MSR WINDPRO User manual

For product service and information contact
Cascade Designs, Inc.
4000 First Avenue South, Seattle, WA 98134 USA
1-800-531-9531 or 206-505-9500
www.msrgear.com
FOR YOUR SAFETY
If you smell gas
1. Do not attempt to light stove.
2. Extinguish any open flame.
3. Disconnect stove from fuel canister.
Do not store or use gasoline or other
liquids with flammable vapors in the
vicinity of this or any other stove.
FOR YOUR SAFETY
INSTRUCTION
MANUAL
WINDPRO™ STOVE
LIMITED WARRANTY/LIMITATIONS OF REMEDIES AND
LIABILITY
USA and Canada
Limited Warranty. Cascade Designs, Inc. (“Cascade”), to the original owner
(“Owner”), under intended use and maintenance, warrants the enclosed
product (“Product”) to be free from defects in materials and workmanship
for the life of the Product. No warranty against defects in materials and workman-
ship will apply if Product is (i) altered in any way, (ii) used for purposes inconsistent with
Product’s intended purpose or design, or (iii) improperly maintained. Warranty will further-
more be voided where Owner/user (i) failed to follow Product instructions or warnings or
(ii) subjected Product to misuse, abuse, or neglect.
During the warranty period, original Product parts determined by Cascade to be defec-
tive in materials or workmanship will be repaired or replaced as Owner’s sole remedy.
Cascade reserves the right to replace any discontinued product with a new product of
comparable value and function. A returned product deemed irreparable becomes the
property of Cascade and will not be returned.
EXCLUDING THE LIMITED WARRANTY PROVIDED ABOVE, CASCADE, ITS AFFILIATES
AND THEIR SUPPLIERS, TO THE MAXIMUM EXTENT PERMITTED BY LAW, MAKE NO
WARRANTIES, EXPRESSED OR IMPLIED, AND DISCLAIM ALL WARRANTIES, DUTIES
AND CONDITIONS, WHETHER EXPRESSED, IMPLIED OR STATUTORY, WITH RESPECT
TO THE PRODUCT, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTIES OF
MERCHANTABILITY, AGAINST LATENT DEFECTS, FITNESS FOR A PARTICULAR PURPOSE,
OR CORRESPONDENCE TO DESCRIPTION.
Warranty Service. To obtain service under this warranty, the warranty-eligible Product must
be presented to a Cascade authorized dealer. In the United States and Canada, warranty
service may also be obtained by calling 1-800-531-9531[M-F, 8:00-4:30, PDT].
Owner is responsible for all costs associated with returning Product to Cascade for
service. Where at its sole discretion Cascade deems Product eligible for warranty repair
or replacement, Cascade will pay the shipping and handling associated with returning
repaired or replaced Product to Owner. In instances where Cascade deems a returned
product ineligible for warranty service, Cascade will, if possible, repair product for a
reasonable fee that includes return shipping and handling. For warranty return service
details, please go to www.msrgear.com.
Limitation of Remedies. Should a court of competent jurisdiction find the limited war-
ranty set forth above breached, Cascade’s only obligation will be to, at its option, either
repair or replace Product. Should the aforementioned remedy fail of its essential purpose,
Cascade will, in exchange for return of Product, refund to Owner Product’s original pur-
chase price. THE FOREGOING REMEDY IS THE SOLE AND EXCLUSIVE REMEDY OF THE
PURCHASER AGAINST CASCADE, ITS AFFILIATES AND THEIR SUPPLIERS, REGARDLESS
OF LEGAL THEORY.
Limitation of Liability. Cascade’s, its affiliates’ and their suppliers’ maximum liability is
limited to incidental damages not to exceed the original purchase price of the Product.
CASCADE, ITS AFFILIATES AND THEIR SUPPLIERS HEREBY DISCLAIM AND EXCLUDE
ANY LIABILITY FOR ANY CONSEQUENTIAL OR OTHER DAMAGES RESULTING FROM
ANY REASON WHATSOEVER. THIS EXCLUSION AND LIMITATION APPLIES TO ALL
LEGAL THEORIES UNDER WHICH DAMAGES MAY BE SOUGHT, AND WILL APPLY EVEN
IF ANY REMEDY FAILS OF ITS ESSENTIAL PURPOSE.
This limited warranty gives Owner specific legal rights; Owner may have additional rights,
which may vary state to state.
Always completely follow safety, use, operation, and maintenance instructions for this or
any other Cascade product.
European Union customer statutory rights are not affected.
FOR OUTDOOR USE ONLY
CARBON MONOXIDE HAZARD
•Thisstovecanproducecarbonmon-
oxide, which has no odor.
•Usingitinanenclosedspacecankill
you.
•Neverusethisstoveinanenclosed
space such as a camper, tent,
vestible, car, or home.
DANGER
IMPORTANT
Read and understand this entire manual carefully before assembling or using
this stove. Keep this manual for future reference. If you do not understand this
manual or have any questions, please call Cascade Designs, Inc. at 1-800-
531-9531.
CARBON MONOXIDE, FIRE & EXPLOSION HAZARD
There are serious hazards associated with using this stove and fuel. Accidental
fire, explosion, and misuse can cause death, serious burns, and property dam-
age. You are responsible for your own safety and the safety of those in your
group. Please use good judgment.
This stove is for OUTDOOR USE ONLY. Never use this stove in a tent, vestible,
car, house, or inside any enclosed area. This stove consumes oxygen and pro-
duces carbon monoxide gas, which is poisonous and has no odor. This stove
can easily ignite nearby combustible materials and flammable liquids or vapors.
If you use this stove in an enclosed area you can be killed or seriously burned.
Keep stove and canister away from other heat sources. Never use cookware
or an Outback Oven™with a diameter larger than 9 inches (23 centimeters).
Oversized cookware can overheat the fuel canister. If you expose the canister to
high heat, it will explode and you can be killed or seriously burned.
Never let children use this stove. Keep children at least 10 feet (3 m) away from
the stove and cooking area, and supervise them at all times.
READ, UNDERSTAND, AND FOLLOW ALL instructions and warnings in this
manual before using this stove. Failure to follow warnings and instructions can
result in death, serious burns or other injury, and property damage.
Nominal rate:
7,800 BTU/h.
2.3 kW h.
184 g/h.
Printed on recycled paper containing 30% post-consumer waste. 117059-3
RECYCLED | RECYCLABLE
Do not attempt to use this stove: (1) before reading and fully understanding
this Instruction Manual; (2) if you are not prepared or comfortable attending
to a burning and/or hot stove at all times; (3) if you observe leaking fuel; or
(4) if you observe any condition with the stove system or in the surrounding
environment that would make operation of an open flamed device danger-
ous. Failure to follow these directions can cause an unsafe situation leading
to fire, burns, severe injury or death.
This stove is designed for the outside (i.e., not within enclosed spaces of
any kind; e.g., tents) boiling of water or cooking of food only—never use
it for any other purpose. Use of stove within any enclosed space, or for a
purpose other than boiling water or cooking food can cause fire, burns,
severe injury or death.
Do not disassemble stove beyond what is described in these instructions. Do
not modify stove. Disassembly or modification of stove in any manner not
consistent with these instructions voids warranty and can result in an unsafe
situation where fire, burns, severe injury or death can occur.
Do not use stove if parts are missing or broken, or with replacement parts
not specific to your stove model. Use of stove with missing or broken parts,
or with replacement parts not specific to your stove model, can result in an
unsafe situation where fire, burns, severe injury or death can occur.
Always use stove on a solid, stable, even surface to avoid tipping and spills.
Tipping of stove can result in an unsafe situation where fire, burns or severe
injury or death can occur.
Cascade Designs, Inc. warrants the use of appropriately sized MSR®brand
cookware only—use of cookware other than MSR®brand cookware will be
at user’s own risk and discretion.
WARNING
AGA 7303
DANGER
0051
90/396/EEC
(B1BO2370-2003)

Stove service must only be done by an individual authorized by Cascade
Designs, Inc. If you have any questions about these instructions, your stove,
replacement parts, or repairs, please contact:
Cascade Designs, Inc., USA - 1-800-531-9531 or 206-505-9500
Cascade Designs, Ltd., Ireland - ([phone]
www.msrgear.com [email protected]
TROUBLESHOOTING
1.Clearcookingareaofcombustiblematerialsandflammableliquidsor
vapors.
2. Place stove assembly on a solid, stable, even surface to ensure stability.
3. Rotate Pot Supports/Legs fully open.
4. Place stove on the center of Heat Reflector.
SET UP STOVE
1. Hold a lit match/lighter over the edge of Burner Head.
2. Open Flame Adjuster Valve (3/4 turn) to release and ignite fuel.
3. Turn Flame Adjuster Valve to desired flame setting.
A proper flame will appear blue.
TURN STOVE ON
1. Set up Windscreen.
Fold ends of Windscreen together.
Leave a 1-inch (2.5 cm) gap between Windscreen and cookware for
optimal performance.
Use Windscreen to improve performance in all conditions.
2.Addappropriatefoodorliquidtocookware.
3.Placecookwareontothecenterofthestove.
4. Turn Flame Adjuster Valve to adjust heat.
USE STOVE TO COOk
1.CloseFlameAdjusterValvewhencookingisdone.
2. After flames are out, wait 5 minutes for stove to cool.
3.Checkthatburnersareextinguishedbeforedisconnectingthegascanister.
4. Fold Flame Adjuster.
5. Close Pot Supports.
6. Move stove assembly away from any ignition sources and unscrew canister.
A small amount of gas may escape when unscrewing canister.
If canister is completely empty of fuel, follow proper disposal requirements in
your local area.
TURN STOVE OFF
Flat
Gasket
Heat Reflector
Pot
Supports
Valve
Body
Flame
Adjuster
WINDPRO™STOVE OPERATING INSTRUCTIONS
1. Unfold Flame Adjuster.
2. Close Flame Adjuster Valve.
3. Finger-tighten canister onto stove Valve Body until connection is secure.
CONNECT STOVE AND CANISTER
kNOW YOUR MSR®WINDPRO™STOVE
Please familiarize yourself with the parts of your WindPro stove and the following
instructions before connecting the stove to its fuel canister. Never use this stove in any
other way than is described in the following instructions.
Windscreen
Top Screw
Burner
Head
Jet
Generator
Tube
CLOSE
OPEN
CLOSE
WAIT
5 MIN.
4-ft. (1.2-m) MIN.
DISTANCE from
COMBUSTIBLE
MATERIALS
GENERAL SAFETY INFORMATION
To avoid being killed or seriously injured, READ, UNDERSTAND, AND FOLLOW ALL
warnings and instructions in this manual before you use this stove.
This stove is a lightweight, compact device made for cooking outdoors. Please consult
with your local outdoor retailer to learn more about cooking outdoors. Seek qualified
instruction before you venture outdoors.
You are responsible for your own safety and the safety of those in your group. This
manual is not intended to replace your good judgment.
Fuel Canister Safety
This stove uses a liquid pressurized gas (LPG) canister that is highly flammable and
explosive. Use only MSR®premium blend canister fuel, 70 Butane/30 Propane or 80
IsoButane/20 Propane mix, cetrtified to EN 417 (4 ounces/113 g or 8 ounces/227
g). Do not attempt to fit other types of gas canisters. For any fuel canister, follow this
safety information:
• Listenandsmellforleakinggas.Leakinggasisaserioushazard.LPGisinvis-
ible and odorless, and strong odorant additives can fade over time. Leaks are
not always detectable by smell. Do not use this stove if it is leaking, damaged,
or does not operate properly.
• Checkthatthestoveandfuelcanisterconnectionissecureandtight.Ifthecon-
nection does not look or feel secure, or if you hear or smell leaking gas, do
not use stove or canister. Move stove to a well-ventilated area away from any
ignition source to locate and stop the leak. Only check for leaks outdoors using
soapy water. Do not try to detect leaks using a flame.
• Onlychangethecanisteroutsideandawayfrompeople.
• Neverusefuelcanisterslargerthan8ounces(227g)ormorethan4inches
(10 cm) in height, because oversized canisters increase stove instability.
• Checkthesealsbeforeconnectinganewfuelcanistertothestove.Donotuse
stove if seals are damaged or worn.
• Keepstoveandfuelcanisterawayfromotherheatsources.Ifyouexposethe
fuel canister to high heat, the canister will explode or leak and you can be
killed or seriously burned.
• Followallwarningsonfuelcanisterregardinguseandstorage.
Flame Adjuster
Valve
Fuel Line
25-ft. (7.6-m) MIN.
DISTANCE from
FLAMMABLE LIQUIDS/
VAPORS
Never over tighten fuel canister to stove. Over tightening can damage stove
or canister causing fuel to leak. Leaking fuel can cause fire, burns, severe
injury or death.
Use extreme caution when using stove in temperatures below freezing. In
freezing temperatures O-rings can stiffen and leak fuel. Always check for
fuel leaks before and after lighting stove. Use of a leaking stove can cause
fire, burns, severe injury or death.
Keep children far away from stove and fuel—Cascade Designs, Inc. recom-
mends no less than 10 feet (3+ meters). Never leave a burning or hot stove
unattended. An unattended stove can lead to fire and/or a situation where
children, pets, or the unwary can be burned, injured, or killed.
Keep combustibles at least 4 feet (1.2 meters) away from the top and sides
of a burning stove, or a stove that you are in the process of lighting. Keep
flammable liquids and vapors at least 25 feet (7.6 meters) away from the
top and sides of a burning stove, or a stove that you are in the process
of lighting. This stove can ignite combustible materials, flammable liquids
and vapors creating a situation where fire, burns, severe injury or death
can result.
Keep fuel canister away from the stove burner and other heat sources.
Position connected fuel canister so that it is as far away from the burner as
possible. Use of canister near burner or other heat sources can result in the
canister exploding and causing fire, burns, severe injury or death.
Never attempt to light stove if flame adjuster valve is left open. If flame
adjuster valve is left open, close it immediately and thoroughly ventilate
area before lighting stove. Failure to ventilate area can result in an explo-
sion that can cause fire, burns, severe injury or death.
WARNING
WARNING
Never place your head or body above the stove while lighting, or cook-
ing. Because stove maintains an open flame, placement of head or body
above stove is an unsafe practice that can cause fire, burns, severe injury
or death.
WARNING
Never move a burning or hot stove. Always extinguish stove and cool for
at least 5 minutes before moving. Moving a burning or hot stove can cause
fire, burns, severe injury or death. Never use cookware with a diameter
greater than 9 inches (23 centimeters). Never place and operate two or
more stoves together. Never operate stove with empty or dry cookware.
Never use non-MSR®reflectors or diffusers. Use of stove in any of the
proceeding manners can result in the fuel canister exploding and causing
fire, burns, severe injury or death. Never use cookware of any size that is
ill-suited and/or inappropriate for use with stove, particularly its pot sup-
ports (e.g., cookware with a convex or concave bottom, some enameled
cookware, etc.). Use of stove with ill-suited and/or inappropriate cookware
can result in cookware and/or stove instability and a situation where hot
cookware and/or cookware contents can spill and cause fire, burns, severe
injury or death.
WARNING
Always disconnect stove from canister before storing it. Failure to disconnect
stove from canister before storing may cause fuel to leak and cause fire,
burns, severe injury or death. Always store fuel canisters in a well-ventilated
location away from any possible heat or ignition source such as: water
heaters, stoves, pilot lights, or furnaces, or where temperatures exceed 120
F (49 C). Storing fuel canisters near any heat or ignition source or where
temperatures exceed 120 F (49 C), can result in the canister exploding and
causing fire, burns, severe injury or death.
WARNING
Problem
Poor Performance Cause Solution
Diminished flames Low fuel Replace canister
Stove does not light Cold canister Swap canisters
Windy conditions Use Windscreen
Empty canister Replace canister
1/2-in. (1.3-cm) FOLD
COOkWARE
9-in. (23-cm) DIA.
MAX.
COOkWARE
5-in. (12.7-cm) HT. MAX.
8-lbs.(3.6-kg)WT.MAX.
