MD2210 INSTALLATION INSTRUCTION
(A0)
17"~39" Max:200x200mm/8x8in
Min:100x100mm/4x4in
x3 x1
Thank you for purchase!We strive to provide products and services of exceptional quality.
We sincerely invite you to write an unbiased review. For parts missed or installation problems,
please contact us at telephone [phone] (USA) Mon - Fri 10am - 6pm (Pacific time) or email
us by [e-mail] , so that we may solve the issue for you.

Before getting started, let’s make sure this mount is perfect for you!
1 Is your TV VESA
equal to/greater than
100x100mm/4x4in and
equal to/less than
200x200mm/8x8in?
2 Does your TV
(including accessories)
weigh less than
44 LBS (20 kg)?
4 Installation Tools
Yes --- Perfect!
No --- This mount is NOT compatible.
MAX:200mm/8"
MAX:
200mm/8"
Yes --- Perfect!
No --- This mount is NOT compatible.
Band Tape
2m
2M2M
5 Safety Caution
Please read this instruction carefully before installation.
If you do not understand these instructions or have doubts about the safety of the
installation, assembly or use of this product, contact Customer Service via
[e-mail].
● The hardware provided in the package can only use in 0.5" thick or above wooden
board installation on RV.
● The wall must be capable of supporting five times the weight of the TV and mount
combined. According to the wall you're going to install, the structure of your RV may
require additional reinforcement.
● Incorrect installation may result in product damage or body injury. Mounting Dream shall
bear no responsibility for any damage or injury resulted from incorrect installation,
incorrect assembly or misuse.
● Do not apply this product to any purpose not indicated by Mounting Dream.
● Make sure to stow the TV and fully lock the mount in place before your RV is moving.
Pencil Screwdriver Electrodrill Socket Wrench
1/2"(13mm)
1
3 Where can you
install this mount?
0.5" thick or above wooden board
Min. 0.5"
5/32"(4mm)
Wood Drill Bit

Parts and Hardware
WARNING:This product contains small items that could be a choking hazard if
swallowed. Before starting assembly, verify all parts are included and undamaged. For parts
shortage or damage, please contact us via [e-mail].
NOTE: Not all hardware included will be used.
M4x12mm
M5x12mm
M6x12mm
M8x25mm
M4x30mm
M5x30mm
M6x35mm
M8x50mm
M5/M6x17mm M8x22mm
M5/M4 M6
10mm 2.5mm
2
Washers
Spacers
TV Screws
x4
x4
x4
x4
x4
x4
x4 x4
x4
x4 x4
x4 x8
x4
Allen Key
x1
1-1 Disassemble Wall Plate Unit into Two Pieces
Wall Plate Unit
x1
Wall plate
TV plate

3
① ①
① ①
② ②
② ②
③ ③
③③
① 100mm x 100mm
② 200mm x 100mm
③ 200mm x 200mm
1-2 Choose Configuration
M8
M6
M5
M4
1-3 Select TV Screws
TV back
Bracket Washer
Bracket
Long Screw
Spacer
No, go to PAGE 4 for detailed combination.
Yes, go to PAGE 4 for detailed combination.
TV back
1-4 Need Spacer?
Short Screw
Washer

4
Tips: If you need to combine M8(d/h) screw with 2.5mm spacer(n), you have to remove
the inner circle.
Screw and washer
Spacer(s), screw and washer
1-5 Attach TV Plate to TV Back

Parts and Hardware
5
Min. 0.5"
Wall plate
Bolt Head UP!
5/32"
(4mm)
Wall plate
Wall Plate
Lag Bolt
x4
CAUTION: All 4 lag bolts MUST BE firmly tightened to
prevent unwanted movement of the wall plate assembly. Ensure the
wall plate assembly is securely fastened to the wall before continuing
on to the next step.

6
44 LBS (20 kg)
Before hanging TV, please conduct "wall plate installation integrity test" first.

7
Handle
② Pull out and hold the handle.
③ Turn the handle in the opposite direction.
④ Push and release the handle.
⑤ Turn handle again to tighten or loosen.
① Turn handle (loosen or tighten)
until stopped by mount.
To tighten or loosen the handle
4-1 Tilting angle adjustment (+5°/-15°)：
Loosen handle and tilting bolt, adjust TV to your desired position,
then tighten handle and tilting bolt.
-15°
+5°
Handle
Loosen
Tighten
Tilting bolts

4-2 TV leveling adjustment (±5°):
Loosen 2 leveling bolts on the rear of TV plate by maximum 2
turns, adjust to level, and retighten to secure.
Important ! Make sure to stow the TV and fully lock the mount in place
before your RV is moving.
Loosen
Tighten
8
Push your TV to the wall until you hear the "click" sound.
Stow

9
100mm
200mm
100mm
200mm
260mm
467mm 72mm
+90°/-90°
+5°
-15°
Pull and hold the strap
Pull out
If you have any questions about the installation,please feel free to contact us at telephone [phone] (USA)
Mon - Fri 10am - 6pm (Pacific time) or email us by [e-mail] .
For more information, please visit our website:www.mountingdream.com
