Multiplex BIC MA-8-2 Installation instructions

Instruction Sheet Subject: BIC Tune Up
SCOPE: MULTIPLEX BIC UNITS MA-8-2, MA-8-2BF, MA-8-2AF
1 of 9
Document Number: 020009017 May 12, 2022
MULTIPLEX
645 PARK EAST BLVD SUITE 5, NEW ALBANY, IN 47150
844-724-CARE
WWW.MULTIPLEXBEVERAGE.COM
Refreshing the Experience
TOOLS REQUIRED
• Safety Gloves (cut resistant)
• Oetiker Pliers (PN 00681815)
• Needle Nose Pliers
• Screw Drivers, Phillips & Flat Head
• 3/8” or ¼” Drive Socket Set (3/8” and 5/16”)
• Standard Open End Wrench Set
• Soft Bristle Brush
• Wet/Dry Shop Vacuum
• Digital Scale (weighs in ounces to once decimal place)
PARTS REQUIRED
• Food Grade Lubricant
• 5 - 6 ft (1.8m) ¼” I.D. X 3/8“ O.D. clear tubing
• TUNE UP KIT 020009016 (contents listed below)
QTY DESCRIPTION PART NUMBER
9 Valve, Dispense Outlet, LMS 1706172
9 15.7 Oetiker Clamp 15.7-706R
2 O-ring, replacement MCP00262
1 Gasket Ice Shaver 3434865
1 Drive belt, Shaver Vitamix 1617 VMP00123
2 Cup Grate O-rings 3547901
1 Instructions Tune Up ENG 020009017
1 Instructions Tune Up French 020009047
1SHAVER BLADE KIT VMP00125
RECOMMENDED TRUCK STOCK LIST FOR TUNE UP
QTY DESCRIPTION PART NUMBER
1SWITCH REED RINSE AREA MOD 2160033
1SWITCH REED RINSE AREA - GRAY 2162748
5FUSE, 5A, MIXER BOARD 2193015
1SWITCH, SNAP ACTION, MINI - BLEN HM 2194807
1BOARD, SRB ,BIC, GEN2 2195346
2CONTROL BLENDER BIC HSM 2195363
1CONTROL, 7 IN UI, BIC 000-BIC-01F9-S
1RELAY, 24DC COIL, DPDT 2196069
2FUSE, 4A, DC HARNESS 2198785
1PUMP, FLOJET, NSF, NO ASO 3239675
1MIXER MTR, 6MM, 120V/50-60, GEN3 SW 3239822
2ASSEMBLY, LOWER BLENDER, 6MM, GEN3 3239825
1SOLENOID VALVE REPAIR KIT 020005547
1VALVE, S.S. SLND, WATER, 1/4" 000-BIC-01B5-S
1SAFETY SWITCH/RECTIFIER ASSEM- 120V VMP00113
1SHAVER BELT VMP00123
1SHAVER BLADE KIT VMP00125
1SENSOR, HALL EFFECT VMP00175
1SHAVER MTR W/PULLEY / MAGNET 120V VMP00172
3MOTOR ISOLATION MOUNT 9324159
1PUSH ROD VMP00134
3CUP ALIGNMENT RING INSERT 1708685
1GASKET, ICE SHAVER 3434865
NOTE: Additional non-warranty parts used need to be
invoiced on a separate invoice to the site. Manager or
Operator must approve additional repairs.
NOTE: All right and left references are based off of standing
in front of the unit.
,CAUTION
Ice shaver blade is sharp on both edges. Wear cut resistant gloves
when handling.
nWarning
Blender shaft contains sharp blades. Wear cut resistant
gloves when handling. Do NOT touch the blades.

2 of 9
Document Number: 020009017 May 12, 2022
Subject: BIC Tune Up
PREPARATION
1. Verify operation with manager. Note any issues on
checklist and take pictures.
2. Record current firmware and recipe versions on
checklist.
From easyToUCH screen select the MANAGER MENU
Select “A” for the password
Select the GREEN check
Arrow DOWN two (2) times
Note the UI Version on Checklist
Note the SRB Version on Checklist
Note the Left and Right Mixer Version on Checklist
Note the File on Checklist
Note the Menu Connect version on Checklist
3. Record blender counts since installation and blender
counts since last maintenance date on the checklist.
From easyToUCH screen select MANAGER MENU
Select “A” for the password
Select the GREEN check
Arrow DOWN three (3) times
Under the DRINKS SINCE INSTALLATION heading
note the Left Mixer count, Total Count, and Right
Mixer Count on Checklist.
Under the LAST MAINTENANCE DATE heading note
the Left Mixer count, Total Count, and Right Mixer
Count on Checklist.
4. Move all product/bins from lower refrigerated cabinet
to store’s walk-in cooler. Empty ice from ice bin first by
scooping ice out with cup then by using touchscreen
and using ICE DISPENSE to dispense ice into a cup or
bowl in dispense area.
INSTRUCTION
5. Remove all blender and dispense grates.
6. Take a flat head screwdriver or pair of needle nose
pliers, remove the O-rings from each blender grate
and discard.
7. Replace with new O-rings over the tip on both grates.
8. Wash, rinse and sanitize the blender and dispense grates.
9. Prepare a five (5) gallon bucket with luke-warm tap
water (no hotter than 105°F/40.5°C) and cleaning
solution. Clean all eight (8) product fittings and
connect the cleaning manifold.
10. Position the dispense shield in the dispense area.
11. Press BACK arrow on the touch screen to reach
easyToUCH Menu. From the easyToUCH screen follow
the next steps to clean and rid each of the product lines
of syrup.
Access the MANAGER MENU
Enter “A”
Press GREEN check
Arrow DOWN
Select the Service Menu
Enter “A”
Press the GREEN check
Select Outputs and activate each valve until only
hot clear water dispenses from the dispensing valve.
Power OFF using the ON/OFF switch located on the
upper left side of the unit. If required, relocate the
unit to the back of the store.
NOTE: If unit is relocated, place a bucket under the rear drain.
12. Remove dispense shield.
13. Replace blender and dispense grates.
14. Prepare beverage drain cleaner according to the
supplier’s specifications and pour down both the left
and right blend chamber drain opening as well as the
center dispense area drain opening. Allow the drain
cleaner to stay in the drains. The drains will be rinsed
with hot tap water later in the Tune Up process.
NOTE: Beverage drain cleaner will be poured down the ice
bowl drain line later in the Tune Up process.

3 of 9
Document Number: 020009017 May 12, 2022
Subject: BIC Tune Up
15. Turn unit OFF and unplug.
OFF
16. Locate the dispense valve mounting plate in the top
center of the dispensing area. Remove the four (4)
outer screws that secure the mounting plate in place.
,CAUTION
Using too much force while pulling down on the plastic mounting
plate could cause damage to the plate.
A. Pull gently down on the mounting plate until the
product tubing can be accessed. With the tubing
now accessible pull down on the tubing lowering
the dispense manifold as far down as possible.
Now locate the tubing inside of the refrigerated
cabinet.
B. The tubing is towards the upper right rear inside
of the cabinet and is separated by the chase that
runs upwards towards the dispensing area. Push
the tubing upwards as far as possible. Return to the
dispense area and pull the tubing downwards as
far as possible.
C. Return to the inside of the cabinet and push the
tubing upwards as far as possible.
D. Repeat the pulling of the tubing downwards in the
dispense area and the pushing up of the tubing
inside of the cabinet until the top of the dispensing
plate is easily accessible.
17. Using a Phillips head screw driver remove the two (2)
screws from the metal mounting plate that secures a
block of three (3) LMS valves to the dispensing valve
mounting plate.
NOTE: The tubing is numbered and will need to be returned
to the same position within the dispensing mounting plate
following the replacement of the LMS valves. Tubing is
positioned 1-8 in a counter clockwise manner with Water
being the 9th tube.
18. Remove the remaining two (2) blocks of three (3) valves
from the dispensing mounting plate.
19. Wash, rinse, and sanitize the dispensing mounting
plate. Using Oetiker pliers cut and remove the existing
Oetiker clamps that secure the product tubing to the
LMS valve.
20. Use the new 15.7 Oetiker clamps to replace the LMS
valves. It is best to replace a block of three (3) valves
at a time. Place the 15.7 Oetiker clamp on and up the
product tubing, insert the new LMS valve through the
metal plate and into the product tubing, crimp the 15.7
Oetiker clamp securing the product tubing to the LMS
valve body.
21. Return each block of three (3) LMS valves to the
dispensing mounting plate.
Front of Unit

4 of 9
Document Number: 020009017 May 12, 2022
Subject: BIC Tune Up
NOTE: The tubing orientation is 1-9 in a counter clockwise
manner as shown.
22. Reposition the dispensing mounting plate to the top of
the dispensing area and secure with the four (4) outer
screws.
A. Reverse actions in Step 16 pulling the tubing
downwards within the refrigerated cabinet and
pushing the tubing upwards in the dispensing area
towards the inside of the tubing chase.
,CAUTION
Ice shaver blade is sharp on both edges. Wear cut resistant gloves
when handling.
23. Remove the ice assist bar, ice bin lid, ice shelf, paddle
nut, and shaver wheel.
24. Using a Phillips head screwdriver remove the four (4)
screws that secure the ice bin to the condensate bowl.
,CAUTION
Be careful not to damage push rod when removing the ice bin.
Push rod should not be bent or have pressure applied to it.
25. Carefully remove the ice bin using caution not to
damage the micro switch push rod. Use caution not to
lose any of the three (3) ice bin grommets attached to
the base of the ice bin bowl.
26. Wash, rinse and sanitize the condensate bowl.
27. Carefully pour beverage drain cleaner down the ice
condensate bowl drain opening.
28. Remove the two (2) screws that secure the shaver blade
and shims to the ice bin and ice chute cartridge.
29. Install new blade using old shims.
NOTE: Shim configuration is important. Shim alignment
should be two (2) .056 thick shims and one (1) #7 thin shim.
30. Wash, rinse and sanitize the ice bin.
31. Remove the shaver gasket. You may find the gasket
adhered to the bottom of the ice bin or the top of the
dispense area cover.
32. Clean all surfaces where the previous gasket made
contact.
33. Dry the contact points for the shaver gasket. Adhere
the new shaver gasket to the top of the dispense area
cover.
NOTE: Ensure the gasket does not block any of the ice chute
opening.
,CAUTION
Be careful not to damage push rod when reinstalling the ice bin.
Push rod should be carefully inserted into bottom of ice bin

5 of 9
Document Number: 020009017 May 12, 2022
Subject: BIC Tune Up
34. Reinstall the ice bin to the condensate bowl using the
four (4) screws.
NOTE: Use caution not to damage the push rod.
35. Remove the two (2) Phillips head screws that secure the
rear panel to the units frame and remove the rear panel.
36. Locate the mounting bracket that houses the power
supply, relays and SRB. Remove the two (2) screws that
secure the mounting bracket to the units frame.
A. Slightly lift the bracket releasing the right side
hinge then carefully lower the bracket down
towards the lower refrigerated cabinet.
37. Mark the position of the shaver motor as currently
positioned within the motor mounting bracket.
NOTE: Once the shaver belt is replaced the motor will be
returned or very near this same position when tight.
38. Locate the four (4) hex head bolts that secure the
shaver motor to the motor mounting bracket.
A. Completely remove one of the bolts that secure
the Hall Effect sensor mounting bracket to the
motor mounting bracket. Loosen the remaining
three (3) hex head bolts.
B. Swing the Hall Effect mounting bracket to the side
allowing room for easy removal of the shaver belt.
39. Remove the existing shaver belt.
40. Replace the provided shaver belt reversing the actions
in Step 37. Tighten the belt by pulling back on the
motor before completely tightening the hex head bolts.
Motor should be positioned at or near the previous
placed reference mark.
41. Confirm Hall Effect Sensor is 1/16 of an inch back from
the edge of the bracket and in good condition.
42. Disconnect the water and CO2 supply lines.

6 of 9
Document Number: 020009017 May 12, 2022
Subject: BIC Tune Up
43. Remove and replace the O-rings on both the water and
CO2 supply lines.
44. Add food grade lube to the O-rings before
reconnecting the water and CO2 supply lines.
45. Use a soft bristle brush to remove the dust, dirt and
debris from the condenser coil.
46. Clean the condensate drain pan with Wet/Dry Shop
Vacuum.
47. Locate the condensate drain line.
A. Clean the condensate drain line with Wet/Dry Shop
Vacuum by applying suction to the outlet of the
drain line.
48. Remove both the left and right side panels.
49. Slowly pour hot tap water down the left side and right
side blend chamber drains, rinse area drain, and the ice
bin drain.
50. Check unit to make sure it is level from front to back
and side to side.
51. Locate the three (3) drain tubes within upper frame of
the unit.
A. Beginning at the discharge of each drain outlet
squeeze the tubing from front to back dislodging
any buildup within the tubing.
B. Snake each drain with a 6 ft (1.8m) piece of ¼” I.D.
x 3/8 “ O.D. clear flexible tubing. Verify water is
draining sufficiently out of the blend chambers.
Or use a Wet/Dry Shop Vacuum to remove any
debris from the drain lines.
52. Repeat previous step until each drain line runs clear.
53. Reconnect incoming water and CO2supply lines and
pressure, observe for any leaks.
54. Power the unit ON using the ON/OFF switch located on
the upper left side of the unit next to the USB port.
55. Connect drain and plug in unit to outlet.
56. Verify the water and CO2 pressure regulators are set to
35 psi dynamic and adjust if necessary.
A. The regulators are located on the upper left side of
the unit.
NOTE: To achieve a dynamic pressure setting for the water
a water solenoid must be activated. To achieve a dynamic
pressure setting for the CO2 one of the product solenoids
must be activated.
B. Follow the next steps from the easyToUCH screen
to activate a water solenoid and/or a product
solenoid:
Select the MANAGER MENU Icon
Select “A” for the password
Select the GREEN check
Arrow DOWN and Select Service
Select “A” for the password
Select the GREEN check
Select OUTPUTS
Activate any of the eight (8) flavor solenoids by
touching the GREEN OFF opposite the selected
solenoid and adjust the CO2 regulator to 35 psi
dynamic
Turn OFF selected flavor solenoid by touching thr
RED ON opposite the selected solenoid.
Arrow DOWN then select either the WATER, LEFT
RINSE, or RIGHT RINSE and adjust the water
regulator to 35 psi dynamic
Turn OFF selected water dispense option
Arrow back three (3) times to return to the main
easyToUCH screen.
NOTE: To increase the pressure lift the knob at the top of
the regulator and turn clockwise. To decrease the pressure
lift the knob at the top and turn counter clockwise.

7 of 9
Document Number: 020009017 May 12, 2022
Subject: BIC Tune Up
57. Once the 35 psi dynamic setting has been achieved
push the knob back to the downward position and turn
OFF the water solenoid and/or the product solenoid.
58. Re-install all exterior panels and move unit into place.
Verify drain line is connected correctly.
59. From the easyToUCH screen select the hand icon. Then
select the Zone 2 icon and follow the instructions to
complete the weekly cleaning.
NOTE: The manager will need to be informed that the
weekly cleaner timer was reset following the Zone 2
cleaning. To get the weekly cleaning back to the stores
normal cleaning schedule they will need to perform the
weekly cleaning on the normal scheduled day.
60. Retrieve the product from the walk in cooler and return
it to the assigned slot position within the BIC unit.
A. Verify flavor slot assignments are in accordance
with corporate direction. If the product
assignments are not in accordance they must be
reassigned.
Strawberry
Banana
Mocha
Caramel
Not
Assigned
Slushy
Not Assigned
or Seasonal
Mango
Pineapple
Yogurt
B. If reassignment is required follow the next steps
from the easyToUCH screen:
Select the MANAGER MENU Icon
Select “A” for the password
Select the GREEN check
Select the Configure Slots Icon
Select Slot Flavor
Select the slot requiring reassignment
Select Unassign Flavor and then select the GREEN
Check
Select the newly Unassigned Slot and select the
correct flavor assignment
Select the Return Arrow three (3) times to return to
the main easyToUCH screen
Select product Inventory Icon
Select the reassigned flavor and follow the steps for
replacing a product bag.
Follow the same procedures for each reassigned
product.
CALIBRATION & SETTINGS
61. Fill the ice bin with ice.
62. Allow cabinet and nozzle temperatures to drop below
39°F. Cabinet temperature will need to be 39°F or below
before beginning next step.
63. Perform FACTORY RESET.
Select MANAGER Menu.
Select “A” for the password
Select the GREEN check
Arrow DOWN one (1) time
Select SERVICE
Select “A” for the password
Select the GREEN check
Arrow DOWN one (1) time
Select FACTORY RESET
Select the GREEN check
Calibrations have been reset
Arrow UP or press BACK arrow to return to main screen
64. Confirm the“CONFIGURE YOGURT SMALL DISPENSE”is
set to zero (0) from the easyToUCH screen:
Select the MANAGER MENU
Select “A” for the password
Select the GREEN check
Arrow DOWN one (1) time
Select SERVICE
Select “A” for the password
Select the GREEN check
Arrow DOWN two (2) times
Select CONFIGURE YOGURT SMALL DISPENSE
Confirm SLOT NUMBER is zero (0).
If SLOT NUMBER is not zero (0), select the box to the
left> Enter 0> Select the GREEN check> Arrow back
twice> and Save if prompted.

8 of 9
Document Number: 020009017 May 12, 2022
Subject: BIC Tune Up
65. Confirm“PLUNGE SPEED”is set at 15 and“CUP OFFSET”
is set at 2.0 from the easyToUCH screen:
Select the MANAGER MENU
Select “A” for the password
Select the GREEN check
Arrow DOWN once
Select SERVICE
Select “A” for the password
Select the GREEN check
Select Options
Arrow DOWN twice
Confirm the box to the left of PLUNGE SPEED is set
to fifteen (15), select box and enter 15 if required>
Select the GREEN check to confirm>
Confirm the box to the left of CUP OFFSET is set to
2.0, if required select the box and enter two (2), zero
(0), this will change the setting to 2.0
Select the GREEN check
Arrow back three (3) times
Select Save when prompted
66. Perform a calibration following the next steps from the
easyToUCH screen:
Select the MANAGER MENU Icon
Select “A” for the password
Select the GREEN check
Select CONFIGURE SLOTS
Select CALIBRATE FLAVOR
Select flavor in slot 1 and follow the onscreen
calibration instructions.
Continue calibrating each flavor, water, and ice.
67. Reset the LAST MAINTENANCE DATE:
NOTE: These passwords must be entered to reset the yearly
maintenance reminder even though the shafts have NOT
been changed.
Select the MANAGER MENU
Select “A” for the password
Select the GREEN check
Select the Down Arrow and select SERVICE
Select “A” for the password
Select the GREEN check
Arrow DOWN and select PLANNED MAINTENANCE
Select MIXER MAINTENANCE PERFORMED
A. 4.0.2 and before
• Enter SILENCE for password
• Select the GREEN check
• You will get a message“Confirmation Blender(s)
Maintenance Done”
• Save Changes
• Arrow back until return to easyToUCH Screen
B. 4.0.10 and 5.0.10
• Enter OEA422R password then press green check
NOTE: Password begins with letter “O” NOT zero.
• On confirmation screen press green check
• Enter OEA422L password then press green check
• On confirmation screen press green check
• Arrow back until return to easyToUCH Screen
68. Power unit OFF for 30 seconds then back ON.
30
SECONDS
OFF ON
CONFIRM OPERATION
69. With the manager present make sample drinks of
each size.
70. Confirm operation of all functions.
71. Complete the Tune Up Checklist and fax to 920-683-
7592 or email to rise.callcent[email protected]
72. Maintain a copy of the Tune Up Checklist to be
submitted along with the invoice for payment.
73. Submit claim for service work through Multiplex Claims
Processing System.

9 of 9
Document Number: 020009017 May 12, 2022
Subject: BIC Tune Up
Verify operation with manager? Step 1 page 2. Note manager concerns:
___________________________________________
___________________________________________
___________________________________________
___________________________________________
___________________________________________
___________________________________________
___________________________________________
Record rmware and recipe versions at beginning ofTune Up? Step 2 page 2.
UI SWVERSION ____________ SRB SWVERSION __________
LEFT MIXER SW____________ RIGHT MIXER SW __________
FILE __________________ MENU CONNECT __________
Record“DRINKS SINCE INSTALLATION”? Step 3 page 2.
LEFT MIXER COUNT _________ TOTAL COUNT ____________
RIGHT MIXER COUNT_________
Record“DRINKS SINCE LAST MAINTENANCE DATE”. Step 3 page 2.
LEFT MIXER COUNT _________ TOTAL COUNT ____________
RIGHT MIXER COUNT_________
Replace Blender Grate O-rings? Step 7 page 2.
Pour beverage drain cleaner down the left blend chamber drain, dispense area
drain and the right blend chamber drain? Step 14 page 2.
Replaced the LMSValves? Step 16 - Step 22 page 4.
Remove the ice bin. Step 24 & Step 25 page 4.
Replaced the shaver blade? Step 28 page 4.
Remove the ice shaver gasket from the ice bin and/or the top of the dispense area
cover? Clean the surface areas? Step 31 page 4.
Replace the shaver gasket? Step 33 page 4.
Wash, rinse and sanitize the ice bin? Step 30 page 4.
Pour beverage drain cleaner down the ice condensate bowl drain opening? Step 27
page 4.
Replaced the shaver belt? Step 39 & 40 on page 5.
Replace the COandWater supply line O-rings? Step 43 & 44 on page 6.
Clean the condenser coil? Step 45 page 6.
Clean the condensate pan? Step 46 page 6.
Clean the condensate drain line? Step 47 page 6.
Pour hot water down drain openings of the ice bin, right blend chamber, dispense
area, and left blend chamber? Step 49 page 6.
Workthe drainsbyhand squeezingoutanybuildup? Step51 -52 onpage 6.
Connect water, CO, drain, and power cord? Step 55 page 6.
Rear drain line connected correctly to store drain? YES NO
Set the water pressure regulator to 35 psi dynamic? Step 56 page 6.
Set the COpressure regulator to 35 psi dynamic? Step 56 page 6.
Re-install all exterior panels? Step 58 page 7.
Retrieve product from the walk in cooler and return to the BIC refrigerated cabinet?
Step 60 page 7.
Verify and assign avor slot assignments in accordance to McDonald’s Corporate?
Step 60 page 7.
Complete the Zone 2 cleaning? Step 59 page 7.
Conrm “CONFIGUREYOGURT SMALL DISPENSE”to zero (0). Step 63 page 7.
Conrm“PLUNGE SPEED”is set at 15. Step 65 page 8
Conrm“CUP OFFSET”is set at 2.0. Step 65 page 8
Perform calibration for all avors, water, and ice? Step 66 page 8.
Reset“LAST MAINTENANCE DATE”? Step B page 8.
Make samples of drinks with manager present. Step 69 page 8.
Fax or email completedTune Up Checklist to the RISE Group at 920-683-
7592 or rise.callcent[email protected]om
Submit claim for service work through Multiplex Claims Processing System.
Tune Up Checklist MUST be attached to claim or claim will be DENIED.
Technician Signature: Date:
Technician Printed Name: Time In:
Service Agent: Time Out:
By signing this you agree that the Preventive Maintenance has been done completely and is satisfactory.
Store Manager/Operator Signature: Date:
Store Manager/Operator Printed Name: Time:
BIC TUNE UP CHECKLIST
Store #
Store Address
Store Phone #
Serial Number
Model
