Mounting Solutions PDV-12UK User manual

PDV-12UK Power Supply
Distributor
www.mnmounting.com
[email protected]om
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
EMEA & Asian region:
[phone]
USA, LATAM, Canada, Australia
& New Zealand region:
[phone]
The PDV-12UK is a vertical power distributor which can be used in a wide variety of Sound Rack and/or
Projector Pedestal applications and areas.
This device offers a high level of protection & safety using class D circuit breakers. The PDV-12UK offers
a trip current of 10 to 20 times the rated current with an operating time of 0.04 to 3 Seconds. It is also used
for very high inductive loads.
The PDV-12UK is easy to connect and exible in transformation.
PACKAGE CONTENTS
1. PDV-12UK - 1 pcs
2. Cable Gland for cable dia 10-14 mm (0,39”-0,55”) - 1 pcs
3. Cable Gland for cable dia 13-18 mm (0,51”-0,71”) - 1 pcs
4. M6 rack screw pack - 4 pcs
5. Installation manual - 1 pcs
SAFETY INSTRUCTIONS
1. Do not use this equipment near water.
2. Only clean with a dry cloth.
3. Do not block any of the ventilation
openings. Install in accordance with the
manufacturer’s instructions.
4. Do not use near heat sources such as
stoves, heat registers, radiators or other
equipment (including ampliers) that
produces heat.
5. Do not use the unit near open re
sources.
6. Only connect the unit to the electric
network with grounding. Only use electric
plugs that provide grounding.
7. Protect the power cord from being
stepped on, pinched, or damaged in general.
8. Only use accessories specied by the
manufacturer.
9. Unplug the unit during lightning storms
or when unused for long periods of time.
10. Refer all servicing to qualied service
personnel. Servicing is required when the
system has been damaged in any way,
such as a damaged power supply cord or
plug, liquid has been spilled over or objects
have fallen into the unit, the unit has been
exposed to rain or moisture, the unit does
not operate normally, or has been dropped.
11. Indoor Use only.
12. WARNING - TO REDUCE THE RISK OF
FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS SYSTEM UNIT TO RAIN OR MOISTURE.
SPECIFICATIONS:
Functions Power Supply Distributor
Power Input AC 32A 250V Tri-Phase
Input Сonnectors DIN rail Terminal Block
Output Сonnectors 12 х 16A UK Socket
Protection Сircuit Breaker 6 x D16A on 2 Sockets
IP Protection IP44
Dimensions 1016 x 133 x 92 mm 40,00” x 5,24” x 3,63”
Shipping dimensions 1100 x 150 x 100 mm 43,31” x 5,91” x 3,94”
Net weight 9,6 kg 21,16 lbs
Shipping weight 9,9 kg 21,83 lbs
OPTIONAL ACCESSORIES
1. SR-600/24U; SR6-600/36U
2. SR-800/24U; SR-800/36U; SR-800/42U; SR-800/48U

PDV-12UK Power Supply
Distributor
www.mnmounting.com
[email protected]om
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
EMEA & Asian region:
[phone]
USA, LATAM, Canada, Australia
& New Zealand region:
[phone]
Dimensions
Cable input locations
Upon your convenience there’s multiple provided cable input locations to choose from. Cable
gland locations are provided on each of the ve sides of the unit.

PDV-12UK Power Supply
Distributor
www.mnmounting.com
[email protected]om
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
EMEA & Asian region:
[phone]
USA, LATAM, Canada, Australia
& New Zealand region:
[phone]
Possible Transformation
1. Rotating side mounts.
For ease of installation and best use of the power distributor, you can rotate its side plates 180
degrees. Simply unscrew the four screws, turn the plate and (re)tighten the screws.
2. Transfer of sockets to the front panel.
For the most convenient connection of the devices to the power distributor, install the sockets
on the front panel. To do this, unscrew the screws securing the panel with sockets, unscrew the
blank panel from the front side, transfer the panel with sockets to the front of the power distributor
(without disconnecting the cables from the sockets) and tighten with the screws. Install the blank
panel on the rear of the power distributor the same way.
