Provape Provari Radius User manual

1
Owner’s Manual
用户手册
Rev: 8.25101
Thank you for purchasing a ProVari Radius personal vaporizer.
We hope you get many years of enjoyment from this device.
非常感谢您购买 ProVari Radius 个人雾化器。
希望该设备能给您带来很多年的享受。
www.ProVape.com
Introduction
介绍
A personal vaporizer (PV) is a battery-powered device that provides inhaled doses of nicotine by way of a vaporized
solution. In addition to the nicotine delivery, this vapor also provides a flavor and physical sensation similar to that
of inhaled tobacco smoke. Vaporizers do not contain tar and have just a few ingredients compared to several
thousand found in traditional cigarettes. There is no tobacco or combustion involved in its operation. There is no ash
and no smell. Vaping is the 21st century alternative to smoking tobacco products. Just please keep in mind that
personal vaporizers are not meant to be a smoking cessation device. This device can also be used without nicotine.
个人雾化器（PV）是一种通过电池供电来雾化液体的方式提供可吸入尼古丁的设备。这种烟雾不仅含有尼
古丁，还具有一种类似烟草的口味和体验。雾化器不含焦油，和含上千种成分的传统香烟相比，雾化器只

2
含有几种确定的成分。它在使用过程中不涉及烟草或燃烧，没有烟灰，没有烟的异味。 电子雾化器是一种
替代烟草的 21 世纪产品。请注意，个人雾化器不是一种戒烟设备。使用这种设备时，也可以不用尼古丁。
The ProVari Radius featuring the ProVape Radius chip is a powerful microprocessor controlled PV that lets you
adjust and fine tune the device to your exact preferences by adjusting the wattage, along with a number of other
parameters which we will explain later in this manual. The ProVari Radius uses the latest technology to bring you
some new and exciting features. The ProVari Radius has regulated power output which keeps the wattage the same
with each puff regardless of your remaining battery power. As the battery drains, the device will keep the power
output consistent, giving you the perfect vapor all day long. Now you can dial-in the perfect settings for your tank or
atomizer and e-liquid!
ProVari Radius 拥有一个功能强大的微处理器，叫 ProVape 原子芯片。这可以让用户通过对功率以及其它参数的调节
对这款设备进行精细设置，满足个人的喜好。我们将在本手册的后面解释如何调节这些参数。ProVari Radius 采用了最
新的技术，给您带来了一些新的和令人兴奋的功能。ProVari Radius 具有调节功率输出的功能，无论剩余电量是多少能
够让您的每口烟都保持恒定的电压或功率。随着电池的消耗，设备的功率输出会保持不变，以确保您整天都可以享受完
美的烟雾。现在您就可以对烟油仓、雾化器及电子烟油进行设置，使之达到完美的状态！
(Please note that due to ongoing software updates, improvements and changes based on customer
feedback, some of the features or screen images shown in this manual may be slightly different)
（请注意，由于软件会根据客户的反馈不断更新、改进和调整，本手册中所示的某些功能或屏幕图像可能会略有不同）
Table of Contents
Introduction ................................................................. 1
Warnings ................................................................... 4
ProVari Radius Features ................................................................................................. 4
ProVari Radius Feature Details ................................................ 8
ProVari Radius Components ................................................. 13
ProVari Radius Adapter ..................................................... 15
Batteries ................................................................... 15
Charging a Battery Using a Standard Battery Charger ........................... 16
Charging a Battery Using the Built-in Charger .................................. 16
Inserting a Battery .......................................................... 17
Menu Flow Chart ........................................................... 19
Push Buttons ............................................................... 20
Screen Layout .............................................................. 21
Check All/Status Screen ..................................................... 22
Warning System ............................................................ 23
Menu Options and Functions ................................................. 25
Money Saved Counter - Cigarette Counter ..................................... 38
Error Messages and Fixes ................................................... 40

3
Error Message Details ....................................................... 40
Radius Energy Gauge ....................................................... 42
Additional Warnings........................................................................................................29
目录
介绍........................................................................ 1
警告........................................................................ 4
ProVari Radius 功能.......................................................... 4
ProVari Radius 功能详情...................................................... 8
ProVari Radius 结构......................................................... 13
ProVari Radius 适配器....................................................... 15
电池 ............................................................................................................................... 15
使用标准充电器充电 ...................................................................................................... 16
使用内置充电器充电......................................................... 16
安装电池................................................................... 17
菜单流程图................................................................. 19
按钮....................................................................... 20
屏幕布局................................................................... 21
检查全部/状态屏幕 .......................................................... 22
警告系统................................................................... 23
菜单选项及功能............................................................. 25
省钱计数 - 香烟计数 ......................................................... 38
错误信息及修复措施......................................................... 40
错误信息详情............................................................... 40
Radius 能量计 .............................................................. 42
其它警告 ..................................................................29

4
Warnings:
警告
●Never abuse your ProVari Radius. Even though it’s durable, you can do damage by dropping it.
切勿滥用 ProVari Radius。即使它是金属做的，掉到地上也会受到损坏。
●Have your ProVari repaired by ProVape. Do not attempt to repair the unit yourself as damage or
personal injury can occur. Any repairs done outside of ProVape will void the warranty.
请让 ProVape 来维修您的 ProVari。不要试图自己修理，否则可能会造成设备损坏或人身伤害。任何不经
过ProVape 的维修将导致保修条款失效。
●Do not remove the circuit board. Doing so will void your warranty.
请勿将电路板拆下。否则会导致保修条款失效。
●Remove the battery from the ProVari Radius if you plan to store it for long periods of time.
如需长时间储存，要从 Provari Radius 中取出电池。
●The ProVari Radius operates on a single battery. NEVER stack two batteries or use batteries that are
not recommended for use in the ProVari Radius. Never use magnets on your batteries. This is very
dangerous.
Provari Radius 工作只需一节电池。不要将两个电池串联或使用非推荐电池。永远不要让磁铁接触电池，否
则很危险。
●ProVape will not be responsible for damaged atomizers or tanks. Driving them with too much power for
too long or running them dry can burn them out. We recommend you start with a low wattage setting and
work your way up until you find the right power setting for your atomizer/tank.
Provape 对雾化器或烟油仓的损坏不负责任。过高功率下长时间工作或烧干都可以将它们烧坏。我们建议
刚开始使用时，采用一个较低的瓦数设置，然后才逐步提高功率直到找到适合您雾化器/烟油仓的设置。
●NEVER use primary or non-rechargeable batteries in this device. Only use recommended high drain
rechargeable batteries. If you are unsure about which batteries to use, please contact us or purchase
your batteries from www.ProVape.com to ensure you use the correct cells. ProVape is not responsible for
any kind of battery failure including misuse, overcharging cells or using a damaged cell. The ProVari
Radius is a single battery device and only uses 1 rechargeable 18650 battery.
永远不要在此设备中使用一次性电池或不可充电电池，只使用推荐的高放电充电电池。如果您不确定哪些
电池可以使用，请联系我们，或从 www.ProVape.com 购买电池以确保您使用正确的电池。ProVape 对任
何电池故障不承担责任，这包括误用、过度充电或使用损坏的电池。ProVari Radius 是只需要一节电池的
设备，只需使用一节可充电的 18650 电池。
●Keep your ProVari Radius away from sources of excessive heat.
请让您的 ProVari Radius 远离过度的热源。
●Keep this device and all nicotine-related products out of reach of children and animals. Never drink the
nicotine fluid. Never leave bottles of E-liquid out where children can access them.
请将本设备和所有尼古丁相关产品置于儿童和动物不可接触的地方。永远不要喝尼古丁液体。不要将装有
烟油的瓶子放在小孩可以接触到的地方。

5
●ALWAYS store your batteries in a plastic battery case. Never put batteries in your purse, pocket or
other locations where coins, keys and other metal objects can touch together and cause a short. This
could cause the battery to catch fire.
始终将电池存储在塑料电池盒里。切勿将电池放在您的钱包，口袋或其它有硬币、钥匙等金属物品的地方，
否则可能会发生短路，导致电池起火。
●If a battery deforms, begins leaking or smells funny, dispose of it properly. Wash your hands after
handling leaky batteries. Do not get the battery fluid in your eyes! If you do, seek medical attention
immediately.
如果电池发生变形，泄漏或发出奇怪的气味，要将其妥善处理。如果触摸了泄漏的电池，要洗手。不要让
电池液体溅入眼里，如果不慎溅入眼里，要立即就医。
●Never use your ProVari Radius without an atomizer. Do not connect to a volt meter without a resistive
load. High voltages without a resistance can damage the device and will void your warranty.
永远不要在没有安装雾化器的时候使用 ProVari Radius。不可在无阻性负载的情况下接到电压表； 无电阻
情况下，高压会损坏设备并导致保修条款失效。
Do not pour alcohol into the ProVari Radius. This can damage the display and will void the
warranty. If you have any problems, please contact our customer service team for
assistance: https://provape.zendesk.com/home
不要将酒精泼到 ProVari Radius 里，否则会损坏显示屏，并导致保修失效。 如果您有任何问题，
请联系我们的客户服务团队寻求帮助： https://provape.zendesk.com/home

6
ProVari Radius Features
ProVari Radius 功能
●The ProVari Radius wattage can be adjusted from 3 – 40* in 0.2 watt increments.
ProVari Radius 可以 0.2 的增量在 3-40*瓦特范围内调节功率。
●Flat top design provides a clean hybrid look with the latest tanks.
平顶设计加上最新的烟油仓具有整洁的混合式风格。
●Self-adjusting center contact pin ensures maximum compatibility with tanks and atomizers.
自调节中心的接触柱确保与烟油仓和雾化器的最大兼容。
●The new P3 thread is a unique top connection which allows you to adapt multiple tanks including 510,
Ego and P3 threaded tanks. As new tank connections become available, the Radius will be able to adapt
with screw-in adapters. Ego style adapters will be sold separately. As new tanks are developed with the
P3 thread, they can be utilized, providing a clean hybrid look. 510 connection included.
新的 P3 接口采用了一种独特的顶部连接，可以适配多种烟油仓：510，Ego 和P3。如果有新的烟油仓接
口问世，Radius 能够通过旋入式适配器与之连接。Ego 款适配器单独有售。如果新的烟油仓具有 P3 接口，
它们就可以组合在一起，形成整洁的混合式风格。 510 接口包括在内。
●Built-in sealed OLED display with scrolling icon-based graphics allows you to visually adjust your
settings.
内置密封的 OLED 显示屏具有滚动的图标，方便您调节设置。
●Three button design allows you to quickly adjust your power settings with the + / - buttons.
三个按键的设计让您能够通过+/-按键快速地调节功率设置。
●Each device has a unique eighteen-digit serial number.
每个设备都有唯一的 18 位序列号。
●A translucent seven color lighted push button acts as a low battery alert and allows you to select from
seven color choices when the button is pressed. There is also a random and disco option which rotates
through all seven colors each time you press the button.
半透明的七色发光按钮在低电量时会发出警告。您可以在七种颜色之中选择一种作为按钮按下显示的颜色。
还有一种随机和迪斯科模式在每次按下按钮时轮换着显示不同的颜色。
●On/Off mode allows you to shut the unit off completely.
开/关模式（On/Off）让您可以完全关闭该设备。
●Safety cutoff turns off the unit if the button is held down for too long.
安全切断功能会在按钮被长时间按下时关闭设备。
●HotShot™ Boost mode allows you to get more vapor with a short power boost with each puff. This
setting is adjustable allowing you to dial-in your favorite boost time setting.
HotShot™增强模式在每吸一口烟时暂时提高功率，让您获得更多的烟雾。此设置是可调节的，可以让您设
置最喜欢的增强持续时间。
●Scrolling OTS (Onboard Troubleshooting System) keeps the user informed of any problems and how to
resolve them with clear instructions.
滚动 OTS（板载故障诊断系统）让用户知道设备发生的任何故障，以及如何解决这些故障的明确指示。

7
●Sub-ohm capability sets the limit by amperage. You can use .3, .4, .5 ohm tanks but you will be limited
to 9.5 amps. At .5 ohms you can power the unit to a full 40 watts.
低电阻功能由电流来决定上限。您可以使用 0.3、0.4 或 0.5 的烟油仓，但是电流的上限是 9.5A。0.5 欧时，
设备的功率最高可达 40 瓦特。
●Amperage limit of up to 9.5 amps * will protect against over-current situations.
高达 9.5 安培*的电流上限可以预防过流的情况。
●Battery gauge tells you how much energy is available to the atomizer.
电池电量表显示可供雾化器使用的剩余电量。
●Smart safety features provide the highest levels of safety available on any device in the world.
If you press the button and can vape, the device is safe!
智能安全功能提供了世界上任何设备所能够拥有的最高级别安全措施。如果您按下按钮就可以吞云吐雾，
那它就是安全的！
●Thermal monitoring shuts the device off if it detects a high temperature condition in either the device or
the battery.
温度监控如果检测到设备或电池温度过高就会关闭该设备。
●Left & right-handed mode allows the user to select which way the display reads.
左/右手模式允许您调整显示的方向。
●Check All mode allows the user to see all their critical settings at a quick glance with one button press
(adjustable setting).
检查全部模式让用户在按一下按钮后就可以快速了解所有的关键设置（可调设置）。
●Save profile. Save all of your favorite settings into 5 available memory slots for quick recall. Your
settings will stay intact even if your battery is removed and/or the unit is updated.
保存配置文件 - 将您喜爱的设置保存在 5个可用的内存插槽，以便快速调用。即使更换电池或设备更新也
不会影响你的配置文件。
●Scroll speed adjust allows the user to select the speed of the scrolling menu.
滚动速度调节允许用户选择菜单滚动的速度。
●OLED brightness adjustment lets you vary the display intensity.
OLED 亮度调节可以让您调节显示的亮度。
●Multi-button combinations allow for shortcuts. Holding all three buttons down for three seconds turns the
device on and off. Holding the two small buttons down for three seconds locks or unlocks the power
adjustment.
多按钮组合构成快捷键。一直按下所有三个按钮三秒钟可以打开或关闭设备。按下两个小按钮三秒钟可以
锁定或解锁功率调节。
●Exclusive reliable and safe electronic switch is designed for long life.
独家的可靠安全电子开关使用寿命长。
●Battery Monitoring shuts the unit off once a battery has reached end-of-charge.
电池监控会在电池耗尽的时候自动关闭设备。
●Reverse battery protection keeps the circuit safe if the battery is accidentally installed backwards.
反向电池保护可以在电池不小心装反的情况下保护电路的安全。

8
●Built-in USB quick charging. Plug in to any USB port to top off your battery with the built-in quick
charger. This USB port is also used to update the firmware when new features are available.
内置 USB 快速充电。插到任一 USB 接口即可通过内置的充电器充电。新功能出来后，也可以通过这个
USB 接口来更新固件
●The Provari Radius is compatible with flat top batteries.
Provari Radius 与平顶电池兼容。
●No compromise components ensures a high quality and reliable device.
无妥协的零件确保了设备的高品质和可靠性。
●Proudly made in the USA.
很自豪地在美国原装生产。
●1 Year Warranty: Excludes accessories like batteries and atomizers.
1年保修：不包括配件，如电池和雾化器等。
●3.4” L x 1.7” W x 1.0" D without atomizer.
3.4 英寸长 x 1.7 英寸宽 x1.0 英寸直径，不包括雾化器。
* Limits - The Provari Radius will go down to .5 ohms and up to 40 watts. It's also capable of running
lower ohm tanks but the unit is then limited to 9.5 amps. As an example, you could run .4 ohms up to 36
watts.
*限制 - Provari Radius 可以低至 0.5 欧姆和高至 40 瓦特。它也可以使用更低阻值的烟油仓，这样的话设备
的上限是 9.5 安培。例如，如果阻值是 0.4 欧姆，功率上限是 36 瓦特。
If the Radius detects you are using a battery that cannot handle the power output, it will limit the output to
something that is safe. Please note that due to safety being our number one concern, there are limits set
to prevent a dangerous situation.
如果 Radius 检测到电池不能达到功率输出设定，它会将输出限制在安全的范围。请注意，安全是我们首要
关注的，各种限制是用来预防危险情况的。
ProVari Radius Feature Details
ProVari Radius 功能详情
●The ProVari Radius wattage can be adjusted from 3 – 40 * in 0.2 watt increments. This feature allows
the user to select their power level in wattage.
ProVari Radius 可按照 0.2 瓦的增量在 3 - 40 *范围内调节功率值。这个功能可以让用户选择合适自己的功
率水平。
Note: The lower the resistance on your atomizer and the higher the power setting, the more
energy you are going to consume. This will likely reduce your battery run time.
注意：雾化器的阻值越低和功率设置越高，能量消耗就越高。电池的使用时间就会缩短。
●Built-in OLED display with scrolling icons allows you to visually adjust your settings. This feature brings
a full graphic experience to the user allowing you to adjust your settings with an innovative scrolling
menu. Later on in this manual we will explain all the different options. While it looks complicated to use,
it’s actually fun and easy. After spending a little time with the new ProVari Radius menu, you will find it’s

9
easy to make changes and adjust your settings to customize the device to your liking.
内置 OLED 显示采用滚动图标，以便您直观地调节设置。这个创新的滚动菜单方便用户进行设置，给用户
带来完整的图形体验。在本手册的后面，我们会解释所有不同的选项。虽然它看起来有点复杂，但实际上
是简单有趣的。花点时间熟悉 ProVari Radius 的新菜单，您就会发现很容易根据您的喜好对这个设备的设
置进行修改和调整。
●Three button design. With the additional two buttons, you can quickly adjust your power level up or
down using these dedicated controls. You can also lock and unlock the device by holding the + and -
buttons down for three seconds, or if you hold all three buttons down together for three seconds, it will
turn the device on/off.
三个按钮设计: 额外增加了两个按钮，您可以利用它们快速地调节功率水平。也可以通过同时按下+和-按钮
三秒钟来锁住或解锁设备。或者可以将三个按钮同时按下三秒钟来开启或关闭该设备。
●The translucent seven color lighted push button allows you to select from seven color choices when the
button is pressed. In the menu, there is an option where you can select from seven different colors for the
lighted push button: red, green, blue, aqua, yellow, pink or white. There are also two random options so
every time you press the button, the color changes. When you press the button to heat up the atomizer,
the button will glow in the color you select. When the battery is depleted and needs to be recharged, the
light will flash red. This red flashing LED color cannot be changed but as soon as you charge your
battery, this will no longer flash.
半透明的七色发光按钮让您可以在七种颜色中选择一种作为按钮按下显示的颜色。菜单中有一个选项可以
让您从七种不同颜色中进行选择：红色，绿色、蓝色、蓝绿色，黄色，粉红色或白色。另外，还有两个随
机选项可以让您在每次按下按钮时显示不同的颜色。当您按下按钮来加热雾化器时，按钮会亮起您选择的
颜色。当电池耗尽需要充电时，指示灯会闪烁红色。这种情况下红色的颜色是不能改变得。但是当您开始
充电时，它就不再闪烁了。
●On/Off Mode allows you to shut the unit off completely. This feature is helpful for when you want to
store the device and don’t want it to accidentally turn on while it’s in your pocket or purse. Anytime a new
battery is installed, the device will default to ON mode even if the device was previously turned off.
On/Off（开/关）模式可让您可以完全关闭设备。当您想存放设备时，不希望它在您的口袋或钱包里不小心
打开，该功能就很有用了。每次安装新电池都会让设备恢复到默认模式-开(ON)，即使该设备先前是处于关
闭状态。
●The safety cutoff turns off the unit if the button is held down for too long. This safety feature ensures
that the device automatically shuts down if it detects the button is being held down.
安全切断功能可以在按钮长时间按下的情况下关闭设备。这个安全功能可以确保按钮被按下时设备可以自
动关闭。
●HotShot ® Boost mode allows you to briefly pre-heat your coil and get more vapor with each puff,
removing the need to take pre-puffs. This setting is adjustable, allowing you to dial-in your favorite boost
time setting. Boost mode is useful for those who want to heat up the atomizer faster. With Boost mode
turned on, the atomizer will get a boost of power for a short period of time and then the power will drop
down to your set power. For example, if you set your wattage to 10 watts and then turn on the boost
mode to 1, by pressing the button, the device will boost the power for the first .25 seconds and then it will
drop it down to 10 watts. Increasing the boost level to 2, 3, 4 or 5 will increase the amount of time the
device boosts the power before it drops down to your selected 10 watts. Note that turning the ProVari
Radius up to max wattage and boosting up to 5 will not exceed the maximum output of the unit which is
up to 40 watts. Boost works up to 35 watts, but anything over 35 watts will only boost to a max of 40 watts
for the selected time.
HotShot®增强模式通过短暂预热线圈让您吸的每一口获得更多的烟雾。此设置是可调节的，您可以设置最
喜爱的增强时间。增强模式对那些想要更快加热雾化器的人是有帮助的。增强模式开启时，雾化器的能量
会短暂地升高，然后会下降到正常值。例如，如果您将功率设置在 10 瓦特，打开增强模式 1，按下按钮后，
在刚开始的 0.25 秒内设备的能量会增加，然后回到 10 瓦特。随着增强模式升级到 2、3、4或5等级，该

10
设备能量升高的持续时间会相应的延长然后下降到设定的 10 瓦特。需要注意的是调高 ProVari Radius 的功
率至最大瓦数并将增强模式设为 5级也不会超过设备的最大输出功率 40 瓦特。增强模式可以到达 35 瓦特，
如果设置是在 35 瓦特以上，增强模式最高只能到 40 瓦特。
Boost 1 - .25 seconds
Boost 2 – .50 seconds
Boost 3 – .75 seconds
Boost 4 – 1.00 seconds
Boost 5 – 1.25 seconds
增强 1 - 0.25 秒
增强 2 - 0.50 秒
增强 3 - 0.75 秒
增强 4 - 1.00 秒
增强 5 - 1.25 秒
●The OTS keeps the user informed if there is a problem with the unit and instructs you on how to resolve
the issue with clear instructions. If there is a problem detected, the ProVari Radius will display the error on
the screen along with a recommended fix.
OTS（板载故障诊断系统）让用户知道设备有什么故障以及解决故障的明确指示。如果检测到故障，
ProVari Radius 会在屏幕上显示故障代码和维修建议。
●The battery gauge tells you how much energy is available to the atomizer. This new approach is a little
different than a typical battery percentage meter. Most percentage meters, like on your cell phone, “count
down” so the battery level is always going down until you reach 0%. The ProVari Radius works more like
an average mileage calculator on a car. As you speed up (or raise your power level), the miles per gallon
will go down because you are using more fuel. As you slow down (lower your power level), the miles per
gallon go up. This is a much more accurate way of telling the user how much energy is left in the battery
for the atomizer to use. This number changes based on the power level you have the Radius set to along
with your style of vaping. You will notice that this percentage will adjust as you change settings and it’s
perfectly normal for it to go back up as the battery recovers between uses. When you first insert your
battery, you will see two question marks: ??. This simply indicates the Radius is evaluating the battery
and after 1-2 puffs, it will update the status of the battery. When the battery runs out, the device will alert
you with an “Empty” alert on the screen and the LED will flash red. At this time, recharge the battery.
电池里程计告诉您还有多少能量可以供雾化器使用。这种新方法与典型的电池百分比计量有些不同。多数
的百分比计，比如手机的，是以“倒计时”的方式记录，因此电池水平会一直下降到 0％。ProVari Radius
的工作方式更像是汽车里常见的里程计。当您加速时（或提高功率水平），每加仑英里数将会下降，因为
您要使用更多的燃料。当您慢下来时（降低功率水平），每加仑英里数会增加。这种方法能更准确地告诉
用户电池里还剩多少可供雾化器使用的能量。这个值会根据 Radius 功率水平以及吸烟方式的变化而有所变
化。您会注意到当您更改设置时，这个值会有相应的变化。并且电池在使用间隔期间会恢复从而导致这个
值上升。这也是完全正常的。当您第一次插入电池时，会看到两个问号：??。这只不过表示 Radius 正在评
估这个电池。吸了 1 - 2 口烟后，它会更新电池的状态。当电池耗尽时，设备将在屏幕上显示“Empty”
（耗尽）来提示您，并且 LED 会显示红色。此时要给电池充电。
●Smart safety features built-in provide the highest level of safety available. Our primary mission is safety.
内置智能安全功能提供了最高水平的保护措施。我们的首要任务是确保安全。
●The Amperage limiting system protects against over-current situations. The ProVari Radius is capable
of outputting up to 9.5 amps. If you want to use the ProVari Radius at maximum power, you will need to
ensure you use the approved batteries sold by ProVape or use the battery that came with your device. If
you install a battery that cannot safely handle the full power output, the ProVari Radius will not allow the
device to work at those levels and the power limit will be reduced. Our number one mission is safety. If

11
you use a subpar battery that can be damaged or if that battery is not capable of handling that kind of
output power, the ProVari will prevent damage to the device and the user. Please check with our
Customer Service team for recommendations on batteries. We are always testing new cells and looking
for a better battery to suggest to our customers.
电流限制系统防止过流的情况。ProVari Radius 的输出可以高达 9.5 安培。如果要将 ProVari Radius 开到
最大功率，您需要确保使用的电池是在 ProVape 处购买的合适电池或是设备自带的电池。如果您安装的电
池不能安全地胜任满功率输出，ProVari Radius 会限制设备的功率工作范围，功率上限会下调。我们的首
要任务是确保安全。如果您使用一个质量欠佳、容易损坏或不能承受高功率输出的电池， ProVari 会检测
到并防止对设备和用户伤害的发生。请和我们的客户服务团队联系以了解推荐的电池。我们一直在测试新
的电池，以便给客户提供更好的推荐选择。
●Thermal monitoring shuts the device off if it detects a high temperature condition in either the device or
the battery. If the ProVari Radius detects that the internal temperature is reaching a dangerous level, it
will turn off the device and internal charger. Then it will alert you on the screen that you need to remove
the battery and let the device cool down before using it again.
温度监控在检测到设备或电池高温时会关闭设备。ProVari Radius 一旦检测到内部温度达到一个危险的水
平，它会关闭设备和内置充电器。然后在屏幕上提醒您取出电池，让设备降温后才能重新使用。
●Left & right-handed mode allows the user to select which way the display reads. This cool new feature
allows the user to select if they want to flip the screen for left or right-handed operation.
左/右手模式允许用户调整显示屏的朝向。这个酷的功能可以让用户根据左/右手使用习惯来翻转屏幕。
●Check All mode allows the user to see all their critical settings at a quick glance (adjustable settings).
The Check All feature shows an at-a-glance screen when you press the button once. This shows you the
remaining power left in the battery, the current selected mode and your current power level. You will also
get a resistance reading on the installed atomizer. If the atomizer is not installed or there is a problem
with the atomizer, you will get an OP reading meaning OPEN. The device does not see the atomizer
installed when this appears. Try changing out the coil or atomizer and try again. The check all menu can
be turned off and you can also adjust the amount of time it appears on your screen every time you press
the button once. See below for how to change these settings.
检查所有模式允许用户快速浏览到他们所有的关键设置（可调节设置）。检查所有功能在您按一下按钮后
会显示一个一目了然的屏幕：电池的剩余电量，当前模式以及与当前的功率水平。您也将看到雾化器的阻
值读数。如果未安装雾化器或雾化器出了问题，您会得到一个 OP 读数（OPEN 敞开）。当设备检测不到
雾化器时，就会显示这个读数。可以尝试更换线圈或雾化器后再试。检查所有菜单可以设置成关闭，或选
择按下按钮后屏幕显示的持续时间。请参阅下面内容以了解如何调整这些设置。
●Save profile. Save all of your favorite settings into 5 available memory slots for quick recall. The Save
and Recall option is a unique new feature which allows you to setup the device with your favorite settings
and then save them for easy recall later. While the device will always remember your settings, even when
changing batteries, the Save and Recall allows you to have lots of different settings for easy recall. Let’s
say you have a vanilla flavored fluid you like at 9 watts and you want the LED color to be white when
using this setup. You would simply setup the ProVari Radius with all these settings and then go into the
menu and select SAV to profile 1. Now let’s say you like a cinnamon flavored fluid at 9.6 watts and want a
red LED. You would setup those parameters and then go to the SAV to profile 2 in the menu. Now that
you have two profiles saved, you can simply go to the recall menu and select which profile you want to
load. This will display all your preferred settings quickly.
保存配置文件 - 有5个可用内存插槽用来保存您所喜爱的设置，以便快速调用。保存和调用选项是一项独
特的新功能，它允许您保存最喜爱的设置，方便以后调用。该设备会一直保存您的设置，即使更换电池后。
保存和调用让您可以保存很多不同的设置以方便调用。比方说，您在用香草味的烟油时喜欢选择 9瓦的功
率和白色的 LED，您只需在 ProVari 设置好后进入菜单，选择 SAV 保存到配置文件 1。另外，假设在用肉
桂味的烟油时您喜欢 9.6 瓦的功率和红色 LED。您设置好这些参数后，SAV 保存到配置文件 2。现在有了
两个配置文件，您就可以简单地到调用菜单选择要加载的配置文件。这样会快速地显示您喜欢的设置。

12
●Scroll speed adjust allows the user to select the speed of the scrolling menu. The default scroll speed is
set to 2. Once you become familiar with the menu system, you may find that the default speed is too slow.
When you are ready to increase the speed at which the menu items go by, you can access the scroll
speed menu to change this speed. We recommend going to 3 and seeing how that works for you before
turning it all the way up to 5.
滚动速度调节允许用户选择菜单滚动的速度。默认的滚动速度为 2。一旦您熟悉了菜单系统，您可能会觉
得默认速度太慢。当您想要提高菜单的速度时，可以通过滚动速度菜单来进行调整。我们建议先设置成 3，
先看看是否合适，然后再调到 5.
●The OLED brightness adjustment allows you to adjust the brightness of the display. Note that with
OLED technology, if you set the brightness all the way to high, the display won’t last as long as if it's
turned down. While we expect you to get many years of enjoyment out of the ProVari Radius, this setting
can affect the life of the internal display.
OLED 的亮度调节可以调整显示屏的亮度。需要注意的是如果亮度调到最高，显示屏寿命的持续时间会比
低亮度的短。虽然我们希望 ProVari Radius 能够给您带来很多年的享受，高亮度可能会影响内置显示屏的
寿命。
●Reverse battery protection keeps the circuit safe if the battery is accidentally installed backwards. The
ProVari Radius has a built-in reverse battery protection. If you install the battery backwards, it will not turn
on. Simply install the battery properly to get power. The Radius is compatible with flat top batteries.
反向电池保护能够在电池不小心装反的情况下保障电路的安全。ProVari Radius 具有内置的反向电池保护
功能。如果电池装反了，设备不会开启。正确地安装电池才能获得电源。ProVari Radius 与平顶电池兼容。

13
ProVari Radius Components
ProVari Radius 结构
Tanks, cartomizers and atomizers screw into the top plate (1).
Make sure you load these devices with your fluid of choice before attempting to use the Radius.
烟油仓，雾化烟弹和雾化器拧入前盖（1）。
在使用 Radius 前，确认设备里已经添加了您选中的烟油。
The top plate (1) is permanently attached to the device. Do not attempt to remove it.
前盖（1）是永久固定到设备上的。不要试图将其拆开
The main Button (2) activates the heating element inside the tank which creates the vapor.
This button is also used to change the user settings on the ProVari Radius. The two smaller buttons are
used to change power settings. There are some shortcuts to turning the device on/off and locking the
adjustment of power using these smaller buttons. We will review these later in this manual.
主按钮（2）激活烟油仓内的加热元件来产生烟雾。
该按钮也用于调节 ProVari Radius 的用户设置。两个小按钮是用来改变电源设置的。关闭/开启设备和锁定/
解锁的快捷键组合都要用到这两个小按钮。在后面的篇章里有详细描述。
Main Body (3)
主体（3）
The End Plate (4) is removed to install the battery. The Radius was designed to be charged and updated
through the Micro-USB port (7). Should you ever need to change the battery, it is accessed by removing
the End Plate.
拆开后盖（4）后放置电池。
要小心避免将后盖螺纹错扣拧进烟管里。Radius 是可以通过微 USB 接口（7）来充电和更新的。如果需要
充电，需要拆开后盖。
Refer to the Battery instructions for more information about charging and installing a battery.
请参考电池操作指南了解如何充电和安装电池的具体信息。
The Window (5) shows the Wattage settings, battery power and other modes as well as error codes in the
event of a malfunction.
窗口（5）显示电瓦数设置、电池能量、其它模式以及发生故障时的错误代码。
The bottom plate is held in place with two thumb screws
(6). To access the battery, remove these two screws
and you can replace the battery when needed. Never
tighten the thumb screws too tight when installing.
底部是由两个拇指螺钉（6）固定住的。如果要更换电池，
拆下这两只螺钉就可以了。安装时永远不要将螺钉拧得太
紧。

14
USB Charging and PC software updates (7) This MicroUSB port is used to charge your device and
update the internal software as new updates are available.
USB 充电和 PC 软件更新（7）：这个微 USB 端口是用来充电和更新可用的内部软件的。

15
ProVari Radius Adapter
ProVari Radius 适配器
The ProVari Radius features a new standardized
thread (P3 thread) which allows the user to easily
switch between 510-style threads, Ego-type threads
and any new hardware equipped with properly
designed P3 threads. On the top of the 510 thread we
have added coin slots so you can tighten the
connector using a penny or dime. It's best to tighten
this connector so it does not come off when you
remove your tank.
ProVari Radius 的特色是采用了新的标准接口（P3 接
口），用户可以轻松地在 510 款，Ego 款以及任何有
P3 接口的新配件之间切换。我们在 510 接口顶部增加
了硬币插槽，这样您可以用硬币来拧紧接口。连接口最
好适当拧紧，以防止在换烟油仓时脱落。
Not only is the P3 thread stronger and more robust than most other attachment systems available, it also
features specially designed adapters to allow the use of virtually any atomizer, tank or cartomizer
available on the market today. By setting a new thread standard with the P3, future innovations can be
adapted for use on the Provari as well!
这个 P3 接口不仅比市场上其它附着系统更结实、更可靠，它还能通过专门设计的适配器接到市面上几乎所
有的雾化器，烟油仓或雾化烟弹。 通P3 这个新的接口标准，未来的新发明也可连接到 Provari 上使用了！
Batteries
电池
We recommend you only use IMR high drain batteries in this device. This will give you the full range of
output power needed to use the device. Only use approved batteries. Always feel free to contact us if you
are not sure which batteries to use. To ensure you get the correct batteries, you should always purchase
them from an Authorized ProVape dealer or online at www.ProVape.com. The ProVari Radius has the
ability to detect what type of battery you have inserted and if that battery is capable of providing adequate
power to the unit. If you use a poor quality battery, the ProVari Radius will reduce the output power to
match what the battery is capable of safely providing.
我们建议在这个设备上只使用 IMR 高放电电池。这样您可以获得该设备输出功率的全部范围。只使用被核
准的电池。如果您不能确定该使用哪种电池，请随时与我们联系。为了确保您得到正确的电池，请到
ProVape 授权的经销商或这个网站购买 www.ProVape.com。ProVari Radius 能够检测出您插入的电池类

16
型，并能够判断出该电池是否能够提供足够的功率来驱动设备。如果您的电池质量不好，ProVari Radius
会根据电池的安全范围降低功率输出。
The ProVari Radius operates on a single battery. Never stack two batteries.
Never use batteries that are not recommended for use in the ProVari Radius.
Never use magnets on your batteries as this is very dangerous.
ProVari Radius 的使用只需要一节电池。切勿串联两节电池。
切勿使用未经推荐在 ProVari Radius 上使用的电池。
切勿让电池靠近磁铁，否则会非常危险。
Charging a Battery Using a Standard Battery Charger
使用标准充电器充电
Plug the charger unit into an appropriate power supply.
将充电器插入合适的电源。
Insert a battery into the charger and make sure you put the battery in the correct direction.
将电池插入充电器，并确保电池的方向正确。
Align the positive (+) end of the battery with the positive (+) mark on the charger.
将电池的正极（+）与充电器正（+）极标记对齐。
The LED on the charger will glow red when the batteries are charging.
电池正在充电时，充电器的 LED 指示灯会发红光。
The LED on the charger will glow green when the batteries are charged.
(This could vary depending on the charger that you purchased)
电池充满后，充电器的 LED 指示灯会发绿光。
（根据您所购买充电器的不同，可能会有些变化）
Do not attempt to charge other types of batteries in the battery charger.
The ProVari uses a special kind of battery. Only use approved rechargeable cells.
NEVER use alkaline batteries and never try to charge an alkaline battery.
不要尝试用充电器对其它类型的电池充电。
ProVari 采用的是一种特殊电池。只使用获得批准的充电电池。
永远不要使用碱性电池，永远不要对碱性电池进行充电。
Charging a Battery Using the Built-in Charger
使用内置充电器充电
The side of the device has a port where you can plug in the micro USB plug. This plug will
insert into the device only one way. When the device is plugged in and charging, you will
see a lightning symbol inside the battery icon showing that it's charging. Once it reaches
full charge, the lightning bolt indicator will no longer appear.
在设备的侧面有一个微 USB 插口。USB 插头只能有一个方向插进去。当设备插入充电时，
屏幕上会显示一个电池及一个闪电的标志以表明正在充电。充满之后，闪电指示就没有了。

17
Be careful when inserting the cable. Forcing or breaking this connection by inserting the wrong cable or
abusing the connector by forcing the plug is not covered under warranty. When plugged into the onboard
USB charger, your battery will begin charging. You can continue using the device while it's plugged in but
the USB cable will not supply enough power to act as a pass-through, using your battery energy when
you vape. When the device is idle, it will continue charging the cell inside. We have tested a number of
USB battery packs and these all work great for charging your device while on the road. You can get these
items from your local electronic store or from Amazon.
插入电缆线时要注意，采用错误的电缆或粗暴地插入导致的接口损坏不在保修范围内。当内置的 USB 充电
器接通时，电池开始充电。充电时，你还可以继续使用该设备，但是这是由电池供电，USB 电缆提供的电
量不够。没有使用设备的时候，它会继续充电。我们测试过很多 USB 充电宝， 它们都能够很方便地对您
的设备进行充电。您在当地的电子商店或亚马逊都购买得到。
Battery Life
电池寿命
When the battery is depleted, the battery icon on the screen will indicate that it's time to recharge. At this
time recharge the battery.
当电池耗尽时，屏幕上的电池图标会显示需要充电了。这时候进行充电。
Inserting a Battery
安装电池
The Radius was designed to easily charge the unit's battery by plugging a Micro USB cable on the side of
the unit. Should you need to replace the battery however, it can be easily serviced at home. On the
bottom of the unit, there are two thumb screws. Remove these two screws and the bottom plate can be
removed. Once the plate is removed you will have access to removing the battery and installing a new
cell. Note, there is a small metal tab that sits between the battery and the spring. Once the new battery is
installed, make sure this metal tab rests on the bottom of the battery, then position the bottom plate onto
the housing with the spring pressing on the metal tab. Install the two screws and you are ready to vape
with a new battery. This whole process takes less than 40 seconds. We've designed the Radius with a
metal plate that covers the bottom end of the battery to ensure you get the best possible battery
connection. This increases your run time and gives you optimum battery performance and longevity.
Radius 的设计方便用微 USB 给设备里的电池充电。但是如果需要更换电池，在家里就可以轻松的完成。
在设备的底部，有两个拇指螺钉。拆下这两个螺钉就可以取下底板。然后就可以取出电池，安装新电池。
请注意，在电池和弹簧之间有一块小金属片。新电池装好后，要确保这个金属片处于电池的底部，安装底
板时，要让它上面的弹簧压住这个金属片。拧上这两个螺钉，就可以重新使用了。整个过程花的时间不到
40 秒。我们在设计 Radius 时，在电池的底部增加了一块金属片以确保最好的电池接触。这会增加您的使
用时间，优化电池的性能和使用寿命。
When assembling the unit, do not over-tighten the screw. They should be snug, but not so tight that you
won’t be able to remove them when you need to replace the battery.
在装配设备时，不要过度拧紧有螺纹。它们之间的接触要适度，不要太紧，否则在换电池时就没办法拧开
了。
Questions? Problems?
疑问或设备故障？

18
If you have any questions or problems with your ProVari Radius, please feel free to contact us or visit the retail
location where you purchased your device. To contact ProVape, visit www.ProVape.com and click on the “Contact
Us” link.
如果您有任何疑问或您的 ProVari Radius 出现了故障，请随时与我们联系或访问您购买设备的零售点。如
果要联系 ProVape，请访问 www.ProVape.com，并点击链接“联系我们”。
© Copyright 2015 ProVape, Inc.

19
MenuFlowChart
菜单流程图
RCL-调用
连按4下
Info-信息 Exit-退出
1P
2P
3P
4P
5P
DIS-显示 LED BOOST
增强
SAV-保存
1P
2P
3P
4P
5P
Exit 退出
OFF 关闭
1 BOOST
增强 1
2 BOOST
增强 2
3 BOOST
增强 3
4 BOOST
增强 4
5 BOOST
增强 5
Exit 退出
Scrolling
Speed
滚动速度
Display
Brightness
显示亮度
Left/Right
Mode
左右模式
Status Time
显示持续时间
1
2
3
4
5
Exit 退出
1B
2B
3B
4B
5B
Exit 退出
Left Handed
左手模式
Right
Handed
右手模式
OFF
5 Seconds
5秒
10 Seconds
10秒
20 Seconds
20秒
Exit 退出
ON
Selected
选择开
OFF
Selected
选择关
LED On/Off
Toggle
LED开关切换
LED COLOR
LED颜色
Red 红
Green 绿
Blue 蓝
Aqua 蓝绿
Yellow 黄
Pink 粉红
White 白
Exit 退出
SET-设置
Random 随机
SET-设置
SAV-保存
DIS-显示
LED
BOOST-增强
Exit-退出
Version, Serial
版本、序列号
1 Seconds
1秒
Cigarette
Counter 香烟
计数
Money Saved
节省金额
Cigs Avoided
少抽香烟
Price Per Pack
每包价格
Puff Count
喷雾计数
Exit 退出
Cigarette
香烟计数
Exit-退出
Back Arrow
后退箭头
Back Arrow
后退箭头
Back Arrow
后退箭头
Back Arrow
后退箭头
Back Arrow
后退箭头
Back Arrow
后退箭头
Rainbow 彩虹

20
Note: Menu items can change slightly due to new features or ongoing improvements.
注：由于新功能的增加或不断改进，菜单项可能会有稍微改变。
PushButtons
按钮
The ProVari Radius has three buttons located on the front of the
unit. The large main button is used to power the device when
vaping. It's also used to get into the menu to change settings by
pressing it 4 times in a row.
ProVari Radius 的正面有三个按钮。大的主按钮是用来给喷雾提供
能量的。它也用于调整设置，连按 4 次就可以进入菜单了。
There are also two smaller buttons labeled + and -
These are used to adjust the wattage up and down.
有两个小的按钮，标志为+ 和 -。
它们用来调高或调低功率的。
There are also some extra features assigned to these buttons for
turning the device on/off and for locking the power adjustments.
这些按钮的额外功能是开启/关闭设备、锁定能量设置。
On/Off (Atomizer) – Turning the atomizer on/off is done by holding all three buttons down at the same
time for 3 seconds. Every time you hold these three buttons, the device will toggle back and forth
between ON and OFF. You can also hold down all three buttons to continuously cycle between On/Off. In
the event you will be storing the device in a pocket or purse and you do not want the fire button to
accidentally get pressed, you can set this to OFF. The atomizer will not fire until you turn this back on or
you remove the battery and reinstall, which will reset this back to ON.
On/Off（开/关雾化器） - 将这三个按钮同时按下 3 秒可以打开或关闭雾化器。每次按下这三个按钮，设
备就会在开启和关闭间切换。假设您要将该设备存放在口袋或钱包里，不希望电源按钮被意外按下，就可
以将这个设置为 OFF（关闭）。只有这个选项设置成 ON（开启）或者重装电池导致设备设置回到默认值
“ON”（开启）时，雾化器才会触发。
Once you have selected the Atomizer ON/OFF
option, the next screen will confirm your selection.
一旦您选择了开/关雾器，下一个屏幕会确认您的选择。
