MSI MPG Z490 GAMING PLUS User manual

I
MPG Z490 GAMING PLUS
Motherboard
User Guide
Benutzerhandbuch
Manuel d’utilisation

III
Quick Start
Thank you for purchasing the MSI® motherboard. This Quick Start section provides
demonstration diagrams about how to install your computer. Some of the installations
also provide video demonstrations. Please link to the URL to watch it with the web
browser on your phone or tablet. You may have even link to the URL by scanning the
QR code.
Kurzanleitung
Danke, dass Sie das MSI® Motherboard gewählt haben. Dieser Abschnitt der
Kurzanleitung bietet eine Demo zur Installation Ihres Computers. Manche
Installationen bieten auch die Videodemonstrationen. Klicken Sie auf die URL, um
diese Videoanleitung mit Ihrem Browser auf Ihrem Handy oder Table anzusehen. Oder
scannen Sie auch den QR Code mit Ihrem Handy, um die URL zu öffnen.
Présentation rapide
Merci d’avoir choisi la carte mère MSI®. Ce manuel fournit une rapide présentation
avec des illustrations explicatives qui vous aideront à assembler votre ordinateur.
Des tutoriels vidéo sont disponibles pour certaines étapes. Cliquez sur le lien fourni
pour regarder la vidéo sur votre téléphone ou votre tablette. Vous pouvez également
accéder au lien en scannant le QR code qui lui est associé.

IV
Installing a Processor/ Installation des Prozessors/ Installer un
https://youtu.be/4ce91YC3Oww
1
2
3
6
45
7
8
9
https://v.youku.com/v_show/
id_XMTgxMzM2MjEzNg==.html
Youtube

V
Installing DDR5 memory/ Installation des DDR5-Speichers/
http://youtu.be/T03aDrJPyQs
Youtube
http://v.youku.com/v_show/id_XNzUyMTI5ODI4.html
DIMMA2 DIMMA2
DIMMB2
DIMMA1
DIMMA2
DIMMB1
DIMMB2

VI
Connecting the Front Panel Header/ Anschließen der
Frontpanel-Stiftleiste/ Connecter un connecteur du panneau
HDD LED
RESET SW
JFP1
HDD LED
HDD LED +
POWER LED +
POWER LED
1
2 10
9
+
+
+
+
Power LED
HDD LED Reset Switch
Reserved
Power Switch
JFP1
1 HDD LED + 2 Power LED +
3 4
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
RESET SW
POWER SW
POWER LED+
POWER LED-
HDD LED
http://youtu.be/DPELIdVNZUI
Youtube
http://v.youku.com/v_show/id_XNjcyMTczMzM2.html

VII
Installing the Motherboard/ Installation des Motherboards/
1
3
https://youtu.be/wWI6Qt51Wnc
https://v.youku.com/v_show/id_
XNDUwMDUyNTkwOA==.html
Torque:
3 kgf·cm*
*3 kgf·cm
= 0.3 N·m
= 2.6 lbf·in
Youtube

VIII
Connecting the Power Connectors/ Stromanschlüsse
anschliessen/ Connecter les câbles du module d’alimentation/
http://youtu.be/gkDYyR_83I4 http://v.youku.com/v_show/id_XNDkzODU0MDQw.html
Youtube
ATX_PWR1
CPU_PWR1
CPU_PWR2

XI
Connecting Peripheral Devices/ Peripheriegeräte/ Connecter

XII
4
3
12

1
Contents
Contents
Safety Information................................................................................................. 3
Specifications......................................................................................................... 4
Package contents .................................................................................................. 9
Rear I/O Panel ..................................................................................................... 10
LAN Port LED Status Table .................................................................................. 10
Audio Ports Configuration.................................................................................... 10
Realtek Audio Console ......................................................................................... 11
Overview of Components .................................................................................... 13
CPU Socket ........................................................................................................... 14
DIMM Slots............................................................................................................ 15
PCI_E1~5: PCIe Expansion Slots.......................................................................... 16
M2_1~2: M.2 Slots (Key M) ................................................................................... 17
SATA1~6: SATA 6Gb/s Connectors....................................................................... 19
JFP1, JFP2: Front Panel Connectors................................................................... 20
JCOM1: Serial Port Connector ............................................................................. 20
CPU_PWR1~2, ATX_PWR1: Power Connectors................................................... 21
JAUD1: Front Audio Connector ............................................................................ 22
............................................................ 22
JUSB3~4: USB 3.2 Gen 1 Connectors .................................................................. 23
JUSB1~2: USB 2.0 Connectors............................................................................. 24
JTPM1: TPM Module Connector........................................................................... 24
CPU_FAN1, PUMP_FAN1, SYS_FAN1~6: Fan Connectors.................................. 25
JCI1: Chassis Intrusion Connector....................................................................... 26
...................................................... 27
JRTD3: Intel RTD3 Connector .............................................................................. 27
JBAT1: Clear CMOS (Reset BIOS) Jumper........................................................... 28
JRGB1: RGB LED connector................................................................................. 29
JRAINBOW1~2: Addressable RGB LED connectors ............................................ 30
Onboard LEDs...................................................................................................... 31
EZ Debug LED....................................................................................................... 31
LED_SW1: EZ LED Control................................................................................... 31
Installing OS, Drivers & Utilities ......................................................................... 32
Installing Windows® 10......................................................................................... 32
Installing Drivers .................................................................................................. 32
Installing Utilities ................................................................................................. 32
UEFI BIOS............................................................................................................. 33
BIOS Setup............................................................................................................ 34
English

2Contents
Entering BIOS Setup............................................................................................. 34
Resetting BIOS...................................................................................................... 35
Updating BIOS....................................................................................................... 35
EZ Mode ................................................................................................................ 37
Advanced Mode .................................................................................................... 40
OC Menu................................................................................................................ 41

3
Safety Information
Safety Information
The components included in this package are prone to damage from electrostatic
discharge (ESD). Please adhere to the following instructions to ensure successful
computer assembly.
Ensure that all components are securely connected. Loose connections may cause
the computer to not recognize a component or fail to start.
Hold the motherboard by the edges to avoid touching sensitive components.
It is recommended to wear an electrostatic discharge (ESD) wrist strap when
handling the motherboard to prevent electrostatic damage. If an ESD wrist strap is
not available, discharge yourself of static electricity by touching another metal object
before handling the motherboard.
pad whenever the motherboard is not installed.
Before turning on the computer, ensure that there are no loose screws or metal
components on the motherboard or anywhere within the computer case.
Do not boot the computer before installation is completed. This could cause
permanent damage to the components as well as injury to the user.
If you need help during any installation step, please consult a certified computer
technician.
Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing any computer component.
Keep this user guide for future reference.
Keep this motherboard away from humidity.
Make sure that your electrical outlet provides the same voltage as is indicated on
the PSU, before connecting the PSU to the electrical outlet.
Place the power cord such a way that people can not step on it. Do not place
anything over the power cord.
All cautions and warnings on the motherboard should be noted.
If any of the following situations arises, get the motherboard checked by service
personnel:
Liquid has penetrated into the computer.
The motherboard has been exposed to moisture.
The motherboard does not work well or you can not get it work according to user
guide.
The motherboard has been dropped and damaged.
The motherboard has obvious sign of breakage.
Do not leave this motherboard in an environment above 60°C (140°F), it may damage
the motherboard.

4Specifications
Specifications
CPU
Supports 10th Gen Intel® Core™ and Pentium® Gold /
Celeron® processors for LGA 1200 socket*
* Please go to intel.com for compatibility information.
* Onboard graphics output are disabled when using the F SKU processors.
Chipset Intel® Z490 Chipset
Memory
4x DDR4 memory slots, support up to 128GB*
Supports 1R 2133/2666/2933 MHz*
1DPC 1R Max speed up to 4800+ MHz
1DPC 2R Max speed up to 4266+ MHz
2DPC 1R Max speed up to 4400+ MHz
2DPC 2R Max speed up to 4000+ MHz
Supports Intel® Extreme Memory Profile (XMP)
*Please refer www.msi.com for more information on compatible memory
Expansion Slot
1x PCIe 3.0 x16 slot (from CPU)
3x PCIe x1 slots (from PCH)
Onboard Graphics
1x HDMI port, supports a maximum resolution of
4096x2160 @ 30Hz
1x DisplayPort port supports a maximum resolution of
4096 x 2304 @ 60Hz
Multi-GPU
Storage
Intel® Z490 Chipset
6x SATA 6Gb/s ports*
2x M.2 slots (Key M)
M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/
2260/ 2280/ 22110 storage devices*
M2_2 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/
2260/ 2280 storage devices**
Intel® Optane™ Memory Ready***
Supports Intel® Smart Response Technology for Intel
Core™ processors
* SATA2 will be unavailable when installing M.2 SATA SSD in the M2_1 slot.
** SATA5 & SATA6 will be unavailable when installing M.2 SATA/PCIe SSD in the
M2_2 slot.
*** Before using Intel® Optane™ memory modules, please ensure that you have
updated the drivers and BIOS to the latest version from MSI website.
Continued on next page

5
Specifications
Continued from previous page
RAID
Intel® Z490 Chipset
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
Supports RAID 0 and RAID 1 for M.2 PCIe storage devices
LAN
USB
Intel® Z490 Chipset
2x USB 3.2 Gen 2 10Gbps ports
back panel, 4 ports through the internal USB connectors,
1
6x USB 2.0 ports
ports through the internal USB 2.0 connectors)
Audio
Supports S/PDIF output
Back Panel
Connectors
1x PS/2 keyboard/ mouse combo port
2x USB 2.0 ports
1x HDMI port
1x DisplayPort port
1x LAN(RJ45) port
1x Optical S/PDIF OUT connector
5x audio jacks
Continued on next page

6Specifications
Continued from previous page
Internal Connectors
6x SATA 6Gb/s connectors
2x USB 3.2 Gen 1 5Gbps connectors (support additional 4
USB 3.2 Gen 1 5Gbps ports)
2x USB 2.0 connectors (support additional 4 USB 2.0 ports)
1x front panel audio connector
2x system panel connectors
1x Chassis Intrusion connector
1x Clear CMOS jumper
1x serial port connector
1x TPM module connector
1x TBT connector*
*Thunderbolt card need support RTD3
LED Features 1x EZ LED Control switch
4x EZ Debug LED
I/O Controller NUVOTON NCT6687 Controller Chip
Hardware Monitor
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
Form Factor ATX Form Factor
12 in. x 9.6 in. (30.5 cm x 24.4 cm)
BIOS Features
1x 256 Mb flash
UEFI AMI BIOS
ACPI 6.2, SM BIOS 3.2
Continued on next page

7
Specifications
Continued from previous page
Software
Drivers
DRAGON CENTER
Intel Extreme Tuning Utility
MSI App Player (BlueStacks)
Open Broadcaster Software (OBS)
Google Chrome™, Google Toolbar, Google Drive
Norton™ Internet Security Solution
Dragon Center
Features
Gaming Mode
Gaming Hotkey
LAN Manager
Mystic Light
User Scenario
Monitor(Hardware
Monitor)
True Color
Live Update
DPC Latency tuner
Speed Up
Smart Tool
Super Charger
Please refer to http://download.msi.
com/manual/mb/DRAGONCENTER2.
pdf for more details.
Special Features
Audio
Audio Boost
Network
2.5G LAN
LAN Manager
Cooling
Extended Heatsink Design
M.2 Shield Frozr
Pump Fan
Smart Fan Control
Continued on next page

8Specifications
Continued from previous page
Special Features
LED
Mystic Light
Mystic Light Extension(RGB)
Mystic Light Extension (RAINBOW)
Mystic Light Sync
EZ LED Control
EZ DEBUG LED
Performance
DDR4 Boost
Core Boost
Game Boost
USB 3.2 Gen 2 10G
USB with type A+C
Dual CPU Power
Protection
Experience
DRAGON CENTER
Click BIOS 5
Other manuals for MPG Z490 GAMING PLUS
2
Table of contents
Languages:
Other MSI Motherboard manuals

MSI
MSI MS-6566E User manual

MSI
MSI MS-98L2 User manual

MSI
MSI MS-7236 (V2.X) Mainboard G52-72361X2 User manual

MSI
MSI MS-6390 User manual

MSI
MSI B360M MORTAR User manual

MSI
MSI 870S-C45 Series User manual

MSI
MSI X99A GAMING 7 User manual

MSI
MSI MS-7317 User manual

MSI
MSI MS-7173 User manual

MSI
MSI ATX IR1 User manual

MSI
MSI MS-98I0 User manual

MSI
MSI PH61A-P35 (B3) User manual

MSI
MSI H110I PRO User manual

MSI
MSI MPG Z390 GAMING EDGE AC User manual

MSI
MSI MS-6507 User manual

MSI
MSI 945 Neo5 Series User manual

MSI
MSI Z68A-GD65 B3 series User manual

MSI
MSI K8NNeo4 Platinum Series User manual

MSI
MSI MAG B660 TOMAHAWK WIFI User manual

MSI
MSI KT4 Ultra User manual
