MS Sedco 59-W Instruction manual

Product Name
59 Series
4 1/2" Square Push Plate Switches
Manufacturer
MS SEDCO
8701 Castle Park Drive
Indianapolis, IN 46256
Phone: [phone]
www.mssedco.com
Product Description
BASIC USE
The 59 Series push plate switches
are designed to provide reliable
activation of any automatic door.
The 59 Series features 4" square
face plates in either stainless
steel or blue powder coated alumi-
num with etched and paint filled
legends. A 4 1/2" square formed
stainless steel back plate elimi-
nates possible wall damage from
standard use.
Designed as a universal switch,
the 59 Series fit single-gang or
2-gang electrical boxes with no
adapters necessary. A surface
mount box is also available.
Each unit is built utilizing heavy
gauge stainless steel, aircraft
quality rivets and screws, durable
finishes and the most reliable
microswitch in the industry.
Technical Data
• 4" x 4" All Active Face Plate
• 4 1/2" x 4 1/2" Formed
Stainless Steel Back Plate
• UL Listed "Cherry Switch", SPDT,
Mom., 15 Amp @ 125V AC
• Rubber “Bellows” Increases
Weather Protection (included)
• Fits single or 2-gang Electrical
Box or MS SEDCO #1015
Surface Mount Box
• Special Finishes: US3, US4,
US10, US10B, US32
• Radio Control Versions
Available
DIMENSIONS
See Reverse
APPLICABLE STANDARDS
American National Standards
Institute (ANSI) - Building Hard-
ware Manufacturers Association
(BHMA) - ANSI/BHMA A156.10 &
A156.19.
APPROVALS
UL (Micro-Switch)
Installation
The 59 Series Switch is easy to
install.
Hardwired Applications:
Mount to a standard single or
2-gang electrical box at the
desired wall location. Remove the
face plate from the switch assem-
bly. Connect the necessary signal
wires to the appropriate switch
contacts (COM & N.O. are stan-
dard). Secure the switch assem-
bly to the electrical box and
reattach the face plate.
59 Series
4 1/2" Square
Push Plate Switches
8701 Castle Park Drive Indianapolis, Indiana 46256 Telephone: [phone] Fax: [phone]
www.mssedco.com [e-mail]
#59-H (Blue Powder Coat with White Paint
Filled Legend)
#59-P (Stainless Steel with Black Paint
Filled Legend)
#59-HSS (Stainless Steel with Blue Paint
Filled Legend)
#59-W (Blue Powder Coat with White
Paint Filled Legend)
#59-WSS (Stainless Steel with Blue Paint
Filled Legend)
NOT SHOWN
#59-Plain (Stainless Steel with No
Legend)
PRESS
TO OPERATE
DOOR
PRESS
TO
OPERATE
DOOR
PRESS
TO OPERATE
DOOR
22006
ClearPath
™
ClearPath™ Radio Control Switches
with HDRC™ solve problems caused
by interference and stray signals —
and are guaranteed to work where
others won't.

Installation (continued)
Wireless Applications:
Mount a ClearPath™ transmitter
and surface mounting box in the
desired location. Program the
transmitter and connect the wire
leads to the COM and N.O. switch
contacts. Attach the wall switch
assembly to the surface box and
reattach the face plate.
Custom Applications:
The 59 Series Switches can be
customized in a variety of ways.
Virtually any legend can be placed
on the face plate as well as
custom colors or finishes. Contact
the factory for pricing.
Availability & Cost
AVAILABILITY
Available internationally from
manufacturer's authorized dist-
ributors; contact MS SEDCO for
the location of nearest distributor.
COST
Cost information on MS SEDCO
products is available from the
manufacturer's authorized
distributors.
Warranty
MS SEDCO, Inc. guarantees this
product to be free from manufac-
turing defects for three years from
date of installation. Unless MS
SEDCO is notified of the date of
installation, the warranty will be in
effect for three years from the
date of shipment from our factory.
If, during the first three years, this
product fails to operate and has
not been tampered with or
abused, the unit can be returned
prepaid to the factory and be
repaired free of charge. After
three years, the unit will be
repaired for a nominal service
charge. Limited warranty is in
lieu of all other warranties,
expressed or implied, including
any implied warrantability of
merchantability. No representa-
tive or person is authorized to
assume for MS SEDCO any other
liability in connection with the
sale of our products. All warran-
ties are limited to the duration of
this written limited warranty. In
no event shall MS SEDCO be
liable for any special, incidental,
consequential or other damage
arising from any unclaimed
breach of warranty as to its prod-
ucts or services.
Maintenance
MS SEDCO recommends that all
maintenance and adjustments be
performed by an AAADM Certified
Technician.
DIMENSIONS
Technical Services
MS SEDCO's staff of factory
trained sales and service person-
nel offer design assistance and
technical support. Local distribu-
tors are also available to assist in
selecting appropriate devices for
specific uses and to provide onsite
installation.
BELLOWS DIAGRAM
8701 Castle Park Drive Indianapolis, Indiana 46256 Telephone: [phone] Fax: [phone]
www.mssedco.com [e-mail]
4 1/2"
4"
4 1/2" 5/8"
3/4"
22006
59 Series
4 1/2" Square
Push Plate Switches
MICRO-SWITCH
COM
N.C. N.O.
INCLUDED
Rubber Bellows
Insert rubber bellows
over spring on
exterior switches for
weather tight fit!
