MrCool Olympus Series User manual

Please read this manual carefully before installation and keep it for future reference.
Please keep this manual where the operator can easily find it. Inside, you
will find helpful hints on how to use and maintain your unit properly.
For more info visit www.mrcool.com
If used as MULTI unit, please refer to the Installation & operation manuals packed with outdoor unit.
User Manual
Olympus Series
Cassette Air Handlers

Contents
Page 1 mrcool.com
Safety Precautions
Hints for Economical Operation
Part Names
Cassette Type
High-static Pressure Parvis Split Type
Duct and Ceiling Type
For Slim Duct Type
For Slim Duct (with air inlet box) Type
Four-way Cassette (slim) Type
One-way Cassette Type
Ceiling & Floor Type (Vertical Discharge Air Conditioner)
Ceiling & Floor Type
Ceiling & Floor Type
Ceiling & Floor Type
Ceiling & Floor Type
Manual Operation
Adjusting Air Flow Direction
Maintenance
Air Conditioner Operations and Performance
Special Functions
Installation
Troubleshooting
Remote Control Troubleshooting
!
1
2
3
4
5
6
7
8
9
10
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
20
21
22
23
24

Page 2
Safety Precautions
mrcool.com
Read Before Using
Incorrect usage may cause serious damage or injury.
The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION.
WARNING
CAUTION
WARNING
DO NOT attempt to service the unit yourself. This unit has no user serviceable components. Opening or
removing the cover will expose you to dangerous voltage. Tuning off the power supply will not prevent
potential electric shock.
DO NOT use liquid cleaners or aerosol cleaners, use a soft and dry cloth for cleaning the unit. To avoid
electric shock, never attempt to clean the units by sprinkling water.
DO NOT put hands or objects into the Air Outlet of indoor or outdoor units. These units are installed with
a fan running at high speed. To touch the moving fan will cause serious injury.
• To avoid the risk of serious electrical shock, never sprinkle or spill water or liquids on unit.
• Ventilate the room regularly while the air conditioner is in use, especially if there is also a gas appliance
in use in this room, failure to follow these directions may result in a loss of oxygen in the room.
• To prevent electric shock, turn off the power or disconnect the power supply plug before beginning any
cleaning or other routine maintenance. Follow the directions for cleaning in the Owner's Manual.
This symbol indicates ignoring instructions may cause death or serious injury.
This symbol indicates that ignoring instructions may cause moderate injury
to your person, damage to your unit, or other property.
This symbol indicates that you should NEVER perform the indicated action.
!
Safety Precautions
CAUTION
DO NOT use caustic household drain cleaners in the unit. Drain cleaners can quickly destroy the unit
components (drain pan and heat exchanger coil etc).
DO NOT attempt to install this unit by yourself. This unit requires installation by qualified persons.
For proper performance, operate the unit in temperature and humidity ranges indicated in this owner's
manual. If the unit is operated beyond these conditions, it may cause malfunctions of the unit or dew
dripping from the unit.
Danger
No
Thinner
No
Household
Drain
Cleaner

Installation Summary
Page 3 mrcool.com
1
Hints for Economical Operation
The following should be noticed to ensure optimal economical operation.
(Refer to corresponding chapter for more details)
• Adjust the air flow direction properly to avoid winding toward your body.
• Adjust the room temperature properly to maintain a comfortable temperature and to avoid supercooling or
superheating.
• While cooling, close the curtains to avoid direct sunlight.
• To keep cool or warm air in the room, refrain from opening and closing doors or windows more often than
necessary. Set the timer for the desired operating time.
• Clear any obstructions from the vicinity of the air outlet or the air inlet. Obstructions will cause lower efficiency,
or sudden stop in operation.
• If you do not plan to use the unit for a long time, disconnect the power and remove the batteries from the
remote control. When the power switch is connected, some energy will be consumed, even if the air
conditioner isn't in operation. Once you plan to use the unit again, switch the power on 12 hours before you
restart the unit to ensure a smooth operation.
• Clean the air filter bi-weekly. A clogged air filter will reduce cooling or heating efficiency.

Part Names
Page 4mrcool.com
2
The air conditioner consists of the indoor unit, the outdoor unit, the connecting pipe
and the remote controller.
Display Panel
Cassette Type
or
Indoor Unit
Air Flow Louver
(at air outlet)
Air Outlet
Remote
Control
Outdoor Unit
Outdoor Unit
Temporary Button
Operation
Lamp
Connecting
Pipe
Infrared
Signal
Receiver
Alarm
Indicator
Timer
Indicator *Pre-Def
Indicator
Drain
Hose
Air Inlet
(with air
filter in it)
Air In
Air In
Air In
Air
Out
Air
Out
Air Out
*Drain Pump
Air
Out
*PRE-DEF indicator (cooling and heating type) or fan only indicator (cooling only type)
*Drain Pump - Drains water from the indoor unit
NOTE
This diagram is based on 24K Btu/h type. Minor differences may exist for the appearance and
functionality for your specific model.
