MS JETS JR FELIX User manual

JR FELIX
Dear Customer, Thank you for purchasing our JR FELIX Sport jet pro uct.
Following you can fin greater information for buil ing an flying this mo el.
Before you get starte buil ing an setting-up your aircraft, please make sure
you have rea this Instruction manual an un erstoo it. If you have any
questions, please on’t hesitate to contact us.
Liability Exclusion an Damages you have acquire a kit, which can be
assemble into a fully working R/C mo el when fitte out with suitable
accessories,as escribe in the instruction manual with the kit.
However, as manufacturers, are not in a position to influence the way you
buil an operate your mo el, an we have no control over the metho s you
use to install, operate an maintain the ra io control system components. For
this reason we are oblige to eny all liability for loss, amage or costs which
are incurre ue to the incompetent or incorrect application an operation of
our pro ucts, or which are connecte with such operation in any way. Unless
otherwise prescribe by bin ing law, the obligation of our company to pay
compensation is exclu e , regar less of the legal argument employe .
This applies to personal injury, eath, amage to buil ings, loss of turnover
an business, interruption of business or other irect an in irect consequent
amages. In all circumstances our total liability is limite to the amount which
you actually pai for this mo el.
BY OPERATING THIS MODEL YOU ASSUME FULL RESPONSIBILITY FOR
YOUR ACTIONS.
It is important to un erstan that the factory, is unable to monitor whether you
follow the instructions containe in this instruction manual regar ing the
construction, operation an maintenance of the aircraft, nor whether you
install an use the ra io control system correctly. For this reason we are
unable to guarantee, or provi e, a contractual agreement with any in ivi ual
or company that the mo el you have ma e will function correctly an safely.
You, as operator of the mo el, must rely upon your own expertise an
ju gement in acquiring an operating this mo el.
1

Har ware Package;
Air intake installation;
Please follow below steps;
-Mark the fiberglass on the
fuselage.
-Cut the oracover for the air
intake.
-Tape well an be careful not
to have air leak.
-Use epoxy glue to
assemble fiberglass intake
2

AILERON, ELEVATOR, FLAP an RUDDER INSTALLATION:
In the har ware bag, you will fin all you nee to fix an link the hinges of the
Flaps an Ailerons:
The Flaps an ailerons are fixe with the hinges to the wing, use glue or
epoxy for hinges, take care not to put glue in the mi le of the hinges.
Install the servo in the servo support(Stan ar size servos with min 10kg
torque)
Glue the aileron Horn in place an check if all work ok.
Screw an a just the linkage at the exact imensions, neutral servo position,
please fix only if the servo position was teste to neutral, otherwise you risk
amage.
3

Cut the oracover for flap hinges an use epoxy glue.
Use san paper on the horn parts for better glue result.
4

Servo installation;
5

Wings fixing part;
Glue the fiberglass' 2,5cm part on the wing.
Use san paper on the fiberglas for better glue result.
Ru er Assembly;
-Use a carbon tube with epoxy glue for permanent fixing.
6

Stabiliser Fixing;
-Use a carbon tube with epoxy glue for permanent fixing.
Turbine Mount:
The turbine mount is prepare in the right angle to fix your Turbine
Move the Turbine as front as possible an fix it, here on picture per ex.with a
KingTech K70G engine.
To avoi amages on the fuselage ue wet starts, secure the fuselage behin
the turbine with alu-tape.
We recommen K70G for Sport flights. Also can use 40 to 70KgN turbines.
7

Use aluminum folio, which is inclu e in the
kit.
Fuel tank assembly;
(Optional 2lt fuel an hea er tank shown in the picture – not inclu e in the
kit.)
- If the fuel tank purchase seperately, wash with iesel fuel before use !
8

Canopy assembly;
Cut the canopy to fix,while the base part screwe on the fuselage. Use Patex
soft glue (or similar). Also use 8pcs 2,5 x 12mm screws - inclu e in the kit.
9

Retract Assembly;
Stick the plastic pools to the mi -wing with epoxy glue, than screw the
retracts with 12pcs
3 x 20mm screws inclu e in the kit.
We recommen spraying liqui grease oil
in the joints of Retracts time to time.
10

CG;
We recommen the c.g. position at 150mm as shown below; this will be
perfect as a starting point. We will recommen a justing after a few flights to
iscover your personal preference.
Recommen e Servo Throw Movement;
Aileron -12mm up/ own,
Elevator - 18mm up/ own,
Ru er - 30mm left/right,
Flap – 30mm in first position – 60mm in secon position.
Elevator - flap mix, on 60mm own flap, mix elevator own, 5mm
(Measurements are measure on the tips of aileron an elevator)
Attention: you must a just the movement, epen ing of your flying mo e
11

Recommen e Extension Cable Measurements; OPTIONAL (not inclu e in
the kit)
1- Mi -wing - 2 x 30cm for Aileron
1 x 30cm for Flap
2- Si ewings - 2 x 30cm
3- Ru er & 2pcs Elevator – 3 x 100cm
4- ECU -Throat Extention - 1 x 30cm
5- GSU ECU Extention – 1 x 30cm
6- Front Wheel Servo – 1 x 40cm
7- Pump Valve – 1 x 20cm
Gear an Steering Servo Installation:
Best is the electric retracts which is suplie as optional.
Suggeste servos: Stan ar size,
Aileron - Stan ar size 10kg
Flap - Stan ar size 15kg
Elevator - Stan ar size 10/13kg
Ru er – Mi i size 10kg (supplie as optional)
Front Gear Steering – Mini size 6kg (supplie as optional)
For other information, please contact; kingtech.t[email protected]
Please make safe flights an have a lot of fun with your JR Felix.
12
