MSH CX300 Manual
1. Attach CX300TU to the TU using double sided tape.
CX300
User and Installation Guide
Installation:
7. Connect handset extension cable for CX300TU to the“EXTENSION PORT”
8. Connect AC/DC power supply to the “DC PWR” port on the CX300HS.
Features:
• Digital communication signal conditioning allowing for extended cable
runs up to 3,000 feet using standard CAT5/CAT5E/CAT6 cables.
• Audio signal conditioning to both the TU/handset speaker and microphone
signals thus signicantly decreasing audio quality noise eects due to
long cable length runs.
• Compatible and guaranteed to work with DT201, DT230, DT240, DT240A &
DT250 handsets (DT-200 and DT-220 require modications)
• Only handset extension system tested and veried by the handset original
equipment manufacturer that the handset operation is not aected.
• Will not void warranty of DT200, DT201, DT220, DT230, DT240, DT240A &
DT250 handsets.
6. Connect handset extension connecters per Figure a*
5. Run handset extension cable from the CX300TU to the CX300HS location.
4. Connect Handset Extension cable for CX300HS to the
“HANDSET EXTENSION” port.
2. Connect the communications cable between the CX300TU’s “TU HANDSET”
to the Hughes 2100 handset port.
3. Install CX200HS at desired location.
All images and text are the property of MSH Technologies, Inc. Copy material contained within this doucment in whole or
in part is not authorized without prior written permission form MSH Technologies, Inc. Copyright (C) 2012, all rights reserved.
All images and text are the property of MSH Technologies, Inc. Copy material contained within this doucment in whole or
in part is not authorized without prior written permission form MSH Technologies, Inc. Copyright (C) 2012, all rights reserved.
Important: Wire handset extension
cable per Figure a. Cable wiring is
non-standard. Improper wiring will
cause system to not function properly.
gure a
Use only interconnect cables provided
by MSH Technologies, Inc. to connect
the CX300TU to the Hughes 2100 TU.
Operation:
Aer the CX300 system is installed and power is on, normal handset
operaon is enabled. Power indicator on the front panel should be on. To
turn on the Hughes 2100 TU, follow the instrucons provided with the Hughes
2100 TU with the following excepon - the handset is connected to the Hughes
2100 TU through the CX300 handset extension system.
Note there are no installaon adjustements or user seng required,
this is a plug and play system
Except as specified above, products sold hereunder shall be free from defects in materials and workmanship and shall conform to MSH Technologies, Inc.
(MSH) published specificaons or other Specificaon’s accepted in wring by MSH Technologies, Inc. for two years from the date of purchase. The foregoing
warranty does not apply to any products which have been subject to misuse, neglect, accident modificaon or alteraon including disassembly of the product.
MSH Technologies, Inc. sole obligaon for products failing to comply with this warranty shall be, at MSH Technologies, Inc. discreon, to either replace the
nonconforming product or issue Buyer credit for the purchase price of the nonconforming product where, within the warranty period and in accordance with
MSH return procedures: (1) MSH has received Buyer's request for a Return Merchandise Authorizaon (RMA) for the return of nonconforming product;
(2) where MSH has issued Buyer a RMA; (3) Buyer has returned the nonconforming product to MSH in accordance with MSH’s return procedures; and
(4) MSH has determined that the product is nonconforming and such nonconformity is not the result of improper installaon, repair or other misuse.
THE FOREGOING WARRANTY AND REMEDIES ARE EXCLUSIVE AND MSH TECHNOLOGIES, INC. HEREBY DISCLAIMS ALL OTHER WARRANTIES, EXPRESSED,
IMPLIED OR OTHERWISE, INCLUDING WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT OF INTELLECTUAL
PROPERTY RIGHTS. MSH TECHNOLOGIES, INC.DOES NOT ASSUME OR AUTHORIZE ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN
CONNECTION WITH ITS PRODUCTS. IN NO EVENT SHALL MSH TECHNOLOGIES, INC. BE LIABLE TO BUYER, OR ANY SUBSEQUENT PURCHASER OF ANY
PRODUCTS FURNISHED TO BUYER, INCLUDING THE ULTIMATE END-USER, IN CONTRACT, TORT, WARRANTY, STRICT LIABILITY, OR OTHERWISE FOR ANY
SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO, THE COST OF LABOR, REQUALIFICATION, DELAY, LOSS OF
PROFITS OR GOODWILL, EVEN IF THE EXCLUSIVE REMEDIES PROVIDED HEREIN FAIL OF THEIR ESSENTIAL PURPOSE AND EVEN IF MSH TECHNOLOGIES, INC.
`IS ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Warranty:
LIMITATION OF LIABILITY:
IN NO EVENT SHALL MSH TECHNOLOGIES, INC BE LIABLE TO BUYER, OR ANY SUBSEQUENT PURCHASER OF ANY PRODUCTS FURNISHED TO BUYER,
INCLUDING THE ULTIMATE END-USER IN CONTRACT, TORT, WARRANTY, STRICT LIABILITY, OR OTHERWISE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO, THE COST OF LABOR, REQUALIFICATION, DELAY, LOSS OF PROFITS OR GOODWILL, EVEN IF
THE EXCLUSIVE REMEDIES PROVIDED HEREIN FAIL OF THEIR ESSENTIAL PURPOSE AND EVEN IF MSH TECHNOLOGIES, INC. IS ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. THE LIABILITY OF MSH TECHNOLOGIES, INC. WITH RESPECT TO THE SALE OF PRODUCTS OR FROM THE DISPOSITION OR USE OF ANY
PRODUCT FURNISHED HEREUNDER, WHETHER IN CONTRACT, TORT, WARRANTY, STRICT LIABILITY, OR OTHERWISE SHALL NOT EXCEED THE PURCHASE PRICE
PAID FOR THE RELEVANT PRODUCTS. THE FOREGOING LIMITATION SHALL APPLY EVEN IF THE ABOVE STATED EXCLUSIVE REMEDIES FAIL OF THEIR
ESSENTIAL PURPOSE
