ACCESSORIES AND BATTERIES

MTX Professional Series Portable Two-Way Radios

Motorola Original®Accessories

let you make the most of your

MTX Professional Series radio’s

capabilities.

You made a sound business decision when you chose

your Motorola MTX Professional Series Two-Way radio.

When you choose performance-matched Motorola

Original®accessories, you’re making another good call.

That’s because every Motorola Original®accessory

is designed, built and rigorously tested to the same

quality standards as Motorola radios. So you can be

sure that each will be ready to do its job, time after

time — helping to increase your productivity. After all,

if you take a chance on a mismatched battery, a flimsy

headset, or an ill-fitting carry case, your radio may not

perform at the moment you have to use it.

We’re pleased to bring you this collection of proven

Motorola Original®accessories for your important

business communication needs. You’ll find remote

speaker microphones for more convenient control.

Discreet earpiece systems to help ensure privacy

and aid surveillance. Carry cases for ease when on

the move. Headsets for hands-free operation.

Premium batteries to extend work time, and more.

They’re all ready to help you work smarter, harder

and with greater confidence.

MTX Series

Table of Contents

MTX Series Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Microphones and Accessories . . . . . . . . . . . . . . . . . . . . . 3

Surveillance Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Completely Discreet Earpiece . . . . . . . . . . . . . . . . . . . . . . 5

EMS and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Temple Transducer, CommPortTM and Accessories . . . . . . . 7

Headsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

Carry Cases and Accessories . . . . . . . . . . . . . . . . . . . 10-11

Chest Packs and Radio PAkTM . . . . . . . . . . . . . . . . . . . . . . .12

Batteries and Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Chargers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

IMPRESTM Smart Energy Systems . . . . . . . . . . . . . . . . . . .15

Battery Analyzers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Travel Chargers and Accessories . . . . . . . . . . . . . . . . . . . .17

MTX PROFESSIONAL SERIES PORTABLE RADIOS

Intelligent radio so advanced, it practically thinks for you. MTX Series Portable

Two-Way Radios are the smart choice for your business - delivering everything

you need for great business communication. Designed to operate on Motorola's

Privacy Plus™ or LTR®trunking systems, these radios can enhance your interac-

tive resources by providing a wider calling randge, faster channel access, greater

privacy and higher user and talkgroup capacity.

MTX850TM

MTX8250TM

MTX8250.LSTM

MTX850.LSTM

MTX950TM

MTX9250TM

Motorola MTX Professional Series radios

keep you connected with a wider calling range,

faster channel access, greater privacy and higher

user and talkgroup capacity.

Windporting Remote Speaker Microphones

The Windporting feature of these microphones helps

lessen background noise from high winds and other severe

weather conditions. Audio can pass through the speaker

grill even when the microphone port is blocked by water.

Now public safety professionals can be more confident

than ever of clear, understandable communication when

Mother Nature is uncooperative. The Windporting Remote

Speaker Microphones allow talking and listening without

removing the radio from the belt or case. Both have a

coiled cord, Push-to-Talk switch, swivel clip, and quick

disconnect latch.

PMMN4021A* Remote Speaker Microphone

with 3.5mm Audio Jack

PMMN4027A* Remote Speaker Microphone

with IP57 Rating

Remote Speaker Microphone – RSM

This Remote Speaker Microphone is water-resistant and

allows talking and listening without removing the radio from

the belt or case. It has a coiled cord and Push-to-Talk

switch. Clothing clip on the microphone back clips securely

onto shirt or collar. Ideal for high-noise environments.

AAHMN9053A* Noise-Cancelling Remote Speaker

Microphone with 3.5mm Audio Jack

HKN9055A Replacement Cable for Remote

Speaker Microphone

Heavy-Duty

Remote Speaker Microphone

Ideal for firefighters, police and other public safety profes-

sionals, this remote speaker microphone lets users talk and

listen without removing the radio from the belt, case or

charger. Designed with an exceptionally rugged housing for

harsh environmental conditions. Controls include a Push-to-

Talk Button and Hi-Low Volume Control. Includes coiled

cord, clothing clip, and audio jack.

RMN5055A* Heavy-Duty Remote Speaker

Microphone with 3.5mm Audio Jack

MicJacket

MicJackets provide speaker microphone users with a way

to further protect the “head” of their microphone from

dust, dirt, metal particles, sweat, body oils and other on-

the-job grime. MicJackets also help make handling and

interacting with the speaker microphone more hygienic.

RLN5009A MicJacket – Fits RSM AAHMN9053E.

*Intrinsically Safe.

MTX Series

audio

PMMN4027A

Remote Speaker

Microphone with

IP57 Rating

RLN5009A

MicJacket

RMN5055A

Heavy-Duty

Remote Speaker

Microphone

Public Safety Microphones – PSM

The newly designed Public Safety Microphones feature a

straight cord assembly, 3.5mm earjack, swivel clip, quick

disconnect latch, antenna connector and receive audio high/low

toggle switch.

RMN5035A* UHF Public Safety Microphone with 30

Inch Cord. Includes 450-470 MHz antenna.

RMN5036A* VHF Public Safety Microphone with 30

Inch Cord. Includes 148-174 MHz antenna.

RMN5075A* UHF Public Safety Microphone with 24

Inch Cord. Includes 450-470 MHz antenna.

RMN5076A* VHF Public Safety Microphone with 24

Inch Cord. Includes 148-174 MHz antenna.

RSM and PSM Accessories

An earphone jack located on the microphone head allows the

user to receive audio when used with the following earpieces.

Compatible with AAHMN9053E, PMMN4021A, RMN5055A,

RMN5035A, RMN5036A, RMN5075A, and RMN5076A.

Features 3.5mm threaded jack.

AARLN4885B* Receive-Only Covered Earbud with

Coiled Cord.

RLN4941A* Receive-Only Earpiece with Translucent

Tube and Rubber Eartip

WADN4190B* Receive-Only Flexible Earpiece

PMLN4620A D-Style Earpiece with 3.5mm Plug.

Receive only.

*Intrinsically Safe.

PMLN4620A

D-Style Earpiece

RMN5035A

UHF Public

Safety

Microphone

Public Safety Microphones:

Emergency professionals will appreciate the reliability of these

microphones. They’re designed to help increase coverage so

users can communicate clearly and accurately.

An earphone jack

located on the

microphone head

allows the user

to receive

discreet audio

when

used with

the earpieces

shown here.

AARLN4885B

Receive-Only Covered Earbud

RLN4941A

Receive-Only Earpiece

WADN4190A

Receive-Only

Flexible Earpiece

RLN6230A

Extreme

Noise Kit

RLN6241A

Low Noise Kit

AARMN4029A

Earpiece with

Microphone

and PTT

Combined

Surveillance Kits

Surveillance accessories allow the radio user to privately receive messages

with the earpiece. They are ideal when environments require discreet

communication.

1-WIRE SURVEILLANCE KITS

AARMN4021A* Receive-Only Earpiece. Beige.

AARMN4028A* Receive-Only Earpiece. Black.

2-WIRE SURVEILLANCE KITS

AARMN4022A* Earpiece with Microphone and PTT Combined. Beige.

AARMN4029A* Earpiece with Microphone and PTT Combined. Black.

3-WIRE SURVEILLANCE KITS

ENMN4017A* Earpiece with Microphone and PTT Separate. Beige.

ENMN4014A* Earpiece with Microphone and PTT Separate. Black.

Surveillance Kits with Extended-Wear Comfort Earpiece

These kits include a comfort earpiece with a rubber eartip and quick disconnect

clear comfortable acoustic tube. Users hear transmissions clearly, while the

clear tube provides a discreet appearance.

RLN5315A 2-Wire, Earpiece w/Microphone and PTT Combined. Black.

RLN5316A 2-Wire, Earpiece w/Microphone and PTT Combined. Beige.

5080370E97 Standard Rubber Eartips, Clear. Pack of 25.

Quick Disconnect Noise Kits

Extreme Noise Kits provide extra comfort and/or noise protection for users

wearing surveillance accessories. Lightweight, translucent tube attaches to

Motorola surveillance accessories to provide flexibility and comfort, which now

includes a new Quick Disconnect Adapter. The Quick Disconnect Adapter

allows users, especially those in multiple shift operations, to easily remove or

alternate acoustic tubes. Clothing clip prevents accessory from being pulled

from the ear due to body movement or head rotation. For optimal performance,

Extra Loud Earphones are recommended.

RLN6230A Extreme Noise Kit. Includes 2 foam earplugs. For high-

noise environments. Noise reduction = 24dB. Can be used

with Clear Comfortable Earpieces. Black.

RLN6231A Extreme Noise Kit. Includes 2 foam earplugs. For high-

noise environments. Noise reduction = 24dB. Can be used

with Clear Comfortable Earpieces. Beige.

RLN6232A Low Noise Kit - Clear Acoustic Tube Assembly. Includes 1

clear rubber eartip. For low-noise environments, does not

provide hearing protection. Black.

RLN6241A Low Noise Kit - Clear Acoustic Tube Assembly. Includes 1

clear rubber eartip. For low-noise environments, does not

provide hearing protection. Beige.

5080369E39† Extra Loud Earphone. Beige.

5080370E91† Extra Loud Earphone. Black.

REPLACEMENT ACCESSORIES

RLN6242A Quick Disconnect Acoustic Tube Replacement

5080384F72 Replacement Foam Plugs. For RLN6230A.

Noise reduction = 24dB. Pack of 50.

5080370E97 Replacement Standard Clear Rubber Eartips. Pack of 25.

*Intrinsically Safe.

†Extra loud earphone (exceeds OSHA limits).

MTX Series

audio

Completely Discreet Earpiece

Enables users to communicate with ease, in full privacy, without visible equipment. This

miniaturized receiver is discreetly hidden in the ear, where it can be worn comfortably for

long periods of time. Small as it is, it offers a full range of audio functions including auto-

matic squelch, automatic gain control and noise filtering. Average battery life is approxi-

mately 100 hours and includes an end-of-life warning signal when the battery needs to be

changed. Kit includes wireless receiver, inductive neckloop, 6 spare batteries and 5 spare

earguards. For use with any standard 2 or 3-Wire Motorola Surveillance Kit.

RLN4922A Completely Discreet Earpiece Kit

RLN4919A Replacement Earguards. 5 per pack.

RNN4005A Replacement 1.4 Volt Batteries. 6 per pack.

Flexible Ear Receiver

This receive-only earpiece contains a flexible earloop and speaker which rests external to

the ear. It plugs directly into adapter or the earjack on speaker microphones.

ENMN4013A* Flexible Ear Receiver

7580372E11 Replacement Foam Ear Cushion

Clear Comfortable Earpieces

The Clear Comfortable Earpiece forms to the inside of the ear and is perfect for low noise

environments. It’s made of easy-to-clean, chemically-inert, hypo-allergenic material.

Compatible with RLN6232A and all Noise and Surveillance Kits.

RLN4760A Small Custom Earpiece - Right Ear

RLN4761A Medium Custom Earpiece - Right Ear

RLN4762A Large Custom Earpiece - Right Ear

RLN4763A Small Custom Earpiece - Left Ear

RLN4764A Medium Custom Earpiece - Left Ear

RLN4765A Large Custom Earpiece - Left Ear

*Intrinsically Safe.

The Completely Discreet

Earpiece is easy to use. Simply

remove the earpiece

from any standard 2 or

3-Wire Motorola Surveillance

Kit and plug in the neckloop,

which is easily hidden under

clothing. Security personnel

will be able to wear this tiny

receiver comfortably

for hours at a time!

Completely Discreet Earpiece:

Enables private communication without visible equipment.

The receiver is hidden in the ear, where it can be worn

comfortably for long periods of time.

ENMN4013A

Flexible Ear Receiver

RLN4922A

Completely

Discreet

Earpiece

Kit

Completely Discreet

Earpiece Receiver

From left to right,

top to bottom:

RLN4765A

RLN4762A

RLN4764A

RLN4761A

RLN4763A

RLN4760A

Ear Microphone System – EMS

This compact, lightweight unit picks up sound through bone

vibrations in the ear. The miniature earpiece leaves the

hands free and face unobscured, good for rescue and emer-

gency personnel that must retain the ability to help, hear

and speak directly to others, those not on the communication

system. EMS may be worn with protective masks without

reduction in sound clarity. It’s ideal for high-noise environments.

Available in PTT or Voice-Activated (VOX). Interface Module is

required and sold separately.

BDN6677A* EMS with PTT Interface. Black.

For standard noise levels (up to 95dB).

BDN6678A* EMS with PTT Interface. Beige.

For standard noise levels (up to 95dB).

BDN6641A* EMS with PTT Interface. Grey.

For high-noise levels (up to 105dB).

AARMN4044A* Push-to-Talk Only Interface Module

AARMN4045A* Push-to-Talk or Voice-Activated Interface

Module. VOX operational only on

conventional channel.

OPTIONAL ACCESSORIES FOR EMS

0180358B38* Remote Push-to-Talk Ring Switch

0180300E83* Remote Push-to-Talk Body Switch

0180300E25 Earguard with Adjustable Loop

0180358B32 Earholder. Black, small.
