USER’S MANUAL
MSTRONIC CO., LTD.
PSE-SW8G44xx
8 Port PoE Switch & Extender

User’s Manual PSE-SW8G44xx series
MSTRONIC CO., LTD.
2
1. General Information
The PoE PSE-SW8G (Power Over Ethernet) Switch family provides seven 1 M/1 M/1 M TX
ports with PoE PSE function plus one 1 M/1 M/1 M TX up-link port with PoE PD function. It
allows power souring equipment (PSE) to be powered from PoE and delivers power to any PoE
powered device (PD), which is compliant with IEEE8 2.3af and IEEE8 2.3at standards to receive
and deliver both Ethernet data and DC power through the traditional UTP or STP cable. The PoE
Switch can extend Ethernet data and DC power up to 2 meters.
2. Hardware Description
*LED Indicator
There are 18 LEDs on the PoE switch to indicate the status of power and signal. The following
section describes the functions of each LED indicator.
Front panel detail
*POWER LED
LED
STATUS Description
Power
Green
LED ON when power input (DC IN on
rear panel or Port 8 (UPLINK) on front
panel) has valid power supplied.
Off No power supplied.

User’s Manual PSE-SW8G44xx series
MSTRONIC CO., LTD.
3
*SWITCH LED (the right indicator on RJ45)
LED STATUS Description
P1~P8
Link/Act
Green A network device is detected (1 Mbps),
but no communication activity is detected.
Green
Blinking
This port is transmitting to, or receiving
package from another device at 1 Mbps.
Yellow A network device is detected (1 Mbps or
1 Mbps), but no communication activity
is detected.
Yellow
Blinking
This port is transmitting to, or receiving
package from another device at 1 Mbps or
1 Mbps.
Off No device is detected.
*PoE LED (the left indicator on RJ45)
P1~P7
PoE
Yellow A valid Powered Device (PD) is detected
and delivering power on this port.
Off No PD is detected on this port.
UPLINK (P8)
PoE
Yellow
powered via all 4 data pairs.
Yellow
Blanking
powered via 2 data pairs. (1,2,3,6 or 4,5,7,8
are all acceptable).
Off No power is detected on this port.

User’s Manual PSE-SW8G44xx series
MSTRONIC CO., LTD.
4
*Power wiring
48VDC typical (44 to 57VDC) (P/N: PSE-SW8G44A4/PSE-SW8G44B4/PSE-SW8G44D4)
The PoE switch family can be powered by another PoE source on port 8 (UPLINK) as a PoE
repeater or extender.
For PSE-SW8G44xx, the range is 44~57VDC,
For PoE operation, make sure your power supply may offer at least 125W for 7x 8 2.3af PoE ports,
or 25 W for 7x 8 2.3at PoE ports. The input voltage must be in the range of 44 to 57VDC if using
for 8 2.3af operation. The input voltage must be in the range of 5 to 57VDC if using for 8 2.3at
operation. If the PoE switch is not powered with the above designated input voltage, it will only
function as an Ethernet switch without PoE output.
In the full range voltage model, if powered via the rear terminal, please make sure the input current
is not over 15A. If powered on port 8, make sure the input current is not over 2Amps. (over 1A,
the gigabit signal will de-rate to 1 M)
Ports 1~7 will deliver DC power over the Ethernet cable as detailed below:
In the A mode: * Data pair A plus V+ on line 1 and 2
* Data pair B plus V- on line 3 and 6
* Data pair C on line 4 and 5
* Data pair D on line 7 and 8
In the B mode: * Data pair A on line 1 and 2
* Data pair B on line 3 and 6
* Data pair C plus V+ on line 4 and 5
* Data pair D plus V- on line 7 and 8
Port 8 may get DC power over the Ethernet cable, as detailed below:
* Data pair A plus V+/V- on line 1 and 2
* Data pair B plus V-/V+ on line 3 and 6
* Data pair C plus V+/V- on line 4 and 5
* Data pair D plus V-/V+ on line 7 and 8

User’s Manual PSE-SW8G44xx series
MSTRONIC CO., LTD.
5
The terminal block on the rear panel should be wired as detailed below:
Model input voltage/output voltage& function select table
Model Input Voltage
(REAR)
Input Voltage
(Port 8) Output voltage 802.3af/at
Isolated
PSE-SW8G44A4
(A mode)
PSE-SW8G44B4
(B mode)
PSE-SW8G44D4
(4 pairs output)
44-57VDC No input 44-57VDC
(non-regulated) Yes No
No input 44-57VDC 44-57VDC
(non-regulated) Yes No
44-57VDC 44-57VDC Higher voltage
(REAR or Port8) Yes No
We recommend that you use the PSE-SW8G series with our adaptor products as detailed below:
MS-180-56 MS-270-56
Maximum output 56VDC/3.21A 56VDC/4.82A
Related model
SE-SW8G44A4
SE-SW8G44B4
SE-SW8G44D4
SE-SW8G44A4
SE-SW8G44B4
SE-SW8G44D4

User’s Manual PSE-SW8G44xx series
MSTRONIC CO., LTD.
6
*Ethernet Port Wiring
The PoE switch family supports one RJ-45 uplink (port 8 with PoE PD, and seven RJ-45 ports (port
1~7 with PoE PSE) with automatic MDI/MDI-X crossover, auto-sense for speed and duplex for
1 Base-T, 1 Base-TX or 1 Base-T connection. Automatic MDI/MDI-X crossover allows you
to connect to other devices (switches, hubs, or workstations etc.), without regard to using
straight-through or crossover cabling.
Port 1 to 7 provides Power over Ethernet function that delivers DC power through the data pairs
(mode A, mode B & 8 pairs) to the PD. Port 8 provides Power Device function which receives
power from 4 pairs or 2 pairs Ethernet cable.
The following tables describe the wiring diagram of straight-through and crossover cabling. The
crossover cables simply cross-connect the transmission lines at each end to the receive lines at the
opposite end.
Straight-through Cabling
Pin 1 Pin 1
Pin 2 Pin 2
Pin 3 Pin 3
Pin 6 Pin 6
Pin 4 Pin 4
Pin 5 Pin 5
Pin 7 Pin 7
Pin 8 Pin 8

User’s Manual PSE-SW8G44xx series
MSTRONIC CO., LTD.
7
Cross-over Cabling
Pin 1 Pin 3
Pin 2 Pin 6
Pin 3 Pin 1
Pin 6 Pin 2
Pin 4 Pin 7
Pin 5 Pin 8
Pin 7 Pin 4
Pin 8 Pin 5
Connect an Ethernet cable into any switch port and connect the other side to your
attached device. The Link/Act LED (green or yellow) will light up when the cable is correctly
connected. Refer to the ED Indicator section for descriptions of each LED indicator.
If a port LED is off, go back and check for connectivity problems between that port and the network
device connected.
The maximum cable length for 1 /1 /1 BaseT with Cat 5 twisted pair cables is typically 1 m
(328 ft.).

User’s Manual PSE-SW8G44xx series
MSTRONIC CO., LTD.
8
*PD Port Wiring
Port 1 to 7 provides PoE injection function with a maximum 35W ability to power up the powered
device using the straight-through or cross-over Ethernet cable.
The PoE switch follows the IEEE8 2.3af Alternative A/B mode connector assignment. The
following table shows pin assignment of alternative A and B for the Power Source Equipment.
Conductor Alternative A
(MDI-X)
Alternative A
(MDI)
Alternative B
(All)
1 Negative Vport Positive Vport
2 Negative Vport Positive Vport
3 Positive Vport Negative port
4 Positive Vport
5 Positive Vport
6 Positive Vport NegativeVport
7 Negative Vport
8 Negative Vport
Be sure the twisted pair cable is bound with the standard RJ-45 pin. If the RJ-45 is bound with the
wrong pin number, the PoE switch will not recognize the PD and won’t deliver DC power to the PD.
The yellow PoE LED will light up when the cable is correctly connected. Refer to the ED
Indicator section for descriptions of each LED indicator. If a port LED is off, go back and check
for connectivity problems between that port and the network device connected.

User’s Manual PSE-SW8G44xx series
MSTRONIC CO., LTD.
9
*Networ Application
The PoE Switch can receive power from a PoE midspan and provide power to the PD which
follows the IEEE 8 2.3af/at standard in the network. The PoE Switch can be installed in a more
appropriate position for better performance to extend Ethernet to 2 meters. The following figure
is an example of a network application for the PoE Switch.

User’s Manual PSE-SW8G44xx series
MSTRONIC CO., LTD.
10
3. Model Information
Model Input Voltage
(REAR)
Input Voltage
(Port 5) Output voltage
802.3af/at
Isolated
Mode
PSE-SW8G44A4 44-57VDC 44-57VDC 44-57VDC
(non-regulated)
Yes No A
PSE-SW8G44B4 44-57VDC 44-57VDC 44-57VDC
(non-regulated)
Yes No B
PSE-SW8G44D4 44-57VDC 44-57VDC 44-57VDC
(non-regulated)
Yes No A+B
*All models are DIN RAIL Mountable
AC/DC Adapter (Option)
We recommend that you use the PSE-SW8G series with our adaptor products as detailed below:
MS-180-56 MS-270-56
Maximum output 56VDC/3.21A 56VDC/4.82A
Related model
SE-SW8G44A4
SE-SW8G44B4
SE-SW8G44D4
SE-SW8G44A4
SE-SW8G44B4
SE-SW8G44D4
Noted: When use MS-180-56, need to parallel 2 PS for all 7 port full load output.

User’s Manual PSE-SW8G44xx series
MSTRONIC CO., LTD.
11
4. Technical Specifications
Standards IEEE8 2.3/IEEE8 2.3u/IEEE8 2.3ab standards (1
base-T/1 base-TX/1 base-T)
Ports 8 ports with PoE (7 PSE &1 PD),
support auto-crossover & auto-polarity
Transmission speed 1 Mbps (1 base-T).1 Mbps (1 base-TX), 1 Mbps(1 base-T)
Auto-negotiation
Switch technology store-and-forward
Protocols CSMA/CD
Flow control IEEE8 2.3x (full-duplex), back pressure (half-duplex)
Data transmission rate 1488 pps for1 base-T, 1488 pps for 1 base-T, 1488 pps for
1 base-T
Address table 8K MAC address table, self-learning
Connect RJ-45
PoE port Port 1-7, PSE auto power management
Pin assignment: mode A:data pair A plus V+(1,2)
data pair B plus V-(3,6)
data pair C (4,5)
data pair D (7,8)
mode B:data pair A (1,2)
data pair B (3,6)
data pair C plus V+(4,5)
data pair D plus V-(7,8)
mode A+B:data pair A plus V+(1,2)
data pair B plus V-(3,6)
data pair C plus V+(4,5)
data pair D plus V-(7,8)
Port 8, 4 pairs PD

User’s Manual PSE-SW8G44xx series
MSTRONIC CO., LTD.
12
Maximum PoE power Port 1-7: IEEE8 2.3af – 16.8W
IEEE8 2.3at – 35W
Port 8: 56W (8 2.3at 2 event classification)
Current limited – 1A (over 1A, the gigabit signal will de-rate to
1 M)
PSE disconnect mode DC disconnect
PoE auto detection IEEE8 2.3af , IEEE8 2.3at (2 event classification signaling)
PoE protection Over-temperature, over-current, over/under voltage
LEDs *Link/Activity (Green ON/ Green Blinking @1 Mbps,
Yellow/Yellow Blinking @1 M/1 Mbps)
*PoE (Yellow) port 1-7 ON - PD detect
Port 8 ON – 4 pair power, Blinking-2 pair power
*POWER Green-normal, Red-alarm(for PSE-8G11xx only)
Power input DC power supply or Port 8 (UPLINK) from network switch or midspan
IEEE8 2.3af 44V~57V
IEEE8 2.3at 51V~57V
Power consumption 5W without PD loading
Power efficiency 83% at full load
Operating temperature -2 0℃~ 70℃
Operation humidity 9 % relative humidity, non-condensing
Storage temperature -30℃~+85℃
Dimensions 4 mm(H)x19 mm(W)x119mm(D)
