Motorola WR850G - Wireless Broadband Router User manual

FEATURES:
• 802.11g wireless access point for wireless access
• Four-port 10/100Base-T Ethernet switch/router for wired
local area network (LAN) connections
• One 10/100Base-T wide area network (WAN) port to
connect either a cable modem or DSL modem
• Allows remote connections through aVirtual Private
Network (VPN) with Internet Protocol Security (IPSec)
and Point-to-PointTunneling Protocol (PPTP)
pass-through support
• IP and MAC address filtering
• Wireless security features include:
>Wi-Fi®Protected Access (WPA) withTemporal Key
Integrity Protocol (TKIP) or Advanced Encryption
Standard (AES)
> Legacy 64-bit and 128-bitWired Equivalency Privacy
(WEP) encryption
> 802.1X access control
• Includes an easy-to-use InstallationWizard as well
as aWeb-based user interface for easy set up
>
Continued on back
Wireless.Wired. Or Both.
With Motorola’sWireless Broadband Routers, the choice is yours.
The latest in customized home or small office networking begins with Motorola’s Wireless
Broadband Routers.They’re the basis of an evolved network.That’s because they’re built
with both an 802.11g wireless access point and a four-port Ethernet router. It’s the best
of both worlds, combined.
BENEFITS:
• Offers both wireless and wired connectivity
• Expansive enough to accommodate everyone in your
home or small office
• Roam almost anywhere up to 328 feet (100 m) indoors
and up to 1312 feet (400 m) outdoors
• Supports a cable or DSL modem so everyone can
share a single broadband connection
• Everyone can also share files, pictures, peripherals,
a printer and more
• Gamers can play competitors on the network or online
• 24-hour technical support available via theWeb or
by toll-free phone, details inside
WHAT’S INCLUDED:
• Wireless Broadband Router
• Power adapter and cord
• Ethernet cable
• Base station stand
(WR850GP only)
WWiirreelleessss
BBrrooaaddbbaannddRRoouutteerrss
WWRR885500
WR850G
WR850G
• Supports wireless data rates up to 54 Mbps1– that’s up
to 5 times faster than 802.11b networking
• Backwards compatible with 802.11b equipment
WR850GP PERFORMANCE ENHANCED
• Wireless performance can be up to 35% faster than
standard 802.11g networking
• Backwards compatible with 802.11g (data rates up
to 54Mbps) and 802.11b (data rates up to 11Mbps)
equipment1
• Quick Start Guide
• CD-ROM containing
InstallationWizard
and User Guide
WR850GP

Continued from front
WWiirreelleessssBBrrooaaddbbaanndd
RRoouutteerrssWWRR885500
SYSTEM REQUIREMENTS SPECIFICATIONS
To view our full line of Broadband Networking Products,
visit ourWeb site at www.motorola.com/homenetworking
MOTOROLA and the Stylized M logo are registered in the US Patent &Trademark Office. All other product or service names are property
of their respective owners. Microsoft Windows®, Windows® Me,Windows® XP and Internet Explorer® are trademarks of Microsoft
Corporation. Netscape®, Netscape Navigator®, and the Netscape® logo are registered trademarks of Netscape in the United States and
other countries.Wi-Fi® certified is a Certification mark of theWireless Fidelity Alliance, Inc. © Motorola, Inc. 2004.
• Microsoft®Internet Explorer®5.2 or
Netscape®Navigator 6.2 or higher
• Broadband Internet access (cable, DSL
or other) with an Ethernet (RJ-45) port
• Each device on the wired network requires
an Ethernet connection
• Each device on the wireless network
requires an 802.11g or 802.11b wireless
adapter (adapters sold separately)
•With theWR850GP, Performance Enhanced
wireless adapters should be used
• CD-ROM drive on your PC
• For easy installation:
> Use the included InstallationWizard
or yourWeb browser for easy set up
>Your PC must support one of the
following: Microsoft®Windows®
98SE/Me/2000/XP Home or Professional
for use of the InstallationWizard
STANDARDS
IEEE 802.3; IEEE 802.3u; IEEE 802.11b
Wi-Fi®Certified; IEEE 802.11gWi-Fi®
Certified;WPA Certified
NETWORK PROTOCOLS
TCP/IP; UDP; NAT; DHCP; PPPoE; PPTP;
DNS; HTTP; IPSec;VPN Pass-Through;
TFTP; SMTP; Router supports both static
and dynamic routing (RIPv1 and RIPv2)
PORTS
LAN
Four-port 10/100 Mbps Ethernet
switch/router; RJ-45 connectors; Full/Half
Duplex; Automatic cross-over/straight
cable adaptation (Auto-MDIX)
WAN
One 10/100 Mbps Ethernet; RJ-45
connector; Full/Half Duplex; Automatic
cross-over/straight cable adaptation
(Auto-MDIX)
WIRELESS DATA RATES
1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54
Mbps1with auto-fallback support
MODULATION
CCK, DQPSK, DPBSK, OFDM
RANGE
Maximum range:
outdoor up to 1312 feet
indoor up to 328 feet
CHANNELS AND FREQUENCY RANGES
1–11 United States and Canada:
2.4 to 2.4835GHz
WIRELESS SECURITY
WPA withTKIP or AES encryption;
Legacy 64-bit and 128-bitWEP
encryption; 802.1X access control
POWER
100V AC to 240V AC, 50 – 60 Hz
INDICATORS
Power LED
Modem LED
Wireless LED
LAN LED x 4
WIRELESSTRANSMIT POWER
MaximumTransmit Power: +15 dBm
PHYSICAL DIMENSIONS
5.95'' (L) x 5.78'' (W) x 0.98'' (H)
WEIGHT
11.9 oz.
WARRANTY
Two-year limited warranty
OPERATINGTEMPERATURE
32˚ F to 104˚ F (0˚ C to 40˚ C)
STORAGETEMPERATURE
-22˚ F to 176˚ F (-30˚ C to 80˚ C)
HUMIDITY
5% to 95% (non-condensing)
EMISSIONS
FCC Part 15 (Subpart B)
REGULATORY APPROVALS
802.11b Wi-Fi®Certified; 802.11g
Wi-Fi®Certified; FCC Class B; CE;
WPA Certified
Recommended for use with Motorola’s Broadband Networking Products.These Wireless Broadband Routers are interoperable with all 802.11g and 802.11b certified equipment.
1AWord About Data Rates: Data rate is the speed at which individual bits of data flow through a channel. It is not the same speed at which entire files are uploaded or downloaded.
These speeds will vary, and are often less than the maximum data rate. Upload and download speeds are affected by several factors including, but not limited to: the capacity of and
the services offered by your cable operator or broadband service provider, channel capacity, network traffic, computer equipment, type of server, number of connections to server,
and availability of Internet router(s).
5619-0804-2K
WR850G WR850GP
