MTD HB227 Manual

REPLACEMENT PARTS - MODEL HB227
2-C CLE GAS BLOWER
PPN 41AS2SCG912
PARTS LIST PART NO. 769-05637 P00 Issued 2/10
1
2
35
7
19
21
22
6
12
10 9
11
4
18
15
14
8
13
7
4
17 20
16
Item Part No. Description
1 753-04620 Muffler Screws
2 753-06027 Muffler Assembly (includes 1 & 3)
3 753-05946 Muffler G sket
4 753-05703 Screw
5 753-05784 Sp rk Plug
6 753-05704 Cylinder G sket
7 753-05947 Shortblock Assembly (includes 4-6 & 8-11)
8 753-05948 Flywheel Assembly
9 753-04833 W sher
10 753-05687 Nut
11 753-05866 Module Assembly
Item Part No. Description
12 753-05949 Le d Wire
13 753-04595 Screw
14 753-05950 Fuel T nk Assembly (includes 13 & 15)
15 791-182529 Fuel C p
16 753-05702 Insul tor G sket
17 753-05632 Insul tor Assembly (includes 16)
18 791-181709 C rburetor G sket
19 753-05951 C rburetor Assembly (includes 18)
20 753-05725 Aircle ner Assembly (includes 21)
21 791-181757 Air Filter
22 753-05952 Throttle C ble

REPLACEMENT PARTS - MODEL HB227
2-C CLE GAS BLOWER
PPN 41AS2SCG912
Issued 2/10
2
1
912
10
8
14
17 14 18
13
6
9
19
3
4
7
4
20
3
15
5
3
11
16
21
Item Part No. Description
1 753-05937 Lower Tube
2 753-05936 Upper Tube
3 753-04595 Screw
4 791-181862 Screw
5 753-06144 Engine Cover Assembly (includes 3 & 4)
6 753-05944 Muffler Cover Assembly (includes 3)
7 753-05932 Outer Trigger Lock
8 753-05921 Impeller Housing (includes 9)
9 753-05919 H ndle Grips
10 753-05924 Inner Trigger Lock
11 753-05925 W vey W sher
Item Part No. Description
12 791-182405 Switch
13 753-05930 Throttle Trigger
14 753-05928 W sher
15 753-05926 L tch Tube
16 753-05939 L tch Spring
17 753-05929 Impeller
18 753-05927 Nut
19 753-05920 Impeller Housing (includes 9)
20 753-05917 Int ke Cover
21 753-05918 Spring
22 753-04834 Lock W sher
