MTB Baumalight QC Series User manual

QC Series Generators
OPERATOR’S MANUAL
Issue Date: December 2016

TABLE OF CONTENTS
SECTION DESCRIPTION PAGE
1
1.1
2
2.1
2.2
2.3
3
4
4.1
4.2
4.3
5
5.1
5.1.1
5.2
5.3
5.4
5.5
5.6
5.6.1
5.6.2
5.6.3
5.6.4
6
6.1
6.1.1
6.1.2
6.1.3
6.2
6.2.1
6.2.2
6.2.3
6.2.4
6.2.5
6.2.6
7
8
Introduction
Overview
Safety
Safety Alert Symbol And Safety Words
Operational Hazards
Maintenance Hazards
Safety Signs
Assembly
Remove Shipping Dunnage And Parts
Remove Generator From Pallet
Driveline Dimension
Operation
Preparation For Use
Neutral Bond To Ground
Machine Components
Attaching Generator To Tractor
Detaching Generator From Tractor
Transporting
Operating The Generator
Initial Start-Up
Monitoring The Load
Shutting Down The Generator
Storing The Generator
Service And Maintenance
Service
Electrical Tests
Automatic Voltage Regulator Operational Test
Voltage Regulator Adjustment
Maintenance
Lubrication Symbol
Every 10 Hours
Every 1000 Hours
Severe Service Recommendations
Maintaining The Permanent Magnets
Restoring Residual Magnetism
Troubleshooting
Warranty
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
............
1
1
2
2
3
6
7
8
8
8
8
10
10
10
10
11
13
13
14
15
16
16
17
18
18
18
19
20
21
22
22
23
23
24
24
25
28
ii

1 INTRODUCTION
Congratulations on your choice of a Baumalight QC Series Generator. This equipment has been designed
and manufactured to meet the needs of a discriminating buyer for efcient auxiliary power.
The Generator is powered by the Power Take Off (PTO) on your tractor.
Safe, efcient and trouble free operation of your Generator requires that you and anyone else who will
be operating or maintaining the Generator, read and understand the Safety, Operation, Maintenance and
Troubleshooting information contained within the Operator’s Manual.
This manual covers the Baumalight QC Series Generators. Use the Table of Contents as a guide to
locate required information.
Keep this manual handy for frequent reference and to pass on to new operators or owners. Call your
Baumalight dealer, distributor or the factory if you need assistance, information or additional copies of
the manuals.
When this machine is worn out and no longer in use, it should be returned to the retailer or other party
for recycling.
OPERATOR ORIENTATION - The directions left, right, front and rear, as mentioned throughout this
manual, are as seen from the tractor driver’s seat and facing in the direction of travel.
1.1 Overview
1

2 SAFETY
You must read, understand and follow the
instructions given by the operating unit
manufacturers, as well as the instructions in this
manual.
The safety information in this manual is denoted
by the safety alert symbol:
This symbol means ATTENTION! BECOME
ALERT! YOUR SAFETY IS INVOLVED!
The level of risk is indicated by the following signal
words:
^DANGER
DANGER - Indicates a hazardous
situation, which, if not avoided, WILL
result in death or serious injury.
^WARNING
WARNING - Indicates a hazardous
situation, which, if not avoided, could
result in death or serious injury.
^CAUTION
CAUTION - Indicates a hazardous
situation, which, if not avoided, could
result in minor or moderate injury.
NOTICE
NOTICE - Indicates a situation that could
result in damage to the equipment or
other property.
2.1 Safety Alert Symbol
And Safety Words
2

2.2 Operational Hazards
^WARNING
Prevent serious injury or death.
Read and understand this manual before
operating generator.
Never allow anyone near the generator
and tractor during operation.
Travel at a safe speed.
^WARNING
Prevent serious injury or death from
moving parts.
Moving parts can crush and dismember.
Do not operate without guards and
shields in place.
Disconnect and lock out power source
before adjusting or servicing.
^WARNING
Use generator only for the designed
applications.
Any other use may result in personal
injury, damage to equipment and may
void the warranty.
^WARNING
Prevent serious injury or death.
Verify generator is hitched to tractor
before operation or transport.
Verify generator driveline is attached to
tractor.
Carefully read all safety messages in this manual
and on equipment safety signs. Keep safety signs
in good condition and replace missing or damaged
safety signs.
New equipment components and repair parts must
include the current safety decal.
Learn how to properly operate equipment.
NEVER operate or work around this equipment
without proper instruction, while fatigued or under
the inuence of alcohol, prescription or non-
prescription medication or if feeling ill.
Keep your equipment in proper working condition.
Know the regulations and laws that apply to you
and your industry. This manual is not to replace
any regulations or laws. Additional information
may be found at: www.asae.org or www.osha.gov.
If you do not understand any part of this manual,
contact Baumalight at 866-820-7603.
3

Prepare For Emergencies
• Be prepared in case of emergencies.
• Keep a re extinguisher and rst aid kit close
to the machine.
• Keep emergency phone numbers close to your
phone.
• Know your address so emergency services
can locate you if an emergency arises.
Replace Safety Signs
• Replace missing or damaged safety signs.
• Safety signs are identied in Section 3 of this
manual.
• Replacement safety signs are available from
your Baumalight dealer.
Do Not Allow Riders
• NEVER carry anyone with generator.
• NEVER use generator as a work platform.
• NEVER allow passengers on generator.
Lower Operating Speed
• Lower operating speed while loading,
unloading or performing heavy operations.
• Keep load low and move at slow speeds on
rough or uneven terrain.
Avoid Rollover
The equipment may rollover, resulting in death or
serious injury. To help prevent rollover:
• Travel at a slow speed.
• Avoid sharp turns & sudden movement on
slopes.
• Avoid holes, ditches and other obstructions
which may cause equipment to rollover.
• Use caution when operating on slopes and do
not operate on excessively steep slopes.
^WARNING
Risk of electrocution. High voltages are
present at the generator’s terminals
when the unit is running.
Additionally, accessory equipment
such as space heaters can be energized
from an outside power source when the
unit is at rest. Be sure to disconnect all
sources of power before working on
equipment.
4

Detach Generator Safely
Detach generator on a rm and level surface.
Generator may roll away if detached on sloping
or soft surface. Be sure people, livestock and pets
are clear of machinery.
Hazards From Modifying
Equipment
Do not make any alterations to your generator.
Altering the equipment may cause unsafe
conditions and may void the manufacturer’s
warranty.
Stay Clear Of Rotating
Drivelines
^WARNING
Entanglement in a rotating driveline can
cause serious injury or death.
Keep tractor shields and driveline
shields in place at all times. DO NOT
operate without driveline guards.
DO NOT wear loose tting clothing.
5

2.3 Maintenance Hazards
Maintenance
Before servicing, park machine on a rm and
level surface, set parking brake, chock wheels,
and place a “Do Not Operate” tag on control
panel. Read and understand this manual. If you
do not understand any part of the manual, contact
Baumalight at 866-820-7603.
Always wear face and/or eye protection, safety
shoes, and other protective equipment appropriate
for the job.
Do not make unauthorized modications. Contact
Baumalight at 866-820-7603 before you weld, cut/
drill holes, or make any other modications.
Always use Baumalight replacement parts.
^WARNING
Moving parts can crush and cut.
Keep clear of moving components.
Follow lockout procedure before
servicing.
^WARNING
Crushing hazard.
Before performing inspections, service
or maintenance:
• Park machine on rm, level surface.
• Engage parking brake.
• Turn engine off and remove key.
• Place “Do Not Operate” tag on
control panel.
^WARNING
Entanglement hazard.
Keep clear of moving components.
Wear proper protective equipment
appropriate for the job.
^WARNING
Burn hazard.
Hot and high pressure hydraulic oil.
Allow oil to cool before servicing.
6

A. MTB-020 Safety Sign
3 SAFETY SIGNS
B. Safety Sign
C. MTB-111 Safety Sign
7

^WARNING
Depending on model, approximate
weight of the generator is 269 - 674 kg
(592 - 1485 lbs)
Do not position feet around or under
pallet.
1. Remove crate material from pallet.
2. Remove all shipping bands, wires and loose
parts from around generator.
4 Assembly
4.1 Remove Shipping
Dunnage And Parts
4.2 Remove Generator
From Pallet
1. Attach hitch to generator frame.
2. Roll generator off of pallet onto oor.
3. Install PTO driveline.
4.3 Driveline Dimension
A PTO driveline is supplied with the machine.
To accompany the variety of hitch geometry
available today, the driveline can be too long for
most machines or too short for others. It is very
important that the driveline be free to telescope
but not to bottom out when going through its
working range. If the driveline bottoms out, the
bearings on both the machine and tractor PTO
shaft will be overloaded and fail in a short time.
1. To determine the proper length of the
driveline, follow this procedure:
a. Clear the area of all bystanders.
b. Attach generator to tractor (see section
5.3) but do not attach driveline.
c. Measure dimension between locking
grooves on tractor PTO shaft and
machine input shaft.
d. Measure the same dimensions on the
compressed driveline.
e. If compressed driveline dimension
exceeds the machine dimension,
driveline will have to be cut.
2. When cutting the driveline, follow this
procedure:
a. Subtract machine dimension (A) from
uncut driveline dimension (B) or (B-A).
This dimension determines how much
too long the driveline is.
b. Add another 1 inch (25 mm) to the
dimension to be sure it doesn’t bottom out,
to determine (C) the cut off dimension.
c. Use a hacksaw to cut dimension (C) from
both ends. Cut both plastic tubes and
metal cores.
d. Use a le to remove burrs from edges
that were cut.
e. Assemble the 2 ends of the shaft.
8
