mr. steam aromasteam Instruction manual

mr
.steam
®
Feel Good In .
AromaSteam
Installation, Operation & Maintenan e Manual

mr.steam® AromaSteam Operation and Installation Instru tions
______________________________________________________________________________________________
MS Aroma
Table of Contents
Box Contents . . . . . . . . . . . . . . . . . . . . . . .3
General Installation . . . . . . . . . . . . . . . . . .3
Installation of Hoses . . . . . . . . . . . . . . . . .4
Assembly Diagram . . . . . . . . . . . . . . . . . .5
Ele tri al Wiring . . . . . . . . . . . . . . . . . . . . .6
Start-up
Initial Priming . . . . . . . . . . . . . . . . . . . . .6
Filling the Pressure Hose . . . . . . . . . . . . .6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . .7
Adjusting amount of oil delivery . . . . . . . .7
Troubleshooting . . . . . . . . . . . . . . . . . . . . .8
Te hni al Information . . . . . . . . . . . . . . . . .8
PUR 100402 Rev 5.16
mr.steam® Sussman-Automati Corporation®I hello@mrsteam. om I www.mrsteam. om
43-20 34th Street, Long Island City, NY 11101 I 9410 S. La Cienega Blvd. Inglewood CA 90301
1 800 76 STEAM FAX: [phone] I 1 800 72 STEAM FAX: [phone]
IMPORTANT NOTE: The warning
label (supplied) shall be posted in a
onspi ious lo ation next to the
steam room door.
AromaSteam
(for illustrative purposes only)
RISK OF ELECTRIC SHOCK - This pump is supplied with
agrounding ondu tor and grounding-type atta hment plug. To redu e
the risk of ele tri sho k, be ertain that it is onne ted only to a properly
grounded, grounding-type re epta le.
RISQUE DE CHOC ÉLECTRIQUE - Cette pompe est
fournie ave un ondu teur de mise à la terre et une fi he de bran hement
de type mise à la terre. Pour réduire le risque de ho éle trique, assurez
vous qu'il est onne té uniquement à une mise à la terre, à la terre prise.
• Do not use with water soluble fragran e or fragran e ontaining
emulsifiers or aldehydes. AromaSteam system damage may result.
MrSteam oils are approved for operation with this system.
• The use of any oils other than MrSteam oils may introdu e ex essive
on entration of oil into the steam room, resulting in a health hazard.
• Vapors may ause drowsiness and dizziness. Keep out of the rea h of
hildren. In ase of onta t with eyes, rinse immediately with plenty of
water and seek medi al advi e. If swallowed, rinse mouth with water
(only if the person is ons ious), seek medi al advi e immediately and
show this ontainer or label.
• Highly Flammable. Keep away from sour es of ignition–No smoking.
Keep ontainer tightly losed & in a well-ventilated pla e. This materi-
al & its ontainer must be disposed of as hazardous waste.
• Not for use in a ryli or fiberglass rooms.
• Material Safety Data Sheet (MSDS) available upon request
IMPORTANT NOTE: As you follow these instru tions, you will noti e
warning and aution symbols. This blo ked information is important for the
safe and effi ient installation and operation of this generator. These are
types of potential hazards that may o ur during installation and operation:
states a hazard may ause serious injury or death
if pre autions are not followed.
signals a situation where minor injury or produ t
damage may o ur if you do not follow instru tions.
IMPORTANT NOTE: This highlights information
that is espe ially relevant to a problem-free
installation.
WARNING
WARNING
WARNING
CAUTION
AVERTISSEMENT
This room is equipped with an aromatic oil dispensing system
Leave the room immediately if you have any adverse or
allergic reactions, including difficulty breathing or eye, nasal,
throat, or skin irritation and seek medical attention.
mr
.steam®
43-20 34th treet, Long Island City NY 11101 1-800-76 TEAM www.mrsteam.com PUR 100405 2/06
WARNING
!

mr.steam® AromaSteam Operation and Installation Instru tions
______________________________________________________________________________________________
AromaSteam System
(with integrated 6 ft. power cord,
8 ft. request cable)
Additional Items Included but Not hown:
• 2x Mounting crews and Anchors
• oft Tubing for priming with injector
BOX CONTENTS
3
1/4 x 1/2 NPT
Atomizing Nozzle
Injector
Foot Valve
Installation & Operation Manual
with Peel-off Warning Label
GENERAL INSTALLATION
Do Not alter or modify any MrSteam
produ t. Doing so may result in an inoperable or hazardous
installation and will void the warranty.
The AromaSteam system is qualified for use
with MrSteam®residential and CT steam generators ONLY.
IMPORTANT NOTE: AromaSteam is for use with AirTempo®,
iSteam®and iTempoPlus®controls only.
1. Lo ate the AromaSteam system to monitor the onsump-
tion of essential oils and for easy oil repla ement.
2. The warning sti ker provided must be pla ed in a
onspi uous lo ation near the steam room door.
3. MrSteam AromaSteam System is designed and intended
for indoor use only and is to be lo ated indoors in a dry
lean lo ation and not subje t to moisture, ondensation or
similar high humidity environments.
4. Do not install AromaSteam Systems outdoors.
5. Do not install AromaSteam Systems in a lo ation where
water ould freeze.
6. Do not install AromaSteam Systems near flammable or
orrosive materials and hemi als. Installation in areas
having high on entrations of hlorine (su h as pool
equipment room) should be avoided.
7. Atta h the AromaSteam System onto a se ure
verti al surfa e.
CAUTION
8 ft.
Pressure
Hose
This room is equipped with an aromatic oil dispensing system
Leave the room immediately if you have any adverse or
allergic reactions, including difficulty breathing or eye, nasal,
throat, or skin irritation and seek medical attention
.
mr
.steam®
43-20 34th treet, Long Island City NY 11101 1-800-76 TEAM www.mrsteam.com PUR 100405 2/06
WARNING
!
8. Provide a ess to AromaSteam System for servi ing,
and refills.
9. The system should not be installed in areas
a essible to hildren. A LOCKED ROOM IS
STRONGLY RECOMMENDED (ie: utility room)
10. Height differen e between AromaSteam System dis-
harge and 90 degree Tis to be held to a maxi-
mum 6 ft. (see page 5).
11. Do not ex eed 30 feet of tubing between the pump
head and atomizing nozzle.
12. Ensure the essential oil ontainer is pla ed on a
level surfa e.
13. Essential oil ontainer must be installed dire tly
below the pump. The maximum distan e from the
pump to the bottom of the ontainer is 4 feet.
WARNING
Warning Sti ker (Not a tual size)

mr.steam® AromaSteam Operation and Installation Instru tions
______________________________________________________________________________________________
GENERAL INSTALLATION (ont.)
Clearance to heat sources
• Do not install the AromaSteam system dire tly below or above the MrSteam
steam generator where it is subje t to heat.
• Minimum distan e between the AromaSteam system and a heat sour e (e.g. steam genera-
tor, heating system) is 1.5 ft. If this minimum distan e of 1.5 ft annot be maintained, install
a radiation plate or heat insulation between the heat sour e and AromaSteam system.
• Ambient temperature at and around the AromaSteam system should not ex eed 90˚ F.
Tubing Connections
1. Completely uns rew tightening nut from pump head (or fitting) and remove omponents
2. Assemble tubing omponents as shown in figure 1.
3. Insert tubing into tubing holder until it rea hes the bottom.
Lubri ate the ID of the tubing as required with soap to fa ilitate insertion.
To prevent damage do not use tools to tighten the nut.
Installing the 90 degree T and Atomizing Nozzle
1. For optimal results lo ate a brass 90 degree T(not provided) and atomizing
nozzle in the steam supply line within 10 feet of the steam head. If using
opper tubing for steam lines, install a female 1/2 NPT or 1/4 NPT redu ing
Tee in the steam line fa ing downward.
2. Tmust fa e downward as shown (in figure 2).
3. If a 1/2 NPT tee is used, ut off the 1/4 NPT portion of the inje tor with a ha ksaw.
4. S rew the atomizing nozzle into 90° Tfitting using teflon tape on the threads.
MPORTANT NOTE: Follow the installation instructions for the steam
pipeline in the MrSteam Steam Bath Installation and Operation Manual.
Visit www.mrsteam.com to download this document.
team Line
90˚ Tee
Figure 2
Figure 1
4
Installation of Pressure Hose to AromaSteam System
1. Insert the pressure hose through the hole of the pressure end nut and firmly
push the pressure hose onto the pressure valve.
2. S rew the pressure end nut onto the pressure valve and tighten the nut by
HAND only.
Installation of Suction Hose in Scent Container
1. Lo ate the “ ontainer ap” in luded with the bottle of oil.
2. Uns rew the ap from the MrSteam s ent ontainer and dis ard.
3. Insert the su tion hose with the open end from below through the
hole in the ontainer ap (see Fig. 3).
4. Insert the foot valve into the s ent ontainer so that the foot valve
rests on the bottom.
5. S rew the ap onto the s ent ontainer.
Open End
to Pump
Container Cap
uction Hose
Foot Valve
Tubing
Tightening Nut
Collar
Tube Holder
Figure 3
CAUTION
Thread atomizing
nozzle into Tee
Container Height
8 inches
Cut 1/4 NPT extension
off atomizing nozzle
to use 1/2 NPT threads

mr.steam® AromaSteam Operation and Installation Instru tions
______________________________________________________________________________________________
5
Installation of Suction Hose to
AromaSteam System
1. Uns rew the su tion end nut from the pump head.
2. Assemble the tubing onne tion as shown in figure
1 on page 4.
3. S rew the su tion tube tightening nut to the su -
tion side of the pump
IMPORTANT NOTE: HAND-TIGHTEN ONLY.
iSteam
Steam Line
Typical Mr.Steam
Steam Generator
Request Cable
Atomzer Nozzle
Pressure Hose
90˚ T
Suction Hose
Essential Oil Container
Pump Line Cord 120V
(grounded receptacle required)
AromaSteam
System
UTILITY
ROOM STEAM ROOM
Steam Head
MaxDistance10ft.
Max ht: 6 ft.
Max ht: 6 ft.
Typical AromaSteam Installation
FOR USE WITH AIRTEMPO®,
iSTEAM®AND iTEMPO/PLUS®
CONTROLS ONLY
Lo ate the AromaSteam system
to monitor the onsumption of
essential oils and for easy
oil repla ement.
NOTE: CABLES SHOULD
NOT CONTACT STEAM PIPE.
For illustrative Purposes Only
Pressure Hose
Repeat the su tion hose installation steps on the
pressure side of the pump.
MrSteam re ommends installing the AromaSteam
lower than the Atomizing nozzle. If the pump must be
installed higher that the atomizing nozzle a loop
should be pla ed in the pressure tubing to prevent
syphoning as required. An air
bubble should be trapped
at the top of the loop.
Pressure Tube
Pressure Tube
Tightening Nut
Priming Port Valve
Priming Port
uction Tube
Tightening Nut
uction Tube
Figure 4

mr.steam® AromaSteam Operation and Installation Instru tions
______________________________________________________________________________________________
Electrical Connection of
AromaSteam System
AromaSteam
Plug
120 VAC
Outlet
(grounded re epta le
required)
Request Cable
24 VAC to steam generator
(see below)
AromaSteam Wiring
Schematic
AromaSteam Connections
CAUTION
This AromaSteam system is fa tory wired. If the
power ord of the Aroma Steam system is damaged it must be
repla ed by the Sussman-Automati servi e department or similar-
ly qualified personnel in order to avoid an ele tri sho k hazard.
All ele tri al onne tions to be made by a li ensed, qualified ele -
tri ian. Dis onne t all power to the steam generator before
making power onne tions.
IMPORTANT NOTE: AromaSteam is for use with AirTempo
®
iSteam®and iTempoPlus®ontrols only.
1. Dis onne t all power to the MrSteam steambath generator and
remove the top over.
2. Run the request able from the AromaSteam System through
one of the kno k outs in the side of the steambath generator.
Use a strain relief bushing or grommet to prevent hafing.
3. Lo ate the two qui k onne t tabs labeled "AROMA" on the
PC board in the lo ation show.
4. Conne t the request able to the terminals. The terminals are
not polarized.
6
Injector
oft Injector Tubing
Priming Valve Knob
START-UP
Initial Priming of the Pump
1. Insure MrSteam s ent ontainer is full.
2. Insert a short pie e of soft inje tor hose onto the tip of the inje tor
(see Fig. 5).
3. Insert the open end of the inje tor hose onto the pressure valve
(see Fig. 5).
4. Open the priming valve by turning the knob ounter lo kwise 1
full revolution.
5. Draw liquid from the inje tor slowly and evenly. Continue until the
inje tor is full of liquid.
6. If you have drawn up the inje tor ompletely and no liquid is in
the inje tor, remove the inje tor hose from the pressure valve.
7. Drain inje tor. Repeat steps until the inje tor is filled.
8. Save the oil inje tor as it will be needed when new oils are used.
9. Close the priming valve ompletely by turning the knob lo kwise.
Failing to lose the valve will result in oil leaking from
the priming port.
Filling the Pressure Hose
1. Insure the AromaSteam System is primed and the s ent
ontainer is full.
2. Insert the open end of the inje tor into the pressure hose.
3. Draw liquid from the inje tor slowly and evenly.
Continue until the pressure hose if full of liquid.
Figure 5
CAUTION

mr.steam® AromaSteam Operation and Installation Instru tions
______________________________________________________________________________________________
7
OPERATION
Powering Up the Pump
IMPORTANT NOTE: This step only needs to be performed
during installation.
1. The pump needs to be turned on before it an be used
2. Press and hold the power button for 2 se onds.
The LED will turn on solid red.
PUMP LED LIGHT:
Blinking Amber Pump is OFF
Solid Red Pump is ON, aroma has not been
a tivated on in-shower ontrol
Solid Amber Pump is ON, aroma has been
a tivated on in-shower ontrol
Air Tempo®
1. Press the ON/OFF button to turn the steam generator ON.
2. Press the AROMA button, AROMA will be displayed on the
s reen when AromaSteam is on.
3. Aroma oils will automati ally be pumped into the steam
line at preset intervals.
iSteam®
1. Press the START button to turn the steam generator on.
2. In the dashboard press the AROMA button, the button
will be highlighted when AromaSteam is on.
3. Aroma oils will automati ally be pumped into the steam
line at preset intervals.
iTempoPlus®
1. Press the ON/OFF button to turn the steam generator ON.
2. Press the AROMA button, AROMA will be displayed on the
s reen when AromaSteam is on.
3. Aroma oils will automati ally be pumped into the steam
line at preset intervals.
Adjusting the Amount of Oil Delivery
The AromaSteam system has been fa tory set to deliver a suitable amount of aromati oil
into a typi al sized steam room. Do not ex eed the maximum setting. Please onta t the
MrSteam Te hni al Servi e Department before hanging this setting.
Conta t the MrSteam Te hni al Servi e Dept. at (800) 76-STEAM (East oast)
or (800) 72-STEAM (West Coast) for assistan e or additional information.
In reasing the settings may introdu e ex essive on entration of oil
into the steam room, resulting in a health hazard.
WARNING
STOP
8:19 AM
20 min. 110˚ F
User 1 User 2
AromaSteam
Button
Aromati
Setting Knob
Power Button
LED Light
AromaSteam Aromati
Setting Knob
chroma
timetemp
aroma
AromaSteam
Button
AromaSteam
Button

mr.steam® AromaSteam Operation and Installation Instru tions
______________________________________________________________________________________________
___________________________________________________________________________________________________________________________________________
2016 © Sussman-Automati Corporation I Mr.Steam and des., A Lifetime of Pleasure, AromaFlo, AudioWizard, AutoFlush, AutoSteam, Butler Pa kage, ChromaSteam, Clean Steam...Every Time, Club
Therapy, Digital 1, Express Steam, From Bathroom to Spa, HomeWizard, iButler, iGenie, iSizing, iSteam, iSteam/Plus, iSteamTV, iTempo, iTempo/Plus, Making Wellness a Way of Life, Musi Therapy,
MySteam, Spa Pa kage, Smart Sizing, Steam Genie, Steam in a Box, Steam on Demand, Steam@Home, SteamStart, SteamStop, SteamTherapy, Sussman, The Intelligent Steambath, Valet Pa kage, Virtual
Spa System, Voi e Genie and Voi e Wizard are registered trademarks of Sussman-Automati Corporation.
PUR 100402 5.16
8
TROUBLESHOOTING
TO AVOID ELECTRIC SHOCK,
DISCONNECT POWER TO PUMP BEFORE SERVICING
Metering pump does not prime
1. Che k if voltage is available.
2. Che k liquid level in s ent ontainer. Replenish liquid, if ne essary.
3. Che k for air bubbles in the su tion hose or the pump head.
To eliminate air bubbles see: Priming Pump.
4. Che k valves for ontamination. Clean valves, if ne essary.
5. Che k foot valve in ontainer for ontamination. Rinse foot valve
under lean water.
Metering pump does not inject oil into steam
room
1. Che k if voltage is available.
2. Che k liquid level in s ent ontainer. Replenish liquid if ne essary.
3. Che k for air bubbles in the su tion hose or the pump head.
To eliminate air bubbles see: Priming Pump.
4. Che k valves for ontamination. Clean valves, if ne essary.
5. Che k foot valve in ontainer for ontamination. Rinse foot valve
under lean water.
6. Che k the pressure hose for kinking or jamming. Straighten or
repla e.
7. Che k if liquid is freely flowing through the atomizing nozzle
when the metering pump is energized. Apply ompressed air
through the atomizing nozzle. Atta h the ompressed air at the
point of onne tion of the pressure hose.
8. Ensure the pump has been powered up. See page 7.
Metering pump oil delivery too much or too little
The AromaSteam system has been fa tory set to deliver
a suitable amount of aromati oil into a typi al sized steam room.
Please onta t the MrSteam Te hni al Servi e Department before
hanging this setting. See page 7 for instru tions on adjusting the
amount of oil delivery.
Conta t the MrSteam Te hni al Servi e Dept. at (800) 76-STEAM
(East oast) or (800) 72-STEAM (West Coast) for assistan e or
additional information.
Dimensions: 7.5"W x 4.5"H x 4.5"D
Weight: 5 pounds
Motor voltage 120VAC, 50/60 Hz
Current Draw 0.5 Amps
________________________________________
4.5”
7.5”
TECHNICAL SPECIFICATIONS
LIST OF SPARE PARTS
Description Part No.
Pump Head 104239
Pressure/Su tion Hose EO1-1032
( ordered by the foot )
Eu alyptus oil, 1 liter MS OIL 1
Lavender oil, 1 liter MS OIL 2
Evergreen oil, 1 liter MS OIL 3
Energizing Mint oil, 1 liter MS OIL 4
Breathe oil, 1 liter MS OIL 5
Atomizing Nozzle 104240
Oil Inje tor 103983
Foot Valve 104241
WARNING
WARRANTY: To view or download
the MrSteam Control Warranty
and register your produ t go to:
blog.mrsteam.com/wr
WARNING
