MT Displays Python User manual

1
Issue No: 12/2015-01 Rev: 01
DIGITAL
SIGNAGE
mt-digitalsignage.com
User Manuel

2Issue No: 12/2015-01 Rev: 01
Dear Customer,
Thank you for choosing MT Displays Digital Signage. MT Displays Digital Signage
products are designed and developed to use long me as long as it is looked aer as
per the informaon provided in this manual.
This manual includes most important informaon about MT Displays Digital
Signage products such as assembly, use and general care. MT Displays cannot be
held responsible in case of misuse or use of non-approved parts of Digital Signage
products.
Important: To know this product and use it for its best performance, please read the
instrucons in this manual carefully.
Warning: Read before using! In order to avoid any damage on parts and components,
it is imperave to keep instrucon menon in this manual. This manual covers use,
safety and maintenance of unit. Please keep this manual with your digital unit at all
me.
Notes
• Some of the wording in this manual can be technical.
• To avoid any damage on unit or person, the instrucons should be followed
• The informaon in this manual is protected by copyrights.
• No part of this publicaon maybe reproduced, stored in a retrieval system or
transmied in any form or by any means, technical, electronic, photo-copying,
recording or otherwise without the prior wrien permission of the publisher.
• The product in this manual cannot be subject to reverse engineering.
• The images in this manual represents the unit, may not be idencal to the
product sold.
!
!

3
Issue No: 12/2015-01 Rev: 01
Content
Safety Instrucons........................................................................................................................................... 4
Shipping And Handling ................................................................................................................................ 5
Product Informaon ...................................................................................................................................... 6
•Python.................................................................................................................................................. 6
•Cobra .................................................................................................................................................... 7
•Boa ........................................................................................................................................................ 9
•Viper................................................................................................................................................... 10
Assembly Instrucons ................................................................................................................................ 11
Operang Instrucons ............................................................................................................................... 12
Cleaning and Maintaining ....................................................................................................................... 18
Storage Condions ...................................................................................................................................... 18
Warranty Condions ................................................................................................................................... 18
Cercaon ..................................................................................................................................................... 19

4Issue No: 12/2015-01 Rev: 01
Safety Instrucons
•Suitable only for indoos use. Keep on dry oors.
• Do not use the damaged cables or plug.
• Do not touch the cable or unit with wet hands. It may result damage on the
person or unit.
• Since the front screen may easily damaged, do not put anything on unit.
• Do not use in outdoor condions.
• Do not unassemble or modify the unit.
• Ensure to turn o the unit and disconnect power supply before cleaning it.
• Keep away from heater or any high pressure equipment.
• Do not scratch surface or label on the unit.
• Do not use if the screen breaks.
• Do not bend power cable.
• Do not use in case:
- unit has any damage
- unit is any contact with any type of liquid
• If any above cases happen, do contact to MT Displays or your dealer.
• In case of any break down, do not open or mend unit. Otherwise it will breach
warranty condions.
• Use of damaged unit or parts, may cause serious injuries.
• Play safe during use or assembly.
• Do not bend power cable.
• Do not use any accessories if not provided by the manufacturer.
• Any error on unit or power supply, contact to your reseller or manufacturer
• Do not use unit in too hot or too cold or humid or dry environment.
• Do not pull power supply cable.
• Unit may heat output at certain degree.
• Keep away unit, components or accessories from heat or re.
• Unplug unit when not in use.
• Use AC power supply specied with the product.
• Do not connect to main power supply without AC adaptor.
• Avoid any impact on unit or power supply. Any damaged products may cause
over heeng which may result re or explosion.
• Unit should have venlaon.
• Keep unit away from magnec eld.
• Use when USB compartment securely closed.

5
Issue No: 12/2015-01 Rev: 01
• Use unit only for its purpose. Otherwise it will breach the guarantee
• Do not insert any foreign substance into unit or power supply. This may cause
serious injuries.
• Before using unit, make sure reading the manual.
Environmental Condions
Unit should be best used in temperature of 0-400C and relave humidity of %20 – 80
Power Supply
15.6” LCD TFT Screen
Input: 100-240V 50/60 Hz 1.5A
Output: 12V 2 A
21.5” LCD TFT Screen
Input: 100-240V 50/60 Hz 1.5A
Output: 12V 3 A
Shipping and Handling
• Avoid unit from dropping or stroke during transport
• Damages during transport is not covered by product warranty condions.
• Transport in original packaging.
• Transport fragile.

6Issue No: 12/2015-01 Rev: 01
Product Informaon
Panel Model
Max Resoluon
Aspect Rao
Pixel Pitch
Viewing Angle
Contrast Rao
Brightness
Response Time
Operaon Temp
Size
21.5” LCD TFT
1920*1080
16:09
0.24825x0.24825
89/89/89/89
3000:1
250cd/m
25ms
(0~50°C)
21,5 Inch
Screen Specicaons
Key Features
Power supplies provided with Digital Signage are suitable to
use 7/16. If 7/24 use required, please order individually as
UYPLD00010 7/24 Power supply EU 3,34A.
Input
Output
100-240V 50/60 Hz 1.53A Max.
12V 3A Max.
Power Supply
Python Digital Kiosk-21,5”-Black
Accessories Included
• Remote control
• USB compartment key x 2
• 3A power supply
Screen Size: 21,5”
Colour: Black
Dimensions: 474 mm(W) X 379 mm(D) X 1665 mm(H)
Pack Size:
1665 mm
40 mm
474 mm
422 mm
323 mm
379 mm
21,5” screen
USB compartment
UDKP0VB215
UDKP1VB215
Without speakers
With speakers
Arcle Descripon
Jack

7
Issue No: 12/2015-01 Rev: 01
Key Features
Cobra Digital Kiosk-15,6”-Black, Portrait
Power supplies provided with Digital Signage are
suitable to use 7/16. If 7/24 use required, please
order individually as UYPLD00010 7/24 Power
supply EU 3,34A.
Input
Output
100-240V 50/60 Hz 1.53A Max.
12V 2A Max.
Power Supply
Panel Model
Max Resoluon
Aspect Rao
Pixel Pitch
Viewing Angle
Contrast Rao
Brightness
Response Time
Operaon Temp
Size
15.6” LCD TFT
1920*1080
16:09
0.17925*0.17925
89/89/89/89
400:1
250cd/m
35ms
(0~50°C)
15.6 Inch
Screen Specicaons
Accessories Included
• Remote control
• USB compartment key x 2
• 2A power supply
Screen Size: 15,6”
Colour: Black
Dimensions: 404 mm(W) X 379 mm(D) X 1300 mm(H)
Pack Size:
1300 mm
379 mm
40 mm
404 mm
257 mm
351 mm
USB compartment
Jack
UDKC0VB156
UDKC1VB156
Without speakers
With speakers
Arcle Descripon
15,6” screen

8Issue No: 12/2015-01 Rev: 01
Cobra Digital Kiosk-15,6”-Black, Landscape
Power supplies provided with Digital Signage are
suitable to use 7/16. If 7/24 use required, please
order individually as UYPLD00010 7/24 Power
supply EU 3,34A.
Input
Output
100-240V 50/60 Hz 1.53A Max.
12V 2A Max.
Power Supply
Panel Model
Max Resoluon
Aspect Rao
Pixel Pitch
Viewing Angle
Contrast Rao
Brightness
Response Time
Operaon Temp
Size
15.6” LCD TFT
1920*1080
16:09
0.17925*0.17925
89/89/89/89
400:1
250cd/m
35ms
(0~50°C)
15.6 Inch
Screen Specicaons
379 mm
1133 mm
467,5 mm
40 mm
404 mm
351 mm
Key Features
Accessories Included
• Remote control
• USB compartment key x 2
• 2A power supply
Screen Size: 15,6”
Colour: Black
Dimensions: 467,5 mm(W) X 379 mm(D) X 1133 mm(H)
Pack Size:
UDKC0LB156
UDKC1LB156
Without speakers
With speakers
Arcle Descripon
USB compartment
Jack
21,5” screen

9
Issue No: 12/2015-01 Rev: 01
Boa Digital Kiosk-21,5”-Black
Power supplies provided with Digital Signage are
suitable to use 7/16. If 7/24 use required, please
order individually as UYPLD00010 7/24 Power
supply EU 3,34A.
Input
Output
100-240V 50/60 Hz 1.53A Max.
12V 3A Max.
Power Supply
Panel Model
Max Resoluon
Aspect Rao
Pixel Pitch
Viewing Angle
Contrast Rao
Brightness
Response Time
Operaon Temp
Size
21.5” LCD TFT
1920*1080
16:09
0.24825x0.24825
89/89/89/89
3000:1
250cd/m
25ms
(0~50°C)
21,5Inch
Screen Specicaons
1200 mm
60 mm
337 mm
516 mm
476 mm
Key Features
Accessories Included
• Remote control
• USB compartment key x 2
• 3A power supply
Screen Size: 15,6”
Colour: Black
Dimensions: 476 mm(W) X 516 mm(D) X 1200 mm(H)
Pack Size:
UDKB0VB215
UDKB1VB215
Without speakers
With speakers
Arcle Descripon
USB compartment
Jack
21,5” screen

10 Issue No: 12/2015-01 Rev: 01
Viper Digital Board-21,5”-Black
Power supplies provided with Digital Signage are
suitable to use 7/16. If 7/24 use required, please
order individually as UYPLD00010 7/24 Power
supply EU 3,34A.
Do not install your Wall Mount Kit while your
screen is turned on It may result in personal injurt
due to electric shock.
Input
Output
100-240V 50/60 Hz 1.53A Max.
12V 3A Max.
Power Supply
Panel Model
Max Resoluon
Aspect Rao
Pixel Pitch
Viewing Angle
Contrast Rao
Brightness
Response Time
Operaon Temp
Size
21.5” LCD TFT
1920*1080
16:09
0.24825x0.24825
89/89/89/89
3000:1
250cd/m
25ms
(0~50°C)
21,5Inch
Screen Specicaons
586 mm
38 mm
339 mm
Key Features
Accessories Included
• Remote control
• USB compartment key x 2
• 3A power supply
• Vesa bracket
Screen Size: 15,6”
Colour: Black
Dimensions: 586 mm(W) X 38 mm(D) X 339 mm(H)
Pack Size:
UDKV0VB215
UDKV1VB215
Without speakers
With speakers
Arcle Descripon
21,5” screen
USB compartment
USB USB
compartment key
HDMI
Jack

11
Issue No: 12/2015-01 Rev: 01
Assembly Instrucons
Python Digital Kiosk-21,5”-Black
Viper Digital Board-21,5”-Black
Boa Digital Kiosk-21,5”-Black
1
2 4 5
3
1 2
3
4
12

12 Issue No: 12/2015-01 Rev: 01
Operang Instrucons
1. Product Descripon
Our HD Media Player product could drive 1920x1080 and below this resoluon LVDS
Panel, can be used for all kinds of electronic products, support 1080p HD Video
playback, it not only has digital mul-media all kinds of playback funcon, also has
rich external funcon interface, making your product with full advantages, and
making all kinds of market requirements.
Features:
• Support USB Copy funcon (max 8GB)
• Support format: MPG1\2\3\4/AVI/RM/RMVB/MP3/JPG……
• Support USB Playback
• Support Rolling subtles
• Support Logo displayed
• Support every week (7 days Mon-Sun)Timer on/o, 5 groups every day)
• Support Timer on/o every day, 5 groups every day
• Support play log
2. Funcon
Main menu includes four opons: Basic Seng, Time Seng, Text Seng, Display
Seng.
In the playback mode, please press Stop buon rst, then press “Setup” buon to
enter the menu, use Up/Down/Le/Right Navigaon buon to choose these opons.
2.1 Seng
Language
English
French
Japanese
Espaol
Italiano
Portugues
Pусский
Chinese
Auto Play
On/O

13
Issue No: 12/2015-01 Rev: 01
Media Type
All/Movie/Photo/Music/Photo+Music
Play mode
Repeat all/Repeat 1/Repeat none
Play Log
On/o
Play Record
O/3s/5s/8s/10s/15s/20s/30s/40s/50s/60s
Slide Mode
On/o
Slide Time
3s/5s/8s/10s/15s/20s/25s/30s/40s/50s/60s
Photo Rotate
Normal/90 Degree/180 degree/270 Degree
Min Volume
0~100
USB Disk Auto Copy funcon
1. Enter the menu rst, then choose one
of below two opons: Copy Type and Copy
Device, Aer nished the setup, exit the
menu.
2. Insert USB into player, the player will
copy the les in the USB Disk into SD Card
automacally. Aer auto copy, the player
will restart automacally to play the les
you update.
Copy Type
Manually update/Fully update/Overlap
update/Append update
Copy Device
B2A USB→SD/CF/A2B CF/SD→USB,Please
choose B2A for default opons
2.2 Clock
Current Clock
Year/Month/Date/Hour/Minute/Sec.

14 Issue No: 12/2015-01 Rev: 01
2.2 Zaman Ayarı
Clock show
OFF/HM/HMS/YMD_HM/YMD_HMS/
YMD_W_HM/YMD_W_HMS
Clock Text Color
White/Black/Red/Blue/Yellow/Green/Grey
Clock Posion
Right-Top/Le-Top
Timer Mode
Every day/Every week
Timer Set
Timer 0-Timer 4
2.3 Advance
Roll Text
On/O
Text Color
White/Black/Red/Blue/Yellow/Green/
Grey
BG (Text background ) Color
Transparent/White/Black/Red/Blue/
Yellow/Green/Grey
Roll Speed
Low/Middle/High
Logo Setup
On/o
Logo on Time 3S/5S/8S/10S/15S/20S/2
5S/30S/40S/50S/60S
Logo o Time (0S3S/5S/8S/10S/15S/20S
/25S/30S/40S/50S/60S
Set Password
Setup menu password, use VOL-
VOL+|<< >>|>> buon to make setup
Key Lock
On/o

15
Issue No: 12/2015-01 Rev: 01
2.4 Picture
Brightness
0~100
Contrast
0~100
Color
0~100
Sharpness
0~100
Color Temp RED
0~148
Color Temp Green
0~148
Color Temp Blue
0~148
Noise Reducon
OFF/Low/Middle/High/Default
Aspect Rao
Just Scan/Auto/4:3/16:9/Panorama
OSD Rotate
Normal/90°/180°/270°

16 Issue No: 12/2015-01 Rev: 01
3. How to make the Roll text  le
To create a new  le named SCROLL.TXT, use TXT tools to open, just like the below picture
Then enter the text you need, save as ANSI code, than copy this  le into root directory of
USB/SD card. (note: Setup Roll Text at “on” mode).
4. How to make LOGO  le
First, choose one JPG  le as Logo  le (resolu on is 120px x 60px), named as JIAOBIAO.LOG
Then, copy this  le into the root directory of memory card. Note: Please make Logo setup
op on at “on” mode, on  me 60sec and o  me “0” sec. if required di erent, adjust the
on and o  me.
5. Play log
In the Se ng menu, please make Play Log at “on” mode  rst, then you could  nd LOG.
TXT  le in the root directory of memory card. You will see it as LOG.XLS.

17
Issue No: 12/2015-01 Rev: 01
Aer opening the le, it will display the below informaon,
Date means play date
Time means play me
File Name means play le
Status means play status (Succeed / Failure)
Remote Controller
Date Time File Name Status
2013-1-1 14:21:03 2308.jpg Succeed!
2013-1-1 14:21:08 1280x720_100%.jpg Succeed!
2013-1-1 14:21:13 1920x1080_04.jpg Succeed!
2013-1-1 14:24:13 2308.jpg Succeed!
2013-1-1 14:24:19 1280x720_100%.jpg Succeed!
2013-1-1 14:24:24 1920x1080_04.jpg Succeed!
2013-1-1 14:24:34 022.avi Succeed!
2013-1-1 14:28:30 oppo.avi Succeed!
2013-1-1 14:30:00 DJG.mpg Succeed!
2013-1-1 14:31:01 007.mp3 Succeed!
2013-1-1 14:31:33 1949.mp3 Succeed!
Power on/o buon
Mute buon to control sound on/o
Mode swi
Copy funcon
STOP Buon
Enter main menu setup
Exit buon
Up navigaon buon
Down navigaon buon
Le navigaon buon
Right navigaon buon
Enter buon
Vol+
Vol-
Play/pause
Fast forward
Fast Backward
Next
Previous
EXIT
SETUP
INPUT
ENTER
COPY

18 Issue No: 12/2015-01 Rev: 01
Support Video/Audio/Picture Format
Format
Video encode
Audio Encode
Video
Music
Max. Resoluon
Max Color
Max Frame
Max stream
Sampling
Bit rate
MPG,MPG-1,MPG-2 MPG-4,AVI,MP4 MOV FLV 3GP,
M2TS,MKV RM RMVB
JPEG BMP PNG
MP3
1920*1080@60Hz
24bit
30frm/s
USB2.0 device:20Mbit/sec
32kHz,44.1kHz,48kHz,96kHz
32kbps to 448kbps
Cleaning and Maintaning
Warranty Condions
To clean the unit, take o all cables connected. Clean the unit with a so clot (not
supplied with the unit)
Warning: Do not use any liquids
Warning: Never use any detergent soluons, spray, solvent or similar, as they
damage the nish.
Digital Signage products are warranted against manufacturing faults when used
in the below menoned condions for the period of one (1) year. MT Displays
undertake to repair or replace the product at no charge if found to be defecve due
to a manufacturing fault during the warranty period. The warranty excludes damage
caused by misuse, neglect, shipping accident, incorrect installaon, and no fault found
with the product or work carried out by anyone other than MT Displays assigned.
MT Displays is not responsible for loss of the product, or for other incidental, special
or consequenal damages or expenses incurred by the purchaser, or for labour or
other costs due to installaon or removal or cost of repairs by other or for any other
expenses not specically stated above.
Storage Condions
If not in use for min 1 week, take o micro SD or USB and power supply. If not
in use longer than 1 month, store it wrapped in so cloth in dry and venlated
environment. Keep away from direct sun.
!
!

19
Issue No: 12/2015-01 Rev: 01
Transport
When sending the product, use the original packing materials, the inner and outer
cartons. If the original packaging is no longer available, use at least bubble wrap and
insert the product in a carton which holds at least 40kg. Important: Any damage in
transit, including scratches, breaks and indentaon in the housing of the product is
NOT covered by this warranty.
NOTE: The use of chlorine or chlorine related products for cleaning can seriously
damage the nish and funcon on the aluminium and plasc surfaces.
Verification of Conformity
EMC Directive 2004/108/EC
Certification No.: TOS11121640
Test Report Ref. No.: 68.5.12.11.0469.01
Holder Of Certificate: Guangzhou Dajing Science and Technology Co., Ltd.
2007-2008, 2F, Block A3, Longyuan Building, 561 Tianhe Road, Tianhe
District, Guangzhou, China
Manufacturer: GuangZhou Dimesion electronic CO., LTD
Product: AC Adapter
Model No.: Please refer to the annex
Parameters: Please refer to the annex
Standards: EN 55022:2010, EN 55024:2010
EN 61000-3-2:2006+A1:2009+A2:2009, EN 61000-3-3:2008
The statement is based on a single evaluation of one sample of above mentioned products. It does not imply an assessment
of the whole production and does not permit the use of the test lab. Logo.
The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in
this report. The applicant should hold the whole technical report at disposal of the competent all the right.
Issued Date:2011-12-30 Prince Wang
Chief Director
After preparation of the necessary technical documentation as well as the EC Declaration of
Conformity the required CE marking can be affixed on the product. Other relevant directives have to
be observed.
A
Ap pp pr ro ov ve ed db by y: :T TE EN N- -O ON NE ES SE ER RV VI IC CE ES SC CO O. ., ,L LT TD D. .W We eb bs si it te e: :w ww ww w. .t to os s- -a as si ia a. .c co om m
The warranty is in eect for the period and usage described above from the date of purchase
from MT Displays. MT Displays can supply parts and accessories aer warranty expires.
To Claim Your Warranty
1. Please contact your distributor or reseller and explain the nature of problem with photos
of the product which shows clearly defect and the environment it has been used.
2. Provide your supplier batch number on Digital Signage unit and proof of purchase.
3. If the claim is within the warranty period and within the terms of the warranty, you will be
required to return your product to manufacturer to analyse the nature of problem at your
cost.
4. As long as the manufacturer conrms the problem is a manufacturing fault, the
replacement can be provided. Unless product or any parts are not returned the
manufacturer for analyses, manufacturer cannot provide replacements.
5. It is user’s responsibility to return the product to distributor or reseller or collect the
replacement.

20 Issue No: 12/2015-01 Rev: 01
MT DISPLAYS FACTORY
Cumhuriyet Mahallesi, Selin Sokak
No:1 41400 Çayırova / Kocaeli - TURKEY
T: [phone] (Pbx)
F: [phone]
[email protected]
www.mtdisplays.com.tr
www.mtplastech.com
www.opti-frame.com
www.mt-digitalsignage.com
MT DISPLAYS LLC
320 W Commercial Ave
Moonachie NJ 07074 1633
Toll Free: 855.678.1000
T: [phone]
[email protected]
www.mtdisplaysllc.com
MT DISPLAYS HUNGARY KFT
Hungary, 2071 Páty, Prologis
Park Budapest M1, DC2 épület
T: +36 23 814 - 050
[email protected]
1200465
mt-digitalsignage.com
