Multipipe 22-23015 User guide

Introduction
A programmable controller is used to switch the heating system and/or the hot
water in your home on and off as needed. It works by controlling the central
heating and/or the hot water with programmed settings that take effect at
different times of the day.
Product Compliance
EU Directives: 2014/30/EU, 2014/35/EU and 2011/65/EU.
Safety Information
Use in accordance with the EU and national regulations.
For indoor use only.
Keep your device completely dry. This product must be installed by a competent
person and in accordance with all the EU and national regulations.
Safety Information
Always isolate the AC Mains supply before installing or working on any
components that require 230 VAC 50Hz supply.
Thank you for purchasing the 22-23015 Single Channel Digital Time
Clock for 230 V.
22-23015 Single Channel Digital Time Clock
CH or HW
Installation Input: 230V, 50Hz
Output: 3A/ switch terminal
Terminal Description Backplate
N Mains Neutral
L Mains Live
1 Not Used
2 Not Used
3 Volt Free Connection
4 Volt Free Connection
Earth Parking
(no electrical connection)
NL1234
NL123456
Jumper Settings
Changes to the jumpers settings should
only be made by the Engineer carrying out
the installation or other qualified person.
The installer should select the jumper
positions required if changes need to
be made to the factory default settings.
These jumpers are found on the rear of the
controller.
* P - Fully pumped system for independent Central Heating and Hot Water.
* G - Gravity Hot Water system with Pumped Central Heating.
22-23015 Switching Bridges
Switch
Program 5-2 days programme or
24h programme
Fully pumped system(P*)
or gravity-fed hot water
system(G*)
Disable/enable the internal
backup battery
System
Feature 22-23015 Settings
Memory
Backup
5-2
OFF
NA
First Power Up
Button Function
Backlight/
Holiday
Mode
+1Hr
Down
Up
Select
Set
Reset
1. Turn on the LCD backlight
2. Press for 3 sec to activate Holiday mode
Select operating mode (ON, ONCE, AUTO, ADV, OFF)
Activate/deactivate Boost function
Decreases the selected setting
Increases the selected setting
Select a clock or programme setting
Sets a clock or programme setting
Reset to Factory settings
MODE
SELECT
SET
+HR
MODE +Hr
SELECT SET
<
<
MODE +Hr
SELECT SET
<
<
Setting date and time
3 sec
Choose your clock format
and press Select.
Press and hold the indicated
buttons together for 3 sec.
Single Channel Digital Time Clock
for 230V
Model: 22-23015
The Single Channel Digital Time Clock is recommended for users that
want to control only the Central Heating or the Hot Water system.
Multipipe Ltd
Unit 12 Great Hayes Business
Park
Lower Burnham Road
Stow Maries
Chelmsford
Essex
CM3 6SQ
Sales
T: 01245 227630
E: [email protected]
Technical
T: 01245 850799
E: [email protected].uk
www.multipipe.co.uk
INSTALLER MANUAL

The circle will be rotating for 22-23015 will remain steady when the
relay output is ON.
1. +Hr Program Override (Boost)
This function is available in ONCE/AUTO/ADV/OFF. After pressing the
button, the function will be immediately applied. You can override the
program for maximum 9 hours. For cancelling the Boost function, press
the button repeatedly until the +8 hours dissapears.
2. BL/Holiday function
Press the button once and the backlight will be turned on.
Press and hold the button for 3 seconds to activate the Holiday
Mode.
Press or to select the number of days for the Holiday Mode and
to confirm your choice.
Press and hold the button for 3 seconds to cancel the Holiday
Mode.
Setting date and time
MODE +Hr
SELECT SET
<
<
MODE +Hr
SELECT SET
<
<
MODE +Hr
SELECT SET
<
<
MODE +Hr
SELECT SET
<
<
Press Up or Down to set the year.
Tap on Select to confirm.
Press Up or Down to set the month.
Tap on Select to confirm.
Press Up or Down to set the hour.
Press Select to confirm.
Press Up or Down to set the minutes.
Tap on Select to confirm.
MODE +Hr
SELECT SET
<
<
MODE +Hr
SELECT SET
<
<
Press Up or Down to set the
Daylight SavingTime On or Off.
Tap on Set to confirm.
Press Up or Down to set the day.
Tap on Select to confirm.
Operating modes
The Single Channel Digital Time Clock has the following operating
modes. You can select them by pressing the MODE button.
Operating Mode Function
ON Continuously on
ONCE On for 1 period a day, from Program 1 ON
to Program 3 OFF
AUTO Automatic program control
ADV
OFF Continuously off
When device is in Auto or Once mode,
press the MODE button for 3 sec for
selecting Advance (ADV). This will move
the unit into the next program. When the
ADV function ends the device will return to
normal program.
Note: In ONCE or AUTO mode, by long pressing the MODE button, the
controller will switch automatically to ADV. You can cancel the ADV by
long pressing the MODE key. The device will then return to ONCE or
AUTO mode.
Programming the 22-23015
You can create personalized
programmes for your
controller. You have the
option to choose between a
5-2 days programme or a daily
one by using the jumpers.
MODE +Hr
SELECT SET
<
<
MODE +Hr
SELECT SET
<
<
Press Set, then Up or Down to
select weekdays or weekends.
Press Select to confirm.
Press Up or Down to set the hour.
Press Select to confirm.
5-2 Days Programme
Weekdays
3 sets of time/channel
Weekends
3 sets of time/channel
Total: 6 settings/week
Note: Don’t forget to move the jumpers to 24h in order to have
the individual programme active. After that please follow the
same instructions as for the 5-2 days programme.
Individual days programme
22-23015 (1 Channel)
1 Day
3 sets of time/channel
Total: 21 settings/week
Please repeat the procedure for all the programmes and channels
that are available for this model.
MODE
MODE +Hr
+Hr
SELECT SET
<
<
Other Functions
+HR
<
<
3. Factory Reset
If you want to return to
the factory settings please
press the Reset button once
(use a pin for this action).
