OPERATION MANUAL
OFFICE PRO 10
READ THIS MANUAL CAREFULLY FOR INSTRUCTIONS ON CORRECT
INSTALLATION AND USAGE, AND READ ALL SAFEGUARDS.
NO POSTAGE
NECESSARY
IF MAILED
IN THE
UNITED STATES
     
FIRST-CLASS MAIL PERMIT NO. 8390 LONG BEACH, CA
BUSINESS REPLY MAIL
DENSO SALES CALIFORNIA, INC.
3900 VIA ORO AVENUE
LONG BEACH CA 90810-9969

LIMITED WARRANTY
DENSO SALES CALIFORNIA, INC. ("DENSO") warrants its MOVINCOOL
Products only to the extent stated in its official written warranties. Unless
otherwise specifically provided in writing by DENSO, DENSO warrants to end-
user that the Products shall be free of defects in materials or workmanship and will
function in accordance with DENSO's published specifications under ordinary in-
tended use and service for a period of twelve (12) months after delivery to the end-
user; provided, however, in the case of the compressor element of the Products
such warranty shall be for a period of thirty six (36) months after delivery to the
end-user. DENSO shall, at its sole option, repair or replace any defective Product
covered by this warranty. Such remedy shall be end-user's sole remedy with
respect to any particular defect in the Products.
This warranty does not cover defects or malfunctions which result from causes
beyond DENSO's control, including, without limitation, (i) unusual physical or
electrical stress; (ii) accident, neglect, abuse, misuse or other abnormal use; (iii)
failure to perform routine maintenance in accordance with DENSO'S recommended
procedures; (iv) normal wear and tear; (v) repairs or attempted repairs by an
unauthorized person; (vi) modifications or alterations to the Products; (vii) use with
supplies or devices not supplied or approved by DENSO; or (viii) improper
servicing. This warranty shall extend only to the original end-user and shall be void
if any labels or other identifying marks permanently affixed to Products when
shipped by DENSO are removed, altered, defaced or obliterated.
The aforesaid warranty is the only warranty made by DENSO with respect to the
Products and is in lieu of all obligations or liabilities on the part of DENSO for
damages arising out of or in connection with the sale, use or performance of the
Products, including, without limitation, any lost profits or any other consequential,
incidental, special or exemplary damages of any kind. DENSO DISCLAIMS ALL
OTHER WARRANTIES WITH REGARD TO THE PRODUCTS, INCLUDING ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE. THERE
ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION CON-
TAINED HEREIN.
PURCHASE DATE: _____________________________________________________
SERIAL NUMBER: _____________________________________________________

DETACH HERE

© 2003 DENSO SALES CALIFORNIA, INC.
All rights reserved. This book may not be reproduced or copied, in
whole or in part, without the written permission of the publisher. DENSO
SALES CALIFORNIA, INC. reserves the right to make changes
without prior notice. MovinCool is a registerd trademark of
DENSO Corporation.

i
OPERATION MANUAL
OFFICE PRO 10

ii

iii
Table of Contents
FOREWORD ............................................................................................ 1
Definition of Terms .......................................................................... 1
GENERAL WARNINGS & CAUTIONS.................................................... 2
INVENTORY ............................................................................................ 3
INSTALLATION ....................................................................................... 4
Choosing an Installation Site.......................................................... 4
Moving the Unit................................................................................ 5
Plugging in the Unit ......................................................................... 6
FEATURES .............................................................................................. 7
OPERATION ............................................................................................ 8
Control Panel ................................................................................... 8
Operating in COOL Mode ............................................................. 10
Operating in Fan Only Mode ......................................................... 10
Changing from Fan Only Mode to COOL Mode .......................... 10
Programming the Unit ................................................................... 11
To Set a Program ........................................................................... 12
Operating Modes ........................................................................... 16
Emptying the Drain Tank ............................................................... 17
Installing the Condenser Plenum and Reducer .......................... 18
Accessory Kit ................................................................................. 19
Accessory Kit Instructions ........................................................... 20
Remote Control (Optional) ............................................................ 22
Drain Pump Kit (Optional) ............................................................. 23
DAILY INSPECTION & MAINTENANCE .............................................. 24
Emptying the Drain Tank ............................................................... 24
Cleaning the Air Filters.................................................................. 24
Filter Removal Method .................................................................. 24
Filter Cleaning Method .................................................................. 25
In-Season/Off-Season Inspection & Maintenance ..................... 25
TROUBLESHOOTING ........................................................................... 26
Self-Diagnostic Codes .................................................................. 26
TECHNICAL SPECIFICATIONS ........................................................... 27

iv

1
FOREWORD
Congratulations on purchasing the MovinCool portable air conditioner.
This manual explains how to install and operate the MovinCool Office
Pro 10 portable air conditioning unit. Please read this operation manual
thoroughly to familiarize yourself with the features of the unit and to
ensure years of reliable operation. You may also find it useful to keep
this operation manual on hand for reference.
Components and/or procedures are subject to change without prior
notice.
Definition of Terms
WARNING: Describes precautions that should be observed in
order to prevent injury to the user during installation or unit opera-
tion.
CAUTION: Describes precautions that should be observed in
order to prevent damage to the unit or its components, which may
occur during installation or unit operation if sufficient care is not
taken.
NOTE: Provides additional information that facilitates installation
or unit operation.

2
GENERAL WARNINGS & CAUTIONS
•All electrical work, if necessary, should only be performed by
qualified electrical personnel. Repair to electrical components by
non-certified technicians may result in personal injury and/or
damage to the unit. All electrical components replaced must be
genuine MovinCool parts, purchased from an authorized reseller.
•The proper electrical outlet for MovinCool units must be equipped
with a UL approved ground-fault breaker to prevent electrical shock
from the unit.
•Because of potential safety hazards under a certain condition, we
strongly recommend against the use of an extension cord. How-
ever, if you still elect to use an extension cord, it is absolutely
necessary that it will be a UL listed, 3-wire grounding type appli-
ance extension cord, having a 3-blade grounding plug and a 3-slot
receptacle that will plug into the appliance. The marked rating of
the extension cord should be 115 V, 15 A or equivalent.
•The Office Pro 10 is equipped with a six (6) foot (1.8 meter) power
cord. If replacement, fixed location (hard wired) or power cord
lengthening (extension cord) cords are required, contact your
reseller or a qualified electrician for approved replacement meth-
ods.
•Never fold or place heavy objects on the power cord. This could
result in damage to the power cord causing electrical shock or fire.
•Do not place water or any other liquid on the unit. This can cause
damage to the unit and increase the risk of electrical shock.
•Do not sit or stand on the unit.

3
INVENTORY
After unpacking your MovinCool unit, please check to make sure you
have the following items:
•Office Pro 10 MovinCool Unit (1)
•Operation Manual/Warranty Card (1)
•Accessory Kit (1)
NOTE: If any of these items were not included in the box or appear
damaged, please contact your MovinCool reseller for replacement.
OPERATION MANUAL / WARRANTY CARD
ACCESSORY KIT
OFFICE PRO 10 MOVINCOOL UNIT

4
INSTALLATION
Choosing an Installation Site
CAUTION: The following are some precautions to consider
before choosing your installation site. Please review carefully as
improper installation may result in personal injury or damage to the
unit.
•Do not use the unit in areas where leakage of flammable gas may
occur.
•Do not use the unit in areas where it will be exposed to rain or
water.
•Do not use the unit in an atmosphere of excessively corrosive gas
or vapor.
•Do not use the unit in areas where the temperature is outside the
allowable operating range.
•Do not install the unit in sloping areas. The unit may move or topple
over even if the casters are set to the LOCKED position.
•Install the unit in areas that can withstand the weight of the unit.
The Office Pro 10 unit weighs approximately 130 lbs (59 kg) (when
the drain tank is full of water).
•Allow 20 inches of unobstructed airflow for both the air inlets and
outlets. The inlets are located on the back of the unit. The outlets
are located on the front of the unit.
•Do not use the unit above 95˚F 60% RH.

5
INSTALLATION (cont.)
Moving the Unit
Unlock the casters and push the MovinCool unit using the side handles
to a flat, level surface and set the casters back to the LOCKED position.
SIDE HANDLES

6
INSTALLATION (cont.)
Plugging in the Unit
•Check the prongs and surface of the power cord plug for dust/dirt.
If dust and/or dirt are present, wipe off with a clean, dry cloth.
•Check the power cord, plug and prongs for damage or excess play.
If any damage or excess play is found, contact your MovinCool
reseller for repair.
WARNING:
•If the power cord or plug is damaged, repair should only be
performed by qualified electrical personnel.
•Do not connect/disconnect the power cord or attempt to
operate buttons with wet hands. This could result in electrical
shock.
CAUTION:
•The AC outlet (115 VAC Single Phase, 60Hz) needs to be rated
at 15A or higher. Do not share the outlet with any other instru-
ment or equipment.
NOTE:
•Make sure the AC outlet is free of dirt, dust, oil, water, or any
other foreign matter.
•The Office Pro 10 model is equipped with an approved NEMA
plug configuration (5-15). The appropriate outlet must be used
for this plug type.

7
FEATURES
•An electronic control panel, which allows the user to control the
unit’s operation easily.
•Dual fan speeds (either HIGH or LOW) in both COOL and Fan
Only modes.
•Digital display that indicates the temperature set point (either
Fahrenheit or Celsius) in which the COOL Mode will operate. This
is also the temperature the unit will try to maintain. The Tempera-
ture set point can be adjusted between LO 65ºF ~ 90ºF HI by the
key down/key up buttons ( /).
•Acondensate drain
TANK FULL
indicator display (LED).
•An automatic restart feature when the power is lost and regained.
The unit will return to the operating mode it was in prior to the loss
of power. Any preset program will be retained in the memory in the
event power loss occurs.
•Aprogrammable Clock/Timer function. This allows the user to
program a specific time of day that the unit will begin to
operate/start and turn off/end (Automatic Operation). The user can
also program the amount of days within the week the unit will cool.
•Atwo-digit room temperature display.
•Aprogrammable temperature function.

8
OPERATION
Control Panel
Before operating the unit, it is important to familiarize yourself with the
basic controls located on the control panel.
1COOL Button Activates/deactivates the
COOL mode/turns the unit off.
2FAN Button Activates/deactivates the HIGH
or LOW fan mode.
3Key Down/Key Up Decreases/Increases the
Buttons ( /)temperature set point; also
used to change the day of the
week, hours and minutes when
programming.
4Info Display Indicates the current room
Area temperature, self-diagnostic
codes (see page 26), set
point temperatures, and also
displays program information.
5COOL LED Illuminates to indicate cooling
is activated or unit is ready to
cool.
6HI/LOW LED Illuminates to indicate HI or
LOW fan operation.
7RUN PROGRAM Activates a program.
Button
COOL
SET PROGRAM
Office Pro 10
FAN
HI DAY HOUR MINLOW
START STOP CLOCK TANK FULL
RUN PROGRAM
TIMER
4351
2
6
37
FAN
HI LOW
COOL
COOL
HI LO
W
RUN PROGRAM

9
OPERATION (cont.)
Control Panel (Cont.)
8SET PROGRAM Allows the user to program the
Button unit or check the current
program.
9TANK FULL LED Illuminates to indicate the tank
is full.
10 TIMER Button Allows the user to set the clock
and program the start time and
end time of operation.
11 DAY/HOUR/MIN Illuminates to indicate the day,
LED hour, and minutes for
programming functions.
12 START/STOP LED Illuminates to indicate the start
and stop operation during
program mode.
13 CLOCK LED Illuminates to indicate clock
programming sequence during
program mode.
14 RUN PROGRAM Illuminates to indicate a
LED program is running. No
illumination indicates unit is in
manual mode.
COOL
SET PROGRAM
Office Pro 10
FAN
HI DAY HOUR MINLOW
START STOP CLOCK TANK FULL
RUN PROGRAM
TIMER 10
11
8
913 1412
SET PROGRAM
TANK FULL
TIMER
DAY HOUR MIN
START STOP
CLOC
K
RUN PROGRAM

10
OPERATION (cont.)
Operating in COOL Mode
•The unit can be operated in COOL mode by pressing COOL (LED
illuminates).
NOTE: In COOL mode the unit can only be turned off by pressing
COOL
again, not by pressing the fan buttons.
•Change the fan speed by pressing FAN .
•Change the temperature set point by pressing the key down/key up
buttons ( /).
NOTE: When turning the unit on, the set point and fan speed are
determined by the last operating mode (program mode not in-
cluded). Ten seconds after the set temperature button has been
pressed in manual mode, the display will revert back to the current
room temperature.
Operating in Fan Only Mode
•The unit can also be operated in Fan Only mode by pressing either
FAN (HI or LOW LED illuminates).
•The unit can then be turned off by pressing the fan speed button
that is illuminated.
Changing from Fan Only Mode to COOL Mode
•The COOL mode can be activated while the unit is operating in Fan
Only mode. To do this, simply press COOL (LED illuminates).
NOTE: The Fan Only mode will not operate after the COOL mode
has been activated. After the COOL mode has been activated, the
unit cannot be turned off by pressing the fan buttons. The COOL
button must be pressed.

11
OPERATION (cont.)
Programming the Unit
In order to use the programming function of the Office Pro 10, the
current time and day of the week must be set.
Make sure the unit is plugged in.
MO =MONDAY
TU =TUESDAY
WE =WEDNESDAY
TH =THURSDAY
FR =FRIDAY
SA =SATURDAY
SU =SUNDAY
•The display and
HOU
R
will illumi-
nate. Press the /buttons to
set the current hour. The Office
Pro 10 utilizes Military time.
See chart for conversion from
Military to Standard time. Press
TIMER to advance.
Note: The Office Pro 10 clock will
have to be reset for Daylight
Savings Time.
•Press
SET PROGRAM
four times
until CLOC
K
is illuminated.
•The display will indicate a day
of the week code and
DA
Y
will
illuminate. Press the /
buttons to set the day of the
week. Press TIMER to advance.
•The display and
MIN
will illuminate. Press the /buttons to set
current minutes. Press
SET PROGRAM
four times to exit programming
mode and finish.
Day Conversion Chart
Military to Standard
Conversion Chart
01 =1AM
02 =2AM
03 =3AM
04 =4AM
05 =5AM
06 =6AM
07 =7AM
08 =8AM
09 =9AM
10 =10 AM
11 =11AM
12 =12PM
13 =1 PM
14 =2 PM
15 =3 PM
16 =4 PM
17 =5 PM
18 =6 PM
19 =7 PM
20 =8 PM
21 =9 PM
22 =10PM
23 =11PM
00 =12AM

12
OPERATION (cont.)
To Set a Program
1. Press
SET PROGRAM
and P1 will show in the display. There are 7 avail-
able options for programming (P1 - P7).
2. Press /to choose which program to edit. (P1 - P7)
COOL
SET PROGRAM
Office Pro 10
FAN
HI DAY HOUR MINLOW
START STOP CLOCK TANK FULL
RUN PROGRAM
TIMER
P1
COOL
SET PROGRAM
Office Pro 10
FAN
HI DAY HOUR MINLOW
START STOP CLOCK TANK FULL
RUN PROGRAM
TIMER
MO
COOL
SET PROGRAM
Office Pro 10
FAN
HI DAY HOUR MINLOW
START STOP CLOCK TANK FULL
RUN PROGRAM
TIMER
14
3. Press
SET PROGRAM
until
START
is illuminated.
4. The display will indicate a day of the week code and
DA
Y
will illumi-
nate. Press the /buttons to set the day of the week. Press
TIMER to advance.
Display shows Monday
Hour start time is 2:00 P.M.
Display shows Program 1
5.
HOU
R
and display will illuminate. Use /to set desired hour start
time. The Office Pro 10 utilizes Military time. See chart for conver-
sion from Military to Standard time on page 11. Press TIMER to
advance to minutes.

13
COOL
SET PROGRAM
Office Pro 10
FAN
HI DAY HOUR MINLOW
START STOP CLOCK TANK FULL
RUN PROGRAM
TIMER
30
P1 start time is now 2:30 P.M.
COOL
SET PROGRAM
Office Pro 10
FAN
HI DAY HOUR MINLOW
START STOP CLOCK TANK FULL
RUN PROGRAM
TIMER
30
STOP LED is illuminated
OPERATION (cont.)
To Set a Program (Cont.)
6.
MIN
and display will illuminate. Use /to set desired minute start
time.
7. Press
SET PROGRAM
until
STO
P
is illuminated.
8. Repeat steps 4,5 & 6 to set program STOP day and time.
COOL
SET PROGRAM
Office Pro 10
FAN
HI DAY HOUR MINLOW
START STOP CLOCK TANK FULL
RUN PROGRAM
TIMER
75
Display shows current set temperature flashing
9. Press
SET PROGRAM
until the information display area is flashing the
current set temperature.
10. Use /to set a new set point temperature. Press
SET PROGRAM
to
advance to fan mode.

14
COOL
FAN
HI LOW
ST
A
COOL
FAN
HI LOW
ST
A
COOL
SET PROGRAM
Office Pro 10
FAN
HI DAY HOUR MINLOW
START STOP CLOCK TANK FULL
RUN PROGRAM
TIMER
75
COOL LED is flashing
11. To change fan speed, press FAN until
HI LO
W
(HI/LOW) begin to
flash. This is the current programmed Fan Speed. Press
SET PROGRAM
to advance to Cooling mode.
OPERATION (cont.)
To Set a Program (Cont.)
COOL
SET PROGRAM
Office Pro 10
FAN
HI DAY HOUR MINLOW
START STOP CLOCK TANK FULL
RUN PROGRAM
TIMER
P2
Display shows new Program 2
12. Press /buttons to cycle between Cool and Fan only modes. For
Cool mode, COOL will flash. For Fan mode,
HI LO
W
will flash.
13. Press
RUN PROGRAM
to run current program or
14. Press
SET PROGRAM
to edit current program or to enter a new program.
Display shows FAN LOW Display shows FAN HI
