Motorola MTP3100 Installation instructions

MTP3000
SERIES
SAFER,
TOUGHER,
EASIER TO USE
PRODUCT SPECIFICATIONS

PRODUCT SPEC SHEET
MTP3000 SERIES
SAFER
SUPERIOR AUDIO AND
INCREASED RANGE
TOUGHER
DURABLE CONNECTORS
AND RUGGED DESIGN
EASIER
INTUITIVE HARDWARE
AND SOFTWARE FEATURES
*SW Upgradable
STAY IN TOUCH
Be safer and more effective with
greater coverage and in-building
performance with the high-sensitivity
receiver and Class 3L (1.8W) power.
HEAR AND BE HEARD
Outstanding audio means you
can be safe and effective in
the most noisy and difficult
environments.
THE kEY BENEFITS
OF THE
MTP3000 SERIES
MTP3100 MTP3200 MTP3250
Bluetooth* No Yes Yes
GPS* No Yes Yes
Keypad Simple Simple Full
GENERAL
Dimensions HxWxD mm 124 x 53 x 33.5 (with standard
battery)
Weight 273g (radio with 1650mAH
battery and antenna)
Battery Performance
(Class 4 and 1650mAH battery)
Duty Cycle 5/5/90 > 16 Hours
Duty Cycle 5/35/60 > 12 Hours
Battery
(Li lon 1650mAh and 2150mAh)
RF SPECIFICATIONS
Frequency Bands 350-430 MHz
Transmitter RF Power Class 3L (1.8W)
& Class 4 (1W)
Receiver Class A and B
Rx Static Sensitivity -114dBm (min); -116dBm
(typical)
Rx Dynamic Sensitivity -105 dBm (min); -107 dBm
(typical);
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature °C -30 to +60
Storage Temperature °C -40 to +85
Humidity ETSI 300 019-1-7 class 7.3E
Dust and Water Ingress
Protection IP55 per IEC 60529
Shock, drop and vibration ETSI 300-019 1-7 class 5M3;
MIL-STD 810 D/E/F
LICENSES/OPTIONS
Efficiency
Language & Keypad Options
Bluetooth*
DMO Repeater
RUA/RUI*
MSPD*
SCCH
RMS*
Call Out*
WAP push*
Safety
GPS*
SECURITY SERVICES
Enhanced Security - OTAR/DMO SCK*
Authentication (Mutual)
Air Interface Encryption Class 1, 2, and 3
SIM Encryption (MTP3200 / MTP3250 only)
Permanent Disable*
Temporary Disable*
MAIN DATA SERVICES
MSPD*
SDS Messaging in TMO & DMO
AT Commands Full Set of AT Commands (including Voice Control)
Short Data Applications
TNP1 Simultaneous operation of Packet Data and Short Data
Services over a common Peripheral Equipment Interface (PEI)
iTM Fleet Management (Remote Programming )

PRODUCT SPEC SHEET
MTP3000 SERIES
*SW Upgradable
PICk IT UP AND USE IT FAST
Transition quickly from analogue
radios with two control knobs.
Navigate quickly through the simple
user interface on the clear screen.
BUILT FOR A TOUGH WORLD
Robust connectors withstand hard use
and dirty environments. IP55 for all
weather and water jet protection.
CUSTOMISE FOR THE END USER
Tough and effective range of audio and
energy accessories suitable for the
same rough use as the radio.
A full range of matching and high performance accessories are available on the
MTP3000 Series Accessory Catalogue by visiting www.motorolasolutions.com/MTP3000
LOCATION SERVICES
Simultaneous Satellites 12
GPS antenna integrated into the external radio antenna
Tracking Sensitivity -160dBm
Accuracy 2 meter (50% probable) @ -130dBm
Protocols ETSI LIP & Motorola LRRP
USER INTERFACE
Easy to use separate volume and talkgroup knobs Contact List up to 1000 contacts up to 6 numbers per contact,
max 2000 numbers
Colour Transflective Display 132x90 pixel screen with 262,144 vivid
colours - viewable in bright sunlight Multiple Dialling Methods user selects how to dial
Flip screen and large/x-large text & icon options Backlight Fast/Flexible Call Response Private Call Response to a Group Call via One
Touch Button
Screen Saver gif image & text (any user’s selection) Multiple Ring Tones
Universal Time Display Message Manager Cellular Type (Flexible)
Multiple Languages Text message list 20
Keypad Lock Intelligent Keypad Text Input (MTP3250)
Talkgroup Management User friendly, flexible, efficient, fast Status list 400
Talkgroups – TMO Folders 256, TMO Unique 2048, TMO Instances 4000 Country/Network Code List 100
Talkgroups – DMO Folders 128, DMO Groups 1024 Scan lists 40 lists of 20 groups
Favourite Folders Up to 3 (to store any favourite talkgroup) User Controls
Menu Tailored to user needs Multi-Rotary Knob Volume, List Scroll, and/or Talkgroup Selection
(The MTP3000 Series have 2 separate knobs)
Menu Shortcuts One touch Buttons & Keys each button key can be programmed with one
of the multiple functions available
Menu Configuration Covert Mode
Contacts Management Cellular Type (Rapid Search)
MAIN VOICE SERVICES
Full Duplex TMO Private, PABX, PSTN, Emergency Individual Emergency Call to PREDEFINED party (half/full duplex)
Half Duplex TMO Private, Group, Emergency HOT MIC talk without need to PTT (user enabled)
Half Duplex DMO Private, Group, Emergency Status Msg sent to dispatch console (user enabled)
Inter-MNI, Gateway, Repeater DMO to TMO enter DMO emergency (with/without gateway)
or enter TMO emergency
Dialling Direct, Scroll, Speed, One touch button/key, Preemptive Priority Calls
AlphaNumeric Search, Call History Redial Call Out*
Emergency Tactical Emergency Group Call to ATTACHED talkgroup PTT Double Push
(tailored by users) Non-Tactical Emergency Group Call to
DEDICATED talkgroup Adaptive Audio Control
OTHERS
Robust and ‘quick connect’ side connector with high-performance
matching accessories SLIM connector Accessories interface
Robust bottom connector Identification ring on antenna
Loud and clear Audio –
2Wrms Audio power (4W peak) through radio and accessories

MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC
and are used under license. All other trademarks are the property of their respective owners. © 2012 Motorola, Inc. All rights reserved. Specifications
are subject to change without notice. All specifications shown are typical. Radio meets applicable regulatory requirements.
MTP3000/SPECSHEET/UK(04/12)
For more information on the MTP3000 Series radio, please visit us on the web at:
www.motorolasolutions.com/MTP3000
MTP3000 SERIES
YOUR LIFELINE WHEN
TIME IS CRITICAL
