedures and processes for repairing the phones at Level 1 and 2 service centers
including:
•Unitswapout
• Repairing of mechanical faults
• Basic modular troubleshooting
• Testing and verification of unit functionality
• Initiate warranty claims and send faulty modules to Level 3 or 4 repair
centers

6809509A88-O February 02, 2007 7
Level 1 and 2 Service Manual Introduction
Conventions
The following special characters and typefaces, are used in this manual to
emphasize certain types of information.
Warranty Service Policy
The product is sold with the standard 12-month warranty terms and conditions.
Accidental damage, misuse, and extended warranties offered by retailers are not
supported under warranty. Non-warranty repairs are available at agreed fixed
repair prices.
Out-of-Box Failure Policy
The standard out-of-box failure criteria applies. Return customer units that fail
very early on after the date of sale to Manufacturing for root cause analysis, to guard
against epidemic criteria. Manufacturing to bear the costs of early life failure.
Product Support
Customer’s original units will be repaired but not refurbished as standard.
Appointed Motorola Service Hubs will perform warranty and non-warranty field
service for level 2 (assemblies) and level 3 (limited PCB component). Motorola High
Tech Centers will perform level-4 (full component) repairs.
Customer Support
Customer support is available through dedicated Call Centers and in-country help
desks. Product Service training is available through the local Motorola Support
Center.
➧
Note: Emphasizes additional information pertinent to the subject
matter.
G
Caution: Emphasizes information about actions which may result in
equipment damage.
E
Warning: Emphasizes information about actions which may result
in personal injury.
P
Keys to be pressed are represented graphically. For example, instead of “Press
the End key”, you will see “Press P ”.
Information from a screen is shown in text as similar as possible to what
displays on the screen. For example, PHONEBOOK .
Information that you need to type is printed in boldface type.

8 February 02, 2007 6809509A88-O
Introduction MOTOKRZR K3
Parts Replacement
When ordering replacement parts or equipment, include the Motorola part number
and description used in the service manual.
When the Motorola part number of a component is not known, use the product model
number or other related major assembly along with a description of the related
major assembly and of the component in question.
In the U.S.A., to contact Motorola, Inc. on your TTY, call: 800-793-7834.
Replacement Parts Service Division (RPSD)
Order replacement parts, test equipment, and manuals from RPSD.
U.S.A. Outside U.S.A.
Phone: [phone] Phone: [phone]
FAX: [phone] FAX: [phone]
Website: http://businessonline.motorola.com
EMEA
Phone: + 49 461 803 1404
Website: http://emeaonline.motorola.com
Asia
Phone: + 65 648 62995
Website: http://asiaonline.motorola.com

6809509A88-O February 02, 2007 9
Level 1 and 2 Service Manual Introduction
Specifications
Table 1. Specifications
Function Specification
Frequency Range EGSM TX: 880 - 915 MHz
Frequency (MHz) = 890 + (0.2 ×n) where: 0 ≤n ≤124
Frequency (MHz) = 890 + (0.2 ×(n – 1024)) where: 955 ≤n ≤1023
RX: 925 – 960 MHz
Frequency (MHz) = 935 + (0.2 ×n) where: 0 ≤n ≤124
Frequency (MHz) = 935 + (0.2 ×(n – 1024)) where: 955 ≤n ≤1023
Frequency Range DCS TX: 1710 to 1785 MHz
Frequency (MHz) = 1710.2 + (0.2 ×(n – 512)) where: 512 ≤n ≤885
RX: 1805.2 to 1879.8 MHz
Frequency (MHz) = 1805.2 + (0.2 ×(n – 512)) where: 512 ≤n ≤885
Frequency Range PCS TX: 1850 to 1910 MHz
Frequency (MHz) = 1850.2 + (0.2 ×(n – 512)) where: 512 ≤n ≤810
RX: 1930 to 1990 MHz
Frequency (MHz) = 1930.2 + (0.2 ×(n – 512)) where: 512 ≤n ≤810
Frequency Range UMTS TX: 1920 to 1980 MHz
Frequency (MHz) = UARFCN
1
÷5, where: 9612 < UARFCN
1
< 9888
UARFCN
1
in increments of 25
RX: 2110 to 2170 MHz
Frequency (MHz) = UARFCN
1
÷5, where: 10562 < UARFCN
1
< 10838
UARFCN
1
in increments of 25
Channel Spacing 200 kHz (GSM, DCS, PCS), 5 MHz UMTS
Channels 174 EGSM, 374 DCS, 274 PCS carriers with 8 channels per carrier, 11 UMTS
Duplex Spacing 45 MHz GSM, 95 MHz DCS, 80 MHz PCS, 190 MHz UMTS
Modulation GMSK AT BT = 0.3 (GSM, DCS, PCS), QPSK (UMTS)
Transmitter Phase Accuracy 5 degrees RMS, 20 Degrees peak
Frequency Error + 0.1ppm
Input/Output Impedance 50 ohms (nominal)
Nominal Operating Voltage 3.6 Vdc +10% (battery)
+4.4 Vdc +10% (external connector)
Dimensions (xyz) 103.2 x 42.3 x 16.3mm
Size 63cc
Weight 105 g
Display Main Display: 262K color QVGA, 320 x 240, 2.0”
CLI Display: 262K color TFT, 120 x 160, 1.3”
Battery Life (950mAh)
2
GSM: Talk time: Up to 237minutes
GSM: Standby time: Up to 452 hours
WCDMA Talk time: Up to 196 minutes
WCDMA Standby time: Up to 365 hours
WCDMA Video talk time:Up to 135 minutes
Nominal Operating
Temperature Range
-10º C to +55º C

10 February 02, 2007 6809509A88-O
Introduction MOTOKRZR K3
GSM System Functions Specification
Speech Coding Type Regular Pulse excitation / linear predictive coding with long term prediction
(RPE LPC with LTP)
Bit Rate 13.0 kbps
RF Power Output 32 dBm nominal GSM, 28.5 dBm nominal DCS / PCS
Spurious Emissions -36 dBm from 0.1 to 1 GHz, -30 dBm from 1 to 4 GHz
Receive Sensitivity -102 dBm GSM, -102 dBm DCS / PCS
RX Bit Error Rate < 2%
UMTS System Functions Specification
Speech Coding Type Adaptive Multirate (AMR)
RF Power Output 21 dBm
Spurious Emissions -36 dBm from 0.1 to 1 GHz, -30 dBm from 1 to 4 GHz
Error Vector Magnitude < 17.5%
PN9 Bit Error Rate (VER) 0.1% @12.2K, -106.7 dBm
ACLR -33 dBm @+5 MHz, -43 dBm @+10 MHz

6809509A88-O February 02, 2007 11
Level 1 and 2 Service Manual Product Overview
Product Overview
Motorola K3 telephones represent the thinnest and slenderest 3G features in a
small and lightweight package. These Global System for Mobile communications
(GSM) General Packet Radio Service (GPRS) Wireless Application Protocol (WAP)
enabled mobile phones incorporate an icon based User Interface (UI) for easier
operation, allows Short Message Service (SMS) text messaging, Multi-media
Messaging Services (MMS), and includes Personal Information Manager (PIM)
functionality.
MOTOKRZR K3 ™ is a multi-band phone that allows roaming within the GSM 900
MHz, 1800 MHz Digital Cellular System (DCS), and PCS 1900 MHz bands, in
addition to the UMTS WCDMA 2100 MHz band.
K3 telephones have a clam form factor design. They feature an anodized aluminum
housing and have an externally viewable 96x80 1.0” 65K CSTN external display for
caller identification and date/time, an internal 176x220 1.9” 262K TFT display, and
the speaker located in the flip. The bottom part of the clam (front housing) contains
the keypad, transceiver printed circuit board (PCB), microphone, flex connection,
external accessory connector, smart button, volume buttons, and voice button. The
standard 750 mAh Lithium Ion (Li Ion) battery fits behind a removable back cover.
The phone accepts both 3V and 1.8V mini subscriber identity module (SIM) cards,
which fit into the SIM holder next to the battery. The antenna is internal.
Inexpensive direct connection to a computer or handheld device via USB or
Bluetooth™ for data and fax calls, and for synchronizing phonebook entries with
Mobile Phone Tools software, can be accomplished by using the optional data cable
and soft modem.
Features
K3 telephones use advanced, self-contained, sealed, custom integrated circuits to
perform the complex functions required for GSM GPRS communication. Aside from
the space and weight advantage, microcircuits enhance basic reliability, simplify
maintenance, and provide a wide variety of operational functions.
Features available in this family of telephones include:
• Ultra Slim form factor
• EDGE for high speed data access (class 12)
• Video Capture & Playback MPEG4 (15 fps CIF)
• Audio/Video streaming (3GPP)
• Video Progressive Download
• Dedicated Carrier Key
• Integrated Stereo Bluetooth Connectivity (Class 2)
• 2MP digital camera with 8x digital zoom
• MicroSD slot for upgradeable memory
• Push To Share (images, video, audio files)
• Dynamic Idle
• 22MB of embedded end user memory
• Rich, pre-loaded J2ME™ games, screen savers
• Downloadable themes, ringer tones, images, animations
• Image borders, text overlay, image editing
• Midi, MP3, AAC, AAC+ Enhanced, iTunes music player
• PIM functionality with Picture Caller ID
• Voice memo & enhanced predictive text

12 February 02, 2007 6809509A88-O
Product Overview MOTOKRZR K3
• Enhanced voice recognition
• Record up to 25 minutes of video on embedded memory
• Firmware Over-The Air (FOTA)
• UI Skinning
• Motosync – contacts (calendar, emails TBC)
Voice Commands and Voice Note Recording
Voice commands can be used for voice dialing phone numbers in the phone book
and for creating voice shortcuts for menu items.
K3 telephones also include a voice recorder that allows up to 2 minutes of personal
messages to be recorded. This feature has a complete set of record, playback, and
management tools that make it easy to store and maintain a list of personal memos.
Wireless Access Protocol (WAP) 2.0 Compliancy
In the WAP environment, access to the Internet is initiated in wireless markup
language (WML), which is derived from hypertext markup language (HTML). The
request is passed to a WAP gateway which retrieves the information from the server
in standard HTML (subsequently filtered to WML) or directly in WML if available.
The information is then passed to the mobile subscriber via the mobile network.
The K3 microbrowser can be configured for baud, idle timeout, line type, phone
number, and connection type.
SIM Application Toolkit
TM
- Class 2
SIM Application Toolkit is a value-added service delivery mechanism that allows
GSM operators to customize the services they offer their customers, from the
occasional user who requests sports news and traffic alerts, to a high call time
business user who receives stock alerts and checks flight times. Operators can now
create their own value-added services menu quickly and easily in the phone. The
customized menu will appear as the first menu and may be updated over-the-air
with new services when customers request them.
Simplified Text Entry
There are three different ways to enter text using the phone keypad:
• iTAP™ predictive text entry. Press a key to generate a character and a
dynamic dictionary uses this to build and display a set of word or name
options. The iTAP™ feature may not be available on the phone in all lan-
guages.
• Tap. Press a key to generate a character.
• Numeric. The keypad produces numeric characters only. For some text areas
this is the only method available; for example, phone numbers.
➧
Bitmap image data will download as text. If the image is larger than the screen,
only part of the image will display.
➧
When the user receives a call while in browser mode, the browser will pause and
allow the user to resume after completing the call.

6809509A88-O February 02, 2007 13
Level 1 and 2 Service Manual Product Overview
Caller Line Identification
Upon receipt of a call, the calling party’s phone number is compared to the phone
book. If the number matches a phone book entry, that name will be displayed. If
there is no phone book entry, the incoming phone number will be displayed. In the
event that no caller identification information is available, the Incoming Call
message is displayed.
Other Features
Detailed descriptions of these and other K3 features can be found in the appropriate
user’s guide listed in the “Related Publications” section toward the end of this
manual.
➧
User must subscribe to a caller line identification service through their service
provider.

14 February 02, 2007 6809509A88-O
General Operation MOTOKRZR K3
General Operation
Controls, Indicators, and Input / Output (I/O) Connections
The K3 series telephone’s controls are located on the sides of the flip and on the
keypad. Indicators, in the form of icons, are displayed on the LCD (see Figure 2).
K3 phones have an audible alert transducer on the top and I/O connectors,
consisting of a charger/accessory port, located on the side of the phone. See Figure 1.
“Soft keys” refer to non-labeled keys that correspond to text options displayed on
the screen. The left and right soft keys perform the function shown in the corners
of the display. The right key will usually select an option whereas the left key will
usually exit a function or return to a previous screen.
The center select key opens the initial menu structure, or allows access to a
submenu.
Color Display
The K3 wireless phones feature a 262K color QVGA 320 x240 pixel display.
062599o
Figure 1. Controls, indicators, and I/O
Left Soft Key
Volume Keys
Charge up or
go handsfree.
Make &
answer calls.
Smart Key
Video Call Key
Scroll up,
down, left, or
right. Open menu
and select.
Right Soft Key
Clear/Back Key
Camera Key
Turn on & off,
hang up, exit
menus.
Microphone
*Make sure your fingers do not cover microphone during calls.
Go online.
Internal Camera Lens

6809509A88-O February 02, 2007 15
Level 1 and 2 Service Manual General Operation
Display animation makes the phone’s menus move smoothly as the user scrolls up
and down. Figure 2 shows some common icons displayed on the LCD.
1. Signal Strength Indicator – Vertical bars show the strength of the network
connection. You can’t make or receive calls when1or 0shows.
2. EDGE/GPRS Indicator – Shows when your phone is using a high-speed
Enhanced Data for GSM Evolution (EDGE) or General Packet Radio
Service (GPRS) network connection. Indicators can include:
3. Data Indicator – Shows connection status.
061309a
Figure 2. Icon Indicators
➧
Whether a phone displays all indicators depends on the programming and services
to which the user subscribes.
H GPRS PDP context
active
œ EDGE
B GPRS packet data
available
L secure packet
data transfer
K unsecure
packet data
transfer
N secure
application
connection
M unsecure
application
connection
S secure Circuit
Switch Data (CSD)
call
T unsecure CSD
call
ΠHigh-Speed Downlink Packet Access
(HSDPA) data transfer
O Bluetooth™ connection is active
5. Active
Line
6. Message
7. Ring Style
8. Battery
Level
4. Roam
3. Data
2. EDGE /
GPRS
1. Signal
Strength
Service Provider
12:00
Options Main Menu

16 February 02, 2007 6809509A88-O
General Operation MOTOKRZR K3
4. Roam Indicator – Shows when your phone is seeking or using a network
outside your home network. Indicators can include:
5. Active Line Indicator – Shows hto indicate an active call, or gto
indicate when call diverting is on. Indicators for dual-line-enabled SIM
cards can include:
6. Message Indicator – Shows when you receive a new message. Indicators
can include:
7. Ring Style Indicator – Shows the ring style setting.
8. Battery Level Indicator – Vertical bars show the battery charge level.
Recharge the battery when your phone shows Low Battery.
Alert Settings
K3 telephones include up to 32 preset alert tones and vibrations that can be applied
to all alert events at the same time.
Battery Function
Battery Gauge
The telephone displays a battery level indicator icon in the idle screen to indicate
the battery charge level. The gauge shows four levels: 100%, 66%, 33%, and Low
Battery.
b 2G home c 2G roam
a 2.5G home Z 2.5G roam
Y 3G home X 3G roam
Ž HSDPA home Š HSDPA roam
HSDPA is High-Speed Downlink Packet
Access, available on some networks.
f line 1
active
i line 1 active, call
divert on
e line 2
active
j line 2 active, call
divert on
É text message Ë voice message
õ loud ring Ì vibrate & ring
ô soft ring ö vibrate then ring
Î vibrate Í silent
➧
Pressing any volume key mutes the alert.

6809509A88-O February 02, 2007 17
Level 1 and 2 Service Manual General Operation
Battery Removal
Removing the battery causes the device to immediately shut down and any pending
work (for example, partially entered phone book entries or outgoing messages) is
lost.
Operation
For detailed operating instructions, refer to the appropriate User’s Guide.
G
If the battery is removed while receiving a message, the message will be lost.

18 February 02, 2007 6809509A88-O
General Operation MOTOKRZR K3

6809509A88-O February 02, 2007 19
Level 1 and 2 Service Manual Tools and Test Equipment
Tools and Test Equipment
The following table lists tools and test equipment recommended for disassembly
and reassembly of K3 telephones. Use either the listed items or equivalents.
Table 1. General Test Equipment and Tools
Part Number
1
Description Application
RSX4043-A Torque Driver Used to remove and replace screws
—Torque Driver Bit T-5 Plus, Apex 440-6IP
Torx Plus or equivalent Used with torque driver
See Table 7 Rapid Charger Used to charge battery and to power
device
0180386A82
Antistatic Mat Kit (includes 66-80387A95
antistatic mat, 66-80334B36 ground
cord, and 42-80385A59 wrist band)
Provides protection from damage to
device caused by electrostatic discharge
(ESD)
6680388B67 Disassembly tool, plastic with flat and
pointed ends (manual opening tool)
Used during assembly/disassembly of
device
6680388B01 Tweezers, plastic Used during assembly/disassembly
Tweezers, metal Used during assembly/disassembly
— Digital Multimeter, HP34401A
2
Used to measure battery voltage
19501980
3
Generic Press Fixture Must be used to install keypad mylar
0-00-00-40862
3
K3 EL & Side key alignment and press
fixture Must be used to install
EL Mylar.
0-00-00-40863
3
Main Lens + CLI Lens + Trim Ring press
fixture
Must be used to install main lens and
CLI lens and trim ring
8102430Z04 GSM / DCS Test SIM Used to enable manual test mode
1. To order in North America, contact Motorola Aftermarket and Accessories Division (AAD) at [phone] or
FAX [phone]; Internationally, AAD can be reached by calling [phone] or faxing [phone].
2. Not available from Motorola. To order, contact Hewlett Packard at [phone].
3. Available at the AMS Online-shop 62.214.1.200 (for access, please contact your local Motorola parts representative)
1 and 2
K3
6809509A88-O

20 February 02, 2007 6809509A88-O
Disassembly K3
Disassembly
The procedures in this section provide instructions for the disassembly of K3
telephones. Tools and equipment used for the phone are listed in Table 1, preceding.
Removing and Replacing the Battery Door and Battery
1. Ensure the phone is turned off.
2. Press in the battery door latch, as shown in Figure 1.
3. Slide the battery door forward and lift it completely off the phone.
G
Many of the integrated devices used in this equipment are vulnerable to damage
from electrostatic discharge (ESD). Ensure adequate static protection is in place
when handling, shipping, and servicing the internal components of this equipment.
G
Avoid stressing the plastic in any way to avoid damage to either the plastic or
internal components.
E
All batteries can cause property damage and/or bodily injury, such as, burns if a
conductive material, such as, jewelry, keys, or beaded chains touch exposed termi-
nals. The conductive material may complete an electrical circuit (short circuit) and
become quite hot. Exercise care in handling any charged battery, particularly when
placing it inside a pocket, purse, or other container with metal objects.
065317o
Figure 1. Removing the Battery Door
Battery door latch
Battery door
