Boundless CFX User manual
CFX VAPORIZER
Building off the powerful innovative
heating technology found in the CF,
The CFX takes vape innovation to
the next level. Featuring a full 1.7 inch
OLED Screen, The CFX easily
produces massive amounts of vapor
while simultaneously cooling down
the vapor being drawn.
With a true convection based heating
system, the CFX can produce a vapor
that has full flavor and a full body.
The CFX easily cools the vapor by
taking advantage of an innovative
bottom airflow path. Creating some of
the purest tasting vape usually
reserved for desktop vaporizers.
Patented Convection Airflow System With Display (CAS)
What’s in the Box：
1 CFX Dry Herb Vaporizer
1 Liquid/Wax Chamber (Organic Cotton)
3 Stainless Steel Screens
1 Packing Tool and Dabber
1 Cleaning Brush
1 USB Charger
1 DC Adapter
1 User Manual
What’s in the Box：
1.77’’ Colored Display with Full Range Temperature Control: 100˚F - 430˚F.
Next Generation Patented Convection-Airflow-System (CAS) Technology.
Portable Vaporizer that is Ergonomically Designed and Easy to Hold and Operate.
Non Combustion Vaporizer.
Fully Isolated Air Path allows for Clean and Pure Vaping.
Compact, Rugged Design.
Vibration Feedback for Operations.
Built with Medical and Food Grade Material.
Dual Charging: Fast Charging DC 12V 1.5A Port, Regular Charging Micro 5-Pin 5V 2A Port.
3.Mouthpiece
4. Mouthpiece Base
5. Housing
6. Display
7. USB Charge Port
8. DC Charging Port
9. Vaporizer Base
10. Liquid/Wax
Chamber
What’s in a CFX Vape?
1. Power Button
2. Temperature
Control Buttons
Product Configur
1. Power Button - On/Off with Vibration Feedback.
2. Temperature Control Buttons - Adjusting accurately by 1˚F per setting, 100˚F-430˚F.
3. Mouthpiece - Food Grade, Rotary 360°, Vape from any direction.
4. Mouthpiece Base - Made with different easy disassembled components.
5. Housing - Hot-Dissipation Design. Rugged and Ergonomically Designed.
6. Display - 1.77’’ TFT Colored Display indicates Temperature Information, Battery Status,
Duration Timer etc.
7. USB Charge Port - Regular Charging, Micro 5-Pin 5V 2A is best suggested.
8. DC Charging Port - Fast Charging, DC 12V 1.5A.
9. Vaporizer Base - Air Inflow.
10. Liquid/Wax Chamber - Fill your choice oil/waxy (not the same time)
How to LOAD
Remove mouthpiece from the CFX.
Insert Screen into ceramic heating camber.
Note: Screens (3 included) in the housing unit and heating
chamber can be changed periodically to ensure clean
vaping. Additional screens sold separately.
Attach CFX mouthpiece.
Load choice blend loosely into the ceramic heating
chamber. Tamp down with the dabber tool.
Do not over-fill. (note: do not turn on device while loading blend).
How to Use CFX with Dry Herbs?
ACTIVATE
wHo t
Rapidly press Power button five times within 2 seconds to power on CFX. The display will
turn on.
The display indicates the Temperature Information, Battery Status, Session Timer etc.
The Session time is 300 seconds (5 minutes). “S” is short for Starting, “F” is short for Finishing.
The Temperature Range is 100˚F-430˚F, shown as below:
sF
300SEC
400F
100
150
200 250 300
350
430
400
DISPLAY INDICATION
When setting the Temperature, the display is Red.
After Temperature is reached, the display turns Green. With Session Timer running.
SF
000S
139F
100
150
200 250 300
350
430
400
sF
300SEC
400F
100
150
200 250 300
350
430
400
LOAD
Oil
Fill oil/wax chamber with at least 5 drops of
(0.2 - 0.3ml) oil. Let oil settle for a few seconds.
Insert oil/wax chamber into ceramic
heating chamber
(note: do not turn on device while loading oil/wax chamber).
Wax
Place concentrated oil around the recess of the lid.
Screw lid on to oil/wax chamber.
Insert oil/wax chamber, with lid facing down
towards ceramic heating chamber (note: do not
turn on device while loading the oil/wax chamber.
How to Use CFX Vape with oil/wax
8
Air is fully directed to the heating chamber, isolating
its path from the electronics. Ensuring a clean and
pure vaping each time.
Fully Isolated Air Path for Clean Vaping
9
CFX VAPE
Technical Speci
Dimension: 5.07’’H x 1.26’’D x 2.79’’W (129mmH x 32mmD x 71mmW)
Temperature Levels: 100˚F - 430˚F
Capacity: 2500mAh
Output Voltage: 7.4V
Power On/Off: Press power button 5 times rapidly
Safety Power Duration: 5 minutes
Safeguard: Dual PCBA/IC Protection
10
CHARGING
The device contains a Lithium-Ion battery. Take caution and dispose in the correct receptacle. Do not
discard in trash. Do not over charge. Do not short circuit the battery.
Notice: Lithium Ion Batteries are subject to degradation and reduced run time over the course of regular use
at over 200˚F
while Boundless Technology took great care in selecting premium quality long life Lithium Ion batteries due to their
non-memory features and ability to cycle 300 times preceding degradation, battery life will
gradually diminish with extended use.
BATTERY
Ba ery and Charging
Charging the CFX while powered on, the OLED display will stay lit.
Charging the CFX while powered off, only the battery icon will be visible.
Do not use CFX while charging. This will cause damage to the device.
To prevent the device from overheating, do not leave the charger plugged in overnight.
Do not leave charger plugged in or unattended without the device. Do not charge unit on bare
carpet or rug.
InitiallychargetheCFXfor4to4.5hoursbyMicro5-PinPort(5V2A),1to1.5hourbyDCPort(12V
1.5A).Thebatterywillstopchargingwhentheiconisfull. Whenthebatterylevelislow,charge
batterywithincludedMicro5-PinChargerorDCCharger.Lowbatterylevelwillbeindicatedwith
iconflashing10timesrepeatedly.
11
90°
How to Load and Remove the Mouthpiece
How to Load the Mouthpiece Components:
1. Place Mouthpiece Components and the Device at a 90°Angle.
2. Press the Mouthpiece Components into the device downward
as shown.
3. Rotate the Mouthpiece Components clockwise.
To Remove follow above steps in reverse.
12
How to Disassemble the Mouthpiece Components
(Mouthpiece Base Top)
(Mouthpiece)
(Mouthpiece Components)
(Silicone Ring)
(Mouthpiece Base Bottom)
(Mouthpiece Base Bottom) (Filter Base) (Filter Top)
1. Use the Opener to pry open as shown,
to disassemble the Mouthpiece Components into
two parts.
2. To disassemble the Silicone
Ring, use the Opener again to pry
apart as shown.
3. Unscrew the Filter components
from the Mouthpiece Base Bottom,
to disassemble the Filter into Filter
Top and Filter Base.
4. Unscrew the Mouthpiece from
the Mouthpiece Base Top. 13
Failure to follow these safety instructions could result in personal injury or damage. Users of this device
do so at their own risk. Neither Boundless Technology, LLC nor its retailers assume any responsibility or
liability associated with the use/misuse of the device. Boundless Technology branded products are
intended for adult use and consumption only. Keep this booklet in a safe place for future reference.
WARNING
This device is designed as a mobile solution for the practitioners of aromatherapy and should be used for
dry herbal blends as indicated. This device is not intended for use with illegal substances.
DISCLAIMER
The CFX contains small parts which may be a choking hazard to small children. Keep device away
from children.
CHOKING HAZARD
Safety
14
Do not drop, deform, bend, crush, puncture, incinerate, microwave, shred, paint or insert foreign
objects into a Boundless Technology, LLC CFX.
Do not clean CFX other than instructed by Boundless Technology, LLC.
Do not attempt to repair or modify CFX yourself.
Do not use a damaged CFX charger or non Boundless Technology charger. Incompatible
chargers may carry different voltage, which may be a fire hazard. Use only the charger provided.
Failure to do so will void the limited warranty offered on Boundless Technology Technology products.
Use caution when handling CFX, the heating chamber area is hot
powered on. Refrain from direct contact with the main heating chamber when hot. Do not leave
the device unattended when it is powered on or while the device is still hot.
HANDLING
Safet
15
The device is equipped with a safety sleep mode. When the device is powered on and after
6 minutes vaping, it will go into sleep mode to avoid over-use.
Press and Hold the power button for 3 seconds to resume vaping.
SLEEP PROTECTION
The device features a smart memory function. It will memorize the data of current use before
powering off. When powered on for next use, the last setting will be displayed.
MEMORY FUNCTION
The CFX is equipped with a smart OLED display to manually configure any desired
temperature setting within the modular range.
SMART TEMPERATURE LEVELS
Safety Features
16
Boundless Technology, LLC warrants this Boundless Technology, LLC branded device against defects in
materials and workmanship under normal use for a period of one (1) year from the date of retail purchase by
the original end-user. The original bill of sale is required to redeem warranty. The limited warranty covers
one (1) year for electronics, ceramic heating chamber, structural integrity and attachments. The Lithium-Ion
battery ninety (90) days. If a physical defect arises and a claim is made within the Warranty Period, at its
option and to the extent permitted by law, Boundless Technology will either:
repair the product defect
exchange the product with a product warranty that is
new or functionally equivalent
refund the purchase price of the device.
1 YEAR LIMITED WARRANTY
Warranty
17
18
