Mr. Christmas 68300 User manual

FOR INDOOR USE ONLY
Mr. Christmas
5ft RGB Christmas Tree
Item # 68300
Instruction Manual
FOR INDOOR USE ONLY

Before starting assembly, be sure to check all contents
and lay out the various tree parts accordingly.
There are:
Step 1 : Check the contents of your box
A. Top tree section.
B. Bottom tree section.
C. Control box and power cord with adaptor.
D. Tree stand.
E. Three pins for the tree stand.
F. Ornament with voice activated command list
G. Spare bulbs: 4 pieces (in the polybag attached to
the end of the light strand inside the tree).
2
C
D
E
G
F
A
B

Step 2 : Expand Stand
1. Take the tree stand and pull apart the legs (Figure A),
open to full Position (Figure B)
2. Take the fully opened tree stand and insert pins into
the pre drilled holes, tightening the pins part way
(complete tightening in Step 3-1).
Figure A Figure B Figure C
3

Step 3-1 : Tree Assembly
Section B
1. Take the tree section labeled “B” and insert
into the top of tree stand.
(Figure A)
2. Fully tighten the 3 pins into place (Figure B).
Secure the tree base firmly to the tree stand.
Figure A
Figure B
4

Step 3-2 : Tree Assembly
Section A
Section B
Take the tree section labeled “A” and insert into the pole into
the top of the pole of section “B”.
IMPORTANT TREE SET UP TIPS:
1. Shake the tree well after
assembly to ensure the
branches are extended.
2. Some shaping of the tree
may be required for best
appearance.
3. Spare bulbs are included in
a small bag inside the tree.
Remove from the tree and
keep in case replacement is
needed.
5

Step 4 : Connect to AC Power
Attach the power cord with adaptor to the control box, plug the adaptor into
an AC power source.
6

Step 5: Connect to Alexa
1. Download the “Amazon Alexa” application from the app store on your mobile
device .
2. Install and open the “Amazon Alexa” application.
3. Go to the settings menu.
4. Select “Add Device”
5. Select “Christmas Tree” and follow the on-screen instructions.
6. To use with a second tree, select “Second Christmas Tree” and follow the on
screen instructions. Alexa will ask for clarification If a command does not target a
specific tree.
Barcode Scanning &
Location
Note that during device
setup you may be asked to
scan a device barcode.
You can find this on the
back of the controller,
shown in Figure A.
Figure A
7

Step 6-A: Change your Christmas Tree LED lighting Mode using Alexa
Follow the voice commands for a list
of functions to achieve up to 40
lighting functions.
Color options
Command – “Set Christmas tree to” :
1. Red
2. Green
3. Yellow
4. Blue
5. Purple
6. Light Blue
7. White
8. Multi-Color
Lighting functions
Command – “Set Christmas tree to” :
a. STEADY
b. SPARKLE
c. FIREFLY
d. FLIP
e. FADE
Figure A
8
Refer page 11-13 for examples of commands.

Step 6-B : Manually change your Christmas Tree LED lighting mode
Push Button on Control Box
to switch Christmas Tree LED
Light Mode.
There are a total of 40
lighting modes:
10
Demo Mode is available:
Press and hold the button
on the control box of the
tree for 3-4 seconds. The
tree lights will turn green
and will flash 3 times
This indicates that the
instructions were received.
The Demo mode will start
and play all 40 lighting
functions.
1. White Steady
2. Red Steady
3. Green Steady
4. Blue Steady
5. Light Blue Steady
6. Purple Steady
7. Yellow Steady
8. Multi-Color Steady
9. White Fade
10. Red Fade
11. Green Fade
12. Blue Fade
13. Light Blue Fade
14. Purple Fade
15. Yellow Fade
16. Multi-Color Fade
17. White Sparkle
18. Red Sparkle
19. Green Sparkle
20. Blue Sparkle
21. Light Blue Sparkle
22. Purple Sparkle
23. Yellow Sparkle
24. Multi-Color Sparkle
25. White Firefly
26. Red Firefly
27. Green Firefly
28. Blue Firefly
29. Light Blue Firefly
30. Purple Firefly
31. Yellow Firefly
32. Multi-Color Firefly
33. White Flip
34. Red Flip
35. Green Flip
36. Blue Flip
37. Light Blue Flip
38. Purple Flip
39. Yellow Flip
40. Multi- Color Flip

Step 6-C : Automate your Christmas Tree with Routines
Alexa Routines allow you to automate your Christmas Tree Functionality. With Routines,
you can turn your tree on with custom commands (i.e. Good Morning) or turn the tree
on/off at scheduled times (i.e. every day at 10AM)
How to Enable Routines with Alexa.
1. Open the Alexa app.
2. Go to the menu and select “Routines”
3. Select Plus
4. Select “When this happens”, and then choose how to begin your Routine
(i.e. “Good Morning, or a scheduled time).
5. Select “Add Action”, select “Smart Home”, and then select “Christmas Tree”.
Configure the desired LED lighting mode for your selected action.
10

Example 1 ：Turn Christmas Tree on
“Turn Christmas Tree ON”
11
Example 2 ：Set lighting mode to red
“Set Christmas Tree to : Red”

12
Example 3 ：Set lighting mode to Fade
“Set Christmas Tree to : Fade”
Example 4 ：Turn Christmas Tree off
“Turn Christmas Tree OFF”

Example 5 ：Turn Christmas Tree on with Routine
“Good Morning / Good Night”
13

Connectivity Troubleshooting
Common connectivity troubleshooting steps.
1. I can’t connect my device to Alexa.
•Check that your Alexa device and the Alexa app have the latest software
version.
•Make sure that your Alexa device and your Christmas Tree are connected to
the same Wi-Fi network.
•Check that your device is within 30 ft. (9 m) of your Christmas Tree.
•Reset your Christmas Tree: press and hold the button on the control box for 10
seconds to reset the Christmas tree.
2. I can’t get my Christmas Tree barcode to successfully scan.
•During the Alexa mobile app setup process, select “Don’t Have a Barcode”
•Follow the on-screen instructions.
3. My Christmas Tree stopped working with Alexa.
•Try a power cycle: Unplug your Christmas Tree from the outlet, and then plug
it back in.
•UGS (User-guided mode set up: Press and hold the button on the control box
of the tree for 5-9 seconds. Indication of action done: 3 flashes of red light.
•Full reset your Christmas Tree: Press and hold the button on the control box of
the tree for 10 seconds. Indication of action done: 3 flashes of white light.
14

User Servicing Instructions
Replace the bulb.
1. Grasp plug and remove from the receptacle or other outlet
device. Do not unplug by pulling on cord.
2. Pull bulb and plastic base straight out of bulb holder
3. Replace bulb with only 3 Volt 0 , 06 Watt LED type bulb
(provided with product).
If the new bulb base does not fit in bulb holder, follow the
steps below before step 3.
a) Remove the base of burned out bulb by straightening bulb
leads and gently pull bulb out.
b) Thread leads of new bulb through holes In old base with
one lead in each hole.
c) After bulb is fully inserted into base, bend each lead up
like other bulbs in the light set. so that the leads will touch
the contacts inside the bulb holder.
When using electrical products, basic precautions should
always be followed including the Following:
a) READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
b) Do not use seasonal products outdoors unless marked
suitable for indoor and outdoor use. When products are
used in outdoor applications, connect the product to a
Ground Fault Circuit Interrupting (GFCI) outlet. If one is not
provided contact a qualified for proper installation.
c) This seasonal use product is not intended for permanent
Installation or use.
d) Do not mount or place near gas or electric heaters, fireplace,
candles or other similar sources of heat.
e) Do not secure the wiring of the product with staples or nails,
or place on sharp hooks or nails.
f) Do not let bulbs rest on the supply cord or on any wire.
g) Unplug the product when leaving the house, when retiring
for the night, or if left unattended.
h) This is an electric product-not a toy! To avoid risk of fire,
burns, personal injury and electric shock it should not be
played with or placed where small children can reach it.
i) Do not use this product for other than its intended use.
j) Do not hang ornaments or other objects from cord, wire, or
light string.
k) Do not close doors or windows on the product or extension
cords as this may damage the wire insulation
l) Do not cover the product with cloth, paper or any material
not part of the product when In use.
m)This product is equipped with push-in type bulbs. Do not
twist bulbs.
n) Read and follow a instructions that are on the product or
provided with the product.
o)Save this instructions.
CAUTION
1. To reduce the risk of fire or electric shock do not attempt to
replace bulbs or modify string.
2. To reduce the risk of fire and electric shock：a) Do not install
on trees having needles, leaves or branch coverings of metal
or materials which look like metal, and b) Do not mount or
support strings in a manner that can cut or damage wire
insulation.
Made in China
Model No : 68300
Amazon ASIN#: B086WY173L
Made by Mr. Christmas Inc.
6045 E. Shelby Dr., Memphis, TN 38141
Phone : [phone]
IMPORTANT SAFETY INSTRUCTIONS
15
