MSI IFC-815N2D Series User manual

i
IFC-815N2D Mainboard
I52-815N2D
IFC-815N2D Series
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

ii
CopyrightNotice
The materialinthisdocumentistheintellectual propertyof MICRO-STAR
INTERNATIONAL.Wetakeeverycareinthe preparationof thisdocument, butno
guaranteeisgivenastothecorrectnessofitscontents.Ourproductsareunder
continualimprovementand wereservetherighttomakechangeswithoutnotice.
Trademarks
Alltrademarksarethepropertiesoftheirrespectiveowners.
Intel andPentium areregisteredtrademarksofIntelCorporation.
AMD,Athlon™,Athlon™XP,Thoroughbred™,andDuron™areregistered trade-
marksofAMDCorporation.
NVIDIA, theNVIDIAlogo,DualNet,and nForceareregisteredtrademarksortrade-
marksof NVIDIACorporationin theUnitedStatesand/orothercountries.
PS/2and OS /2areregisteredtrademarks ofInternationalBusiness Machines
Corporation.
Windows 98/2000/NT/XP/Vistaareregisteredtrademarksof MicrosoftCorporation.
Netware isaregisteredtrademarkofNovell,Inc.
Award isaregisteredtrademarkofPhoenixTechnologiesLtd.
AMI isaregistered trademarkofAmerican MegatrendsInc.
RevisionHistory
Revision RevisionHistory Date
V1.0 Firstrelease November2008
TechnicalSupport
Ifaproblemariseswithyoursystemandnosolutioncanbeobtainedfromtheuser’s
manual,pleasecontactyourplaceofpurchaseorlocaldistributor.Alternatively,
pleasetrythefollowing helpresourcesforfurtherguidance.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

viii
CONTENTS
CopyrightNotice..............................................................................................................ii
Trademarks.......................................................................................................................ii
RevisionHistory..............................................................................................................ii
Technical Support...........................................................................................................ii
SafetyInstructions.........................................................................................................iii
FCC-B RadioFrequencyInterferenceStatement........................................................iv
WEEE(WasteElectricalandElectronicEquipment)Statement....................................v
Chapter1ProductOverview................................................................................1-1
MainboardSpecifications...................................................................................1-2
BlockDiagram.......................................................................................................1-5
MainboardLayout................................................................................................1-6
BoardDimension..................................................................................................1-9
BackPanel &I/OShield Drawing......................................................................1-10
PowerConsumption..........................................................................................1-13
SafetyCompliance&MTBF..............................................................................1-15
Chapter2HardwareSetup....................................................................................2-1
Quick ComponentsGuide....................................................................................2-2
Memory.................................................................................................................2-3
PowerSupply......................................................................................................2-4
BackPanel I/O......................................................................................................2-5
Connector............................................................................................................2-9
Jumper................................................................................................................2-17
Slot......................................................................................................................2-18
Chapter3BIOSSetup.............................................................................................3-1
EnteringSetup.....................................................................................................3-2
The Menu Bar......................................................................................................3-4
Main......................................................................................................................3-5
Advanced............................................................................................................3-6
Boot....................................................................................................................3-17
Security..............................................................................................................3-19
Chipset...............................................................................................................3-20
Power.................................................................................................................3-25
Exit......................................................................................................................3-26
Chapter4SystemResources.............................................................................4-1
WatchDog TimerSetting.....................................................................................4-2
AMIPOSTCode...................................................................................................4-3
ResourceList......................................................................................................4-7
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1-1
ProductOverview
Chapter1
ProductOverview
Thankyouforchoosing theIE-945GSESeries(IFC--
815N2D3 . )MiniITXmainboards
Basedontheinnovative Intel 945GSE &ICH7M con-
trollersforoptimalsystemefficiency,the IE-945GSE
Seriesaccommodatethelatest Intel AtomTM processor
N270(1.6GHzsingle corewithHT)and supportone
DDR2533/667/800 SO-DIMM slot toprovide themaxi-
mumof1GBmemorycapacity.
Three optionsareavailablefortheIE-945GSE Series:
Option 01S ATXPower, High RearI/O,DVI, VGA,
1RS-232/422/485Port, 5RS-232 Ports
Option 02S DC Power, LowRearI/O, DVI-I,
1RS-232/422/485Port, 4RS-232 Ports
Option 03S DC Power, LowRearI/O, VGA, LVDS,
1RS-232/422/485Port, 4RS-232 Ports
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

IEC-815N2D
1-2
MainboardSpecifications
Processor
-IntelAtomprocessorN270 (1.6GHzsinglecorewithHT)
FSB
-533MHz
Chipset
-Northbridge:Intel945GSE chipset
-Southbridge:IntelICH7Mchipset
Memory
-1unbufferednon-ECC DDR2533/667/800 SO-DIMM slot
-Upto1GBmemorycapacity
LAN
-SupportsGigabitEthernetbyIntel82574LController
Audio
-HDACodecbyRealtek ALC888 7.1channel(compliantwith
Azalia1.0specs)
-TPA3005D2amplifier(forOptionC)
IDE
-1IDEportbyIntelICH7M
-SupportsUltraDMA66/100mode
-SupportsPIO,BusMasteroperationmode
SATA
-2SATAportsbyIntelICH7M
-Supports2SATAdevices
-Supportsup to1.5Gb/sdatatransferrate
Graphics
-Onboardgraphics integratedinIntel945GSE
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
Mainboard

1-3
ProductOverview
Connectors
01SBackPanel
-1doublestackDB-9connector
-1stackup VGAand DVI-Dconnector
-1stackupRJ45and USBconnector
-1 doublestackUSB connector
-1GigabitLANjack
-3audiojacks
02SBackPanel
-1DB-9connector
-1DVI-Iconnector
-2doublestack USB connectors
-1GigabitLANjack
-2audiojacks
03SBackPanel
-1DB-9connector
-1VGAconnector
-2doublestack USB connectors
-1GigabitLANjack
-2audiojacks
OnboardConnectors
-1frontaudiopinheader
-1USB 2.0pinheader(2ports)
-1parallelportconnector
-4serialportconnectors
-1SPIFlashROMpinheader(fordebugging)
-1chassisintrusionswitchpinheader
-1S/PDIF-Outpinheader
-1amplifierpinheader(for03Sonly)
-1LVDSconnector(for03S only)
-120-pinATXpowerconnector(for01Sonly)
-14-pinDC 12Vpowerconnector(for02S, 03Sonly)
-14-pinDC 5V/12Vpowerconnector(for02S, 03Sonly)
Slots
-1MiniPCI-Eslot
-132-bit/33MHzPCIslot
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1-4
FormFactor
-MiniITX: 170mmx170mm
Mounting
-4mountingholes
Environmental
StorageEnvironment
-Temperature:-20oC~80oC
-Humidity:5%~90% noncondensing
OperationEnvironment
-Temperature:0oC~60oC
-Humidity:5%~90% noncondensing
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
IEC-815N2D Mainboard

1-5
ProductOverview
Block Diagram
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1-6
PCI1
DIMM1
COM1
COM2
COM3
COM4
IDE 1
JLPT1
CPUFAN1
JFP1
JAUD1
ALC888
JSPDO1
JUSB1 SATA1 SATA2
JSPI1
JRTC1
JCI1
ATX1
JCOMP2
CON1CON1
Top: LAN Jack
Bottom: USB Ports
T:Line-In
M:Line-Out
B:Mic-In
Top: VGAPort
Bottom: DVI Port
Intel
ICH7M
Intel
945GSE
Intel
AtomCPU
JLAN1
USBPorts
COM Ports
JCOMP1
JCOMP3
JCOMP4
JCOMP5
JCOMP6
MainboardLayout
IE-945GSE Series Mini ITXMainboard-Option 01S
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
IFC-815N2D Mainboard

1-7
ProductOverview
PCI1
DIMM1
IDE 1
JLPT1
CPUFAN1
JFP1
JAUD1
ALC888 JSPDO1 JUSB1 SATA1 SATA2
JSPI1
JRTC1
JCI1
JPWR1
(For HDD)
JPW1
(DC-IN)
CON1CON1
T:Line-Out
B:Mic-In
JLAN1
USBPorts
USBPorts
JDVI1
COM5
Intel945GSE IntelAtomCPU
IntelICH7M
JCOMP1
COM1
COM2
COM3
COM4
JCOMP3
JCOMP4
JCOMP5
JCOMP6
IE-945GSE Series Mini ITXMainboard-Option 02S
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1-8
DIMM1
IDE 1
JLPT1
CPUFAN1
JFP1
JAUD1
ALC888 JSPDO1 JUSB1
JLVDS1
JAMP1
JCOMP1
SATA1 SATA2
JSPI1
JRTC1
J1 JCI1
CON1CON1
T:Line-Out
B:Mic-In
JLAN1
USBPorts
USBPorts
COM5
JVGA1
Intel945GSE IntelAtomCPU
IntelICH7M
JVDD1
JPW1
(DC-IN)
JPWR1
(For HDD)
COM1
COM2
COM3
COM4
JCOMP4 JCOMP6
JCOMP3 JCOMP5
PCI1
IE-945GSE Series Mini ITXMainboard-Option 03S
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
IFC-815N2D Mainboard

1-9
ProductOverview
BoardDimension
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1-10
Back Panel&I/OShieldDrawing
IE-945GSE Series Mini ITXMainboard-Option 01S
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
IFC-815N2D Mainboard

1-11
ProductOverview
IE-945GSE Series Mini ITXMainboard-Option 02S
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1-12
IE-945GSE Series Mini ITXMainboard-Option 03S
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
IFC-815N2D Mainboard

1-13
ProductOverview
PowerConsumption
Component Description
CPUIntel AtomProcessor200Series
MemoryCorsair1GDDR2-800x1
Add-OnVGANA
HardDiskWestern80GIDE7200rpmHDDx1
Operating System MicrosoftWindowsXPProfessional SP2
3.3Vinput 5Vinput 12Vinput 5VSB Total
Watt
(ATX)
Current(A) Current(A) Current(A) Current(A) Watt
EnterDOS(stable)0.54 1.03 0.30 0.06 10.83W
EnterBIOS(stable)0.56 1.03 0.30 0.06 10.90W
Idle 0.54 1.10 0.27 0.05 10.77W
CPUStress 100% 0.54 1.18 0.31 0.05 11.65W
Windowsstress
(3dMARK2006)0.55 1.11 0.36 0.05 11.94W
WindowsDesktop
StandbyS1without
LANconnected
(stable)
0.48 1.03 0.25 0.05 9.98W
WindowsDesktop
StandbyS3without
LANconnected
(stable)
0 0 0 0.22 1.10W
WindowsDesktop
HibernateS4without
LANconnected
(stable)
0 0 0 0.13 0.65W
WindowsDesktop
Soft Off S5without
LANconnected
(stable)
0 0 0 0.15 0.75W
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
IEC815N2D

1-14
Component Description
CPUIntelAtomProcessor200 Series
MemoryTRANSCEND1GDDR2-800x1
Add-OnVGANA
HardDisk MAXTOR40G IDE7200rpmHDDx1
OperatingSystem MicrosoftWindowsXPProfessionalSP2
12Vinput
(DC) Current(A) Watt
EnterDOS(stable)0.956A 11.47W
EnterBIOS(stable)0.952A 11.42W
Idle 0.934A 11.21W
CPUStress100% 1.02A 12.24W
Windowsstress
(3dMARK2006)1.28A 15.36W
WindowsDesktop
StandbyS1without
LANconnected
(stable)
0.875A 10.50W
WindowsDesktop
StandbyS3without
LANconnected
(stable)
0.119A 1.43W
WindowsDesktop
HibernateS4without
LANconnected
(stable)
0.05A 0.60W
WindowsDesktop
Soft OffS5without
LANconnected
(stable)
0.05A 0.60W
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
IFC-815N2D Mainboard
IEC815N2D

1-15
ProductOverview
MTBF -ReliabilityPrediction
SafetyCompliance &MTBF
CertificationStandardnumber Titleofstandard
EN 55022: 2006 Product family standard
EN 2006 Limitsforharmoniccurrent emission
EN 1995+A1:2001+A2:2005 Limitation of voltage fluctuationand
flickerinlow-volt
ag
es
upply
sy
stem
Immunity EN 55024:1998+A1:2001+A2:2003Product family standard
BSMI
C-Tick
RFI
CE
FCC
VCCI
CNS13438
類 (1995 年 6 月版 )
AS/NZSCISPR 22:2006
FCCCFR Title47 Part 15 Subpart B: 2005ClassB
CISPR 22: 2006
VCCI V-3:2008 ClassB
VCCI V-4:2008 ClassB
815N2 Calculation Model Operation
Tem
p
erature
(
°
C)
Operation
Environm
ent
DutyCycle MTBF (hr.)
01S Telcordia Issue 1 40 GB, GC- Ground Benign,
Controlled 6,429.899614 155,523
02S Telcordia Issue 1 40 GB, GC- Ground Benign,
Controlled 6,311.357614 158,445
03S Telcordia Issue 1 40 GB, GC- Ground Benign,
Controlled 6,841.490152 146,167
SafetyCompliance
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

viii
Thispageisintentionallyleftblank.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

2-1
HardwareSetup
HardwareSetup
Chapter2
Thischapterprovidesyou withtheinformation about
hardwaresetupprocedures.Whiledoingthe installation,
becarefulinholdingthecomponentsandfollowthe
installationprocedures.Forsomecomponents,ifyou
install inthewrong orientation,thecomponentswillnot
workproperly.
Useagroundedwrist strapbeforehandlingcomputer
components.Staticelectricitymaydamagethe
components.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
