Mpow HM353A User manual

Projection
Alarm Clock
We offer a 6-month return policy and a quality guarantee for 24 months.
If you have any doubt please don’t hesitate to contact us at
[email protected]

1. Do not expose the unit to extreme temperatures, direct sunlight, dust or humidity.
2. A cloth or other protective material should be placed between the clock and the furniture.
3. Cut off the power before cleaning the clock with a soft cloth moistened only with mild soap and water.
4. You must use the original adapter.
5. Do not disassemble the clock or touch any components.
1. FM Radio Button
2. Snooze or Dimmer Button
3. Projection Button
4. Menu or Turn on/off two
Alarms
5. Up
6. Right or Turn on/off Alarm 2
7. Down
8. Left or Turn on/off Alarm 1
9. OK or Switch 12/24 hour
format
10. Reset
11. Speaker
12. Antenna
13. Micro Charging Port
14. USB Charging Port
15. Projecting Cylinder
16. Projecting Lens
Thanks a lot for choosing our product. Please read the following information carefully:
1. This product is designed to be used with the original adaptor provided in the package.
2. The built-in button battery inside the product is only for time backup in case of a power outage.
3. Please follow the instructions to set up the product.
We hope you have a nice experience using our product.
Before use
Precautions:
Diagram
Chapter1
1 2 3
48 5
6
9
7
10
12
1314
1516 11

After clicking , press or to set the time, the hour changes with the minute increase or decrease.
press or to switch between 12/24 hours, and press again to save the setup.
NOTE: Exit the setting, you can switch between 12/24 hours by pressing the OK button.
Press + to enter Alarm 1 setting, and press or for time setting.
Press to choose the ringtone (Chords, waves, birds, FM Radio and Turn off the alarm)
Press to adjust the volume of the alarm(L01,L02,L03)
Press to save or to continue setting up the Alarm 2 (same steps as Alarm 1 setting).
NOTE:
1. When the ringtone is selected, the screen will display:01, 02, 03, rd(awaken up by radio) and OFF. When
you choose FM Radio as the ringtone, the channel and volume remain the same as the last time you
used the FM Radio.
2. Exit setting, press to quickly turn on/off the alarm 1, press to quickly turn on/off the alarm 2.
When the alarm goes off, press to turn it off temporarily. It goes off again in 9 minutes.
Time settingChapter2
Alarm setting
or
+
Flash
Flash
save the setup
Flash
Snooze setting
When the alarm goes off, press any button other than to turn it off.
NOTE: The alarm is only turned off for the day. It goes off again the next day.
Turning off the alarm
Chapter3
or
or
or
Flash
Flash
Step 1
Step 2 Flash

Press to listen to the radio, press or to change channels and or to change volume.
long press or to automatic search.
NOTE:
1. Enable the antenna when using the FM function for better signals.
2. The FM in the clock is different from traditional FM radio and the signals will be different.
3. The FM signal is not very strong. It is recommended to be used by the window, away from mobile phones,
computers, metal and other devices with radiation.
Choose the channel to be saved, long press . When the digits in the screen start to flicker, press
again to save. long press to recall the stored radio channel.
1. FM and volume setting
2. FM channel saving
NOTE: When the sleeping time is over, the FM Radio turns off automatically.
3. FM sleep function
Press or to turn off the FM Radio.
4. Turn off the FM
FM settingChapter4
or
or
Long press
Press again
Flash
or
When the FM is active, press to enter the sleep mode, or to choose the time of sleeping. Radio
sleep timer can be set to 5, 15, 30, 45, 60, 75, 90 minutes, double press to see the remaining sleeping
time.

Press to adjust the brightness of the screen: Dim-Low-Medium-High-Highest-OFF.
Press to turn on the projection, short press again to adjust the brightness and long press to reverse
180°.
Note:
1. The most recommended distance for projection is 0.5-3m
2. The projection is not visible during the day
1. Brightness adjustment
Projection settingChapter5
Brightness setting
Chapter6
The USB port in the back can be used for charging mobile phones and other devices.
Note: Please use the original adaptor to charge
Input: 5V 1.5A USB output: 5V 1.2A(Max)
Radio Frequency: 76-108 MHz Projection distance: 0.5-3m
Projection angle: -30°—90° Screen brightness: 5level
Projection brightness: 3level Ringtones: 3 ringtones+ FM
USB Charging functionChapter7
SpecificationsChapter8
Rotate the cylinder to adjust the projection angle. Range: -30°—90°
2. Adjust the projection angle
Long press
Short press

Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC statement
Package contents
Chapter9
Clock Micro USB Cable Adapter User Manual
x1 x1x1 x1
