MSI K8NNeo2-FX Series User manual

i
English/French/German
Version
G52-M7025XC
MS-7025(v1.X)ATXMainboard
K8NNeo2-FXSeries

ii
ManualRev:1.4
ReleaseDate:Mar,2005
FCC-BRadio Frequency Interference Statement
Thisequipment hasbeen testedandfoundtocomplywiththelimitsforaclassB
digital device,pursuanttopart15ofthe FCCrules.Theselimitsaredesigned to
providereasonableprotection againstharmful interferencewhentheequipmentis
operated inacommercial environment.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyand,if notinstalledand usedinaccordancewiththe
instructionmanual,maycauseharmfulinterferencetoradiocommunications.Operation
ofthisequipment in aresidentialarea islikelytocauseharmful interference, inwhich
casetheuserwill berequiredtocorrecttheinterferenceathisownexpense.
Notice1
Thechangesormodificationsnotexpresslyapprovedbythepartyresponsiblefor
compliancecould void theuser sauthoritytooperatetheequipment.
Notice2
Shielded interfacecablesandA.C.powercord,if any,mustbeusedin orderto
complywiththeemissionlimits.
VOIRLANOTICED INSTALLATIONAVANT DERACCORDERAURESEAU.
Micro-StarInternational
MS-7025
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe
followingtwoconditions:
(1)thisdevicemaynotcauseharmful interference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethat
maycauseundesiredoperation

iii
CopyrightNotice
The materialin thisdocumentistheintellectualpropertyof MICRO-STAR
INTERNATIONAL.Wetakeeverycarein thepreparationof thisdocument, butno
guaranteeisgivenastothe correctness of itscontents.Ourproductsareunder
continualimprovementand wereservetherighttomakechangeswithoutnotice.
Trademarks
Alltrademarksarethepropertiesoftheirrespectiveowners.
AMD,Athlon™,Athlon™XP, Thoroughbred™,and Duron™areregistered
trademarksofAMDCorporation.
Intel®andPentium®areregisteredtrademarksofIntelCorporation.
PS/2and OS®/2areregistered trademarks of InternationalBusinessMachines
Corporation.
Microsoftisaregistered trademarkofMicrosoft Corporation.Windows®98/2000/NT/
XPareregistered trademarks ofMicrosoftCorporation.
NVIDIA, theNVIDIAlogo,DualNet,and nForceareregisteredtrademarksortrade-
marksof NVIDIACorporationin theUnitedStatesand/orothercountries.
Netware®isaregisteredtrademarkofNovell,Inc.
Award®isaregisteredtrademarkofPhoenixTechnologiesLtd.
AMI®isaregistered trademarkofAmerican MegatrendsInc.
Kensingtonand MicroSaverareregistered trademarks of theKensingtonTechnology
Group.
PCMCIAand CardBusareregisteredtrademarks of thePersonalComputerMemory
CardInternationalAssociation.
RevisionHistory
Revision RevisionHistory Date
V1.0 FirstreleaseforPCB1.X July2004
withnVidianForce3Ultra(Platinum)
V1.1 FirstreleaseforPCB1.X July2004
withnVidianForce3Ultra(Platinum)
ForEuropeanmanuals
V1.2 FirstreleaseforPCB1.X Dec.2004
withnVidia nForce3 Ultra(Standard)
V1.3 FirstreleaseforPCB1.X Mar.2005
withnVidianForce3-250Gb
V1.4 FirstreleaseforPCI 1.X Mar.2005
withnVidianForce3-250Gb
ForEuropeanmanuals

iv
1. Alwaysread thesafetyinstructionscarefully.
2. KeepthisUser sManualforfuturereference.
3. Keepthisequipmentawayfromhumidity.
4. Laythisequipmentonareliableflatsurfacebeforesetting itup.
5. Theopeningsontheenclosureareforairconvectionhenceprotectstheequip-
mentfromoverheating.Donotcovertheopenings.
6. Makesurethevoltageofthe powersourceand adjust properly110/220Vbe-
foreconnectingtheequipmenttothepowerinlet.
7. Placethepowercordsuchawaythatpeoplecannotstepon it. Donotplace
anythingoverthepowercord.
8. AlwaysUnplugthe PowerCordbeforeinsertinganyadd-on cardormodule.
9. All cautionsand warningsontheequipmentshouldbenoted.
10. Neverpouranyliquidintotheopeningthatcoulddamageorcauseelectrical
shock.
11. If anyof thefollowing situationsarises, gettheequipmentcheckedbyaservice
personnel:
†Thepowercordorplug isdamaged.
†Liquidhaspenetratedintotheequipment.
†Theequipmenthasbeenexposedtomoisture.
†Theequipment hasnot workwell oryoucannotget itworkaccording to
User sManual.
†Theequipmenthasdroppedanddamaged.
†Theequipmenthasobvioussign of breakage.
12.Donotleavethisequipmentin anenvironmentunconditioned,storage
temperatureabove 600 C(1400F),itmay damagetheequipment.
SafetyInstructions
CAUTION:Dangerofexplosionifbatteryisincorrectlyreplaced.
Replaceonlywiththesameorequivalenttyperecommended bythe
manufacturer.
TechnicalSupport
Ifaproblemariseswithyoursystemandnosolutioncanbeobtainedfromtheuser s
manual,pleasecontactyourplaceofpurchaseorlocal distributor.Alternatively,
pleasetrythefollowinghelp resourcesforfurtherguidance.
†VisittheMSIhomepage &FAQsitefortechnical guide,BIOSupdates,driver
updates,and otherinformation: http://www.msi.com.tw & http://www.msi.
com.tw/program/service/faq/faq/esc_faq_list.php
†Contactourtechnicalstaffat: [e-mail]

v
CONTENTS
FCC-B RadioFrequencyInterferenceStatement......................................................ii
CopyrightNotice.......................................................................................................iii
RevisionHistory.......................................................................................................iii
TechnicalSupport....................................................................................................iv
SafetyInstructions..................................................................................................iv
English..............................................................................................................E-1-1
1.GettingStarted.........................................................................................E-1-3
2. HardwareSetup.......................................................................................E-2-1
3.BIOSSetup...............................................................................................E-3-1
Français...............................................................................................................F-1
Manueldutilisation..........................................................................................F-3
Deutsch...............................................................................................................G-1
Benutzerhandbuch.........................................................................................G-3

E-1-1
GettingStarted
E-1-1
K8NNeo2-FX
(MS-7025 v1.X)
ATXmainboard
English

E-1-2
MS-7025 ATXMainboard

E-1-3
GettingStarted
Chapter1.Getting
Started
Thankyouforchoosing the K8NNeo2-FX (MS-7025)v1.X
ATXmainboard.The K8NNeo2-FX mainboardisbasedon nVIDIA
nForce™3250Gb chipset foroptimal systemefficiency.Designed
tofittheadvanced AMD K8Athlon 64 FX/Athlon 64 processor,
the K8NNeo2-FX mainboarddeliversahigh performanceand pro-
fessionaldesktopplatformsolution.
GettingStarted

E-1-4
MS-7025 ATXMainboard
MainboardSpecifications
CPU
†SupportsSocket-939forAMDK8Athlon 64FX/Athlon64(Socket939)processor
†Supportsupto3500+, 3800+Athlon64FX53,orhigherCPU
(ForthelatestinformationaboutCPU,pleasevisit http://www.msi.com.tw/program/
products/mainboard/mbd/pro_mbd_cpu_support.php)
Chipset
†nVIDIAnForce3 250Gb
-HyperTransport linktotheAMDAthlon64/Athlon64 FXCPU
-HyperTransportsupporting speedupto800MHz(1600MT/s)
-AGP3.08Xinterfaceat533 MT/s(milliontransferspersecond)
-TwoindependentSATAcontrollers,forfourdrives
-IEEE802.3nVIDIAMACfor1000BASE-T
-DualFast ATA-133 IDEcontrollers
Main Memory
†Supportsdualchannel,eightmemorybanks DDR 266/333/400,usingfour184-
pinDDRDIMMs
†Supportsamaximummemorysizeupto4GB
†Supports2.5vDDR SDRAMDIMM
(Fortheupdatedsupporting memorymodules, pleasevisit http://www.msi.com.tw/
program/products/mainboard/mbd/pro_mbd_trp_list.php.)
Slots
†OneAGP(AcceleratedGraphics Port)slot
-AGPspecificationcompliant
-SupportsAGP3.08x
†Five32-bitMasterPCIBusslots,includesoneorangeslotwhichisreservedas
acommunicationslot.
†Support3.3V/5VPCIbusInterface
On-BoardIDE
†AnIDEcontrolleronthenVIDIA nForce3-250GbchipsetprovidesIDEHDD/CD-
ROMwithPIO,BusMasterandUltraDMA66/100/133 operationmodes
†Can connect upto4IDEdevices
On-BoardSATA
†Supports4SATAports. Transferrateisup to150MB/s.
USBInterface
†8USBports
-ControlledbynForce3-250Gbchipset
-4portsin therearI/O,4portsviatheexternalbracket

E-1-5
GettingStarted
NVRAID(Software)
†Supportsup to4SATAand 4ATA133 Harddrives
-RAID0or1,0+1,JBODissupported
-RAIDfunction availableforATA133+SATAH/Ddrives
LAN
†SupportsLANjack
-1stLANsupports10/100/1000 FastEthernetbyMarvell 88E1111
Audio
†ChipintegratedbyRealtekALC850 (7.1chS/Waudio)
-Direct SoundAC97audio
-7.1Channeloutput
-1CD-In
On-BoardPeripherals
†On-BoardPeripheralsinclude:
-1floppyport supports1FDD with360K, 720K,1.2M,1.44Mand 2.88Mbytes
-1serialport(COM1)
-1parallelport supportingSPP/EPP/ECPmode
-1Audiojack(5-in-1), coaxial/fiberSPDIFout
-1IrDApinheader
-1D-Bracket2pinheader
-3IEEE1394s(Rear*1/Front*2)
-8USB1.1/2.0ports(Rear*4/ Front *4)
BIOS
†ThemainboardBIOSprovides “Plug &Play”BIOSwhichdetectstheperipheral
devicesandexpansioncardsoftheboardautomatically.
†ThemainboardprovidesaDesktopManagementInterface(DMI)functionwhich
recordsyourmainboardspecifications.
†SupportsbootfromLAN,USBDevice1.1&2.0,andSATAHDD.

E-1-6
MS-7025 ATXMainboard
MSIRemindsYou...
1.Pleasenotethatuserscannotinstall OS,eitherWinMEorWin98,in
theirSATAharddrive.UnderthesetwoOSs, SATAcan onlybe used
asanormalstorage device.
2.TocreateabootableRAIDvolumeforaWindows2000environment,
Microsoft sWindows2000 ServicePack 4(SP4)isrequired.Asthe
endusercannotbootwithoutSP4,acombination installation CD
mustbecreatedbeforeattempting toinstalltheoperatingsystem
ontothe bootableRAIDvolume.
Tocreatethe combination installation CD,pleaserefertothefollow-
ingwebsite:
http://www.microsoft.com/windows2000/downloads/
servicepacks/sp4/HFdeploy.htm
Dimension
†ATXFormFactor(30.4cmX24.4cm)
Mounting
†9mounting holes

E-1-7
GettingStarted
MainboardLayout
K8NNeo2-FXSeries(MS-7025 v1.X) ATXMainboard
JPW1
DIMM1
DIMM3
DIMM4
DIMM2
I
D
E
1
I
D
E
2
A
T
X
1
S
A
T
A
2
SATA4
SATA1
SATA3
PCISlot3
PCISlot2
PCI Slot1
PCI Slot4
PCI Slot5
JUSB1
JUSB2
C
P
U
F
A
N
1
N
B
F
A
N
1
SFAN1
JFP1
JDB1
JIR1
JFP2
JCI1
BATT
+
F
D
D
1
JBAT1
JAUD1
BIOS
AGP1
JCD1
Winbond
W83627HF
88E1111-RCJ
Top:mouse
Bottom:keyboard
USBports
T:LAN jack
B:USBports
T:
M:
B:
Line-In
Line-Out
Mic
T:RS-Out
M:CS-Out
B:SPDIFOut
Top:ParallelPort
Bottom:
COM1
SPDIF-out
(Coaxial)
Codec
S
F
A
N
2
NVIDIA
nForce3
-250Gb

E-2-1
HardwareSetup
Chapter2. HardwareSetup
ThischaptertellsyouhowtoinstalltheCPU,memorymodules,
and expansioncards,aswell ashowtosetupthejumpersonthe
mainboard.Also,itprovidestheinstructionsonconnecting theperiph-
eral devices, suchasthemouse,keyboard,etc.
Whiledoing theinstallation,becarefulinholdingthecompo-
nentsand followthe installationprocedures.
HardwareSetup

E-2-2
MS-7025 ATXMainboard
Quick ComponentsGuide
BIOS
DDR DIMMs,
p.2-7
JDB1, p.2-21
JFP1, p.2-19
BackPanel
I/O, p.2-12
JPW1, p.2-10
IDE1/2, p.2-17
ATX1, p.2-10
JFP2, p.2-19
AGP Slot, p.2-25
PCISlots1~5,
p.2-25
JUSB1,JUSB2, p.2-19
SATA2,SATA1,
p.2-18
SATA3,SATA4,
p.2-18 NB_FAN1,
p.2-16
CPUFAN1, p.2-16
JAUD1, p.2-20
JBAT1, p.2-24
FDD1, p.2-16
SFAN2, p.2-16
SFAN1, p.2-16
JIR1, p.2-20
JCD1, p.2-18
JCI1, p.2-17

E-2-3
HardwareSetup
Central ProcessingUnit:CPU
ThemainboardsupportsAMD Athlon64processor. The mainboardusesaCPUsocket
calledSocket-939 foreasyCPUinstallation.Whenyou areinstalling theCPU, make
suretheCPUhas aheatsinkandacoolingfanattachedon thetop to
preventoverheating. If youdonothavetheheatsinkand cooling fan,contactyour
dealertopurchaseand install thembeforeturning onthecomputer.
Forthe latestinformationaboutCPU,pleasevisit http://www.msi.com.tw/program/
products/mainboard/mbd/pro_mbd_cpu_support.php.
MSIRemindsYou...
Overheating
Overheatingwill seriouslydamagethe CPUand system, always make
surethecoolingfancanworkproperlytoprotectthe CPUfrom
overheating.
Replacing theCPU
While replacing theCPU,alwaysturnoffthe ATXpowersupplyor
unplugthepowersupply spowercordfromgroundedoutletfirstto
ensurethe safetyofCPU.
Overclocking
Thismotherboardisdesignedtosupportoverclocking. However,please
makesureyourcomponentsareabletotoleratesuchabnormal setting,
whiledoing overclocking.Anyattempttooperatebeyondproductspeci-
ficationsisnotrecommended. Wedonotguaranteethedamages
orriskscausedbyinadequateoperationorbeyondproduct
specifications.

E-2-4
MS-7025 ATXMainboard
CPUInstallation ProceduresforSocket939
1. Pleaseturnoffthepowerand
unplug thepowercordbefore
installing the CPU.
2. Pulltheleversidewaysaway
fromthe socket.Makesureto
raisetheleverup toa90-de-
greeangle.
3.Lookforthe goldarrow.Thegold
arrowshouldpointasshownin
the picture.TheCPUcanonlyfit
in thecorrect orientation.
4.If theCPUiscorrectlyinstalled,
thepinsshould becompletely
embeddedintothesocketand
cannotbeseen.Pleasenote
thatanyviolation ofthe correct
installationproceduresmay
causepermanentdamagesto
yourmainboard.
5. Press theCPUdownfirmlyinto
thesocketandclosethelever.
AstheCPUislikelytomovewhile
theleverisbeingclosed,al-
waysclosetheleverwithyour
fingerspressingtightlyon top of
the CPUtomakesurethe CPUis
properlyand completelyembed-
dedintothesocket.
OpenLever
90degree
Sliding
Plate
Goldarrow
Goldarrow
Goldarrow
CorrectCPUplacement
IncorrectCPUplacement
X
O
Close
Lever
Press down
theCPU
Goldarrow

E-2-5
HardwareSetup
Installing AMDAthlon64 CPUCoolerSet
Whenyouareinstallingthe CPU, make suretheCPUhas aheatsinkanda
cooling fanattachedon thetop topreventoverheating. If youdonothavethe
heatsinkandcoolingfan,contactyourdealertopurchaseandinstallthembefore
turning onthecomputer.
1.Detachtheshield of thebackplate’s
paster.
2.Turnoverthemainboard,and install
thebackplatetotheproperposition.
3.Turnoverthemainboardagain,and
placethemainboardontheflat
surface.
Locatethetwoscrewholesofthe
mainboard.
4.Aligntheretention mechanismand
thebackplate.
Fixtheretentionmechanism and the
backplatewithtwoscrews.
retentionmechanism

E-2-6
MS-7025 ATXMainboard
6.LocatetheFixLever, SafteyHook
and theFixedBolt.
Liftup theintensivefixedlever.
5.Position the cooling setontothere-
tentionmechanism.
Hookoneendofthe cliptohookfirst,
andthenpressdowntheotherend
of theclip tofasten the coolingset on
thetopoftheretentionmechanism.
7.Fastened downthe lever.
8.Makesurethesafetyhookcompletely
claspsthefixedboltoftheretention
mechanism.
SafetyHook
Fixed Bolt
Fixed Lever
9.AttachtheCPUFancabletotheCPU
fanconnectoronthemainboard.
MSIRemindsYou...
Whiledisconnecting the SafetyHookfromthefixed bolt, itisneces-
sarytokeepaneyeonyourfingers,becauseoncetheSafetyHookis
disconnected fromthefixed bolt,thefixed leverwill spring back instantly.

E-2-7
HardwareSetup
DIMM ModuleCombination
Install atleast oneDIMM moduleontheslots. EachDIMMslotsupportsup toamaximum
sizeof1GB.Userscaninstall eithersingle-ordouble-sidedmodulestomeettheir
ownneeds.Pleasenotethat eachDIMMcanworkrespectivelyforsingle-
channelDDR,buttherearesome rules whileusing dual-channelDDR (Please
refertothe suggestedDDRpopulation tablebelow).Usersmayinstallmemorymodules
of differenttypeand densityondifferent-channelDDR DIMMs.However,the same
typeanddensitymemorymodules arenecessarywhileusing dual-channelDDR,
orinstabilitymayhappen. Pleaserefertothefollowingtable fordetailed dual-channel
DDR.Othercombinationnotlistedbelowwill functionassingle-channelDDR.
Memory
DIMM1~4
(frombottomtotop)
IntroductiontoDDR SDRAM
DDR(DoubleDataRate)SDRAMissimilartoconventionalSDRAM,butdoublesthe
ratebytransferringdatatwicepercycle.It uses2.5voltsasopposed to3.3volts
used inSDR SDRAM, andrequires184-pinDIMMmodulesratherthan168-pin DIMM
modulesusedbySDRSDRAM.HighmemorybandwidthmakesDDRan idealsolution
forhighperformancePC,workstationsand servers.
The mainboardprovides4slotsfor184-pin DDRSDRAMDIMM(DoubleIn-LineMemory
Module)modulesandsupportsthememorysizeupto4GB. YoucaninstallDDR266/
333/400/433/466/500/533modulesontheDDRDIMMslots(DDR1~4).
Forthe updated supporting memorymodules,pleasevisit http://www.msi.com.tw/
program/products/mainboard/mbd/pro_mbd_trp_list.php.

E-2-8
MS-7025 ATXMainboard
RecommendedMemory Combination List
S:SingleSide D:DoubleSide
DDR400
DIMM2 DIMM3DIMM4
S
DIMM Slots
MaxSpeed
- -
S
-
D-
-
D-
-
S
-
S
DDR400
DDR400
DDR400
DDR333
DDR400
DDR400
DDR400
DDR400
DDR400
DDR333
DDR400
DIMM1 -
--
--
-
S
SSS
- - S S
D
DD D
S - S -
D - D -
D D - -
- - D D
Green
MSIRemindsYou...
-Dual-channel DDRworks ONLY inthe3combinationslistedin
the tableshowninthe previouspage.
-Pleaseselecttheidentical memorymodulestoinstall on thedual
channel,and DONOTinstallthree memorymoduleson three
DIMMs,oritmaycausesomeunkonwnfailure.
-AlwaysinsertthememorymodulesintotheGREENslotsfirst, and
itisstronglyrecommended nottoinsertthe memorymodulesinto
the PURPLEslotswhilethe GREENslotsareleft empty.
-ThismainboardDONOTsupportthememorymoduleinstalled
withmorethan 18piecesofIC(integratedcircuit).
Green
Purple Purple
DIMM1(ChA) DIMM2(ChB) DIMM3(ChA) DIMM4(ChB) SystemDensity
128MB~1GB 128MB~1GB 256MB~2GB
128MB~1GB 128MB~1GB 256MB~2GB
128MB~1GB 128MB~1GB 128MB~1GB 128MB~1GB 512MB~4GB
GREEN PURPLE
GREEN PURPLE
