mr. steam Butler Instruction manual

Installation, Operation & Maintenance Manual
Basic Butler / Linear
mr
.steam® Feel Good Inc.
Rev 5.2022
Table of Contents:
iTempo & iTempoplus Control PUR100474 1-15pg
AromaSteam SteamHead PUR100421 16-17pg
Linear Steam Head PUR103936 18-28pg
MS/Super AutoFlush PUR100200E 29-31pg
Condensation Pan TS0012 32-33pg

Installation, Operation & Maintenance Manual
iTEMPO & iTEMPOPLUS
CONTROLS
mr
.steam® Feel Good Inc.
PUR100474 Rev 5.22
® ®

2
HYPERTHERMIA occurs when the
internal temperature of the body
reaches a level several degrees above
the normal body temperature of 98.6°
F. The symptoms of hyperthermia
include an increase in the internal
temperature of the body, dizziness,
lethargy, drowsiness, and fainting. The
effects of hyperthermia include:
a) Failure to perceive heat;
b) Failure to recognize the need to exit
the steambath;
c) Unawareness of impending risk;
d) Fetal damage in pregnant women;
e) Physical inability to exit the steam-
bath;
and
f) Unconsciousness.
The use of alcohol, drugs, or medica-
tion can greatly increase the risk of
hyperthermia.
When installing and using this electrical equipment, basic safety
precautions should always be followed, including the following:
IMPORTANT SAFETY INSTRUCTIONS
1. READ AND FOLLOW ALL INSTRUCTIONS
2. Supervise children at all times.
3. Steam is hot and can cause injury or death
if improperly used. Steam rooms contain steam and ele-
vated temperatures. Please read and observe all warnings
in this manual before installing or using a steam room.
4. To reduce the risk of injury:
A. The wet surfaces of steam enclosures may be slippery.
Use care when entering or leaving.
B. The steam head is hot. DO NOT touch the steamhead
and avoid the steam near the steamhead.
C. Prolonged use of the steam system can raise exces-
sively the internal human body temperature and impair
the body’s ability to regulate its internal temperature
(hyperthermia). Limit your use of steam to 10-15 min-
utes until you are certain of your body’s reaction.
D. Excessive temperatures have a high potential for caus-
ing fetal damage during the early months of pregnancy.
Pregnancy or possibly pregnant women should consult a
physician regarding correct exposure.
E. Obese persons and persons with a history of heart disease,
low or high blood pressure, circulatory system problems,
or diabetes should consult a physician before using a
steambath.
F. Persons using medication should consult a physician before
using a steambath since some medication may induce
drowsiness while other medications may affect heart rate,
blood pressure and circulation.
SAVE THESE INSTRUCTIONS
WARNING
!
WARNING
!
WARNING
!
WARNING
!

3
mr
.steam®Installation & Operating Instructions
_________________________________________________________________
READ ME FIRST!
As you follow these instruc-
tions, you will notice warning and caution
symbols. This blocked information is impor-
tant for the safe and efficient installation
and operation of this generator. These are
types of potential hazards that may occur
during installation and operation:
Indicates a potentially
hazardous situation, which, if not avoided,
could result in death or serious injury.
Indicates a potentially
hazardous situation, which, if not avoided
may result in minor or moderate injury or
product damage.
IMPORTANT NOTE: This highlights
information that is especially relevant to
a problem-free installation.
All information in these instructions is
based on the latest product information
available at the time of publication.
MrSteam reserves the right to make
changes at any time without notice.
Table of Contents:
Important Safety Instructions.............................. 3
Before Installing.................................................. 5
Dimensional Information .................................... 6
Installations......................................................7-9
iTempo Operating Instructions ...................10-11
iTempoPlus Operating Instructions.............12-15
Care and Maintenance .....................................16
Warranty ........................................................... 16
WARNING
!
WARNING
!
CAUTION
!

4
mr
.steam®Installation & Operating Instructions
_________________________________________________________________
BEFORE INSTALLING
Carefully inspect the control and packaging for shipping
damage. In the event of shipping damage, please contact
the carrier for claim information. Our customer service de-
partment can assist you with any missing or damaged parts.
To avoid unintentional steambath
operation, do not locate the control where other controls,
accessories, shower heads, valves, body sprays or similar
within the shower could cause confusion or interfere with
the MrSteam control’s intended use and function.
Do not use any iTempoPlus®, iTempo®, HomeWizard®or
iGenie®controls without reading and understanding the
respective Installation and Operation Manual and MrSteam
steam generator Installation and Operation Manual. Failure
to read and understand these instructions may result in an
inoperative or hazardous installation.
A peel and stick warning sticker is provided
in the MrSteam steam generator Installation, Operation
and Maintenance Manual. This manual is provided with
every steam generator. The warning sticker must be read
and permanently affixed in a conspicuous location near the
steam room. Failure to read and affix this warning sticker in
a conspicuous location may result in serious injury or death.
Please call MrSteam at 800 767-8326 for a free replacement
or if you have any questions regarding the warning sticker.
Install the iTempo or iTempoPlus controls according to
installation instructions. Failure to install according to in-
structions will result in an inoperative control or hazardous
overheating or inadequate heating of the steam room.
Failure to install according to instructions will result in an
inoperative control and overheating of the steam room.
IMPORTANT NOTE: If the desired location for the control
is outside the steam room a Remote Temperature Probe
(MSTS) must be installed inside the steam room. Contact
CAUTION
!
MrSteam technical service 1-800-767- 8326 for
more information on the Remote Temperature
Probe.
Do not route iTempoPlus, iTempo,
HomeWizard or iGenie control wiring inside conduit
together with power lines or close to hot water or
steam piping. Doing so may result in an inoperative
or hazardous installation.
Do not alter or modify any MrSteam
product. Doing so may result in an inoperative or
hazardous installation and will void the warranty.
IMPORTANT NOTES:
UÊ
Turn power to the steam generator OFF before
connecting the control to the generator. Failure
to turn the power off will result in an inoperable
control.
UÊÊÌÊ«iÀ>ÌiÊ/i«*ÕÃ]Ê/i«]ÊiÊ
Wizard or iGenie controls with anything other
than a MrSteam iTempo compatible steam gen-
erator. MrSteam residential steam generators
with serial numbers lower than 900000, or any
other brand of steam generator are not to be op-
erated with iTempo controls. Doing so may result
in an inoperative installation.
UÊ/ÃÊ`VÕiÌÊVÌ>ÃÊ«ÀÌ>ÌÊÃ>viÌÞ]Ê«iÀ>-
tion and maintenance information. Leave this
document with the homeowner. Do not discard
this document.
UÊÃVÌÕiÊÕÃiÊvÊÌiÊÃÌi>Ê}iiÀ>ÌÀÊÀÊVÌÀÊ
if the steam generator is damaged or otherwise
not functioning properly. Doing so may result in
an inoperative or hazardous installation.
UÊÊÕÃÌÀ>ÌÃÊ>ÀiÊvÀÊÕÃÌÀ>ÌÛiÊ«ÕÀ«ÃiÃÊÞ°
WARNING
!
WARNING
!
WARNING
!
