MSR Superfly User manual

FOR YOUR SAFETY
If you smell gas
1. Do not attempt to light stove.
2. Extinguish any open flame.
3. Disconnect from fuel canister.
CARBON MONOXIDE HAZARD
• Thisstovecanproducecarbonmon-
oxide,whichhasnoodor.
• Usingitinanenclosedspacecankill
you.
• Neverusethisstoveinanenclosed
spacesuchasacamper,tent,
vestible,car,orhome.
DANGER
Do not store or use gasoline or other
liquidswithflammablevaporsinthe
vicinity of this or any other stove.
FOR YOUR SAFETY
DANGER
INSTRUCTION
MANUAL
CARBONMONOXIDE,FIRE&EXPLOSIONHAZARD
There are serious hazards associated with using this stove and fuel. Accidental
fire, explosion, and misuse can cause death, serious burns, and property dam-
age. You are responsible for your own safety and the safety of those in your
group. Please use good judgment.
This stove is for OUTDOOR USE ONLY. Never use this stove in a tent, vestible,
car, house, or inside any enclosed area. This stove consumes oxygen and
produces carbon monoxide gas, which is poisonous and has no odor. This
stove can easily ignite nearby combustible materials and flammable liquids or
vapors. If you use this stove in an enclosed area you can be killed or seriously
burned.
Keep stove and canister away from other heat sources. Never use any kind of
windscreen. Never use cookware or an Outback Oven™with a diameter larger
than 8 inches (20.3 cm). If you expose the canister to high heat, it will explode
and you can be killed or seriously burned.
Never let children use this stove. Keep children at least 10 feet (3 m) away
from the stove and cooking area, and supervise them at all times.
READ, UNDERSTAND, AND FOLLOW ALL instructions and warnings in this
manual before using this stove. Failure to follow warnings and instructions can
result in death, serious burns or other injury, and property damage.
IMPORTANT
Read and understand this entire manual carefully before assembling or using
this stove. Keep this manual for future reference. If you do not understand
this manual or have any questions, please call Cascade Designs at 1-800-
531-9531.
SUPERFLY™STOVE/SUPERFLY
STOVE WITH AUTOSTART
FOR OUTDOOR USE ONLY
Nominal rate:
10,000 BTU/h.
3.5 kW h.
269 g/h.
Printed on recycled paper containing 30% post-consumer waste. 119994-6
For product service and information contact
CascadeDesigns,Inc.
4000 First Avenue South, Seattle, WA 98134 USA
1-800-531-9531 or 206-505-9500
www.msrgear.com
RECYCLED | RECYCLABLE
Do not attempt to use this stove: (1) before reading and fully understanding this
Instruction Manual; (2) if you are not prepared or comfortable attending to a
burning and/or hot stove at all times; (3) if you observe leaking fuel; or (4) if you
observe any condition with the stove system or in the surrounding environment
that would make operation of an open flamed device dangerous. Failure to fol-
low these directions can cause an unsafe situation leading to fire, burns, severe
injury or death.
This stove is designed for the outside (i.e., not within enclosed spaces of any kind;
e.g., tents) boiling of water or cooking of food only—never use it for any other
purpose. Use of stove within any enclosed space, or for a purpose other than boil-
ing water or cooking food can cause fire, burns, severe injury or death.
Do not disassemble stove beyond what is described in these instructions. Do not
modify stove. Disassembly or modification of stove in any manner not consistent
with these instructions voids warranty and can result in an unsafe situation where
fire, burns, severe injury or death can occur.
Do not use stove if parts are missing or broken, or with replacement parts not
specific to your stove model. Use of stove with missing or broken parts, or with
replacement parts not specific to your stove model, can result in an unsafe situation
where fire, burns, severe injury or death can occur.
Cascade Designs, Inc. warrants the use of appropriately sized MSR®brand cook-
ware only—use of cookware other than MSR®brand cookware will be at user’s
own risk and discretion.
LIMITED WARRANTY/LIMITATIONS OF REMEDIES AND LIABILITY
USA and Canada
Limited Warranty. Cascade Designs, Inc. (“Cascade”), to the original
owner (“Owner”), under intended use and maintenance, warrants the
enclosed product (“Product”) to be free from defects in materials and
workmanship for the life of the Product. No warranty against defects in materi-
als and workmanship will apply if Product is (i) altered in any way, (ii) used for purposes
inconsistent with Product’s intended purpose or design, or (iii) improperly maintained.
Warranty will furthermore be voided where Owner/user (i) failed to follow Product instruc-
tions or warnings or (ii) subjected Product to misuse, abuse, or neglect.
During the warranty period, original Product parts determined by Cascade to be defec-
tive in materials or workmanship will be repaired or replaced as Owner’s sole remedy.
Cascade reserves the right to replace any discontinued product with a new product of
comparable value and function. A returned product deemed irreparable becomes the
property of Cascade and will not be returned.
EXCLUDING THE LIMITED WARRANTY PROVIDED ABOVE, CASCADE, ITS AFFILIATES
AND THEIR SUPPLIERS, TO THE MAXIMUM EXTENT PERMITTED BY LAW, MAKE NO
WARRANTIES, EXPRESSED OR IMPLIED, AND DISCLAIM ALL WARRANTIES, DUTIES
AND CONDITIONS, WHETHER EXPRESSED, IMPLIED OR STATUTORY, WITH RESPECT
TO THE PRODUCT, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTIES
OF MERCHANTABILITY, AGAINST LATENT DEFECTS, FITNESS FOR A PARTICULAR
PURPOSE, OR CORRESPONDENCE TO DESCRIPTION.
Warranty Service. To obtain service under this warranty, the warranty-eligible Product
must be presented to a Cascade authorized dealer. In the United States and Canada, war-
ranty service may also be obtained by calling 1-800-531-9531[M-F, 8:00-4:30, PDT].
Owner is responsible for all costs associated with returning Product to Cascade for ser-
vice. Where at its sole discretion Cascade deems Product eligible for warranty repair
or replacement, Cascade will pay the shipping and handling associated with returning
repaired or replaced Product to Owner. In instances where Cascade deems a returned
product ineligible for warranty service, Cascade will, if possible, repair product for
a reasonable charge that includes return shipping and handling. For warranty return
service details, please go to www.msrgear.com.
Limitation of Remedies. Should a court of competent jurisdiction find the limited war-
ranty set forth above breached, Cascade’s only obligation will be to, at its option,
either repair or replace Product. Should the aforementioned remedy fail of its essential
purpose, Cascade will, in exchange for return of Product, refund to Owner Product’s
original purchase price. THE FOREGOING REMEDY IS THE SOLE AND EXCLUSIVE
REMEDY OF THE PURCHASER AGAINST CASCADE, ITS AFFILIATES AND THEIR
SUPPLIERS, REGARDLESS OF LEGAL THEORY.
Limitation of Liability. Cascade’s, its affiliates’ and their suppliers’ maximum liability is
limited to incidental damages not to exceed the original purchase price of the Product.
CASCADE, ITS AFFILIATES AND THEIR SUPPLIERS HEREBY DISCLAIM AND EXCLUDE
ANY LIABILITY FOR ANY CONSEQUENTIAL OR OTHER DAMAGES RESULTING
FROM ANY REASON WHATSOEVER. THIS EXCLUSION AND LIMITATION APPLIES
TO ALL LEGAL THEORIES UNDER WHICH DAMAGES MAY BE SOUGHT, AND WILL
APPLY EVEN IF ANY REMEDY FAILS OF ITS ESSENTIAL PURPOSE.
This limited warranty gives Owner specific legal rights; Owner may have additional
rights, which may vary state to state.
Always completely follow safety, use, operation, and maintenance instructions for this
or any other Cascade product.
European Union customer statutory rights are not affected.
0051
90/396/EEC
(51BL3207-2000)
AGA 6089
WARNING

Stove service must only be done by an individual authorized by Cascade
Designs, Inc. If you have any questions about these instructions, your stove,
replacement parts, or repairs, please contact:
Cascade Designs, Inc., USA - 1-800-531-9531 or 206-505-9500
Cascade Designs, Ltd., Ireland - ([phone]
www.msrgear.com [email protected]
TROUBLESHOOTING
1.Clearcookingareaofcombustiblematerialsandflammableliquidsor
vapors.
2.Placestoveassemblyonasolid,stable,evensurfacetoensurestability.
3.RotatePotSupportsfullyopen.
Pot Supports should not touch AutoStart.
SETUPSTOVE
1.OpenFlameAdjusterValve(about1/4turn)toreleasefuel.
Listen for hiss as fuel flows into Burner Head.
2.ClickAutoStartButtonquicklytoignitefuel.
Fuel ignition may take several clicks.
3.TurnFlameAdjusterValvetodesiredflamesetting.
Proper flame will appear blue.
NOTE: To light fuel without AutoStart, hold lit match/lighter near Burner
Ports and slowly open Flame Adjuster Valve.
TURN STOVE ON
1.Addfoodorliquidtocookware.
2.Placecookwareontothecenterof
the stove.
3.TurnFlameAdjusterValveto
adjustheat.
USE STOVE TO COOk
1.CloseFlameAdjusterValvewhencookingisdone.
2.Afterflamesareout,wait5minutesforstovetocool.
3.FoldFlameAdjuster.
4.ClosePotSupports.
5.Movestoveassemblyawayfromanyignitionsources.
Hold Multi-Mount Grabber in place and unscrew stove from canister.
A small amount of gas may escape when unscrewing stove.
If canister is completely empty of fuel, follow proper disposal requirements
in your local area.
TURN STOVE OFF
AutoStart™
ThreadedStem
(withO-ringStop)
Multi-Mount™
Grabber
PotSupports
Valve
Body
Flame
Adjuster
SUPERFLY™STOVEOPERATINGINSTRUCTIONS
The SuperFly stove attaches to fuel canisters differently than other stoves
because of its Multi-Mount™technology.
1.UnfoldFlameAdjuster.
2.CloseFlameAdjusterValve.
3.ScrewMulti-MountGrabbertothebottomofThreadedStem.
4.SlideMulti-MountGrabberundercanisterlip.
5.HoldMulti-MountGrabberinplaceandfinger-tightenstoveuntilconnec-
tion is secure.
CONNECT STOVE AND CANISTER
kNOW YOUR MSR®SUPERFLY™STOVE
Please familiarize yourself with the parts of your SuperFly stove and the following
instructions before connecting the stove to its fuel canister. Never use this stove in
any other way than is described in the following instructions.
BurnerHead
OPEN CLOSE
WAIT
5 MIN.
FlameAdjuster
Valve
4-ft.(1.2-m)MIN.
DISTANCE from
COMBUSTIBLE MATERIALS
COOKWARE8-in.(20.3-cm)
DIA. MAX.
5-in.(12.7-cm)HT.MAX.
8-lbs.(3.6-kg)WT.MAX.
CLOSE
NEVER USE WINDSCREEN
BurnerPorts
AutoStart
Button
25-ft.(7.6-m)MIN.
DISTANCE from
FLAMMABLE LIQUIDS/
VAPORS
CLICk
Never over tighten fuel canister to stove. Over tightening can damage
stove or canister causing fuel to leak. Leaking fuel can cause fire, burns,
severe injury or death.
Use extreme caution when using stove in temperatures below freezing. In
freezing temperatures O-rings can stiffen and leak fuel. Always check for
fuel leaks before and after lighting stove. Use of a leaking stove can cause
fire, burns, severe injury or death.
Keep children far away from stove and fuel—Cascade Designs, Inc. rec-
ommends no less than 10 feet (3+ meters). Never leave a burning or hot
stove unattended. An unattended stove can lead to fire and/or a situation
where children, pets, or the unwary can be burned, injured, or killed.
WARNING
Keep combustibles at least 4 feet (1.2 meters) away from the top and
sides of a burning stove, or a stove that you are in the process of lighting.
Keep flammable liquids and vapors at least 25 feet (7.6 meters) away
from the top and sides of a burning stove, or a stove that you are in the
process of lighting. This stove can ignite combustible materials, flammable
liquids and vapors creating a situation where fire, burns, severe injury or
death can result.
Never attempt lighting stove if flame adjuster valve is left open. If flame
adjuster valve is left open, close it immediately and thoroughly ventilate
area before lighting stove. Failure to ventilate area can result in an explo-
sion that can cause fire, burns, severe injury or death.
WARNING
Never move a burning or hot stove. Always extinguish stove and cool for
at least 5 minutes before moving. Moving a burning or hot stove can cause
fire, burns, severe injury or death. Never use cookware or an Outback
Oven™ with a diameter greater than 8 inches (20.3 centimeters). Never
place and operate two or more stoves together. Never operate stove with
empty or dry cookware. Never use non-MSR®reflectors or diffusers. Use
of stove in any of the proceeding manners can result in the fuel canister
exploding and causing fire, burns, severe injury or death. Never use cook-
ware of any size that is ill-suited and/or inappropriate for use with stove,
particularly its pot supports (e.g., cookware with a convex or concave
bottom, some enameled cookware, etc.). Use of stove with ill-suited and/
or inappropriate cookware can result in cookware and/or stove instability
and a situation where hot cookware and/or cookware contents can spill
and cause fire, burns, severe injury or death.
WARNING
Always disconnect stove from canister before storing it. Failure to discon-
nect stove from canister before storing may cause fuel to leak and cause
fire, burns, severe injury or death. Always store fuel canisters in a well-
ventilated location away from any possible heat or ignition source such
as: water heaters, stoves, pilot lights, or furnaces; or where temperatures
exceed 120 F (49 C). Storing fuel canisters near any heat or ignition
source or where temperatures exceed 120 F (49 C), can result in the can-
ister exploding and causing fire, burns, severe injury or death.
GENERAL SAFETY INFORMATION
To avoid being killed or seriously injured, READ, UNDERSTAND, AND FOLLOW
ALL warnings and instructions in this manual before you use this stove.
This stove is a lightweight, compact device made for cooking outdoors. Please
consult with your local outdoor retailer to learn more about cooking outdoors. Seek
qualified instruction before you venture outdoors.
You are responsible for your own safety and the safety of those in your group. This
manual is not intended to replace your good judgment.
Fuel Canister Safety
This stove uses a liquid pressurized gas (LPG) canister that is highly flammable and
explosive. Use only MSR®premium blend canister fuel, 70 Butane/30 Propane
or 80 IsoButane/20 Propane mix, certified to EN 417 (4 ounces/113 g or 8
ounces/227 g). For any fuel canister, follow this safety information:
• Listenandsmellforleakinggas.Leakinggasisaserioushazard.LPGis
invisible and odorless, and strong odorant additives can fade over time.
Leaks are not always detectable by smell. Do not use this stove if it is leak-
ing, damaged, or does not operate properly.
• Checkthatthestoveandfuelcanisterconnectionissecureandtight.Ifthe
connection does not look or feel secure, or if you hear or smell leaking gas,
do not use stove or canister. Move stove to a well-ventilated area away from
any ignition source to locate and stop the leak. Only check for leaks out-
doors using soapy water. Do not try to detect leaks using a flame.
• Onlychangethecanisteroutsideandawayfrompeople.
• Neverusefuelcanisterslargerthan8ounces(227g)ormorethan4inches
(10 cm) in height, because oversized canisters increase stove instability.
• Checkthesealsbeforeconnectinganewfuelcanistertothestove.Donot
use stove if seals are damaged or worn.
• Keepstoveandfuelcanisterawayfromotherheatsources.Ifyouexposethe
fuel canister to high heat, the canister will explode or leak and you can be
killed or seriously burned.
• Followallwarningsonfuelcanisterregardinguseandstorage.
WARNING
Never place your head or body above the stove while lighting, or cook-
ing. Because stove maintains an open flame, placement of head or body
above stove is an unsafe practice that can cause fire, burns, severe injury
or death.
WARNING
Problem
Poor Performance Cause Solution
Diminished flames Low fuel Replace canister
Stove does not light Cold canister Swap canisters
Windy conditions Shelter stove behind a
rock/natural barrier
Empty canister Replace canister
Damaged AutoStart Bend electrode closer
to Burner Ports (<3/16
in./4.8 mm)
Hold lit match/lighter
near Burner Ports and
slowly open Flame
Adjuster Valve
Replace AutoStart
