Whirlpool WUW35X24DS User manual

WINE CELLAR
Use & Care Guide
For questions about features, operation/performance,
parts or service, call: 1-800-253-1301
In Canada, call for assistance 1-800-807-6777
or visit our website at...
www.whirlpool.com or www.whirlpool.ca
BODEGA
Manual de uso y cuidado
Para consultas respecto a características, operación/desempeño, partes o servicio, llame al: 1-800-253-1301
o visite nuestro sitio de internet en...
www.whirlpool.com
CAVE À VIN
Guide d’utilisation et d’entretien
Au Canada, pour assistance, composez le 1-800-807-6777
ou visitez notre site web à
www.whirlpool.ca
Table of Contents/Índice/Table des matières...2
W10739679G

TABLE OF CONTENTS
WINE CELLAR SAFETY .................................................................3
INSTALLATION REQUIREMENTS.................................................5
Tools .............................................................................................5
Location Requirements................................................................5
Opening Dimensions....................................................................5
Electrical Requirements ...............................................................5
INSTALLATION INSTRUCTIONS...................................................6
Unpack the Wine Cellar ...............................................................6
Door Closing ................................................................................6
Wine Cellar Doors ........................................................................7
Base Grille ....................................................................................8
Handle Assembly .........................................................................8
WINE CELLAR USE........................................................................9
Normal Sounds ............................................................................9
Using the Control .........................................................................9
Wine Racks ................................................................................11
Stocking the Wine Cellar............................................................11
Lighting the Wine Cellar.............................................................12
WINE CELLAR CARE...................................................................12
Cleaning. ....................................................................................12
Vacation and Moving Care.........................................................13
TROUBLESHOOTING ..................................................................13
ASSISTANCE OR SERVICE .........................................................14
In the U.S.A. ...............................................................................14
In Canada. ..................................................................................14
Accessories................................................................................14
ÍNDICE
SEGURIDAD DE LA BODEGA.....................................................15
REQUISITOS DE INSTALACIÓN .................................................17
Herramientas..............................................................................17
Requisitos de ubicación.............................................................17
Medidas de la abertura ..............................................................17
Requisitos eléctricos..................................................................17
INSTRUCCIONES DE INSTALACIÓN.........................................18
Desempaque de la bodega........................................................18
Cierre de la puerta......................................................................18
Puertas de la bodega.................................................................19
Rejilla de la base ........................................................................20
Ensamblaje de la manija ............................................................20
USO DE LA BODEGA...................................................................21
Sonidos normales ......................................................................21
Uso del control...........................................................................21
Portabotellas ..............................................................................23
Cómo almacenar en la bodega..................................................23
Cómo iluminar la bodega...........................................................24
CUIDADO DE LA BODEGA..........................................................24
Limpieza .....................................................................................24
Cuidado durante las vacaciones y mudanzas...........................25
SOLUCIÓN DE PROBLEMAS......................................................25
AYUDA O SERVICIO TÉCNICO...................................................27
En los EE.UU..............................................................................27
En Canadá..................................................................................27
Accesorios..................................................................................27
TABLE DES MATIÈRES
SÉCURITÉ DE LA CAVE À VIN....................................................28
EXIGENCES D’INSTALLATION ...................................................30
Outillage .....................................................................................30
Exigences d’emplacement.........................................................30
Dimensions de l’ouverture .........................................................30
Spécications électriques..........................................................31
IINSTRUCTIONS D’INSTALLATION............................................31
Déballage de la cave à vin .........................................................31
Fermeture de la porte.................................................................31
Portes de la cave à vin...............................................................32
Grille de la base..........................................................................33
Manette ......................................................................................33
UTILISATION DE LA CAVE À VIN................................................34
Sons normaux ............................................................................34
Utilisation de la commande .......................................................34
Casiers à vin...............................................................................36
Stockage dans la cave à vin ......................................................36
Éclairage de la cave à vin...........................................................37
ENTRETIEN DE LA CAVE À VIN..................................................37
Nettoyage...................................................................................37
Précautions à prendre pour les vacances et avant un
déménagement ..........................................................................38
DÉPANNAGE.................................................................................38
ASSISTANCE OU SERVICE.........................................................40
Aux États-Unis. ..........................................................................40
Au Canada..................................................................................40
Accessoires................................................................................40

3
WINE CELLAR SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
WARNING:
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Children should be supervised to ensure that they do not
play with the appliance.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory, or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their
safety.
Do not use an extension cord.
If power supply cord is damaged, it must be replaced by the
manufacturer, its service agent, or a similarly qualified
person in order to avoid a hazard.
Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
Do not use replacement parts that have not been
recommended by the manufacturer (e.g., parts made at
home using a 3D printer).
Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
This appliance is intended to be used in household and
similar applications such as: staff kitchen areas in shops,
offices, and other working environments; farm houses and
by clients in hotels, motels, and other residential-type
environments; bed and breakfast-type environments; and
catering and similar non-retail applications.
To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions,
including the following:

4
Proper Disposal of Your Old
Wine Cellar
WARNING: Risk of child entrapment. Before You Throw Away
Your Old Wine Cellar:
■Take off the doors.
■Leave the racks in place so that children may not easily climb
inside.
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned wine cellars are still dangerous
– even if they will sit for “just a few days.” If you are getting rid
of your old wine cellar, please follow these instructions to help
prevent accidents.
WARNING
Suffocation Hazard
Remove door from your old wine cellar.
Failure to do so can result in death or brain damage.
Important information to know about disposal of
refrigerants:
Dispose of refrigerator in accordance with Federal and Local
regulations. Refrigerants must be evacuated by a licensed,
EPA certified refrigerant technician in accordance with
established procedures.

5
INSTALLATION REQUIREMENTS
Tools
Tool Needed
Gather the required tool before starting installation.
■Phillips screwdriver
Location Requirements
NOTES:
■It is recommended that you do not install the wine cellar near
an oven, radiator, or other heat source.
■Do not install in a location where the temperature will fall
below 55°F (13°C). For best performance, do not install the
wine cellar behind a cabinet door or block the base grille.
Opening Dimensions
■Height dimensions are shown with the leveling legs extended
to the minimum height.
NOTE: When leveling legs are fully extended, add 5/8"
(15 mm) to the height dimensions.
■If the oor of the opening is not level with the kitchen oor,
shim the opening to make it level with the kitchen oor.
15" Models
Depth Dimensions
A* 247/8" (63.2 cm) - w/o
handle
B* 265/8" (67.7 cm) -
WUW35X15DS
WUW35X15DS
CA
B
D
Dimensions
A217/8" (55.5 cm)
B251/2" (64.7 cm)
C 15" (38.0 cm)
D341/16" - 345/8"
(86.5 cm - 88.0 cm)
NOTE: Door clearance of 105/8" (27 cm) required to allow full shelf
extension.
24" Models
Depth Dimensions
A* 247/8" (63.2 cm) - w/o
handle
B* 265/8" (67.7 cm) -
WUW35X24DS
B1* 267/8" (68.2 cm) -
WUW55X24HS
WUW35X24DS WUW55X24HS
Dimensions
A217/8" (55.5 cm)
B251/2" (64.7 cm)
B1 2511/16" (65.2 cm)
C2313/16" (60.5 cm)
D347/16" - 35"
(87.5 cm - 89.0 cm)
NOTE: Door clearance of 161/8" (41 cm) required to allow full shelf
extension.
Electrical Requirements
Before you move your wine cellar into its nal location, it is
important to make sure you have the proper electrical connection.
Recommended Grounding Method
A 115 V, 60 Hz, AC only, 15 A or 20 A fused, grounded electrical
supply is required. It is recommended that a separate circuit
serving only your wine cellar be provided. Use an outlet that
cannot be turned off by a switch. Do not use an extension cord.
If the supply cord is damaged it must be replaced by the
manufacturer or its service agent or a similarly qualied person.
Do not use a cord that shows cracks or abrasion damage along
its length, or at either the plug or connector end.
NOTE: Before performing any type of installation, cleaning, or
removing a light bulb, unplug wine cellar or disconnect power.
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from wine cellar.
Failure to do so can result in death, explosion, or fire.
A*
B*
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
CA
B
D
CA
B1
D
A*
B*
B1*
153/4"
(40 cm)
13/16"
(3 cm)
351/4" 3513/16"
(89.5-91.0 cm)
355/8"-363/16"
(90.5-92.0 cm)
245/8"
(62.5 cm)
13/16"
(3 cm)

6
INSTALLATION
INSTRUCTIONS
Unpack the Wine Cellar
Remove the Packaging
■Remove tape and glue residue from surfaces before turning
on the wine cellar. Rub a small amount of liquid dish soap
over the adhesive with your ngers. Wipe with warm water
and dry.
■Do not use sharp instruments, rubbing alcohol, ammable
uids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your wine cellar. For
more information, see “Wine Cellar Safety.”
■Dispose of/recycle all packaging materials.
Clean Before Using
After you remove all of the packaging materials, clean the inside
of your wine cellar before using it. See the cleaning instructions in
“Wine Cellar Care.”
Door Closing
Your wine cellar has four leveling legs. If your wine cellar seems
unsteady or you want the door to close more easily, adjust the
wine cellar’s tilt using the instructions below.
1. Plug into a grounded 3 prong outlet.
2. Move the wine cellar into its nal location.
3. Turn the leveling legs to the right to lower the wine cellar or
turn the leveling legs to the left to raise it. It may take several
turns of the leveling legs to adjust the tilt of the wine cellar.
NOTE: Having someone push against the top of the wine
cellar takes some weight off the leveling legs. This makes it
easier to adjust the leveling legs.
4. Open the door and check that it closes as easily as you like.
If not, tilt the wine cellar slightly more to the rear by turning
both front leveling screws to the left. It may take several
more turns, and you should turn both leveling legs the same
amount.
WARNING
Excessive Weight Hazard
Use two or more people to move and install wine cellar.
Failure to do so can result in back or other injury.
When Moving Your Wine Cellar:
Your wine cellar is heavy. When moving the wine cellar for
cleaning or service, be sure to cover the floor with cardboard
or hardboard to avoid floor damage. Always pull the wine
cellar straight out when moving it. Do not wiggle or “walk” the
wine cellar when trying to move it, as floor damage could
occur.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Excessive Weight Hazard
Use two or more people to move and install wine cellar.
Failure to do so can result in back or other injury.

7
Wine Cellar Doors
Tool Needed: #2 Phillips screwdriver
Remove Door and Hinges
1. Open the door to a 90° angle and remove the screws for the
bottom door hinge.
2. Remove the door by pulling it forward and away from the wine
cellar.
3. Remove the three screws from the top hinge and remove the
hinge.
Reverse Door Swing (optional)
NOTE: There are two hinges for reverse door installation, one for
a right-hand door swing and one for a left-hand door swing.
Install the top hinge designed for the desired door swing.
1. Remove the two screws attaching the bottom hinge to door.
2. Remove the door by lifting it up, and then pulling it away from
the wine cellar.
3. Remove the three decorative screws from the upper left
corner of the front of the wine cellar.
4. Remove the three screws from the right top hinge, and then
remove the hinge.
5. Using the three screws removed in the previous step, attach
the left top hinge to the upper left corner on the front of the
wine cellar.
NOTE: The left hinge is included in the bag with the “Use and
Care Guide.”
6. Insert the three decorative screws removed in Step 3 into the
three holes in the upper right corner of the front of the wine
cellar.
7. Remove the screws for the mechanical switch and door stop;
remove the mechanical switch and door stop. Attach the
mechanical switch and door stop to the reverse side of the
door.
NOTE: The screws for the mechanical door switch are located
behind the seal. Remove the seal rst, and then remove the
mechanical door switch screws. After reattach the mechanical
door switch, place the seal in the original position.
8. Remove Whirlpool badge. (Only models: WUW55X24HS)
9. Attach the bottom hinge to the reverse side of the door, and
then ip the door 180º so that the hinge is now on the bottom
of the door.
10. Insert the top corner of the door into the top hinge pin and
reinstall the door on the wine cellar.
11. Press the door and the bottom hinge pin onto the bottom
hinge.
AB
C
A. Bottom hinge pin
B. Door stop
C. Bottom hinge

8
12. Put decal at the top of wine cellar.
13. After you change door (left hinge), place Whirlpool badge at
bottom of wine cellar. (Only models: WUW55X24HS)
NOTE: The decal & Whirlpool badge are included in the bag
with Use and Care Guide.
14. Check the alignment of the door and the door seals.
15. Tighten the hinge screws (as necessary).
Base Grille
You must remove the base grille to access the condenser coils for
cleaning.
To Remove the Base Grille:
1. Open the wine cellar door.
2. Using a Phillips screwdriver, remove the two screws from the
base grille.
3. Remove the two screws holding the mechanical switch to the
grille.
4. Remove the base grille.
To Replace the Base Grille:
1. Open the wine cellar door.
2. Reattach the mechanical switch using the two sensor screws.
3. Replace the two base grill screws. Tighten the screws.
Handle Assembly
NOTE: Only for models WUW55X24HS.
Helpful Tip: Put cardboard under wine cellar until it is installed in
cabinet opening. The cardboard will help avoid damage to oor
covering during installation.
NOTES:
■To ease installation, using two or more people, place wine
cellar on its back.
■To avoid scratching the front panel, place a soft cloth or towel
against the panel while installing the door handle.
■Setscrews are preinstalled in the handle.
1. Remove the door handle and hardware bag containing the hex
key from the bubble pouch.
2. Place the handle on the mounting studs. The setscrews should
face down when installed correctly. If the handle is installed
upside down, proper installation will not be possible.
3. Push the door handle tightly against the door.
4. Insert the short end of the hex key into the setscrew and
tighten 1/4 turn past snug. Setscrew will not be recessed into
the handle.
5. Repeat Step 4 for other setscrew.
6. Keep the hex key with the Installation Instructions.
NOTE: The handle installation procedure should take less than
5 minutes.
Place decal here
Place decal
Decal
WARNING
Excessive Weight Hazard
Use two or more people to move and install wine cellar.
Failure to do so can result in back or other injury.
A
B
C
D
A. Mounting stud
B. Door handle
C. Setscrew
D. Hex key

9
WINE CELLAR USE
Normal Sounds
Your new wine cellar may make sounds that your old one
didn’t make. Because the sounds are new to you, you might be
concerned about them. Most of the new sounds are normal. Hard
surfaces, such as the ooring and surrounding structures, can
make the sounds seem louder. The following describes the kinds
of sounds and what may be making them.
■Your wine cellar is designed to run more efciently to keep
your wine at the desired temperatures and to minimize energy
usage. The high efciency compressor and fans may cause
your wine cellar to run longer than your old one. You may also
hear a pulsating or high-pitched sound from the compressor
or fans adjusting to optimize performance. Remove Door and
Hinges.
■Rattling noises may come from the ow of refrigerant or items
stored inside the wine cellar.
■As each cycle ends, you may hear a gurgling sound due to the
refrigerant owing in your wine cellar.
■You may hear water running into the drain pan when the wine
cellar is defrosting.
■You may hear clicking sounds when the wine cellar starts or
stops running.
Using the Control
For Style 1 and Style 2 models, the control for this models is located at the top front of the wine cellar compartment. Default
temperatures are in °F.
Style 1: Models WUW35X15DS and WUW35X24DS
Style 2: Model WUW55X24HS
The control for this model is located in the middle of the wine cellar compartment.
ADEC
B
A. Power
B. Light
C. Compartment display
D. Decrease temperature
E. Increase temperature
GA E
D
H J
K
I
C
BF
F. Lower compartment display
G. Temperature indicator
H. Increase temperature
(lower compartment)
I. Decrease temperature
(lower compartment)
J. F/C Control
K. Light
A. Eco mode
B. Power
C. Decrease temperature
(upper compartment)
D. Increase temperature
(upper compartment)
E. Upper compartment
display

10
Controls
For your convenience, your wine cellar control is preset at the
factory.
For single-compartment models (WUW35X15DS,
WUW35X24DS), the preset temperature is 54°F (12°C). For
the two-compartment model (WUWDDX24HS), the preset
temperature for the upper compartment is 45°F (7°C) and the
preset temperature for the lower compartment is 54°F (12°C).
■When the power is on, the temperature display shows the set
point temperature of the compartment(s).
■Wait 24 hours for your wine cellar to cool completely before
adding wine.
NOTE: Adjusting the wine cellar temperature control to
a colder than the recommended setting will not cool the
compartments any faster.
Turn Wine Cellar On/Off:
■Press the Power button/touch pad on your wine cellar for
3 seconds to turn On the wine cellar cooling system.
■Press and hold the Power button/touch pad again to turn Off
the wine cellar cooling system. A 3 second countdown will
show in the compartment display. The Light button/touch pad
will operate to turn the light on and off within the wine cellar
compartment.
Increasing and Decreasing Compartment Temperature:
■Press the Increase Temperature button/touch pad until the
desired temperature is reached in the desired compartment,
displayed in the compartment display(s).
■Press the Decrease Temperature button/touch pad until the
desired temperature is reached in the desired compartment,
displayed in the compartment display(s).
Turn Light On/Off:
■Press Light button/touch pad to turn the light on and off
within wine cellar compartment. The wine cellar will remain
illuminated for 10 minutes (even when door is closed) when
the Light is turned on. When the Light is turned off, the wine
cellar compartment will be illuminated when the door is open.
The light will turn off when the door is closed.
■Press and hold the Power button/touch pad again to turn Off
the wine cellar cooling system. A 3 second countdown will
show in the compartment display. The Light button/touch pad
will operate to turn the light on and off within the wine cellar
compartment.
Change Temperature Setting (on some models):
■For models with °F/°C control button/touch pad, press the
°F/ °C Control button/touch pad to switch from Fahrenheit
to Celsius or Celsius to Fahrenheit. The °F or °C on the
Temperature Indicator touch pad will illuminate to indicate
which temperature setting is currently in use.
■For models without °F/°C control button/touch pad, press and
hold the Decrease Temperature and Increase Temperature
buttons/touch pads for 3 seconds. A 3 second countdown will
display.
Using Eco Mode (on some models):
When Eco mode is activated, the compartment display light will
turn off when the door is closed. When the wine cellar door is
opened, the light will stay on until the door is closed. The Light
button/touch pad and °F/°C control button/touch pad will operate
normally.
■To activate Eco mode, press and hold the Eco mode button
for 3 seconds. A 3 second countdown will display.
■To deactivate Eco mode, press and hold the Eco mode button
for 3 seconds. A 3 second countdown will display and the
wine cellar will return to normal operation.
Adjusting the Control:
If you need to adjust the temperature, wait at least 24 hours
between adjustments and then recheck the temperature.
To make the wine cellar colder, adjust the setting to a lower
temperature. To make the wine cellar less cold, adjust the setting
to a higher temperature.
NOTE: On some models, adjusting the temperature control raises
or lowers the temperature in the corresponding compartments,
but not both compartments.
Temperature Separator (Temperature Display)
(on some models)
The temperature separator displays the current temperatures
(Fahrenheit or Celsius) for the upper and lower compartments of
the wine cellar. To adjust the temperature settings, see “Adjusting
the Control” earlier in this section.
Recommended Storing Locations (on some models)
For best storing and serving temperatures for your bottle of wine,
use the wine producer's recommended temperature setting. See
the wine’s label for details. It is recommended to store wine for
short-term (few months) at 55°F (13°C).
WINES COMPARTMENT
White Wine Upper compartment
Lighter Red Wine Lower compartment
Red Wine Lower compartment

11
Wine Racks
Remove and Replace the Top and Middle Racks
To Remove Racks:
1. Pull the rack forward until it stops.
2. Lift up on both sides of the rack to clear the shelf brackets
from the bracket support pins.
3. Pull the rack forward and out of the rack supports.
To Replace Racks:
1. Insert the rack into the compartment and slide it toward the
rear of the wine cellar.
2. Align the bracket support pins with the holes in the shelf
brackets, and then place the shelf into the rack supports until
properly in place.
Stocking the Wine Cellar
NOTE: For optimum wine storage, place white wines at the top of
the wine cellar, light red wines in the center and red wines at the
bottom.
To Stock the Wine Cellar
1. Start stocking the wine cellar with the bottom display rack.
2. Starting on the left-hand side, place the rst bottle in the rack
on its side with the neck of the bottle facing the front of the
wine cellar.
3. Place the next bottle on its side with the neck of the bottle
facing the back of the wine cellar.
4. Alternate in this manner until the display rack is full.
5. Push the rack all the way in before pulling the next one
forward.
6. Pull the next rack forward and repeat steps 2 through 4;
repeat for remaining racks.
Front of rack

12
7. To stock the bottom of the wine cellar, place bottles in the
grooves on the bottom of the wine cellar with the necks of the
bottles facing the back of the wine cellar. Lighting the Wine Cellar
The refrigerator has an interior light that comes on any time the
door is opened. Refer to the “Using the Controls” section for
options on controlling the interior light.
NOTE: The light is an LED which does not need to be replaced.
If the LED does not illuminate when the door is opened, call
Service to replace the light. See Assistance or Service for contact
information.
WINE CELLAR CARE
Cleaning
Clean the wine cellar about once a month to avoid buildup of
odors. Wipe up spills immediately.
To Clean Your Wine Cellar:
1. Unplug wine cellar or disconnect power.
2. Remove all racks from inside the wine cellar.
3. Clean the interior.
Style 1 - Models with stainless steel trim
Using a clean sponge or soft cloth and a mild detergent dissolved
in warm water, hand wash and rinse thoroughly the removable
parts and interior surfaces. Dry with a soft cloth.
Style 2 - Models with wooden trim
IMPORTANT: To avoid damaging wooden trim pieces, wipe the
trim with a clean sponge or soft cloth and warm water. Do not use
detergent or immerse the entire rack into water when cleaning.
Using a clean sponge or soft cloth and a mild detergent dissolved
in warm water, hand wash and rinse thoroughly the removable
parts and interior surfaces. Dry with a soft cloth.
■Do not use abrasive or harsh cleaners such as window
sprays, scouring cleansers, ammable uids, cleaning waxes,
concentrated detergents, bleaches or cleansers containing
petroleum products on plastic parts, interior and door liners
or gaskets. Do not use paper towels, scouring pads, or other
harsh cleaning tools. These can scratch or damage materials.
■To help remove odors, you can wash interior walls with a
mixture of warm water and baking soda (2 tbs to 1 qt [26g to
0.95L] of water).
4. Wash stainless steel and painted metal exteriors with a clean
sponge or soft cloth and a mild detergent in warm water. Do
not use abrasive or harsh cleaners, or cleaners containing
chlorine. These can scratch or damage materials. Dry
thoroughly with a soft cloth.
NOTE: To keep your stainless steel wine cellar looking like new
and to remove minor scuffs or marks, it is suggested that you use
the manufacturer’s approved Stainless Steel Cleaner and Polish.
To order the cleaner, see “Accessories.”
IMPORTANT: This cleaner is for stainless steel parts only.
Do not allow the Stainless Steel Cleaner and Polish to come into
contact with any plastic parts such as the trim pieces, dispenser
covers or door gaskets. If unintentional contact does occur, clean
plastic part with a sponge and mild detergent in warm water. Dry
thoroughly with a soft cloth.
5. Replace the racks.
6. Clean the condenser coils regularly. They are located behind
the base grille. Coils may need to be cleaned as often as
every other month. This may help save energy.
■Remove the base grille. See “Base Grille.”
■Use a vacuum cleaner with an extended attachment to
clean the condenser coils when they are dusty or dirty.
■Replace the base grille.
7. Plug in wine cellar or reconnect power.
WARNING
Explosion Hazard
Use nonammable cleaner.
Failure to do so can result in death, explosion, or re.

13
Vacation and Moving Care
Vacations
If you choose to turn the wine cellar off before you leave, follow
these steps.
1. Remove all wine bottles from the wine cellar.
2. Unplug the wine cellar.
3. Clean the wine cellar. See “Cleaning.”
4. Tape a rubber or wood block to the top of the door to prop
it open far enough for air to get in. This stops odor and mold
from building up.
Moving
When you are moving your wine cellar to a new home, follow
these steps to prepare it for the move.
1. Remove all wine bottles from the wine cellar.
2. Unplug the wine cellar.
3. Clean, wipe, and dry it thoroughly.
4. Take out all removable parts, wrap them well, and tape them
together so they don’t shift and rattle during the move.
5. Tape the doors shut and tape the power cord to the wine
cellar.
When you get to your new home, put everything back and refer to
the “Installation Instructions” section for preparation instructions.
TROUBLESHOOTING
Try the solutions suggested here rst in order to avoid the cost of an unnecessary service call.
Your wine cellar will not operate
■Is the power supply cord unplugged? Plug into a grounded
3 prong outlet.
■Has a household fuse blown, or has a circuit breaker
tripped? Replace the fuse or reset the circuit.
■Is the Wine Cellar Control turned to the OFF position?
See “Using the Control.”
The lights do not work
■Is the power supply cord unplugged? Plug into a grounded
3 prong outlet.
■Your wine cellar is equipped with LED lighting which does not
need to be replaced. If there is power to the wine cellar and
the lights do not illuminate when the door is opened, call for
service or assistance.
The motor seems to run too much
■Is the temperature outside hotter than normal? Expect
the motor to run longer under warm conditions. At normal
temperatures, expect your motor to run about 40% to 80% of
the time. Under warmer conditions, expect it to run even more
of the time.
Is the door opened often? Expect the motor to run longer when
this occurs. In order to conserve energy, try to get everything you
need out of the wine cellar at once, keep wine bottles positioned
label side up so that they are easy to nd, and close the door as
soon as the wine is removed.
Is the control set correctly for the surrounding conditions?
See “Using the Control.”
Is the door closed completely? Push the door rmly shut. If it
will not shut all the way, see “The door will not close completely”
later in this section.
Are the condenser coils dirty? This obstructs air transfer and
makes the motor work harder. Clean the condenser coils. See
“Cleaning.”
Temperature is too warm
■Is the door opened often? Be aware that the wine cellar
will warm when this occurs. In order to keep the wine cellar
cool, try to get everything you need out of the wine cellar at
once, keep wine bottles positioned label side up so that they
are easy to nd, and close the door as soon as the wine is
removed.
■Is the control set correctly for the surrounding conditions?
See “Using the Control.”
■Is the base grille blocked? For best performance, do not
install the wine cellar behind a cabinet door or block the base
grille.
There is interior moisture buildup
■Is the door opened often? To avoid humidity buildup, try to
get everything you need out of the wine cellar at once, keep
wine bottles positioned label side up so that they are easy
to nd, and close the door as soon as the wine is removed.
When the door is opened, humidity from the room air enters
the wine cellar. The more often the door is opened, the faster
humidity builds up, especially when the room itself is very
humid.
■Is it humid? It is normal for moisture to build up inside the
wine cellar when the air is humid.
■Is the control set correctly for the surrounding conditions?
See “Using the Control.”
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

14
The door is difcult to open
■Is the gasket dirty or sticky? Clean the gasket and the
surface that it touches. Rub a thin coat of parafn wax on the
gasket following cleaning.
The door will not close completely
■Are the racks out of position? Put the racks back into their
correct positions. See “Wine Cellar Use” for more information.
■Is the gasket sticking? Clean the gasket and the surface
that it touches. Rub a thin coat of parafn wax on the gasket
following cleaning.
■Is the door installed properly? If the door was reversed
improperly, re-installation may be required. See “Reverse Door
Swing.”
WARNING
Explosion Hazard
Use nonammable cleaner.
Failure to do so can result in death, explosion, or re.
WARNING
Explosion Hazard
Use nonammable cleaner.
Failure to do so can result in death, explosion, or re.
ASSISTANCE OR SERVICE
Before calling for assistance or service, please check
“Troubleshooting.” It may save you the cost of a service call. If
you still need help, follow the instructions below.
When calling, please know the purchase date and the complete
model and serial number of your appliance. This information will
help us to better respond to your request.
If You Need Replacement Parts
If you need to order replacement parts, we recommend that you
only use factory specied replacement parts. Factory specied
replacement parts will t right and work right because they are
made with the same precision used to build every new Whirlpool®
appliance.
To locate factory specied replacement parts in your area, call us
or your nearest designated service center.
In the U.S.A.
Call the Whirlpool Customer eXperience Center toll free:
1-800-253-1301.
Our Consultants Provide Assistance With:
■Features and specications on our full line of appliances.
■Installation information.
■Use and maintenance procedures.
■Warranty.
■Accessory and repair parts sales.
■Specialized customer assistance (Spanish speaking, hearing
impaired, limited vision, etc).
■Referrals to local dealers, repair parts distributors, and
service companies. Whirlpool designated service technicians
are trained to fulll the product warranty and provide after
warranty service, anywhere in the United States.
To locate the Whirlpool designated service company in your area,
you can also look in your telephone directory Yellow Pages.
For Further Assistance
If you need further assistance, you can write to Whirlpool with any
questions or concerns at:
Whirlpool Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
Please include a daytime phone number in your correspondence.
In Canada
Call the Whirlpool Canada Customer eXperience Centre toll free:
1-800-807-6777, or visit our website at www.whirlpool.ca.
Our Consultants Provide Assistance With:
■Scheduling of Service. Whirlpool designated service
technicians are trained to fulll the product warranty and
provide after-warranty service anywhere in Canada.
■Features and specications on our full line of appliances.
■Referrals to local dealers.
■Use and maintenance procedures.
■Accessory and repair parts sales.
For Further Assistance
If you need further assistance, you can write to Whirlpool Canada
with any questions or concerns at:
Whirlpool Brand Home Appliances
Customer eXperience Centre
200 - 6750 Century Ave.
Mississauga, Ontario L5N 0B7
Please include a daytime phone number in your correspondence.
Accessories
The following accessory is available for your wine cooler. To order
accessory, contact us and ask for the part number.
In the U.S,A., visit our webpage www.whirlpool.com/
accessories or call 1-800-253-1301.
In Canada, visit our webpage www.whirlpoolparts.ca or call
1-800-807-6777.
Stainless Steel Cleaner & Polish
Order Part #4396095

15
SEGURIDAD DE LA BODEGA
Si no sigue las instrucciones de inmediato, usted
o sufrir una lesión grave.
Si no sigue las instrucciones, usted puede morir
o sufrir una lesión grave.
To dos los mensajes de seguridad le dirán el peligro potencial, le dirán cómo reducir las posibilidades de sufrir
una lesión y lo que puede suceder si no se siguen las instrucciones.
Su seguridad y la seguridad de los demás es muy importante.
Hemos incluido muchos mensajes importantes de seguridad en este manual y en su electrodoméstico.
Este es el símbolo de alerta de seguridad.
Este símbolo le llama la atención sobre peligros potenciales que pueden ocasionar la muerte o una
y de la palabra “PELIGRO” o “ADVERTENCIA”. Estas palabras significan:
PELIGRO
ADVERTENCIA
a usted y a los demás.
Lea y obedezca siempre todos los mensajes de seguridad.
To dos los mensajes de seguridad irán a continuación del símbolo de advertencia de seguridad
puede morir
lesión
ADVERTENCIA:
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
GUARDE ESTAS INSTRUCCIONES
■Los niños deben estar bajo supervisión para garantizar que
no jueguen con el electrodoméstico.
■Este electrodoméstico no se diseñó para ser usado por
personas (incluidos niños) con capacidad física, sensorial o
mental reducida, o con falta de experiencia y conocimiento,
a menos que una persona responsable de su seguridad les
brinde supervisión o instrucciones relativas para su uso.
■No utilice un cable de extensión.
■Si el cable de suministro eléctrico está dañado, el
fabricante, su servicio técnico o personas calificadas
idóneas deben reemplazarlo para evitar cualquier riesgo.
■No guarde en este electrodoméstico sustancias explosivas,
como latas en aerosol con propelente inflamable.
■No dañe el circuito de refrigerante.
■No use piezas de repuesto que no hayan sido
recomendadas por el fabricante (por ejemplo, piezas
hechas en casa con una impresora 3D).
■Mantenga las aberturas de ventilación, en el gabinete del
electrodoméstico o en la estructura integrada, libres de
obstrucciones.
■No use aparatos eléctricos dentro de los compartimientos
de almacenamiento de alimentos del electrodoméstico, a
menos que sean del tipo recomendado por el fabricante.
■Este electrodoméstico está diseñado para uso doméstico y
aplicaciones similares, como áreas de cocina para el
personal en tiendas, oficinas y otros entornos de trabajo;
granjas; por parte de clientes en hoteles, moteles y otros
entornos residenciales; posadas, servicios de comida y
aplicaciones similares que no sean de venta al por menor.
Para reducir el riesgo de incendio, descarga eléctrica o lesiones al usar el electrodoméstico, siga las siguientes
precauciones básicas:

16
Cómo deshacerse adecuadamente de
su refrigerador viejo
ADVERTENCIA: Riesgo de niños atrapados. Antes de
descartar su vieja bodega:
■Saque las puertas.
■Deje los estantes en su lugar así los niños no pueden
introducirse con facilidad.
IMPORTANTE: El atrapamiento y asxia de niños no es un
problema del pasado. Las bodegas tiradas y abandonadas son
un peligro, aún si van a quedar ahí “por unos pocos días”. Si
Ud. está por deshacerse de su bodega vieja, por favor siga las
instrucciones que se dan a continuación para prevenir accidentes.
ADVERTENCIA
Peligro de Asfixia
Remueva las puertas de su bodega vieja.
No seguir esta instrucción puede ocasionar la muerte
o daño al cerebro.
Información importante para saber acerca del desecho
de refrigerantes:
Deshágase del refrigerador siguiendo los reglamentos
federales y locales. Los refrigerantes deberán ser evacuados
por un técnico certificado en refrigeración por EPA (Agencia
de protección del medioambiente) según los procedimientos
establecidos.

17
REQUISITOS DE INSTALACIÓN
Herramientas
Herramienta necesaria
Reúna la herramienta necesaria antes de comenzar la instalación.
■Destornillador Phillips
Requisitos de ubicación
NOTAS:
■No se recomienda instalar la bodega cerca de un horno,
radiador u otra fuente de calor.
■No lo instale en un lugar donde la temperatura pueda ser
menor de 55 °F (13 °C). Para obtener un funcionamiento
óptimo, no instale la bodega detrás de la puerta de un
armario ni bloquee la rejilla de la base.
Medidas de la abertura
■Las medidas de altura se muestran con las patas niveladoras
extendidas a la altura mínima.
NOTA: Cuando las patas niveladoras están totalmente
extendidas, agregue 5/8" (15 mm) a la altura.
■Si el piso de la abertura no está nivelado con el piso de la
cocina, ponga calzas en la abertura para que quede nivelado
con el piso de la cocina.
Modelos de 15"
Dimensiones de profundidad
A* 247/8" (63,2 cm) - sin
manija
B* 265/8" (67,7 cm) -
WUW35X15DS
WUW35X15DS
Dimensiones
A217/8" (55,5 cm)
B251/2" (64,7 cm)
C 15" (38,0 cm)
D341/16" - 345/8"
(86,5 cm - 88,0 cm)
NOTA: Espacio de 105/8" (27 cm) requerido para permitir la
extensión de la parrilla completa.
Modelos de 24"
WUW35X24DS WUW55X24HS
NOTA: Espacio de 161/8" (41 cm) requerido para permitir la
extensión de la parrilla completa.
Requisitos eléctricos
Antes de mover la bodega a su ubicación nal, es importante
asegurarse de que tiene la conexión eléctrica adecuada.
Método de conexión a tierra recomendado
Se requiere una fuente de energía eléctrica de 115 V, 60 Hz, CA
solamente y con fusibles de 15 A ó 20 A, debidamente conectada
a tierra. Se recomienda que use un circuito separado sólo para su
bodega. Use un tomacorriente que no se pueda apagar con un
interruptor. No use un cable eléctrico de extensión.
Si se ha dañado el cable de suministro, deberá ser reemplazado
por el fabricante, por el agente de servicio del fabricante o
por una persona con calicación similar. No use un cable que
presente grietas o daño por desgaste en el largo, el enchufe o la
punta del conector.
NOTA: Antes de realizar cualquier tipo de instalación, limpieza o
de quitar un foco de luz, desenchufe la bodega o desconecte la
fuente de energía.
ADVERTENCIA
Peligro de Explosión
Mantenga los materiales y vapores inflamables,
tales como gasolina, alejados de la bodega.
No seguir esta instrucción puede ocasionar la muerte,
explosión, o incendio.
A*
B*
CA
B
D
ADVERTENCIA
Peligro de Choque Eléctrico
Conecte a un contacto de pared de conexión a tierra de
3 terminales.
No quite la terminal de conexión a tierra.
No use un adaptador.
No use un cable eléctrico de extensión.
No seguir estas instrucciones puede ocasionar
la muerte, incendio o choque eléctrico.
CA
B
D
CA
B1
D
A*
B*
B1*
153/4"
(40 cm)
13/16"
(3 cm)
351/4" 3513/16"
(89,5-91,0 cm)
355/8"-363/16"
(90,5-92,0 cm)
245/8"
(62,5 cm)
13/16"
(3 cm)
Dimensiones de profundidad
A* 247/8" (63,2 cm) - sin
manija
B* 265/8" (67,7 cm) -
WUW35X24DS
B1* 267/8" (68,2 cm) -
WUW55X24HS
Dimensiones
A217/8" (55,5 cm)
B251/2" (64,7 cm)
B1 2511/16" (65,2 cm)
C2313/16" (60,5 cm)
D347/16" - 35"
(87,5 cm - 89,0 cm)

18
INSTRUCCIONES DE
INSTALACIÓN
Desempaque de la bodega
Cómo quitar los materiales de empaque
■Quite los residuos de cinta y goma de las supercies antes de
encender la bodega. Frote un poco de detergente líquido para
vajillas sobre el adhesivo con los dedos. Limpie con agua tibia
y seque.
■No use instrumentos losos, alcohol para fricciones, líquidos
inamables o productos de limpieza abrasivos para eliminar
los restos de cinta o goma. Estos productos pueden dañar
la supercie de su bodega. Para más información, vea
“Seguridad de la bodega”.
■Deshágase de todos los materiales de embalaje o recíclelos.
Limpieza antes del uso
Una vez que usted haya quitado todos los materiales de
empaque, limpie el interior de su bodega antes de usarla. Vea las
instrucciones de limpieza en “Cuidado de su bodega”.
Cierre de la puerta
Su bodega tiene cuatro patas niveladoras. Si su bodega parece
inestable o usted quiere que la puerta se cierre con mayor
facilidad, ajuste la inclinación de la bodega usando las
instrucciones a continuación.
1. Conecte a un contacto de pared de conexión a tierra de 3
terminales.
2. Mueva la bodega hacia su posición nal.
3. Gire las patas niveladoras hacia la derecha para bajar la
bodega o gírelas hacia la izquierda para levantarla. Puede
precisar darle varias vueltas a las patas niveladoras para
ajustar la inclinación de la bodega.
NOTA: Para quitar un poco de peso de las patas niveladoras,
haga que alguien empuje la parte superior de la bodega. Esto
facilita el ajuste de las patas niveladoras.
4. Abra la puerta y verique para asegurarse que se cierra
con la facilidad que usted desea. Si no es así, gire ambos
tornillos niveladores delanteros hacia la derecha para inclinar
levemente la bodega más hacia atrás. Puede tomar varias
vueltas más, y usted deberá girar ambas patas niveladoras la
misma cantidad de veces.
ADVERTENCIA
Peligro de Peso Excesivo
Use dos o más personas para mover e instalar
la bodega.
No seguir esta instrucción puede ocasionar una
lesión en la espalda u otro tipo de lesiones.
Cuando mueva su bodega:
Su bodega es pesado. Cuando mueva el bodega para
limpiarlo o para darle servicio, cerciórese de cubrir el piso
con cartón o madera para evitar daños en el mismo. Al
mover el bodega, siempre tire directamente hacia afuera. No
menee el bodega de lado a lado ni lo haga “caminar”
cuando lo trate de mover ya que podría dañar el piso.
ADVERTENCIA
Peligro de Choque Eléctrico
Conecte a un contacto de pared de conexión a tierra de
3 terminales.
No quite la terminal de conexión a tierra.
No use un adaptador.
No use un cable eléctrico de extensión.
No seguir estas instrucciones puede ocasionar
la muerte, incendio o choque eléctrico.
ADVERTENCIA
Peligro de Peso Excesivo
Use dos o más personas para mover e instalar
la bodega.
No seguir esta instrucción puede ocasionar una
lesión en la espalda u otro tipo de lesiones.

19
Puertas de la bodega
Herramienta necesaria: Destornillador Phillips N° 2
Cómo quitar la puerta y las bisagras
1. Abra la puerta a un ángulo de 90° y quite los tornillos de la
bisagra inferior de la puerta.
2. Quite la puerta, jalándola hacia adelante y hacia afuera de la
bodega.
3. Quite los tres tornillos de la bisagra superior y sáquela.
Cambio del sentido de apertura de la puerta (opcional)
NOTA: Hay dos bisagras para la instalación de la puerta con
sentido de apertura invertido, una para el sentido de apertura de
la puerta hacia la derecha y otra para el sentido de apertura de
la puerta hacia la izquierda. Instale la bisagra superior diseñada
para el sentido de apertura de puerta deseado.
1. Quite los dos tornillos que sujetan la bisagra inferior a la
puerta.
2. Quite la puerta, levantándola y jalándola hacia afuera de la
bodega.
3. Quite los tres tornillos decorativos de la esquina superior
izquierda del frente de la bodega.
4. Quite los tres tornillos de la bisagra superior derecha y
sáquela.
5. Usando los tres tornillos que quitó en el paso anterior, sujete
la bisagra superior izquierda a la esquina superior izquierda
del frente de la bodega.
NOTA: La bisagra izquierda se incluye en la bolsa con el
Manual de uso y cuidado.
6. Inserte los tres tornillos decorativos que quitó en el Paso 3 en
los tres oricios de la esquina superior derecha del frente de
la bodega.
7. Quite los tornillos del interruptor mecánico y el tope de la
puerta; retire el interruptor mecánico y el tope de la puerta.
Coloque el interruptor mecánico y el tope de la puerta en el
lado opuesto de la puerta.
NOTA: Los tornillos para el interruptor mecánico de la puerta
se encuentran detrás del sello. Quite primero el sello y luego
saque los tornillos del interruptor mecánico de la puerta.
Luego de volver a sujetar el interruptor mecánico de la puerta,
coloque el sello en su posición original.
8. Retire la insignia de Whirlpool. (Solo los modelos:
WUW55X24HS.)
9. Sujete la bisagra inferior en el lado opuesto de la puerta y gire
la puerta 180° de manera que la bisagra ahora se encuentre
en la parte inferior de la puerta.
10. Inserte la esquina superior de la puerta dentro del pasador de
la bisagra superior, y vuelva a instalar la puerta en la bodega.
11. Presione la puerta y el pasador de la bisagra inferior hacia
adentro de la bisagra inferor..
AB
C
A. Pasador de la bisagra inferior
B. Tope de la puerta
C. Bisagra inferior

20
12. Coloque la etiqueta autoadhesiva en la parte superior de la
cava de vino.
13. Después de cambiar la puerta (bisagra de la izquierda),
coloque la insignia de Whirlpool en la parte inferior de la cava
de vino. (Solo los modelos: WUW55X24HS.)
NOTA: La etiqueta autoadhesiva y la insignia de Whirlpool se
inclu yen en la bolsa con la Guía para el uso y el cuidado.
14. Verique la alineación y los sellos de la puerta.
15. Apriete los tornillos de la bisagra (según fuera necesario).
Rejilla de la base
Debe quitar la rejilla de la base para acceder a los serpentines del
condensador y limpiarlos.
Para quitar la rejilla de la base:
1. Abra la puerta de la bodega.
2. Saque los dos tornillos de la rejilla de la base con un
destornillador Phillips.
3. Quite los dos tornillos que sujetan el interruptor mecánico a la
rejilla.
4. Quite la rejilla de la base.
Para volver a colocar la rejilla de la base:
1. Abra la puerta de la bodega.
2. Vuelva a sujetar el interuptor mecánico con los dos tornillos
con sesnsores.
3. Vuelva a colocar los dos tornillos de la rejilla de la base.
Apriete los tornillos.
Ensamblaje de la manija
NOTA: Solo para los modelos WUW55X24HS.
Consejo útil: Coloque cartón debajo de la bodega hasta que esté
instalada en la abertura del armario. El cartón ayudará a proteger
la cubierta del piso durante la instalación.
NOTAS:
■Para facilitar la instalación, coloque la bodega sobre su parte
posterior con la ayuda de dos o más personas.
■Coloque un paño suave o una toalla contra el panel frontal
mientras instala la manija de la puerta para evitar rayarlo.
■Los tornillos opresores han sido instalados previamente en la
manija.
1. Quite la manija de la puerta y la bolsa de herramientas que
contiene la llave hexagonal en L de la bolsa de burbujas.
2. Coloque la manija en los pernos de montaje. Los tornillos
opresores deberán mirar hacia abajo cuando se hayan
instalado correctamente. Si la manija se instala al revés, la
instalación apropiada no será posible.
3. Empuje rmemente la manija contra la puerta.
4. Inserte el extremo corto de la llave hexagonal en L en el
tornillo opresor y apriete el tornillo opresor 1/4 de vuelta bien
ajustado. El tornillo opresor no estará empotrado en la manija.
5. Repita el paso 4 para el otro tornillo opresor.
6. Guarde la llave hexagonal en L con las instrucciones de
instalación.
NOTA: El procedimiento de instalación de la manija deberá
tomar menos de 5 minuto.
Pegue la etiqueta
autoadhesiva aquí
Pegue la etiqueta autoadhesiva
Etiqueta autoadhesiva
ADVERTENCIA
Peligro de Peso Excesivo
Use dos o más personas para mover e instalar
la bodega.
No seguir esta instrucción puede ocasionar una
lesión en la espalda u otro tipo de lesiones.
A
B
C
D
A. Perno de montaje
B. Manija de la puerta
C. Tornillo opresor
D. Llave hexagonal
