MPI Technologies The Blue Kit IPDS for HP User manual

All HP LaserJet printers use the PCL standard to control the output to the
printed page. The comparative standard for the IBM Mainframe and AS/400-
TM
iSeries environment is called AFP/IPDS. By adding the Blue Kit IPDS solution,
IBM IPDS emulation is added to the HP LaserJet printers without having to
change the existing LAN interface.
TM
Simply plug in the Blue Kit IPDS, power up the printer and set-up the IBM
required parameters using the control panel of the HP LaserJet printer.
Your normal LAN printing will continue as before, but in addition you can
receive AFP/IPDS output over TCP/IP from IBM Mainframe systems, AS/400-
iSeries and AIX systems to be printed on your standard HP LaserJet printer.
TM
Blue Kit IPDS can also be used to add IPDS emulation to HP LaserJet printers
connected to IBM Coax (3270) and Twinax (5250) systems. Using the MPI Tech
TM
Coax or Twinax interfaces (HostCom) for physical connection, The Blue Kit
IPDS will add full IPDS compatibility and offer direct replacement of IBM
printers using the HP LaserJet printers.
TM
Being «HP Focus Solutions» certified by HP, MPI Tech Blue Kit IPDS is the
perfect solution for all IPDS printing needs on HP LaserJet printers.
HP Personality Module
TM
Blue Kit IPDS for HP
Plug-in IBM AFP/IPDS emulation
For HP LaserJet Printers
Printing and Conversion Solutions
l
l
l
l
l
l
l
l
l
IPDS native emulation
”HP focus Solutions” certified
IBM emulations: 3112/16, 3812/3816,
3912/16, 4028, 43xx, InfoPrint
Seamless emulation switching between
PCL, PostScript, SCS, IPDS and ASCII
Input IPDS resolution 240, 300 dpi and
auto
IBM 3812/4028 Raster resident fonts
Outline resident fonts
Margin adjustments
Directly supports bi-directional PPD/PPR
Host protocol via HP JetDirect print
servers

Mainframe systems
MVS, z/OS (PSF)
Midrange sytems
AS/400, iSeries (PSF)
Server systems
IBM Infoprint Manager
Supports all the IPDS towers (GOCA, FOCA,
IOCA...)
Full IPDS bidirectional communication
Raster and outline font sets
DBCS font support
Full Color support (gray scale or color)
Supports FS45, object containers (TIFF,
JPEG...)
Enhanced N-Up support
Resource Resolution 240, 300, 600 and Auto
2D Barcode (Datamatrix, PDF417...)
via front panel on printer
via web browser
IPDS DIMM
HP Color LaserJet: 3700, 4600, 5500, 9500
HP LaserJet 4000, 4050, 4100, 4100mfp,
4101mfp, 4200/4200L/4300, 5000, 5100,
8000, 8000mfp, 8100, 8100mfp, 8150,
8150mfp, 9000, 9000mfp, 9000Lmfp,
9055mfp/9065mfp.
IPDS COMPACT FLASH
HP Color LaserJet: 4650, 4700, 4730mfp,
CM4730mfp, 5550, 9500mfp
HP LaserJet 2410/2420/2430,
4240/4250/4350, 4345mfp, 5200,
9040/9050, 9040mfp/9050mp
IPDS USB FLASH
HP Color LaserJet: 3000, CP3505, 3800,
CP6015, CM6030mfp, 6040mfp,
CM8050mfp/8060mfp.
HP laserJet P3005, M3035mfp, P4015,
M4345mfp, P4515, M5035mfp,
M9040mfp/M9050mfp
PC Attachment
HP JetDirect Printservers
LinkCom III EIO
HostCom™ Coax (Mainframe)
HostCom™ Twinax (AS/400)
Attachment
System Requirements (IPDS)
Supported Printers Set-up
Features
Warranty
1 year manufacturing fault warranty
HP Models MPI Tech HP Models MPI Tech
Black & White Part number Color Part number
D16118-005
for any technical or typographical errors and reserves the right to make changes to products and documentation without prior notification.
Company and product names mentioned in this text are trademarks or registered trademarks of their respective owners. MPI Tech cannot be held responsible
MPI Tech Offices
France
40, rue du Général Malleret Joinville
BP 88 - 94402 Vitry sur Seine Cedex Berkshire SL5 7 NT Huntington Beach, CA 92649-5506
Phone: [phone] Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone] Fax: [phone]
E-mail: [email protected] E-mail: [email protected] E-mail: [email protected]
Denmark Germany North America - East Coast
Vadstrupvej 35 Poccistrasse 7 901 North Stuart Street Suite 1105
DK-2880 Bagsvaerd D-80336 Muenchen Arlington, VA 22203
Phone: [phone] Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone] Fax: [phone]
E-mail: [email protected] E-mail: [email protected] E-mail: [email protected]
United Kingdom North America - West Coast
Gibbs House, Kennel Ride, Ascot 4952 Warner Avenue, Suite 301
Print data
Mainframe IPDS over TCP/IP
Mainframe Telnet 3270E (SCS)
AS/400 IPDS Over TCP/IP
AS/400 Telnet 5250 (SCS)
LaserJet 2410/2420/2430
LaserJet P3005
LaserJet M3035mfp
LaserJet 4000
LaserJet P4014/P4015
LaserJet 4050
LaserJet 4100
LaserJet 4100mfp/4101mfp
LaserJet 4200
LaserJet 4240/4250
LaserJet 4300
LaserJet 4345mfp
LaserJet M4345mfp
LaserJet 4350
LaserJet P4515
LaserJet 5000
LaserJet M5035mfp
LaserJet 5100
LaserJet 5200
LaserJet 8000
LaserJet 8100
LaserJet 8150
LaserJet 9000
LaserJet 9000mfp
LaserJet 9000Lmfp
LaserJet 9040/9050
LaserJet 9040mfp/9050mfp
LaserJet M9040mfp/M9050mfp
LaserJet 9055mfp
LaserJet 9065mfp
999356-006
999358-003
999358-004
999350-002
999358-019
999350-003
999350-004
999350-010
999350-015
999356-001
999350-016
999356-007
999358-006
999356-002
999358-019
999350-005
999358-005
999350-014
999356-013
999350-006
999350-007
999350-008
999350-009
999350-011
999350-023
999356-005
999356-008
999358-018
999350-017
999350-018
IPDS B & W only
Color LaserJet 3000
Color LaserJet CP3505
Color LaserJet 3700
Color LaserJet 3800
Color LaserJet 4600
Color LaserJet 4650
Color LaserJet 4700
Color LaserJet 4730mfp
Color LaserJet CM4730mfp
Color LaserJet 5500
Color LaserJet 5550
Color LaserJet CP6015
Color LaserJet CM6030mfp/CM6040mfp
Color LaserJet CM8050mfp
Color LaserJet CM8060mfp
Color LaserJet 9500
Color LaserJet 9500mfp
IPDS Full color
Color LaserJet 3000
Color LaserJet CP3505
Color LaserJet 3800
Color LaserJet 4650
Color LaserJet 4700
Color LaserJet 4730mfp
Color LaserJet M4730mfp
Color LaserJet 5550
Color LaserJet CM8050 mfp
Color LaserJet CM8060 mfp
Color LaserJet 9500
Color LaserJet 9500mfp
999358-002
999358-008
999350-022
999358-001
999350-013
999356-003
999356-012
999356-010
999356-020
999350-021
999356-004
999358-017
999358-020
999358-010
999358-011
999350-020
999356-009
999358-012
999358-013
999358-014
999356-014
999356-015
999356-016
999356-017
999356-018
999358-015
999358-016
999350-025
999356-019
System support
