Multimo 107-SINGLE WARDROBE User manual

Assembly Instructions
107-SINGLE WARDROBE
45 min.
Technical Service
90 min.
End User
+-
VIDEO
link

Page 1 Page 2
A-R
A-L
B
C
C
C
D
E
G
G
H
Accessories List
TS - 01
4 / piece
F
Piece T hickness Length Width Piece T hick H eight M ost
A0,71 81,89 21,26 2 18 2080 540
B1,18 17,32 21,22 1 30 440 539
C0,71 17,32 20,43 3 18 440 519
D0,71 17,32 19,69 1 18 440 500
E0,71 27,56 18,50 1 18 700 470
F0,71 40,35 18,50 1 18 1025 470
G6,30 18,50 16,46 2 160 470 418
H0,31 81,06 17,99 1 8 2059 457
Track Title
(inch)
(mm)
MNG - 01
16 / piece
PM - 01
4 / piece
VD - 03 ( 3,5x18 ) mm
20 / piece
MNX 02
16 / piece
TAP - 01
16 / piece
AVT - 01
4 / piece
VD - 02 (3,5x25) mm
12 / piece
KVL 01
16 / piece
ER - 01
8 / piece
TSY - 01
2 / piece
AF - 02
2 / piece
BO - 01
1 / piece
KP - 03
4 / piece
VKP - 01 (22) mm
2 / piece
VKP - 03 (40) mm
2 / piece
RYP - 02
2 / piece

Page 1 Page 2
A-R
A-L
B
C
C
C
D
E
G
G
H
Accessories List
TS - 01
4 / piece
F
Piece T hickness Length Width Piece T hick H eight M ost
A0,71 81,89 21,26 2 18 2080 540
B1,18 17,32 21,22 1 30 440 539
C0,71 17,32 20,43 3 18 440 519
D0,71 17,32 19,69 1 18 440 500
E0,71 27,56 18,50 1 18 700 470
F0,71 40,35 18,50 1 18 1025 470
G6,30 18,50 16,46 2 160 470 418
H0,31 81,06 17,99 1 8 2059 457
Track Title
(inch)
(mm)
MNG - 01
16 / piece
PM - 01
4 / piece
VD - 03 ( 3,5x18 ) mm
20 / piece
MNX 02
16 / piece
TAP - 01
16 / piece
AVT - 01
4 / piece
VD - 02 (3,5x25) mm
12 / piece
KVL 01
16 / piece
ER - 01
8 / piece
TSY - 01
2 / piece
AF - 02
2 / piece
BO - 01
1 / piece
KP - 03
4 / piece
VKP - 01 (22) mm
2 / piece
VKP - 03 (40) mm
2 / piece
RYP - 02
2 / piece

Page 3 Page 4
VIDEO
link
STEP 1
VIDEO
link
MNX - 02
KVL 01
MNX - 02 X 8
ER - 01 X 4
TRACK TITLE
A LEFT / A RIGHT
A
KVL - 01 X 4
C
KVL - 01 X 4
B
B
C
C
C
A-L
STEP 2
RYP - 02 X 2
STEP 3
MNG - 01
210°
MNG - 01 x 8
VD - 03 X 8
F
E
TS - 01

Page 3 Page 4
VIDEO
link
STEP 1
VIDEO
link
MNX - 02
KVL 01
MNX - 02 X 8
ER - 01 X 4
TRACK TITLE
A LEFT / A RIGHT
A
KVL - 01 X 4
C
KVL - 01 X 4
B
B
C
C
C
A-L
STEP 2
RYP - 02 X 2
STEP 3
MNG - 01
210°
MNG - 01 x 8
VD - 03 X 8
F
E
TS - 01

Page 5 Page 6
VIDEO
link
VIDEO
link
H
STEP 6
STEP 4
STEP 5
MNG - 01 A-R
210°
MNG - 01 x 8
VD - 02 x 6
VD - 02 x 4
AVT - 01 x 4

Page 5 Page 6
VIDEO
link
VIDEO
link
H
STEP 6
STEP 4
STEP 5
MNG - 01 A-R
210°
MNG - 01 x 8
VD - 02 x 6
VD - 02 x 4
AVT - 01 x 4

Page 7 Page 8
VIDEO
link
VIDEO
link
STEP 7
PM - 01 x 4
TAP - 01
STEP 8
VKP - 03
2
1RR
KP - 03
G X 2
BO - 01
VD - 03
AF - 02
D

Page 7 Page 8
VIDEO
link
VIDEO
link
STEP 7
PM - 01 x 4
TAP - 01
STEP 8
VKP - 03
2
1RR
KP - 03
G X 2
BO - 01
VD - 03
AF - 02
D

Page 9 Page 10
E
F
VIDEO
link
TSY- 01 x 2
1- 2- 3-
STEP 9
ATTENTION / HOW TO / READ ME / OWNER'S GUIDE
1. When mountng on a regular drywall, furnture must be fastened to wood or
metal studs. Sold walls made of brck, concrete or smlar strong materal are
also accaptable. Do not mount furnture to paper-mache or sheet rock lke
materal wthout properly aaxng to stud.
2. For safety and product longevty you must perodcally nspect the mountng
and mechancal connectons for ntegrty and tghtness. Confrm hardware
remans properly affxed and connectons snug.
3. Wall Bed mattress thckness may not exceed 8 nch. Take care to remove
pllows and excess blankets before closng. Dong so keeps mechansm free of
obstructon and unnecessary stress.
4. Do not lean or rest heavy objects on sde or top of furnture. Ths may cause
balance ssues and compromse the ntegrty of your mountng connectons.
5. Please use the furnture's beds, desks and shelvng as ntended. Not desgned
to be sat, stood, leaned, jumped (etc) on. Improper use may cause personal njury
and damage to property.
6. Wth seasonal humdty change you must nspect nteror and exteror of
furnture.
7. Sngle, Twn, Twn XL beds accommodate the weght of one person.
Improperly sleepng more than one person rsks njury to person and damage to
property.
8. Before any un-mountng or dsassembly please contact Multmo for techncal
support and nstructon. Falure to properly detach rsks njury to person and
damage to property.
9. For Bunk Beds:
a. Always use provded ladder when accessng top bunk.
b. Be slow, careful and aware of surroundngs when openng top bunk.
c. Do not horseplay. Beds are to be slept on only.
d. Some have legs that fully extend when open- be aware of where the leg s and
wll be.
VD - 03
TS - 01
KP - 03
VKP - 01

Page 9 Page 10
E
F
VIDEO
link
TSY- 01 x 2
1- 2- 3-
STEP 9
ATTENTION / HOW TO / READ ME / OWNER'S GUIDE
1. When mountng on a regular drywall, furnture must be fastened to wood or
metal studs. Sold walls made of brck, concrete or smlar strong materal are
also accaptable. Do not mount furnture to paper-mache or sheet rock lke
materal wthout properly aaxng to stud.
2. For safety and product longevty you must perodcally nspect the mountng
and mechancal connectons for ntegrty and tghtness. Confrm hardware
remans properly affxed and connectons snug.
3. Wall Bed mattress thckness may not exceed 8 nch. Take care to remove
pllows and excess blankets before closng. Dong so keeps mechansm free of
obstructon and unnecessary stress.
4. Do not lean or rest heavy objects on sde or top of furnture. Ths may cause
balance ssues and compromse the ntegrty of your mountng connectons.
5. Please use the furnture's beds, desks and shelvng as ntended. Not desgned
to be sat, stood, leaned, jumped (etc) on. Improper use may cause personal njury
and damage to property.
6. Wth seasonal humdty change you must nspect nteror and exteror of
furnture.
7. Sngle, Twn, Twn XL beds accommodate the weght of one person.
Improperly sleepng more than one person rsks njury to person and damage to
property.
8. Before any un-mountng or dsassembly please contact Multmo for techncal
support and nstructon. Falure to properly detach rsks njury to person and
damage to property.
9. For Bunk Beds:
a. Always use provded ladder when accessng top bunk.
b. Be slow, careful and aware of surroundngs when openng top bunk.
c. Do not horseplay. Beds are to be slept on only.
d. Some have legs that fully extend when open- be aware of where the leg s and
wll be.
VD - 03
TS - 01
KP - 03
VKP - 01
