FOR INDOOR USE ONLY Mr. Christmas
RGB Christmas Tree
Instruction Manual
FOR INDOOR USE ONLY

Step 1 : Check the contents of your box
Before starting assembly, be sure to check all contents and
lay out the various tree parts accordingly.
There are:
A. Top Tree Section
B. Middle Tree Section
C. Bottom Tree Section
D. Control box and power cord with adaptor
E. Tree Stand
F. Three pins for the tree stand
G. Ornament with voice activated command list
H. Spare bulbs: 8 pieces (in the polybag attached
end of the light strand inside the tree)
F
A
BC
D
E
G
H

Step 2 : Expand Stand
1: Take Tree Stand and pull apart the legs (Figure A),
open to full Position (Figure B)
2. Take fully opened tree stand and insert pins into
the pre drilled holes, tightening the pins part way
(complete tightening in Step 3-A.
Figure A Figure B
Figure C

Step 3-1 : Tree Assembly
Section C
1. Take Tree Section labeled “C” and insert into the top of tree stand.
(Figure A)
2. Take the Pins and fully tighten the 3 pins into place (Figure B).
Secure the tree base firmly to the tree stand.
Figure A
Figure B

Step 3-2 : Tree Assembly
Section B
Section C
Take Tree Section labeled “B” and insert into the top of the pole of section “C”.

Step 3-3 : Tree Assembly
Section A
Section B
Section C
Take Tree Section labeled “A” and insert into the pole into the top of the pole of section “B”.
IMPORTANT TREE SET UP TIPS:
1. Shake the tree well after
assembly to ensure the
branches are extended.
2. Some shaping of the tree may
be required for best appearance.
3. Spare bulbs are included in a
small bag inside the tree.
Remove from the tree and keep
in case replacement is needed.

Step 4 : Connect to AC Power
Attach the power cord with adaptor to the control box, plug the adaptor into an AC power
source.

Step 5: Connect to Alexa
1. Download the “Amazon Alexa” application from the app store on your mobile device .
2. Install and open the “Amazon Alexa” application.
3. Go to the settings menu.
4. Select “Add Device”
5. Select “Christmas Tree” and follow the on-screen instructions.
6. To use with a second tree, select “Second Christmas Tree” and follow the on screen instructions.
For ease of use, update the device names as needed (for example, “living room tree” or “dining
room tree”). Alexa will ask for clarification If a command does not target a specific tree.
Barcode Scanning & Location
Note that during device setup you may be
asked to scan a device barcode. You can find
this on the back of the controller, described in
Figure A.
Figure A

Step 6-A: Change your Christmas Tree LED lighting Mode using Alexa
Follow the voice commands for a list of functions:
1. Red
2. Green
3. Yellow
4. Blue
5. Purple
6. Light Blue
7. White
8. Multi-Color
9. Candy Cane
10.Multi Sparkle
11.Snowflakes
12.Multi Fade
13.Multi Twinkle
Figure A

Step 6-B : Manually change your Christmas Tree LED lighting mode
1. Red
2. Green
3. Yellow
4. Blue
5. Purple
6. Light Blue
7. White
8. Multi-Color
9. Candy Cane
10.Multi Sparkle
11.Snowflakes
12.Multi Fade
13.Multi Twinkle
Push Button on Control Box to switch Christmas Tree LED Light Mode.
There are a total of 13 lighting modes listed below:

Step 6-C : Automate your Christmas Tree with Routines
Alexa Routines allow you to automate your Christmas Tree Functionality. With Routines, you can turn
your tree on with custom commands (i.e. Good Morning) or turn the tree on/off at scheduled times
(i.e. every day at 10AM)
How to Enable Routines with Alexa.
1. Open the Alexa app.
2. Go to the menu and select “Routines”
3. Select Plus
4. Select “When this happens”, and then choose how to begin your Routine (i.e. “Good Morning, or
a scheduled time).
5. Select “Add Action”, select “Smart Home”, and then select “Christmas Tree”. Configure the
desired LED lighting mode for your selected action.

Example 1 ：Turn Christmas Tree on
“Turn my Christmas Tree ON”

Example 2 ：Set lighting mode to red
“Set my Christmas Tree to : Red”

Example 3 ：Turn Christmas Tree off
“Turn my Christmas Tree OFF”

Example4 ：Turn Christmas Tree on with Routines
“Good Morning / Good Night”

Connectivity Troubleshooting
Common connectivity troubleshooting steps.
1. I can’t connect my device to Alexa.
•Check that your Alexa device and the Alexa app have the latest software version.
•Make sure that your Alexa device and your Christmas Tree are connected to the same Wi-Fi
network.
•Check that your device is within 30 ft. (9 m) of your Christmas Tree.
•Reset your Christmas Tree: press and hold the button on the control box for 10 seconds to reset the
Christmas tree.
2. I can’t get my Christmas Tree barcode to successfully scan.
•During the Alexa mobile app setup process, select “Don’t Have a Barcode”
•Follow the on-screen instructions.
3. My Christmas Tree stopped working with Alexa.
•Try a power cycle: Unplug your Christmas Tree from the outlet, and then plug it back in.
•Reset your Christmas Tree: press and hold the button on the control box of the tree for 10 seconds.

IMPORTANT SAFETY INSTRUCTIONS
When using electrical products, basic precautions should always be followed including the
Following:
a) READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
b) Do not use seasonal products outdoors unless marked suitable for indoor and outdoor
use. When products are used in outdoor applications, connect the product to a Ground
Fault Circuit Interrupting (GFCI) outlet. If one is not provided contact a qualified for
proper installation.
c) This seasonal use product is not intended for permanent Installation or use.
d) Do not mount or place near gas or electric heaters, fireplace, candles or other similar
sources of heat.
e) Do not secure the wiring of the product with staples or nails, or place on sharp hooks
or nails.
f) Do not let bulbs rest on the supply cord or on any wire.
g) Unplug the product when leaving the house, when retiring for the night, or if left
unattended.
h) This is an electric product-not a toy! To avoid risk of fire, burns, personal injury and
electric shock it should not be played with or placed where small children can reach it.
i) Do not use this product for other than its intended use.
j) Do not hang ornaments or other objects from cord, wire, or light string.
k) Do not close doors or windows on the product or extension cords as this may damage
the wire insulation
l) Do not cover the product with cloth, paper or any material not part of the product
when In use.
m) This product is equipped with push-in type bulbs. Do not twist bulbs.
n) Read and follow a instructions that are on the product or provided with the product.
o) Save this instructions.
If the new bulb base does not fit in bulb holder, follow the steps below
before step 3.
a) Remove the base of burned out bulb by straightening bulb leads
and gently pull bulb out.
b) Thread leads of new bulb through holes In old base with one lead
in each hole.
c) After bulb is fully inserted into base, bend each lead up like other
bulbs in the light set. so that the leads will touch the contacts
inside the bulb holder.
User Servicing Instructions
Replace the bulb.
1. Grasp plug and remove from the receptacle or other outlet device. Do not unplug by pulling
on cord.
2. Pull bulb and plastic base straight out of bulb holder
3. Replace bulb with only 3 Volt 0 , 06 Watt LED type bulb
(provided with product).
CAUTION
1. To reduce the risk of fire or electric shock do not attempt to replace bulbs or modify string.
2. To reduce the risk of fire and electric shock：a) Do not install on trees having needles, leaves
or branch coverings of metal or materials which look like metal, and b) Do not mount or
support strings in a manner that can cut or damage wire insulation.
Model No : 60625
Unlock/lock
Made in China
Amazon ASIN#: B07WC7M2GY
Made by Mr. Christmas Inc.
5841 E. Shelby Dr., Memphis, TN 38141
Phone : [phone]
