Movie Vision MV-DVD-PL3 User manual

Owner's Manual
Mobile DVD Player
Model: MV-DVD-PL3
For operational or technical assistance, after reading this manual,
please call us toll free at [phone].
DVD • CD • CDRW • MP3 PLAYER
REMOTE PLAY/
PAUSE
MV-DVD-PL3 3/12/03 2:33 PM Page 1

2
Features
Compatible with PAL and NTSC Systems
This player can play discs recorded in
either PAL or NTSC format.
• A single LSI chip now integrates all major
DVD playback circuit functions including
MPEG2 decoder, video D/A converter, and
audio decoder.
• L/R stereo analog audio outputs for
connection to existing head unit aux.
inputs. Video output is composite video.
• Supplied Remote Features: multi-language
audio-track/subtitle, multi-angle, plus all
basic functions.
Use this Product Safely
Driving
To be aware of road and traffic conditions,
keep the volume level low.
Car Washing
Do not expose the product to water or
excessive moisture. This could cause elec-
trical shorts, fire or other damage.
Parking
Parking in direct sunlight can produce very
high temperatures inside your vehicle.
Give the car interior a chance to cool down
before starting playback.
Proper Power Supply
This product is designed to operate with a
12 Volt DC, negative ground battery system.
Protecting the Disc Mechanism
Avoid inserting any foreign objects into the
slot of this player. Failure to observe this pre-
caution, may cause malfunction of this unit.
Repairs
Contact our customer service representa-
tives. Do not attempt to disassemble or
adjust this product yourself.
Installation
The unit should be installed in a horizontal
position with the front end up at a conven-
ient angle at not more than 30°.
MV-DVD-PL3 3/12/03 2:33 PM Page 2

3
Safety Information . . . . . . . . . . . . . . . . . 3
Disc Notes . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . 5
Electric Connection. . . . . . . . . . . . . . . . . 6
Remote Control. . . . . . . . . . . . . . . . . . . . 7
Preparing the Remote Control . . . . . . . . 8
Loading a DVD/VCD/CD Disc . . . . . . . . . 8
Ejecting a Disc . . . . . . . . . . . . . . . . . . . . 8
On-Screen Display Function . . . . . . . . . 10
Multi-audio Language Function . . . . . . 10
Menu Function . . . . . . . . . . . . . . . . . . . 11
Title Menu Function (For DVD only). . . 11
Multi-Subtitle Language Function
(For DVD only) . . . . . . . . . . . . . . . . . . . 11
Multi-Angle Function (For DVD only) . . 11
MP3 Disc Play . . . . . . . . . . . . . . . . . . . 12
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Initial Setup. . . . . . . . . . . . . . . . . . . . . . 13
General Setup. . . . . . . . . . . . . . . . . . . . 13
Speaker Setup. . . . . . . . . . . . . . . . . . . . 15
Audio Setup . . . . . . . . . . . . . . . . . . . . . 15
Preferences Setup. . . . . . . . . . . . . . . . . 17
Defaults Table . . . . . . . . . . . . . . . . . . . . 18
Specifications . . . . . . . . . . . . . . . . . . . . 18
Replacement Parts . . . . . . . . . . . . . 19-20
Warranty . . . . . . . . . . . . . . . . . . . . . . . . 20
Contents
Safety Information
CAUTION:
MOBILE DVD PLAYER IS A CLASS I LASER
PRODUCT. HOWEVER THIS MOBILE DVD
PLAYER USES A VISIBLE/INVISIBLE LASER
BEAM WHICH COULD CAUSE HAZARDOUS
RADIATION EXPOSURE IF DIRECTED. BE
SURE TO OPERATE THE MOBILE DVD PLAY-
ER CORRECTLY AS INSTRUCTED. USE OF
CONTROLS OR ADJUSTMENTS OR PERFOR-
MANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE. DO
NOT OPEN COVERS AND DO NOT REPAIR
YOURSELF. REFER SERVICING TO QUALI-
FIED PERSONNEL.
WARNING:
• TO REDUCE THE RISK OF FIRE OR ELEC-
TRIC SHOCK, DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
•TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, AND ANNOYING
INTERFERENCE, USE ONLY THE RECOM-
MENDED ACCESSORIES.
This product incorporates copyright protec-
tion technology that is protected by method
claims of certain U.S. patents and other
intellectual property rights owned by
Magnadyne Corporation and other rights
owners. Use of this copyright protection
technology must be authorized by
Magnadyne Corporation, and is intended for
home and other limited viewing uses only
unless otherwise authorized by Magnadyne
Corporation. Reverse engineering or disas-
sembly is prohibited.
Region Management Information:
This Mobile DVD Player is designed and
manufactured to respond to the Region
Management Information that is recorded
on a DVD disc. If the Region number
described on the DVD disc does not corre-
spond to the Region number of this Mobile
DVD Player, this Mobile DVD Player cannot
play this disc.
MV-DVD-PL3 3/12/03 2:33 PM Page 3

Disc Formats Supported by this Player:
Discs which cannot be played with this
player:
• DVD-ROM
• DVD-R/DVD-RAM
• CDV
• CD-G
Handling and Cleaning
• Dirt, dust, scratches and warping disc
will cause non operation.
• Do not place stickers on disc or
scratch disc.
• Do not warp discs.
• A disc should always be kept in its case
when not in use to prevent damage.
• Do not place discs in the following
places:
1. Direct sunlight
2. Dirty, dusty and damp areas
3. Near car heaters
4. Car seats or dashboard
Disc Cleaning
Use a dry soft cloth to wipe the surface. If
the disc is quite dirty, use a soft cloth
slightly moist with isopropyl (rubbing)
alcohol. Never use solvents such as ben-
zine, thinner or conventional record clean-
ers as they may mar the surface of the
disc.
Note: A disc may become somewhat
scratched (although not enough to make it
unusable) depending on your handle it and
conditions in the usage environment.
Preparing New Discs with Rough Spots
A new disc may have rough edges on its
inside and outside edges. If a disc with
rough edges is used, the proper setting
will not be performed, and the player will
not play the disc. Therefore, remove the
rough edges in advance by using a ball
point pen or pencil as shown. To do this,
press the side of the pen or pencil against
the inside and outside edges of the disc.
4
Disc Notes
V
I
D
E
O
Label side up
Do not touch
the underside
of the disc
Do not bend
Wipe the disc from center
toward the outside edge
Rough spots
on inside edge
Ball point pen
or pencil
Rough spots on
outside edge
MV-DVD-PL3 3/12/03 2:33 PM Page 4

5
Note:
1. First remove the two screws that lock the
player mechanism (see figure below).
Then attach the brackets on both sides
of unit with the M4x5 screws. Next,
install the unit with the M5x25 screws.
2. When mounting the unit, slide the
screws to the left or right side to meet
desired position. Select position 1 and 3,
or 2 and 4 to mount the bracket.
SCREW
M4x5
SCREW
M5x25
12
34
Screws Lock the
Player Mechanism
Installation
SCREW
M4x5
SCREW
M5x25
12
34
Screws Lock the
Player Mechanism
MV-DVD-PL3 3/12/03 2:33 PM Page 5
