Motorola OM 2000 User manual

INSTALLATION & OPERATION MANUAL
OM 2000
Out of Band Modulator, Software Version 1.0.x
Replaces: 539808-001-c

i
CAUTION
These servicing and installation instructions are for use by qualified personnel only. To reduce the risk
of electrical shock, do not perform any servicing other than that contained in the Installation and
Troubleshooting Instructions unless you are qualified to do so. Refer all servicing to qualified service
personnel.
SPECIAL SYMBOLS THAT MIGHT APPEAR ON THE EQUIPMENT
This symbol indicates that dangerous voltage levels are present within the equipment.
These voltages are not insulated and may be of sufficient strength to cause serious
bodily injury when touched. The symbol may also appear on schematics.
The exclamation point, within an equilateral triangle, is intended to alert the user to
the presence of important installation, servicing, and operating instructions in the
documents accompanying the equipment.
For continued protection against fire, replace all fuses only with fuses having the
same electrical ratings marked at the location of the fuse.
Electrostatic discharge (ESD) can damage the OM unit and circuit card asOMblies.
Wear an antistatic wrist strap attached to a chassis ground to prevent ESD damage.
This equipment operates over the marked Voltage and Frequency range without
requiring manual setting of any selector switches. Different types of line cord sets
may be used for connections to the mains supply circuit and should comply with the
electrical code requirements of the country of use. This equipment requires a
grounding conductor in the line cord.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE. THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.
CAUTION: TO PREVENT ELECTRICAL SHOCK, IF THIS UNIT IS PROVIDED WITH A POLARIZED
PLUG, DO NOT CONNECT THE PLUG INTO AN EXTENSION CORD, RECEPTACLE, OR OTHER
OUTLET UNLESS THE PLUG CAN BE FULLY INSERTED WITH NO PART OF THE BLADES EXPOSED.
CAUTION: TO ENSURE REGULATORY AND SAFETY COMPLIANCE, USE ONLY THE PROVIDED
POWER CABLES.
EQUIPMENT MUST BE CONNECTED TO PROTECTIVE EARTH
THIS EQUIPMENT HAS BEEN DESIGNED FOR CONNECTION TO AN IT POWER DISTRIBUTION
SYSTEM WHEN POWERED BY AC.
THIS DEVICE WHEN POWERED BY DC MUST BE PROTECTED BY A LISTED BRANCH CIRCUIT
PROTECTOR RATED MAXIMUM 25A.
It is recommended that the customer install an AC surge arrestor in the AC outlet to which this device
is connected. This is to avoid damaging the equipment by local lightning strikes and other electrical
surges.
CAUTION: THE POWER SUPPLY PLUG IS INTENDED TO SERVE AS A POWER DISCONNECT
DEVICE. THE SOCKET-OUTLET SHALL BE INSTALLED NEAR THE EQUIPMENT AND SHALL BE
EASILY ACCESSIBLE.

ii
FCC COMPLIANCE
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the Installation Manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his/her own expense. Any changes or
modifications not expressly approved by Motorola could void the user’s authority to operate this
equipment under the rules and regulations of the FCC.
CANADIAN COMPLIANCE
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
International Declaration of Conformity
We Motorola, Inc.
101 Tournament Drive
Horsham, PA 19044, U.S.A.
declare under our sole responsibility that the
Out-of-band Modulator OM 2000
to which this declaration relates is in conformity with one or more of the following standards:
EMC Standards
EN55013 EN50083-2 CISPR-13
Safety Standards
EN50083-1 EN60950-1 IEC 60950-1
following the provisions of the Directive(s) of the Council of the European Union:
EMC Directive 2004/108/EC RoHS Directive 2002/95/EC Low Voltage Directive 2006/95/EC

iii
CARING FOR THE ENVIRONMENT BY RECYCLING
When you see this symbol on a Motorola product, do not dispose of the product with
residential or commercial waste.
Recycling your Motorola Equipment
Please do not dispose of this product with your residential or commercial waste. Some
countries or regions, such as the European Union, have set up systems to collect and
recycle electrical and electronic waste items. Contact your local authorities for
information about practices established for your region. If collection systems are not
available, call Motorola Customer Service for assistance.
© 2009 Motorola, Inc. All rights reserved. No part of this publication may be reproduced in any form or
by any means or used to make any derivative work (such as translation, transformation, or adaptation)
without written permission from Motorola, Inc.
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.
MediaCipher is a registered trademark of Motorola. Pentium is a registered trademark of Intel
Corporation. Microsoft, Windows, Windows NT and Windows XP are either trademarks or registered
trademarks of Microsoft Corporation in the U.S. and/or other countries. Microsoft product screen
shot(s) reprinted with permission from Microsoft Corporation. Sun, Java and all other Java-based marks
are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.
Netscape Navigator is a registered trademark of Netscape Communications Corporation. UNIX is a
registered trademark of The Open Group. Linux is a registered trademark of Linus Torvalds. Infineon
Technologies is a trademark of Infineon Technologies AG. Finisar is a trademark of the Finisar
Corporation. Optical Communications Products and OCP are trademarks of Optical Communications
Products, Inc. Methode Electronics is a trademark of Methode Electronics, Inc. Agilent Technologies is
a trademark of Agilent Technologies, Inc. The following websites are not sponsored, affiliated, or
controlled by Motorola, Inc.: www.netscape.com, www.microsoft.com, www.infineon.com, www.ocp-
inc.com, www.methode.com, www.agilent.com, www.finisar.com, and www.java.sun.com. All other
product or service names are the property of their respective owners.
© Motorola, Inc. 2009
Motorola reserves the right to revise this publication and to make changes in content from time to time
without obligation on the part of Motorola to provide notification of such revision or change. Motorola
provides this guide without warranty of any kind, implied or expressed, including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose. Motorola may make
improvements or changes in the product(s) described in this manual at any time.

v
CONTENTS
1 Introduction .............................................................................................................................................1
Using This Manual .............................................................................................................................2
Related Documentation.....................................................................................................................2
Document Conventions .....................................................................................................................3
Getting Help.........................................................................................................................................4
Returning for Repair...........................................................................................................................5
2 Overview ..................................................................................................................................................7
Functional Overview ..........................................................................................................................8
OOB Signal Processing..............................................................................................................8
Physical Overview..............................................................................................................................13
Indicators and Connectors........................................................................................................13
Input/Output and Power Connections .....................................................................................15
3 Installation ...............................................................................................................................................17
Before You Begin................................................................................................................................17
Mounting the OM 2000 ......................................................................................................................18
Connecting the Interface Cables.....................................................................................................19
Connecting Ethernet and Modulator Output Cables .............................................................19
Connecting Optional Serial Port Cables..................................................................................20
Connecting the Optional Ground .....................................................................................................20
Connecting Emergency Alert Wiring...............................................................................................20
OM 2000 Power Connection to AC Power......................................................................................21
OM 2000 Power Connection to DC Power......................................................................................21
Confirming Correct Installation........................................................................................................22
4 Setup and Operation ..............................................................................................................................23
Network Connection..........................................................................................................................23
Verifying the Network Connection ..................................................................................................23
OM-EM Requirements.......................................................................................................................23
Browsers .............................................................................................................................................24
Hardware.............................................................................................................................................24
Operating Systems.............................................................................................................................24
Initiating an OM-EM Session ...........................................................................................................24
OM-EM Software Toolset..................................................................................................................28
System .................................................................................................................................................29
Reboot..................................................................................................................................................30
Administration.....................................................................................................................................31
Setting the Password .................................................................................................................32

CONTENTS
vi
About............................................................................................................................................ 32
Exit ................................................................................................................................................ 33
Configuration...................................................................................................................................... 33
Physical Interface Configuration............................................................................................. 34
Logical Ports Configuration ...................................................................................................... 35
Network Configuration .............................................................................................................. 38
Status ........................................................................................................................................... 39
Status—Alarms .......................................................................................................................... 40
OM Identification........................................................................................................................ 42
Status — Save Entire OM Status ............................................................................................ 43
5 Troubleshooting...................................................................................................................................... 45
Testing the RF Modulator ................................................................................................................. 47
Appendix A — Specifications................................................................................................................. 49
RF Output............................................................................................................................................. 49
IF Output.............................................................................................................................................. 49
AC Electrical Specifications ............................................................................................................ 49
DC Electrical Specifications ............................................................................................................ 49
Operating Environment..................................................................................................................... 50
Physical Specifications .................................................................................................................... 50
Performance Specifications............................................................................................................ 50
Interconnection Specifications....................................................................................................... 51
Data (Bit) Rate.................................................................................................................................... 51
Appendix B — Cabling Specifications .................................................................................................. 53
RS-232 DB9 Interface Cabling ......................................................................................................... 53
DB25 RS-530 Interface Cabling ....................................................................................................... 54
Ethernet 10/100 Base-T Interface Cabling..................................................................................... 55
Appendix C — Initialization Information ............................................................................................... 57
Self-Boot Initialization ...................................................................................................................... 57
External Initialization from a LAN Resident BOOTP Server ........................................................ 57
BOOTP Request and Reply Format.......................................................................................... 58
Typical OM BOOTP Packet Files .............................................................................................. 59
Reference Specifications ......................................................................................................... 59
HCT 1000 as BOOTP Server.............................................................................................................. 60
Appendix D — Fan Field Replacement Procedure.............................................................................. 61
Fan Removal ....................................................................................................................................... 61
Replacement Fan Kit Assemblies.................................................................................................... 62
Fan Replacement............................................................................................................................... 62
Appendix E — RS-232 Console Port ...................................................................................................... 63

CONTENTS
vii
Establishing Communication with a PC ..........................................................................................63
General Operations............................................................................................................................63
Getting the Unit’s ENET1 MAC Address ..................................................................................63
Setting the Unit’s ENET1 IP Address........................................................................................63
Glossary ......................................................................................................................................................65
Abbreviations and Acronyms...........................................................................................................65
Definitions of Terms ...........................................................................................................................67
Figure 1-1 — OM 2000 Out-of-band Modulator ....................................................................................1
Figure 2-1 — OM 2000 operational flow diagram.................................................................................7
Figure 2-2 — OOB data flow through the OM 2000..............................................................................9
Figure 2-3 — Creating an output multiplex............................................................................................11
Figure 2-4 — RF modulator block diagram............................................................................................12
Figure 2-5 — OM 2000 dimensions .........................................................................................................13
Figure 2-6 — OM 2000 front panel..........................................................................................................13
Figure 2-7 — Rear panel ..........................................................................................................................15
Figure 3-1 — OM 2000 Ethernet and modulator output connection..................................................19
Figure 3-2 — OM 2000 optional serial and interface output connection..........................................20
Figure 3-3 — Emergency alert connection ...........................................................................................21
Figure 4-1 — Initiating an OM-EM Session...........................................................................................25
Figure 4-2 — File download pop-up .......................................................................................................25
Figure 4-3 — OM Element Manager Login window.............................................................................26
Figure 4-4 — Incorrect Password error popup ....................................................................................26
Figure 4-5 — OM 2000 Alarms window..................................................................................................27
Figure 4-6 — OM-EM Main window.......................................................................................................28
Figure 4-7 — System drop-down menu, root user logged in..............................................................29
Figure 4-8 — System drop-down menu, non-root user logged in .....................................................30
Figure 4-9 — OM 2000 Reboot pop-up ...................................................................................................30
Figure 4-10 — Administration window...................................................................................................31
Figure 4-11 — Set Password window....................................................................................................32
Figure 4-12 — About popup.....................................................................................................................32
Figure 4-13 — Exit popup .........................................................................................................................33
Figure 4-14 — Configuration drop-down list.........................................................................................33
Figure 4-15 — OM 2000 Physical Interface Configuration window...................................................34
Figure 4-16 — OM 2000 Logical Ports Configuration window............................................................36
Figure 4-17 — PID window ......................................................................................................................37
Figure 4-18 — Network Configuration window ....................................................................................38
Figure 4-19 — Status drop-down list......................................................................................................39
Figure 4-20 — Alarms window................................................................................................................40

CONTENTS
viii
Figure 4-21 — Events window ................................................................................................................ 42
Figure 4-22 — OM Status ........................................................................................................................ 43
Figure 4-23 — Save OM Status window ............................................................................................... 43
Figure D-1 — Fan removal/replacement............................................................................................... 62
Table 2-1 — OM 2000 input ports ........................................................................................................... 9
Table 2-2 — Multiplexer output destinations ....................................................................................... 10
Table 2-3 — OM 2000 front panel RF monitor jack and indicators.................................................... 14
Table 2-4 — OM 2000 input/output and power connections.............................................................. 15
Table 4-1 — Memory Specifications ..................................................................................................... 24
Table 4-2 — OM-EM Software Toolset Button Functionality............................................................. 28
Table 4-3 — Administration window option field definitions............................................................. 31
Table 4-4 — System Time window field definitions............................................................................. 36
Table 4-5 — Ethernet window field definitions.................................................................................... 39
Table 4-6 — OM Element Manager Status Drop-down List Definitions........................................... 40
Table 4-7 — Alarms window field definitions....................................................................................... 41
Table 4-8 — Events window field definitions ....................................................................................... 42
Table 5-1 — LED status indicators......................................................................................................... 45
Table 5-2 — Common fault indications.................................................................................................. 46
Table 5-3 — Modulator port testing modes.......................................................................................... 47
Table B-1 — RS-232 DB9 Interface Connector Pinout........................................................................ 53
Table B-2 — DB25 RS-530 interface connector pinout ...................................................................... 54
Table B-3 — Ethernet 10/100Base-T interface connector pinout..................................................... 55
Table C-1 — HCT 1000 OM parameters................................................................................................. 60

1
1 INTRODUCTION
The Motorola OM 2000 Out-of-band Modulator links the digital headend equipment
with the distribution system by combining the various out-of-band inputs into a
quadrature phase shift key (QPSK)-modulated signal. It converts multiple digital input
streams into an RF output signal for transmission over the cable system.
Figure 1-1 illustrates the OM 2000:
Figure 1-1 — OM 2000 Out-of-band Modulator
The OM 2000:
•Receives Ethernet User Datagram Protocol (UDP) packets from a controlling
processor
•Multiplexes downstream data from multiple sources
•Provides forward error correction (FEC) encoding of the bitstream, as well as
interleaving and randomization
•Provides downstream QPSK-modulated output within the 71 to 129 MHz range
•Provides industry-standard Ethernet 10Base-T connectivity for operation,
administration, maintenance, and provisioning (OAM&P)
•Performs periodic insertion of internally stored messages
•Controls and provides status/alarm reporting using Simple Network Management
Protocol (SNMP)

1 INTRODUCTION
2
Using This Manual
The following sections provide information and instructions to install, configure, and
operate the OM.
Section Title and Purpose
Section 1 Introduction provides a product description, related documentation, the technical
helpline, and repair/return information.
Section 2 Overview describes functions of the OM 2000.
Section 3 Installation provides instructions on how to install the OM 2000.
Section 4 Setup and Operation provides instructions on how to set up and operate the
OM 2000.
Section 5 Troubleshooting provides troubleshooting, testing, and maintenance
information.
Appendix A Specifications provides the technical specifications for the OM 2000.
Appendix B Cabling Specifications provides the cabling specifications for the OM 2000.
Appendix C Initialization Information provides special information on the OM 2000
initialization process.
Appendix D Fan Field Replacement Procedure provides instructions to replace a
malfunctioning OM 2000 fan.
Glossary The Glossary provides the full spelling of the abbreviations and acronyms and
definitions of the special terms used in this manual.
Related Documentation
The System Release Notes provide information that can be used with the OM 2000.
Although these documents provide information that may be of interest, they are not
required to install or operate the OM 2000:
•SDM User Guide

1 INTRODUCTION
3
Document Conventions
Before you begin, familiarize yourself with the stylistic conventions used in this
document:
Bold type Indicates text you must type exactly as it appears, or a
default value
Italic type Denotes a displayed variable or a variable that you
must fill in
Condensed type Indicates a field, menu, or button you must select on a
graphical user interface (GUI)
Courier font Indicates text displayed on a GUI, such as system
messages
ALL CAPS Denotes silk screening on the equipment, typically
representing front- and rear-panel controls and
input/output (I/O) connections, and LEDs
KEY+ KEY Key combinations indicating that you hold down the
first key and press the second key
KEY, KEY Key combinations indicating that you press the first
key, release it, and then press the second key

1 INTRODUCTION
4
Getting Help
If you need assistance, contact the Motorola Technical Response Center (TRC):
•Inside the U.S.: 1-888-944-HELP (1-888-944-4357)
•Outside the U.S.: 1 847 725 4011
•Motorola Online: http://businessonline.motorola.com
The TRC is on call 24 hours a day, 7 days a week. In addition, Motorola Online offers
a searchable solutions database, technical documentation, and low-priority issue
creation and tracking. For specific toll-free numbers when calling from outside the
United States, please refer to your product manual or our Web page.

1 INTRODUCTION
5
Returning for Repair
If repair is necessary, call the Motorola Repair Facility at 800 642 0442 for a Return
for Service Authorization (RSA) number before sending the unit. When calling from
outside the United States, use the appropriate international access code then 52 631
311 1100 to contact the Repair Facility. The Repair Facility is open from 7:00 AM to
4:00 PM Pacific Time, Monday through Friday.
The RSA number must be prominently displayed on all equipment cartons. When
shipping equipment for repair:
1. Pack the unit securely.
2. Complete and enclose the checklist provided with the unit.
3. Enclose a copy of the invoice that verifies the warranty status.
4. Ship the unit prepaid to the address provided with the RSA.

7
2 OVERVIEW
The Motorola OM 2000 creates a QPSK-modulated signal to carry the out-of-band
(OOB) datastream of a digital CATV system from the headend to set-top devices
(STDs) installed in subscribers’ homes. The OOB datastream is the control link
through which the headend transmits the commands and authorization messages
that control the STDs distributed throughout the CATV system. The headend can
also use the OOB datastream to deliver other types of information, including:
•Electronic Program Guide (EPG) information
•Application code downloads
•Control messages for emergency situations
•Data services
•Executable code downloads to fix or upgrade cable terminal operation
Other devices in the headend create the specific commands, messages, and
downloadable code that make up the information contained in the OOB datastream.
The OM 2000 accepts this information and processes it for delivery on the OOB
channel by combining it into an MPEG-2-compliant transport multiplex and outputting
that transport multiplex as an RF signal. Other output formats are also available to
support specific application requirements.
Figure 2-1 illustrates the operational flow through the OM 2000:
Figure 2-1 — OM 2000 operational flow diagram

2 OVERVIEW
8
Functional Overview
The OM 2000’s primary function is to combine multiple OOB data inputs into a
single datastream that is transmitted over the OOB channel as an RF signal. The OM
2000 also provides additional signal-processing functionality:
Serial data communications To support other application requirements, the OM 2000
transmits and receives baseband digital data over
various serial data ports.
Emergency alert operation The OM 2000 can monitor an emergency alert remote
control unit and receive and store special cable terminal
control messages. When a relay closure is sensed, the
special messages are inserted into the OOB data
transmission.
OOB Signal Processing
In converting the OOB data inputs into an RF signal, the OM 2000 performs the
following OOB signal processing functions:
•Receives the cable terminal control stream and other OOB data from multiple
input sources
•Multiplexes the information into a single, packet-based, MPEG-2-compliant
transport stream
•Inserts PID 0 and PID 1 control streams into the transport stream, if necessary
•Modulates the digital transport stream onto a 1.8 MHz-wide RF carrier using
QPSK modulation
•Upconverts the resulting signal into an RF output with a center frequency in the
71 through 129 MHz range. (An IF output is available for optional external
upconversion to other frequencies.)
Figure 2-2 shows the typical flow of OOB data from the input port(s) through the
packet multiplexer to the RF modulator:

2 OVERVIEW
9
Figure 2-2 — OOB data flow through the OM 2000
Receiving OOB Data Inputs
The OM 2000 can receive OOB data through multiple input ports. All data ports are
located on the back panel, and each has a unique numeric identifier. Table 2-1
describes the OM 2000 input ports:
Table 2-1 — OM 2000 input ports
Port Type Port ID Description
RS-232 DB9 pin serial data
(Front)
1 A standard RS-232 serial data port for an external
terminal (console) port is used for internal diagnostics.
RS-232 DB9 pin serial data
(Rear)
2 A standard RS-232 serial data port (asynchronous only)
receives EPG information, code download, and other
OOB data types. In some systems, an RS-232 port is
configured to receive cable-terminal control-stream
information instead of, or in conjunction with, the
Ethernet port.
Ethernet 1 3 The standard Ethernet port is the primary input to the
OM 2000. Because it is an Ethernet connection, port 3
supports communication with multiple devices over
the same physical port.
Generator port GEN The MPEG message generator is a virtual input only
port that supplies MPEG messages at periodic
intervals to the output ports configured by the
datapipe. The control interface sets the insertion
interval, availability status, and the message data.
RS-530 DB25 serial data 4 The RS-530 serial data port is an expansion port that
can be used in the same way as port 2. Like the
standard serial data ports, port 4 can be configured for
input or output operation.
Ethernet Not supported in initial release.

2 OVERVIEW
10
In general, OOB data input to the OM 2000 must be in MPEG-2 transport packets.
Data sent to configure, control, and boot the OM 2000 need not conform to MPEG-2
format.
Multiplexing the OOB Data
The packet multiplexer combines OOB data from the Ethernet and serial input ports
into a single MPEG-2-compliant transport multiplex, and then routes this multiplex to
the RF modulator. The multiplexer can also accept input data from special internal
sources (for example, the internal generator for emergency alert messages or for
PID 0 and PID 1 control data) if necessary.
Caution!
The aggregate input rate of all data to be combined into the RF
output must not exceed 2.005 Mbps. If the rate is lower than
2.005 Mbps, the multiplexer will add null packets to achieve the
correct data rate. If the aggregate input rate is higher than
2.005 Mbps, the multiplexer will drop packets.
The main destination for most OOB data is the RF modulator; however, the
multiplexer can route data to other output destinations. Each input packet stream
can be routed to up to three different output destinations. Table 2-2 lists the available
destinations.
Table 2-2 — Multiplexer output destinations
Destination Description
RF modulator The RF modulator uses QPSK modulation to convert an MPEG-2-
compliant transport multiplex into a 1.8 MHz-wide RF signal with a
center frequency between 1 and 129 MHz. Data directed to this
destination is output from the RF Out and IF Out connectors on the OM
2000 back panel.
Serial data ports Data directed to a serial data port is output as a serial datastream. The
serial data ports are valid destinations only when configured as output or
bi-directional ports.
UDP connections over
the Ethernet port
Data directed to a UDP port is output as a serial datastream. The UDP
connections are valid destinations only when configured as output ports.
A legal UDP port number must be assigned to each connection, and the
IP address of the receiving device must be configured.
Null port The null port is a conceptual destination equivalent to routing a packet to
nowhere (that is, discarding the packet).
Because of the number of possible input sources and output destinations, the
OM 2000 relies on a collection of data-handling specifications called PID maps to
support the proper multiplexing and routing of data through the packet multiplexer.
One set of PID maps is defined for each input port to control how the multiplexer
handles packets from those streams. Within the set for a port, a single PID map
controls the handling of one packet stream, and each set includes a default PID map
to control the handling of packet streams having no explicit PID mapping.
