MTL WIO-800LR User manual
Quick Start Guide
QSG 800LR
WIO-800LR
wireless I/O receiver unit
2QSG 800LR-1.8
May 2010
ABOUT THIS DOCUMENT
This is the Quick Start Guide for the MTL WIO-800LR Wireless I/O Receiver
Unit and contains the following sections:
Section Read this section if you want to …
1Basic steps for
using your unit
Learn the basic steps for installing and using
your unit.
2Factory default
configuration
Understand how the transmitter sends
information to the receiver.
3 Unit components Understand the different parts of your unit.
4 Antenna installation Learn how to install an antenna with your unit.
5Resetting factory
defaults
Reset your unit to the original factory default
settings.
6 Linking Tx and Rx units Link your units to work as a dedicated pair.
7 Safety information
Understand important safety information related
to your unit.
NOTE: You must read this information before
installing your unit.
8 Specifications See the technical information.
For more information, see the following sections.
1 Basic steps for using your unit
This document describes how to configure your unit using the default factory
configuration that lets you easily setup your network as a simple send/receive
network using a dedicated pair of transmitter and receiver units.
The basic steps for using your unit are:
1. Connect the antenna power supply and transducer signals using the
instructions in this document. Power supply and transducer connection
is described in the section Unit components and connections. Antenna
connection is described in the section Antenna installation. For more
information, see the WIO-800L Installation Manual.
2. Reset the transmitter and receiver units to the factory default configurations.
3. Link the transmitter and receiver units to work as a dedicated pair.
4. Bench test your configuration before deploying.
NOTE: You can also configure your network using a user-defined customised
configuration that lets you set specific information about your network. For
more information on setting a user-defined customised configuration, see the
WIO-800L User Manual on the enclosed CD.
2 Factory default configuration
When you configure the units using the configuration in this document, the
inputs from the transmitter are sent to the outputs at the receiver as follows
WIO-800LT(Transmitter) Sends WIO-800LR (Receiver)
Digital Input 1 _ Digital Output 1
Digital Input 2 _ Digital Output 2
Analogue Setpoint _ Digital Output 3
Analogue input (4-20 mA) _ Analog output (4-20 mA)
Thermocouple Input (Not used) Communication Failure
(Comes on if no messages
from WIO-800LT)
Setpoint Output (Local indication)
System OK (On if system OK) System OK (On if system OK)
3
QSG 800LR-1.8
May 2010
3 Unit components and connections
Your WIO-800LR receiver unit has the following components and terminal
connections:
IMPORTANT ELECTRICAL SAFETY INFORMATION
In order to comply with Electrical Safety Regulations, this module must be installed in
an Electrical AND Fire enclosure. This enclosure may be a single or multiple enclosures.
Access to the module is to be made by a Service Person only.
In order to comply with Electrical Safety Standards, when connecting SELV AND
voltages which are greater than SELV (30VAC or 60VDC) together, then Relay Output 2
must NOT be used in order to provide sufficient isolation between the outputs.
4QSG 800LR-1.8
May 2010
The front panel provides the following components:
The LEDs on the front panel indicate the unit status:
LED Status Indicates
None No power supply.
OK Green Current status of the unit OK.
OK Red Fault condition detected in unit.
RX Flashes Receiving Message.
CF ON Module Communication Failure Output is active.
PG ON Configuration Cable Connected.
D1, D2, D3 ON The Output LEDS (D1, D2, D3) light when the corresponding output is active.
D1 Relay output D1 is ON (i.e. contact closed).
D2 Relay Output D2 is ON.
D3 Relay Output D3 is ON.
LEDs with RSSI
Push Button
Pressed
When you press the RSSI push button, the unit shows the signal strength by
lighting the LEDs from the bottom to the top. Signal strength is the strength
of the last message received that was addressed to this station.
LED Signal Strength LED Signal Strength
D1 Better than -85 dBm RX Better than -100 dBm
D2 Better than -90 dBm CF Better than -105 dBm
D3 Better than -95 dBm PG Always on during RSSI
test
Output LED
flashing quickly
If an output is in communication failure, the corresponding LED flashes at 5 Hz.
D1 Relay Output D1 is in communication failure.
D2 Relay Output D2 is in communication failure.
D3 Relay Output D3 is in communication failure.
PG Analog output is in communications failure.
SMA antenna connector
at top of unit
RS232 configuration port
RSSI push button
5
QSG 800LR-1.8
May 2010
4 Antenna installation
The antenna must be be installed above all local obstructions
5 Resetting your unit to factory defaults
You must reset the receiver unit to factory defaults before linking the
transmitter and receiver units.
To reset the default factory configuration:
1. Press and hold the RSSI push button.
2. Power on the WIO-800LR receiver.
3. The WIO-800LR receiver flashes all LEDs at medium flash (i.e. 1.6 Hz).
NOTE: If the LEDs do not flash, you must repeat steps 1 and 2 until the LEDs
flash before continuing.
4. Release the RSSI push button within 5 seconds.
5. Within a further 60 seconds, press and hold the RSSI push button for 5
seconds (until the LEDs stop flashing) and then release.
6. The WIO-800LR receiver lights all LEDs for 2 seconds before returning to
normal operation.
NOTE: If the LEDs do not light, you must repeat the process from step 1 until
the LEDs light before continuing.
7. You can now link the transmitter and receiver units.
6QSG 800LR-1.8
May 2010
6 Linking your transmitter and receiver units
You must reset the transmitter unit to factory defaults (to disable encryption)
before linking the transmitter and receiver units. For more information, see
the WIO-800LT Transmitter Quick Start Guide.
NOTE: You must complete the linking process in 60 seconds.
To link the transmitter and receiver units:
1. Press and hold down the RSSI Pushbutton on the receiver.
2. Power on the receiver while holding down the RSSI Pushbutton
3. Release the RSSI Pushbutton as soon as the Receiver LEDS flash (within
5 seconds of powering the receiver).
4. The receiver will flash all LEDs for a maximum 60 seconds while it tries to
link to the transmitter.
5. Power on the transmitter. The transmitter sends a special “Link” message
to allow the receiver to recognise the transmitter.
6. When the units link, the receiver lights all LEDs for 2 seconds before
returning to normal operation.
NOTE: If the receiver LEDs continue flashing within the 60 seconds, the
units are not linked and you should retry the linking process by powering the
transmitter off and on again. If you exceed the 60 seconds, you must restart
the linking process from step 1.
You can now bench test your configuration before deploying.
7 Safety information
Thank you for selecting the WIO-800LR receiver for your telemetry needs.
We trust it will give you many years of valuable service. To ensure your
WIO-800LR receiver enjoys a long life, double-check ALL your connections
with the user’s manual before powering on the unit.
WARNING: Incorrect termination of supply wires may cause internal damage
and will void warranty.
7
QSG 800LR-1.8
May 2010
8 Unit specifications
Input/output Number Additional information
Digital outputs 3 Voltage-free contacts rated at 250 VAC 1A,
30VDC 1A.
2 for digital inputs and 1 for setpoint.
Status outputs 2 Separate System OK and communication
failure output.
Analog output 1 16-bit resolution, 0.1% accuracy, single-
ended source output.
Power supply 1 9-30 VDC 0.25 Amp CSA certified Class
2 power supply. For use in Class 1 Div 2
hazardous areas, the power supply must
be approved for Class 1 Div 2 use.
WARNING: Explosion hazard - do not
connect or disconnect while circuit is live
unless area is known to be non-hazardous.
Radio receiver 1 High sensitivity DFSK Fixed Frequency
receiver.
Frequency 868.525 MHz
869.875MHz
Actual frequency range depends on Paired
Transmitter.
Sensitivity -111 dBm At PER 8%.
