MRS Ponto User manual

Inflatablemouth
Grabloops
Jointstrip
Hull
Thighstrapsbuckle
Seatpullring
Hullbottom
Seat
Displaymodel：NomadS1
CHENGDU
MICRORAFTINGSYSTEM
TRADECO.,LTD
Backrest

1M
2M
3M
4M
1M
2M
3M
4M
STILLWATERSERIES
WHITEWATERSERIES
Ponto/Tulo AdventureX2 BarracudaR2 NomadS1
NomadS1D MicroPackrfat
ExtraLong
BarracudaR2PRO Alligator2SPRO Alligator2S MicroPackraft
1
XS
S
M
L

INFLATE
Connectinginflatablebag
1.STEP ONE
Removetheinflatablenozzleonthe
boatandtheinflatablepocketcanbe
insertedintotheinflationmouth.
Inflatingwithaninflatablebag
2.STEP TWO
Opentheairbagtofillitwithair,then
closetheairbagandpresstheairinto
thehull.Repeattheaboveoperationto
quicklyinflate.
Inflatingwithmouth
3.STEP THREE
Whenthehullisabout80%inflated,
removetheairbag,quicklyclosetheair
nozzle,opentheone-wayairinletat
thetopoftheairnozzle,andfilltheair
pressurewiththemouth.
Itisrecommendedtouseaninflatable
bagtoinflate,usually6timestocharge
theboatto90%,plususethemouthto
filltheair,ittakeslessthan1minute
andahalf,lightandefficient.We
recommendfirstinflatingtheseat
cushion,backrestandwaveskirt,then
toinflatethemainhull.
or
2
Almostfull
Thespecialblockingsystemallowsthe
airflowtobeinaccessible,andinthe
end,theinflationofthemouthcan
effectivelymaintaintheinternalair
pressure.
Mouthvalve

INSTALL/ADJUSTINGTHEBACKREST
3
C C
CC
BB
B B
A A
UPUPUP
Makesurethebackrestis
up(themouthvalveis
facingup).
ConnectAandBand
adjustthelengthofthe
webbingtofit.TheABis
themainpointofforce,
sobesuretotighten.
ThenconnectCand
adjusttotheappropriate
length.
Adjustthebackrestso
thatitstandsontheseat
cushion.
AA
A
B
C
QUICK DISASSEMBLYQUICK DISASSEMBLYQUICK DISASSEMBLY
Quickreleasebackrest
(Onlymiddle/frontrow)
Easyinsertioncanbeconnected Holdthemiddlebuttonandpullitout.
A
BC
FRONTFRONTFRONT
1.STEP ONE 2.STEP TWO 3.STEP THREE 4.STEP FOUR
Therearbackrestisfactory-installedbydefaultanddoesnotrequireinstallationadjustments.

RECOMMENDEDLENGTHOFPADDLE
SHARKFINUSEMETHOD
BALANCETHEPACKRAFT
Singlebladepaddle
Doublebladepaddle
Baggage Baggage
Baggage
Whenloadingheavyobjects,besureto
payattentiontothefrontandrearload
balanceofthehull.Whenthehull
postureisunbalanced,theforward
resistanceincreases,andthestability
andthetrackingpropertydeteriorate.
When using in white water, this phenomenon
will be amplified and you need to pay attention!
Whenusingtheboatfins,itincreases
thepossibilityofbottominginshallow
water,causingsometrouble.Butthe
advantagesofusingtheboatfinsare
alsosignificantandworthtrying.Itcan
reducetheswingoftheship,
concentratethepropulsionenergyfor
advancement,andreducetheextra
paddleactiontomakerepeated
correctiondirections,makingthe
paddleeasy.
Ifyouconsideraddingtheship'sfinsin
thelaterstage,theinstallationposition
shouldbeasfaraspossiblefromthe
sternofthepaddlertoeatdeeper,soas
toachievebetterstability.
220~230cm (87~90.5〃inch)
137cm (54〃inch)
Choosingtherightlengthofthepaddle
ismoreconducivetoforce,andavoid
touchingthesidesofthehullforbest
use.

INSTALLSPRAYDECK
ThereisazipperontheshipwithSpray
deck.Afterpullingit,youcanputthe
aluminumtubebrackettosupportthe
skeletonoftheSpraydeck.
A-Tube
B-Tube
Thespraydeckismadeof70dripstop
nylontpucoating,verythinandlight,do
notgraborsitonthespraydeck!
Thespraydeckhasanemergencypull-out
handlenearthelefthandforescapeafter
boarding.
Thespraydeckmustbestoredinadry
environment,otherwiseitwilllosethe
smoothnessandeventhetpucoating
peelingoff,whichisapermanentdamage
thatcannotberemedied!
EMERGENCYPULL-OUTHANDLE
EMERGENCYPULL-OUTHANDLE
EMERGENCYPULL-OUTHANDLE
5
TheAtubeisplacedinthesleeveatthe
frontandrearends,andtheBtubeis
placedontheleftandrightsidesand
thetopisconnectedtotheinsideofthe
Atubetosupportacircularshape.
Afterinstallingthealuminumtubeframe,
usetheelasticcoilatthebottomofAto
enclosethealuminumtubeframe.A
simplestepisrequiredandAisinstalled.
Openzipper
1.STEP ONE
2.STEP TWO
Closezipper
3.STEP THREE
4.STEP FOUR
Theredescapehandlemustbeleftoutside!

INSTALLTHIGHSTRAPS
Theroleofthethightstrapisto
enhancethepaddler'sabilitytocontrol
thehullinthewaves.
Connectingpullring
1.STEP ONE
ConnectAandCtothehull(asshown
inthefollowingfigure),adjusttheAC
first,thenconnectB.Aisalargeone,C
isasmallone.
B
AC
Fixedlegposition
2.STEP TWO
Thepaddlersitsintheboat,adjuststhe
bodytoacomfortableandnatural
posture,bendstheknees,andraisesthe
calfslightly.Atthesametime,adjusts
thelengthofthelegbeltsAandC,so
thatthethightstrapcanholdtheknees
andthekneesforceinward.Theforce
canbetransmittedtothehullthrough
thethightstraps,andthenthelengthof
theB-legstrapcanbeadjustedto
increasetheeffectonthehullcontrol.
Liftingmethod:Straightenyourknees
andquicklyreleasethetractionofthe
thightstraps.
6
ABC
B
AC

INSTALLTHIGHSTRAPS-PRO
Theprofessionalversionoftheleg
strapmakesiteasierandmoreaccurate
toadjustthekneeposition,andit
deliverscontrolmoredirectly.The
connectionpointsB1andB2eachhave
6holes,whichcanbeselectedforthe
kneeposition.
FACADE REVERSESIDE
OnlytheAlligator2SPROcomeswiththighstraps-PRO
1 2
43
1
Turnthehookbackfromtoptobottom.
Easilyhangintotheholewiththe
inclinedsurfaceonthebackofthehook.
Flipthehook180°frombottomtotop,
Holdthehookinthepositivedirection
andalignitwiththeappropriatehole.
2
3
4
7
A
B1
B2
C

CAUTION
1
PSI
STOREAFTERDRYING PREVENTINSOLATION NOWATERINLET
OPTIMUMAIR
PRESSURE1PSI
Nearthelefthandsideofthesprayskirt(Inforntofthe
W-typespraydeck),thereisanemergencyrelease
handle,whichisusedtoescapeafterturningover.
ThecushionandbackrestaremadeofTPUnylonmesh.
Itisnecessarytopayattentiontothesunexposure.
Transitionalexpansionwilldamageitswelding.
Sprayskirtmustbestoredindryenvironment,
otherwiseitwilllosethesurfacegloss,andeventhe
TPUlayerwillfalloff,whichcannotberemedied.
Afterrowingonthewater,itisfoundthatthehullis
somewhatsoft.Thisisnotaleak,butacoldcontraction
ofthegasinthesleepingboatwhenthehulltouches
thesleepingboat.Atthistime,youneedtofilltheair
withyourmouth.
Itisrecommendedthatthisfolding
methodbereducedtosmallersizeand
betterforhullmaintenance.First,the
leftandrightsidesshouldbefolded
vertically,andthenbewrappedup
laterally.
QUICKFOLDING
8
(6.9kpa)
Pleaseleavetheemergencyreleasehandleoutside!

MRS'szippersystemsfeature
top-of-the-lineTIZIPzippers.
Rubberhead,long-term
storage,pleasebringsilicone
Tightness
TheTIZIPSuperSealispressuretestedwith700
mbarairpressure,appliedtothefrontsurfacein
cludingtheendstops.Thesliderengagespositively
intothedockingend. maycauseHeavybending
leakage.Pleasetrytoavoid!
Tightness
TherearetwooptionsfortheMRS
customISSseries.Oneisthezipperat
thebow/tail,andtheotherisinthe
middleoftheboat.Thefoldingboat
needstoavoidthezipperpositionto
preventtheairtightzipperfrom
bending.Theairtightzipperisfolded,
nottothecurvedzipperatalarge
angle.
1
2
9

ACCESSORIES PACKINGLIST
Comfortbackrest
(Onlybackrow)
Spraydeck Spraydeckframe
Iflationbag ISS Thighstraps-PRO Thighstraps
Straps Repairmaterial
Alligator2S
Alligator2SPRO
MicroPackraft
BarracudaR2PRO
BarracudaR2
NomadS1
NomadS1D
AdventureX2
Ponto
Tulo
Seatcushion Backrest SprayskirtSprayskirt
(Detachable)(Detachable)
Sprayskirt
(Detachable)
Spray
deck
Thigh
straps Repair
material
Inflation
bag Straps Spraydeck
frame ISS
Light
MODEL
Fin/Skeg
3Itypehigh(low)seat 2Itypehigh(low)seat Quickreleasebackrest
(Onlymiddle/frontrow)Lightbackrest (Onlybackrow)
MicroPackraft
ExtraLong
3Itype
Light
Light
Light
Comfort
Comfort
Quickrelease
Quickrelease
Quickrelease
Light&
Quickrelease
Comfort&
Quickrelease
Comfort&
10
3Itype
3Itype
3Itype
3Itype
3Itype
2Itype
2Itype
2Itype*2
2Itype*2
2Itype*2

MRSInstructionmanual2019
LISTOFDEALERSAROUNDTHEWORLD
Web:https://packraftnorge.no/
TEL:004748385523
Email:[e-mail]
Addr:PackraftNorgeAS,IverHesselbergsvei3,
3260,Larvik,Nor
Norway
Sweden
Germany
Finland
Japan
Web:https://packraft-sverige.se/
TEL:+46(0)761184701
Email:[e-mail]
Addr:PackraftSverigeKärnavägen4
58662LinköpingSweden
Web:www.packrafting-store.de
TEL:[phone]
Email:[e-mail]
Addr:AnfibioPackraftingStoreKörnerplatz3d
04107Leipzig,Germany
Web:www.melomo.fi
TEL:+358401634550
Emali:info@melomo.fi
Addr:MelomoOyAlppitie12
90530OuluFinland
Web:www.packrafting.biz
TEL:06-6195-7761
Email:mrs.packr[email protected]
Addr:1-1-26HIMESATO.NISHI-YODOGAWA-KU.
OSAKA.JAPAN
NewZealand
Web:furtherfaster.co.nz
TEL:0297721170
Email:[e-mail]
Addr:57ABuchanSt,Sydenham,
Christchurch8023,NewZealand
Chile
Korea
Web:www.packraft.cl
TEL:+56988200621
Emali:packr[email protected]
Addr:Maturana557,Santiago,Chile.
Web:https://cafe.naver.com/microrafting
TEL:82-10-7626-6007
Email:[e-mail]
Add: NO. 138, WU XING STREET, DA MIAN TOWN , LONG QUAN YI, CHENG DU , SI CHUAN,CHINA
http://www.mrsraftings.com E-mail: [email protected] After-sale : [email protected]
