mr. steam Linear Steam Head 104216 User manual

READ ME FIRST!
As you ollow these instructions, you will notice
warning and caution symbols. This in ormation
is important or the proper, sa e and trouble ree
installation o the Linear Steam Head. These are
types o potential hazards that may occur i in-
stallation instructions are not care ully ollowed.
This signals a situation where injury or property
damage may occur i you do not ollow instructions.
IMPORTANT NOTE: This highlights in ormation that is espe-
cially relevant to a problem- ree installation.
All in ormation in these instructions is based on the latest in orma-
tion available at the time o publication. Sussman-Automatic Corpo-
ration reserves the right to make changes at any time without notice.
1
Linear Steam Head® mr
.steam
®
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Installation Instructions Model 104216
• Linear Steam Head model 104216 is suitable or MrSteam
generator models MS90 – MS400, MSSUPER1– MSSUPER3,
MX4 – MX6.
Do not use Linear Steam Head model 104216 or any other
MrSteam steam generator. Do not use the Linear Steam
Head with any steam generator that is not a MrSteam steam
generator. Failure to ollow these instructions may result in a
leak within the wall cavity and cause problems associated
with leaks, moisture and property damage rom leaks.
• Do not use the Linear Steam Head with any steam generator
that is not a MrSteam steam generator. Do not locate the
steam head in any location where the steam emission zone
is near a seat, bench or any space occupied by any persons.
Failure to ollow these instructions may result in a
hazardous condition, scalding or personal injury.
Using model 104216 or any steam generator model larger
than the MX6, or or any non MrSteam brand generators
may result in an improper installation or hazardous
condition.
•Do not use the Linear Steam Head with any NON-MrSteam
equipment or devices, including but not limited to water
so teners, steam generators, etc. Using the Linear Steam
Head with any NON-MrSteam equipment or devices may
result in personal injury or, Linear Steam Head damage or
property damage.
•MrSteam steam generators Models MX4, MX5 and MX6
require two 104216 steam heads. Failure to use two steam
heads may result in steam head operation where incidental
contact by the bather with direct steam emission may occur.
Do not locate the steam head in any location where the
steam emission zone is near a seat, bench or any space
occupied by any persons. Failure to ollow these
instructions may result in a hazardous condition, scalding or
personal injury.
CAUTIONS
!
• Because the steam head and direct steam emission
are very hot, locate the steam head where incidental
contact by the user with the steam head or direct
steam emission cannot occur.
• Model 104216 Linear Steam Heads are or residential
use only. Do not use Model 104216 Linear Steam
Heads or commercial installations, Day Spa, or with
commercial steam generators. Using Model 104216
Linear Steam Heads or commercial, Day Spa or
installations with commercial steam generators or any
installation with steam sessions exceeding 60 minutes
a day, may result in Linear Steam Head damage,
property damage or personal injury.
• Do not use any Linear Steam Head in any commercial
installation or with any commercial steam generator.
Using any Linear Steam Head in a commercial
installation or with any commercial steam generator
may result in Linear Steam Head damage, property
damage or personal injury.
• Install in a horizontal orientation only. Installation in a
non-horizontal orientation may concentrate the steam
and result in excessive temperatures. Failure to install
in a horizontal orientation may result in steam head
operation where incidental contact by the bather with
direct steam emission may occur. Failure to ollow
these instructions may result in a hazardous condition,
scalding or personal injury.
• Insulate the steam head and piping as required to
reduce temperatures within the wall cavity. Do not
locate the steam head or plumbing near any materials,
including wiring, devices, or products that may be
adversely a ected by elevated temperatures. Failure
to ollow these instructions may result in the ailure o
materials, including wiring, devices, or products.
(continued on next page
CAUTION
!
100561-1 Rev 3.20.1
mr
.steam
®
Sussman-Automatic Corp® [email protected] www.mrsteam.com
43-20 34th Street, Long Island City, NY 11101 tel: 1 800 76 STEAM
9410 S. La Cienega Blvd. Inglewood CA 90301 tel: 1 800 72 STEAM

READ ME FIRST! (cont.)
Linear Steam Head®
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Installation Instructions: Model 104216
mr
.steam
®
2
NOTE: Drawings are for illustrative purposes only. Consult with quali ied designer, architect or contractor or steam room construction.
21/4”
Round
Mounting
Holes
5/8”
71/2”
Slotted
Mounting
Holes
2”
Steam
Outlet
141/8”
3/4”NPT Steam
Outlet Connection
121/8”
Figure 1
• Steambath controls eature an integral temperature
sensor. Locate the Steam Head in a location where
steam emissions will not come in direct contact with
the control (or the remote temperature sensor).
Failure to ollow these instructions may result in a
hazardous condition, scalding or personal injury.
• Use the supplied high temperature silicone sealant as
required to create a permanent moisture seal. Do not
seal the steam head with grout or any other material.
Failure to ollow these instructions may result in
moisture and property damage.
• The Linear Steam Head model 104216 must be
installed by a quali ied and licensed plumber. Failure
to use a quali ied and licensed plumber may result in
a leak within the wall cavity and cause problems
associated with leaks, moisture and property damage
rom leaks.
• DO NOT use black iron pipe or galvanized pipe or
the steam line. Use brass pipe or copper tubing only,
and in accordance with national and local plumbing
codes.
• Do not modi y or alter the steam head. Do not
cover, block or insert any product that is not a
MrSteam supplied product into the steam outlet.
Failure to ollow these instructions may result in a
leak within the wall cavity, or result in a hazardous
condition and/or personal injury.
IMPORTANT NOTES:
• See the Installation and Operation Manual provided with
the steam generator or additional important installation
and operation in ormation. I this installation and
operation manual is not available then go to
www.mrsteam.com or an online copy, or contact
MrSteam Customer or Technical Services at
800-767-8326 or 800-727-8326 or a ree copy.
• Do not disassemble the steam head. The steam head is
shipped ully assembled and requires no additional
assembly. Failure to ollow these instructions may result
in a leak within the wall cavity and cause problems
associated with leaks, moisture and property damage
rom leaks.
• Consult with supplier o acrylic, iberglass and other
non-heat resistant enclosures or elevated temperatures,
steam, and moisture compatibility. Consult with supplier
o acrylic, iberglass and other non-heat resistant
enclosures or recommended steam head locations.
• To prevent damage to property do not locate the steam
head where steam, elevated temperatures, moisture or
water can contact any products, wall sur aces, materials,
door seals, devices, electronics that are not designed
or steam, elevated temperatures, moisture or water.
• Do not use abrasive cleansers or chemicals to clean
the steam head. Use only water with mild soap and a
non-abrasive sponge. The use o abrasive cleansers or
chemicals will damage the inish on the Linear Steam
Head.
BOX CONTENTS:
• Linear Steam Head
• Silicone Sealant
• Installation Instructions
Number Steam
Generator of Linear Emission
Model Steam Heads Zone
MS90-MS400 1 18”
Super1-Super3 1 24”
MX4-MX6 2 24”

INSTALLATION STEPS
Because steam emissions are very hot, locate
the steam head where incidental contact by the bather with
direct steam emission cannot occur. Do not locate the steam
head in any location where the steam emission zone is near a
seat, bench or any space occupied by any persons. See Fig. 2
or a diagram o the steam emission zone. Failure to ollow
these instructions may result in a hazardous condition,
scalding or personal injury.
Do not install a Linear Steam Head in a tub or
acrylic/ iberglass shower enclosure. Failure to ollow these
instructions may result in a hazardous condition, scalding or
personal injury
STEP 1. Locate the steam head 6-12” above the inished
loor. Do not locate the steam head in any location where the
steam emission zone is near a seat, bench, or any space
occupied by any persons. See Fig. 2 or a diagram o the
steam emission zone.
STEP 2. Con irm proper stud spacing: The studs must have
a minimum spacing o 14-1/8” and a maximum spacing 141⁄2“.
I the stud spacing is outside the required range then shim or
otherwise reposition the studs as required.
Installing the steam head between incorrectly
spaced studs may result in damage to the steam head and
result in a leak within the wall cavity and cause property
damage.
STEP 3. Determine the location o the inished wall sur ace.
Mount the steam head between two studs using the our
slotted holes to position the steam outlet ace to be lush or
extend 1/8” rom the inished wall sur ace (see Fig. 4).
Failure to position the steam head ace to be
lush or extended 1/8” rom the inished wall sur ace may
result in a leak within the wall cavity and cause problems
associated with leaks, moisture and property damage rom
leaks.
STEP 4. Use a level to ensure the steam head is level (see
Fig. 3 ) and the steam head ace is lush or extends 1/8” rom
the inished wall sur ace. Install the our screws in the
mounting holes to secure the steam head to the studs.
STEP 5. Plumb rigid copper tubing or brass pipe rom the
steam generator to the steam head. Plumbing must not orm
traps or valleys. Thread sealant must be used as required to
ensure a leak ree joint.
Linear Steam Head®
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Installation Instructions: Model 104216
mr
.steam
®
3
NOTE: Drawings are for illustrative purposes only. Consult with quali ied designer, architect or contractor or steam room construction.
Copper Tubing
or Brass Pipe
(not provided)
Steam Outlet
Threaded
Adaptor or
Thread Plug
as required
(not provided)
Stud
Stud
Level
141/8”–141/2”
Figure 3
CAUTION
!
CAUTION
!
Steam
head
6”-12”
above
floor
STEA M
EMIS SI ON
ZONE
Steam Room
Interior
STEAM
EMIS SI ON
Figure 2
CAUTION
!
CAUTION
!

Linear Steam Head®
–
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Installation Instructions: Model 104216
mr
.steam
®
4
NOTE: Drawings are for illustrative purposes only. Consult with quali ied designer, architect or contractor or steam room construction.
• Complete steam room tile construction in ormation is available rom the Tile Council o America, Inc. by
purchasing the TCA Handbook or Ceramic Tile Installation. 864- 646-8453 or www.tileusa.com.
In ormation on marble steam room construction is available rom the Marble Institute o America www.marble-
institute.com. Failure to ollow these instructions may result in damage to tile, marble or other materials.
• Finished wall sur ace may be tile, marble, granite or other steam rated sur ace.
• MrSteam is not responsible or the steam room construction.
• Consult with quali ied designer, architect or contractor or steam room construction.
For Installation assistance please call Customer or Technical support:
East Coast 1-800-767-8326 • West Coast 1-800-727-8326
To view an installation video please go to: www.mrsteam.com
This video is or added visual assistance only. Do not install the Linear Steam Head using the video.
Use only these installation instructions or a sa e and problem ree installation.
Figure 4
• Plumbing must be installed by a quali ied and licensed
plumber. Plumbing in a manner that results in traps or
valleys in the pipe may result in a noisy or inoperable
installation.
• Plumbing without proper thread sealant may result in a
leak within the wall cavity and cause problems associated
with leaks, moisture and property damage rom leaks.
• DO NOT use black iron pipe or galvanized pipe or the
steam line. Use brass pipe or copper tubing only, and in
accordance with national and local plumbing codes.
STEP 6. Run the steam generator or a ew steam cycles to
observe and veri y that the steam head, steam head
installation and plumbing are correct and ree o leaks.
STEP 7. Insulate steam line and steam head using insulation
rated 212°F or higher. Insulate the steam head and piping as
required to reduce temperatures within the wall cavity. DO
NOT locate the steam head or plumbing near any materials,
including wiring, devices, or products that may be adversely
a ected by elevated temperatures. Failure to ollow these
instructions may result in the ailure o materials, including
wiring, devices, or products.
STEP 8. A ter the inished wall sur ace has been installed use high
temperature caulking around the steam outlet as required to make a
waterproo seal. (see Fig. 4)
STEP 9. A plastic protective ilm has been provided to protect the steam
head during installation. Remove the plastic protective ilm covering the
steam outlet to complete the installation.
CAUTIONS
!
Cement Board
Thin Set
Finished
Wall Surface
Steam Outlet Face
Silicone
Silicone
STUD
Flush to 1/8
”
