MTD 510 Series Setup guide

MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
Op e r a t O r ’sMa n u a l
Log Splitter — Model Series 510 thru 570
Form No. 769-03971A
(April 14, 2008)

20
22
B
54
32
A
60
8
81
63
68
79
5
4780
6
3
223
32
A
9
40
65
57
20
10
13
58
56
41
34
41
39
36
42
24
31
23
22
25
18 12
11
15
19
1
41
C
C
51
23
D
53
54
B
60
21
71
23
51 55
44
67
65
61
62
44
41
41 69
52
48
45
73
48
50
30
27
28
26
72 59
29
59
72
61
33
17
44
37
38
14
78 75
74
77
18
35
49
47
76
46
D
48
20
Illustrated Parts List 9

21se c t i O n 12 — il l u s t r a t e d pa r t s li s t
Ref. Part Number Description
1. 718-0769A Hydraulic Cylinder
2. 727-04166 Hydraulic Tube
3. 710-1018 Hex Cap Screw, ⁄-20 x 2.75
4. 737-0192 90 Degree Solid Adapter
5. 718-0481A Control Valve — 570 Series
—718-04533 Control Valve — 550 Series
6. 737- 0153 Return Elbow
7. 737-0238 Nipple Pipe, ⁄-14
8. 710-1806 Hex Cap Screw, ⁄-13 x 3.25
9. 719-0550A Wedge Assembly
10. 712-3058 Hex Lock Nut, ⁄-20
11. 712-0711 Hex Jam Nut, ⁄-24
12. 710-0459A Hex Cap Screw, ⁄-24 x 1.5
13. 781-0351 Adjustable Gib
14. 736 - 0116 Flat Washer, .635 x.93 x.06
15. 712-3022 Hex Lock Nut, ⁄-13
16. 681- 04071A Beam Assembly
17. 710-3056 Hex Screw, ⁄-18 x 3.25
18. 710-0654A Hex Washer Screw, ⁄-16 x 1.0
19. 781-1048A Dislodger Bracket
20. 781-0790 Back Plate
21. 737-04093 Inlet Filter
22. 727-0443 Return Hose, ⁄” ID x 44” Lg.
23. 726 - 0132 Hose Clamp, ⁄”
24. 737-0316 Filter Housing
25. 723-0405 Oil Filter
26. 734-0873 Hub Cap
27. 714-0162 Cotter Pin
28. 712- 0359 Slotted Nut, ⁄-16
29. 634-0186 Wheel Assembly
30. 736-0351 Flat Washer, .760 ID x.500 OD
31. 737-0312 Adapter, ⁄-14
32. 781-0526A Hose Guard
33. 737-0348A Vented Dipstick
34. 711-1587 Clevis Pin
35. 781-0690 Lock Rod
36. 714-0470 Cotter Pin
37. 726-0214 Push Cap
38. 732-0583 Compression Spring
39. 781-04180 Log Tray Bracket
40. 710-04484 Hex Washer Screw, ⁄-18 x .750
41. 712- 04065 Flange Lock Nut, ⁄-16
42. 781-04179 Log Tray
Ref. Part Number Description
43. 681-04040A Frame Assembly
44. 710-0521 Hex Bolt, ⁄-16 x 3”
45. 719-0353 Coupling Shield
46. 714 - 0122 Square Key, ⁄” x.75
47. 718-04392 Coupling, .500
—718-04393 Coupling, 1.00
—735-04103 Spider Bushing
—710-1842 Set Screws
48. 712-04063 Flange Lock Nut, ⁄-18
49. 781-0097 Rear Coupling Support Bracket
50. 781-1024 Fender Mounting Bracket
51. 727-04130 Hose
52. 718- 04127 Gear Pump
53. 737-0329 45 Degree Elbow Fitting
54. 727-0502 High Pressure Hydraulic Hose
55. 781-0788 Tongue Assembly
56. 747-1261 Latch Rod
57. 781-1045 Latch
58. 732-3127 Compression Spring
59. 736-0371 Flat Washer
60. 781-0538A Hose Guard
61. 710-3085 Hex Cap Screw, ⁄-16 x 3.50
62. 736-0185 Flat Washer, .375 x.738 x.063
63. 747-04539 Hydraulic Valve Control
64. 681-04030 Hitch Coupling Assembly
65. 713-0433A Chain
66. 731-2496A Fender
67. 711- 0 813 Clevis Pin
68. 720-04088 Grip
69. 732-0194 Spring Pin
70. 781-0789 Jack Stand
71. 715-0120 Spiral Pin
72. 710-0650 TT Screw, ⁄-18 x 0.875”
73. 710-0602 TT Screw, ⁄-18 x 1.00
74. 625-0062 Light Kit (A)
75. 681-0164 Light Bracket — LH (A)
—781-1027A Light Bracket — RH (A)
76. 710-0376 Hex Screw, ⁄-18 x 1.00
77. 712-3008 Jam Nut, ⁄-16 (A)
78. 726-0201 Speed Nut, .3125 ID (A)
79. 711- 0 4585 Clevis Pin
80. 713-04036 Valve Handle Link
81. 714 - 0111 Cotter Pin
A — Equipped on 570 Model
21se c t i O n 12 — il l u s t r a t e d pa r t s li s t
