Motorola MC18 User manual

MC18
Mobile Computer
Accessories Guide

What Ships with Every MC18
MC18
1x Battery
(Electronic User Guide
loaded onto device)

BTRY-MC18-27MAG-01 MC18 PowerPrecision + 2,725 mAh
Lithium-Ion Battery. Single Pack.
Step 1:
Choose a spare battery Spare Battery options
Standard Battery
BTRY-MC18-27MAG-10 MC18 PowerPrecision + 2,725 mAh
Lithium-Ion Battery. 10-Pack.

CRD-MC18-1SLOT-01
Cradle Options
Step 2:
Choose a charging method
CRD-MC18-3SLOTH-01
MC18 3-Slot Non-Locking
High Density Cradle.
3 Slot Cradles
PSS-3KY01-00R
Single-Slot Cradle Release Key. DOES
NOT WORK ON 3-SLOT CRADLES.
CRD-MC18-3SLCKH-01
MC18 3-Slot Locking
High Density Cradle.
CRD-MC18-3SLCKS-01
MC18 3-Slot Locking Super
High Density Cradle.
KT-MC18-CKEY-20
MC18 3-Slot Cradle Release Key
(QTY-20). Used to mechanically unlock
the MC18 Terminal from the 3-Slot
Cradles and 1-Slot Cradles.
3 Slot Cradle Accessories
KT-MC18-CTOOL-01
MC18 3-Slot Cradle Cover Removal Tool.
Designed for use where hand space is limited.
MC18 Single-Slot Locking Cradle.
All MC18 Cradles require PWRS-14000-241R, DC line
cord, and Country Specific AC line cord sold separately.
!
Single Slot Cradles
Single Slot Cradle Accessories

Step 3:
Choose cradle connection method: Single Slot Cradles
Step 1
•Power Supply: PWRS-14000-241R
•AC Line Cord: AC Line Cord Matrix
is located on the last page
Step 3
Standard - 1.0 AMP: 12 Cradles/Devices
Fast – 1.5 AMPS: 9 Cradles/Devices
Select one of each. Step 2
Select one DC Y Cable to connect power
supply to a maximum of 12 cradles.
(6 cradles MAX linked to each Y connector)
19.5 Inch 1 Meter 2 Meters
25-66210-
01R 25-67592- 01R CBL-MC18- Y2MET-01
Choose your required charging mode.
Standard Charging Mode Fast Charging Mode
Choose the number of cradle interconnect cables and power
extension cables required based on the table below.
(12 Connected Cradles Max – 6 Max Per Y Connector)
Number of
Cradles 2 3 4 5 6 7 8 9 10 11 12
# of Interconnect
Cables required 1 2 3 4 5 5 6 7 8 9 10
# of Extension
Cables required 2 3 4 5 6 7 8 9 10 11 12
Number of
Cradles 2 3 4 5 6 7 8 9
# of Interconnect
Cables required 1 2 3 4 5 5 6 7
# of Extension
Cables required 2 3 4 5 6 7 8 9
Cradle Interconnect Cable
(12.6 inch): 25-66431-01R
Choose the number of cradle interconnect cables and power
extension cables required based on the table below.
(9 Connected Cradles Max – 6 Max Per Y Connector)
Power Extension Cable:
CBL-MC18-EXINT1-01 Cradle Interconnect Cable
(12.6 inch): 25-66431-01R Power Extension Cable:
CBL-MC18-EXINT1-01

Step 3:
Choose cradle connection method: 3-Slot Cradles
Step 1
•Power Supply: PWRS-14000-241R
•AC Line Cord: AC Line Cord Matrix
is located on the last page
Step 3
Standard - 1.0 AMP
4x 3-Slot Cradles / 12 Devices
Fast – 1.5 AMPS
3 x 3-Slot Cradles / 9 Devices
Select one of each. Step 2
Select one DC Y Cable to connect power
supply to a maximum of 12 cradles.
(6 cradles MAX linked to each Y connector)
19.5 Inch 1 Meter 2 Meters
25-66210-
01R 25-67592- 01R CBL-MC18- Y2MET-01
Choose your required charging mode.
Standard Charging Mode Fast Charging Mode
Choose the number of cradle interconnect cables and power
extension cables required based on the table below.
(4 Connected Cradles Max – 2 Max Per Y Connector)
Number of Cradles 2 3 4
# of Interconnect Cables required 1 1 2
# of Extension Cables required 2 3 4
Number of Cradles 2 3
# of Interconnect Cables required 1 1
# of Extension Cables required 2 3
Choose the number of cradle interconnect cables and power
extension cables required based on the table below.
(3 Connected Cradles Max – 2 Max Per Y Connector)
Cradle Interconnect Cable
(12.6 inch): 25-66431-01R Power Extension Cable:
CBL-MC18-EXINT1-01 Cradle Interconnect Cable
(12.6 inch): 25-66431-01R Power Extension Cable:
CBL-MC18-EXINT1-01

CBL-MC18-EXINT1-01
Cradle Power Extension Cable. Connects
cradle to interconnect cable in order to lengthen
cable and allow for easier installation.
PWRS-14000-241R
PWR SPLY: 100-240VAC,12VDC, 9A .
Cradle Cables
Step 4:
Choose cradle accessories
Cables
25-66210-01R
DC Charging “Y” Cable 19.5 Inch (1 meter).
Runs from Power Supply
(PWRS-14000-241R) to two separate
charging cradles.
25-66431-01R
Cradle Interconnection Cable (12.6 Inch).
Connects Cradles to each other to run off
one power supply (PWRS-14000-241R).
Daisy Chain max = 6 Terminals per.
25-67592-01R
DC Charging “Y” Cable 39.7 Inch.
25-66431-01R
MC18 USB Client Communication Cable for
Cradle to the host system.
Power Supply
DC Cables
25-66420-01R
DC Charging Cable for use with 1-Slot Cradles
(19.5 Inch). Runs from the Power Supply
(PWRS-14000-241R) to one charging cradle.

Keys and Tools
Step 5:
Choose accessories
KT-MC18-CKEY-20
Release Key (20-Pack) for 3-Slot Cradles.
Used to mechanically unlock the MC18
Terminal from the 3-Slot & Single-Slot Cradles.
Keys and Tools
KT-MC18-REBOOT-05
Terminal Reboot Tool (5-Pack). This tool
can be reused to reboot the MC18 terminal
by connecting and holding the pins on the
tool to the terminal while holding down the
scan key for 10 seconds.
KT-MC18-CSTKIT-01
MC18 Deployment Starter Kit. Includes 20-pack of
Release Keys (KT-MC18-CKEY-20), 5-pack of
Terminal Reboot Tool (KT-MC18-REBOOT-05), and
1 Cradle Housing Tool (KT-MC18-CTOOL-01).
KT-MC18-CTOOL-01
Cradle Cover Removal Tool. The
MC18 Cradle Cover Removal tool aids
in the removal of the top housing of the
3-Slot Cradles.
PSS-3SH01-00R
This holder allows mounting the MC17 mobile
computer on a shopping cart.
Cartholder Mounting Kit
QTY-20
QTY-5
QTY-1
Deployment Kit

Step 6:
Choose an AC Line Cord
Country Three Wire Grounded AC Line Cord
Abu Dhabi 50-16000-220R: 1.8M long, CEE 7/7 plug.
Australia 50-16000-217R: 1.9M long, AS 3112 plug.
Bolivia 50-16000-220R: 1.8M long, CEE 7/7 plug.
Brazil 50-16000-727R: 18AWG, 250V, 16A, BR (3w).
China 50-16000-217R: 1.9M long, AS 3112 plug.
50-16000-257R: 1.8M long, IEC 60320 C13 plug.
Dubai 50-16000-220R: 1.8M long, CEE 7/7 plug.
Egypt 50-16000-220R: 1.8M long, CEE 7/7 plug.
Europe 50-16000-220R: 1.8M long, CEE 7/7 plug.
Hong Kong 50-16000-219R: 1.8M long, BS1363 plug.
India 50-16000-669R: 1.9M long, BS 546 plug.
Iran 50-16000-220R: 1.8M long, CEE 7/7 plug.
Iraq 50-16000-219R: 1.8M long, BS1363 plug.
Israel 50-16000-672R: 1.9M long, S132 plug.
Italy 50-16000-671R: 1.8M long, CIE 23-16 plug.
Japan 50-16000-218R: 1.8M long, NEMA 1-15P plug.
Korea 50-16000-220R: 1.8M long, CEE 7/7 plug.
50-16000-256R: 1.8M long, CEE7/7 plug.
Malaysia 50-16000-219R: 1.8M long, BS1363 plug.
New Guinea 50-16000-217R: 1.9M long, AS 3112 plug.
Russia 50-16000-220R: 1.8M long, CEE 7/7 plug.
Singapore 50-16000-219R: 1.8M long, BS1363 plug.
UK 50-16000-219R: 1.8M long, BS1363 plug.
US 23844-00-00R: 7.5 feet long.
50-16000-221R: 1.8M long, USA NEMA 5-15P.
Vietnam 50-16000-220R: 1.8M long, CEE 7/7 plug.
