MRC BPS-200/2000-C1-V2 User manual

PLEASE READ THIS MANUAL
CAREFULLY BEFORE OPERATION
3, Hagavish st. Israel 58817
Tel: [phone], Fax: [phone] [email protected]
MRC.VER.01-12.13
O
Op pe er ra at ti io on n M Ma an nu ua al l
B
BP PS S- -C C1 1- -V V2 2 S Se er ri ie es s
LCD BALANCES

- 3 -
1. TECHNICAL DATA .................................................................................7
1.1. Connection ports....................................................................................... 10
2. BASIC INFORMATION ........................................................................ 11
2.1. Intended use ............................................................................................. 11
2.2. Inappropriate use ...................................................................................... 11
2.3. Warranty ................................................................................................... 11
2.4. Monitoring the metrological parameters of the instrument ........................ 12
2.5. Data included in this user manual ............................................................. 12
2.6. Staff training ............................................................................................. 12
3. TRANSPORT AND STORAGE ........................................................... 12
3.1. Delivery check .......................................................................................... 12
3.2. Packaging ................................................................................................. 12
4. UNPACKING, ASSEMBLING AND START-UP .................................. 13
4.1. Assembling and place of use .................................................................... 13
4.2. Unpacking ................................................................................................. 14
4.3. Levelling ................................................................................................... 17
4.4. Cleaning ................................................................................................... 17
4.5. Plugging to mains ..................................................................................... 19
4.6. Connecting additional equipment.............................................................. 20
5. BASIC FUNCTIONS ............................................................................ 20
6. KEYBOARD ......................................................................................... 22
7. START-UP ........................................................................................... 23
7.1. Connecting peripheral devices ................................................................. 23
7.2. Balance temperature stabilisation period .................................................. 23
8. USER MENU ....................................................................................... 24
8.1. Moving through user menu ....................................................................... 24
9. LOGGING IN ....................................................................................... 27
10. WEIGHING .......................................................................................... 29
10.1. Required weighing procedures ................................................................. 29
10.2. Zeroing ..................................................................................................... 31
10.3. Taring ....................................................................................................... 31
10.4. Settings for mode <WEIGHING> .............................................................. 33
1.1.1 Setting level of filtering .................................................................... 33
1.1.2 Value release .................................................................................. 34
1.1.3 Autozero function ............................................................................ 35
1.1.4 Displaying the last digit ................................................................... 35
1.1.5 Balance ambient conditions ............................................................ 36
10.5. Printing mode ........................................................................................... 36
10.6. Temporary measuring unit ........................................................................ 38
10.7. Start-up measuring unit ............................................................................ 38
10.8. Availability of measuring units .................................................................. 39
10.9. User unit ................................................................................................... 40
10.10. Information ............................................................................................. 41
10.11. Non-standard information ....................................................................... 42
10.12. F button shortcuts .................................................................................. 43
10.13. Dual range balance (BPS-200/2000-C2) ................................................ 44

- 4 -
11. OTHER PARAMETERS ....................................................................... 45
11.1. Available menu languages ........................................................................ 45
11.2. Access levels ............................................................................................ 45
11.3. ‘Beep’ sound – reaction on pressing function button ................................ 45
11.4. Backlight and adjusting display brightness ............................................... 46
11.5. Date .......................................................................................................... 46
11.6. Time .......................................................................................................... 46
11.7. Date format ............................................................................................... 46
11.8. Time format ............................................................................................... 47
11.9. GLP autotest ............................................................................................. 47
12. INFORMATION ABOUT THE BALANCE ............................................. 49
13. BALANCE ADJUSTMENT ................................................................... 50
13.1. Internal adjustment ................................................................................... 51
13.2. Menu adjustment settings ......................................................................... 53
13.3. Manual adjustment ................................................................................... 55
13.3.1. Internal adjustments ................................................................... 55
13.3.2. External adjustment .................................................................... 56
13.3.3. User adjustment ......................................................................... 56
13.4. Adjustment report printout......................................................................... 57
14. DETERMINING CONTENT OF A PRINOUT ....................................... 58
14.1. Adjustment report ..................................................................................... 58
14.2. Header printout ......................................................................................... 60
14.3. Measurement result printout – GLP PRINTOUT ....................................... 62
14.4. Footer printout .......................................................................................... 64
14.5. Non-standard printouts ............................................................................. 66
14.5.1. Inserting texts ............................................................................. 66
14.6. Variables ................................................................................................... 69
15. DATABASE .......................................................................................... 70
15.1. Users ........................................................................................................ 70
15.2. Products.................................................................................................... 73
15.3. Tares ........................................................................................................ 74
15.4. Weighments .............................................................................................. 75
15.5. ALIBI ......................................................................................................... 78
16. EXPORT AND IMPORT OF DATABASE ............................................. 80
16.1. Export database ........................................................................................ 81
16.2. Import database ........................................................................................ 82
16.3. Measurement data print-out ...................................................................... 82
17. BALANCE WORKING MODES ............................................................ 84
17.1. Setup for availability of working modes ..................................................... 85
17.2. Counting parts of the same mass ............................................................. 86
17.2.1. Setup for mode COUNTING PIECES ......................................... 87
17.2.2. Setting the reference mass by determining from the sample of
known quantity............................................................................ 88
17.2.3. Setting the reference mass by entering its mass ........................ 90
17.2.4. Returning to the weighing mode ................................................. 91
17.3. Checkweighing ......................................................................................... 92
17.3.1. Declaration of mass thresholds .................................................. 93
17.4. Dosing....................................................................................................... 95

- 5 -
17.4.1. Setting a target weight by entering values .................................. 96
17.4.2. Returning to the weighing mode ................................................. 98
17.5. Deviations % against the mass of the standard ........................................ 98
17.5.1. Setup for reference mass determined by weighing .................... 99
17.5.2. Setup for reference mass by typing its mass ............................ 100
17.5.3. Returning to the weighing mode ............................................... 101
17.6. Animal weighing...................................................................................... 101
17.6.1. Additional setting for animal weighing mode ............................ 101
17.6.2. Method of operation to manually start the process ................... 103
17.6.3. Method of operation to automatically start the process ............ 105
17.7. Density of solids...................................................................................... 106
17.7.1. Density determination of solids ................................................. 108
17.8. Density of liquid ...................................................................................... 112
17.8.1. Density of liquids determination ................................................ 112
17.9. Statistics ................................................................................................. 115
17.9.1. Means of operation ................................................................... 116
17.9.2. Deleting statistics ..................................................................... 119
17.9.3. Returning to the weighing mode ............................................... 120
17.10. Totalising .............................................................................................. 121
17.10.1. Means of operation ................................................................... 122
17.10.2. Returning to the weighing mode ............................................... 124
17.11. Peak hold ............................................................................................. 125
17.11.1. Means of operation ................................................................... 126
17.11.2. Returning to the weighing mode ............................................... 127
18. COMMUNICATION ............................................................................ 128
18.1. RS 232 ports settings ............................................................................. 128
18.2. WIFI port settings.................................................................................... 129
19. PERIPHERALS .................................................................................. 131
19.1. Computer ................................................................................................ 131
19.2. Printer ..................................................................................................... 132
19.3. Bar code reader ...................................................................................... 132
19.4. Additional display .................................................................................... 133
19.5. External buttons ...................................................................................... 133
20. WORKING WITH EXTERNAL DEVICES SUCH AS PRINTER OR
COMPUTER ................................................................................ 135
20.1. Cable pinout diagram .............................................................................. 136
20.2. Format of data setting ............................................................................. 137
20.3. Format of data sent on pressing of PRINT button................................... 137
20.3.1. Format of data sent as response for commands generated from a
computer .................................................................................. 137
21. COMMUNICATION PROTOCOL ...................................................... 139
21.1. List of commands.................................................................................... 139
21.2. Responses format for commands sent from computer level ................... 140
21.3. Commands description ........................................................................... 140
22. ERROR MESSAGES ......................................................................... 145
23. UNDER HOOK WEIGHING ............................................................... 146
24. ADDITIONAL EQUIPMENT ............................................................... 147
24.1. Anti-vibration table .................................................................................. 147

- 6 -
24.2. Rack for under hook weighing ................................................................ 147
24.3. Density determination kit (for solids and liquids) ..................................... 147
24.4. Additional display .................................................................................... 147

- 7 -
1. TECHNICAL DATA
Balance ASB-C2-V2 series:
ASB-
60/220-C2-V2
ASB-
160-C2-V2
ASB-
220-C2-V2
ASB-
310-C2-V2
Max capacity 60/220g 160g 220g 310g
Min capacity 1mg 10 mg 10 mg 10 mg
Readability 0.01/0.1mg 0.1mg 0.1mg 0.1mg
Tare range -220g -160 g -220 g -310 g
Pan size Φ 85 mm
Sensitivity drift 1 ppm/°C in temperature +10 ° - +40 °C
Working
temperature
+10 ° - +40 °C
Power supply 12 ÷ 16 V DC / 2.1 A
Dimensions:

- 8 -
Balance BPS-C2-V2 series with weighing pan 128 x 128 mm:
Dimensions:
Type balance
BPS-
200/2000-C1-V2
BPS-
210-C1-V2
BPS-
360-C1-V2
BPS-
600-C1-V2
BPS-
750-C1-V2
BPS-
1000-C1-V2
Max capacity 200/2000g 210g 360g 600g 750g 1000g
Tare range -2000g -210g -360g -600g -750g -1000g
Min capacity 20mg 20mg 20mg 20mg 20mg 20mg
Readability 1/10mg 1mg 1mg 1mg 1mg 1mg
Working
temperature
+10°C - +40°C
Power supply 12 ÷ 16 V DC / 2,1 A
Sensitivity drift 2 ppm/°C in temperature +10°C -+ 40°C
Pan size 128x128 mm

- 9 -
Balance BPS-C2-V2 series with weighing pan 195 x 195 mm:
Type balance BPS-
1200-C1-V2
BPS-
2100-C1-V2
BPS-
3500-C1-V2
BPS-
4500-C1-V2
BPS-
6000-C1-V2
Max capacity 1200g 2100g 3500g 4500g 6000g
Tare range -1200g -2100g -3500g -4500g -6000g
Min capacity 500mg 500mg 500mg 500mg 500mg
Readability 10mg 10mg 10mg 10mg 10mg
Working
temperature
+10°C - +40°C
Power supply 12 ÷ 16 V DC / 2,1 A
Sensitivity drift 2 ppm/°C in temperature +10°C - +40°C
Pan size 195x195mm
Dimensions:

- 10 -
Balance BPP-C2-V2 series:
BPP-
10-C2-V2
BPP-
35-C2-V2
Max capacity 10 kg 35 kg
Tare range -10 kg -35 kg
Min capacity 2 g 2 g
Readability 0.01 g 0.1 g
Working temperature +10 °C - +40 °C
Power supply 12 ÷ 16 V DC / 2,1 A
1.1. Connection ports
1
- power port
2
- COM 2 port (e.g. additional display)
3
- COM 1 port (e.g. printer)
4
- USB 2 port (e.g. computer)
5
- USB 1 port (e.g. computer keyboard)

- 11 -
2. BASIC INFORMATION
2.1. Intended use
The purchased balanced serves to determine the weighing value of loads in
laboratory environment. It is intended for application as a non-automatic
weighing instrument only, i.e. the material to be weighed is manually and
carefully placed in the centre of the weighing pan. Weighing result should be
read only after stable reading has been obtained.
2.2. Inappropriate use
Do not use the balance as a dynamic weighing instrument. Even if small
quantities of weighed material are added or removed from the weighing pan of
the instrument, the reading should be taken only after stabilisation of the
measurement results. Do not place any magnetic materials on the weighing
pan, as this can cause damage to the measuring system of the instrument.
Be sure to avoid impact shock and overloading the balance in excess of the
prescribed maximum measuring range (max capacity), minus any possible tare
weight that has been applied.
Never use the balance in an environment where explosion is possible. This
balance has not been adjusted for operation in explosive areas.
There must not be any modification made to the balance.
2.3. Warranty
Warranty is invalid for the following:
• non- observation of the guidelines of this user manual,
• use of the balance other than specified in this manual,
• alteration to or opening of the device,
• mechanical damage and damage caused by media, water, wear and
tear,
• inappropriate assembling or defects of electric installation,
• overloading of the measuring instrument.

- 12 -
2.4. Monitoring the metrological parameters of the instrument
Metrological characteristics of the balance require periodical inspection to be
carried out by its user. Inspection frequency is dependent on ambient
conditions in which the balance is used, types of performed processes and
accepted quality management system in organisation.
2.5. Data included in this user manual
Please read the user manual carefully before assembling and start-up, even if
the user is experienced with this type of weighing instruments.
2.6. Staff training
This balance should only be operated and maintained by personnel who is
trained and experienced in using this type of balances.
3. TRANSPORT AND STORAGE
3.1. Delivery check
Please check the packaging immediately upon delivery and the device during
unpacking for any visible signs of external damage.
3.2. Packaging
Please retain all parts of the original packaging should the balance be
transported in the future. Only the original packaging should be used for
shipping the balance. Before packing, disconnect all attached cables and
remove any loose/movable parts (weighing pan, anti-draft shield, etc.). Please
place balance and its components in their original packaging, and protect them
against damage during transport.

- 13 -
4. UNPACKING, ASSEMBLING AND START-UP
4.1. Assembling and place of use
• The balance should be stored and used in locations free of vibrations and
shakes, free of air movement and dust,
• ambient air temperature should not exceed the range of: +10 °C ÷ +40 °C,
• ambient relative humidity should not exceed 80%,
• during balance operation, ambient temperature in the weighing room should
not change more than 3°C within one hour,
• the balance should be located on a stable wall console desk or a stable
working table which is not affected by vibrations and distant from heat
sources,
• take special precaution when weighing magnetic objects, as part of the
balance is a strong magnet. Should such loads be weighed, use under hook
weighing option, which removes the weighed load from area influenced by
the balance’s magnet. For assembling the hook for under hook weighing
option see the bottom section of balance’s housing,
• in order to avoid the influence of static electricity on the measurement
process, ground the balance’s housing. The grounding bolt is located at the
back of the balance’s housing.

- 14 -
4.2. Unpacking
Balance ASB with weighing pan Φ 85 mm:
• open side doors of the weighing
chamber,
• inside the weighing chamber place lower
shield of the weighing chamber (1),
• put centering ring [framing facing
downwards] (2),
• in the centre of centering ring assembly
the weighing pan (3),
• put anti-draft shield in the chamber (4),
• close side doors of the weighing
chamber,
• plug the balance to mains,
pin of power adaptor should be
connected to socket in the back of
balance housing.

- 15 -
Balance BPS
Remove the adhesive tape. Carefully remove the balance from its packaging.
Remove all the elements necessary for correct operation from the accessory
box. Carefully remove the plastic and foil transport protective elements and
gently place the balance in its intended place of use.
Assemble the weighing pan, and other elements according to below schema:
Assembling a balance with reading interval 10mg:
- remove the adhesive tape
protecting the mass spring on one
of the rubber bumpers (1),
- assemble the weighing pan (2) on
the rubber bumpers (1),
- after assembling the balance
components, check whether the
weighing pan is firmly placed on the
rubber bumpers.
Assembling a balance with reading interval 1mg:
- remove the adhesive tape protecting the
mass spring on on
e of the rubber bumpers
(1),
- assemble the weighing pan (2) on the
rubber bumpers (1),
- assemble the glass anti-draft shield (3)
- after assembling the balance components,
check whether the weighing pan is firmly
placed on the rubber bumpers.

- 16 -
Balance BPP
• Remove the weighing pan and remove transport protective elements as
shown in the picture above (if these elements are attached).
• After the unpacking of the balance unscrew the bolt (1) which blocks the
calibration mechanism.
• Assemble the weighing pan.
• Make sure the weighing pan is placed properly on the shock absorbers:
the weighing pan cannot touch the housing and should be stable.
• After removing the protective elements and placing the weighing pan, plug
the indicator into the port which is on the back of the housing. Next, plug in
all the additional devices. Only then can the scales be connected to mains
(the power port is located at the back of the balance’s housing).

- 17 -
• Place the balance at the workplace.
• Using the wrench (3), after adjusting the balance level (see below); tighten
the bolt (2) on the foot (1) to the balance’s footing until the point of
resistance.
4.3. Levelling
Before plugging to mains, level the balance by turning the
adjustable feet in a way that the air bubble of the level is in
its central ring. The balance should be placed at the
workplace firmly on all of its feet.
4.4. Cleaning
Balance should be cleaned with damp cloth by gentle wiping smudges of dirt.
Cleaning of the weighing pan when assembled may cause damage of the
measuring system of the balance. Hence, it is crucial to remove it from the
balance before cleaning.

- 18 -
In order to clean the glass walls of the draft shield of the ASB-C2-V2 series balance,
it is acceptable to remove the walls of the draft shield following the below
instruction.
1. Twist off and remove the top glass wall safety frame, and slide the top
glass wall out of the slideway.
2. Remove the back glass wall.
3. Remove the side glass walls. The side glass walls are not replaceable, so
it is important to remember which one is left and right, and after cleaning
install them back properly in the draft shield.

- 19 -
4. CAUTION: do not remove the front glass wall.
5. Remove the weighing pan, the weighing pan safety rings and the bottom
metal plates, so as not to damage the balance mechanism durin the
cleaning.
Thus prepared draft shield and glass walls can be properly cleaned. All the
operations should be done carefully. Pay special CAUTION to the place
where the weighing pan was installed: dirt and other small elements might
enter the balance construction through this openiing, which might
negatively influence the balance parametres.
4.5. Plugging to mains
Balance can be connected to mains only with a power adapter that
comes standard with the balance. Nominal power supply of the power

- 20 -
adapter (specified on the data plate of the power adapter) should be
compatible to the power from mains.
Plug the balance to mains – the plugging socket is located at the back of
balance housing.
The test of the display unit takes place after connecting to the power (all the
elements and pictograms are backlit for a short time). Next, the name and the
program number appears consequently, the indication will reach ZERO level
(with reading unit depending on the balance). During the process of starting
the balance, the test of the internal mass adjustment mechanism occurs
(single location and elevation of the internal mass adjustment).
If the indication is different from zero, please press button.
NOTE: If the balance is “verified”, automatic adjustment/calibration occurs right
after it has been switched on.
4.6. Connecting additional equipment
It is inevitable to plug the computer out of the main before connecting additional
equipment or changing it (printer, PC computer, additional display, computer
keypad, etc.).
Connect only the equipment recommended by the balance manufacturer.
When the devices are connected, plug the balance to the main.
5. BASIC FUNCTIONS
• functions related to measuring units
- weighing in grams [g],
- weighing in milligrams [mg] (in balances with d≤0.001g),
- weighing in kilograms [kg] (in balances with d≥0.01g,
- weighing in carats [ct],
- weighing in units from beyond SI (available only in non-verified
instruments):
[lb], [oz], [ozt], [dwt], [tlh], [tls], [tlt], [tlc], [mom], [gr], [ti], [N], [baht], [tola]
• functions related to working modes
- counting pieces,
- checkweighing (control +/-),
- dosing,
- percent setup,
- density determination of solids,
- density determination of liquids,

- 21 -
- animal weighing,
- statistics
- totalising
- peak hold
• functions related to setting a balance to ambient conditions at a
workstation
- enabling and disabling autozero system,
- setting parameter of measurement result averaging,
- value release,
- display backlight,
- beep signal,
• functions related to use of communication ports (RS232, USB, WIFI)
- setting communication port,
- setting bound rate,
- continuous data transmission in basic measuring unit,
- continuous data transmission in current measuring unit,
- automatic operation mode.
Balance can be used to weigh loads under the weighing platform – i.e. under hook
weighing option. Balance software enables generating a report from adjustment
process in a form of a printout containing modifiable data (see CAL REPORT)
