QuickSpecs
Compaq iPAQ Pocket PC H3100 Series
DA-10680 World Wide — Version 16 — March 8, 2002
1
Overview
At A Glance
Compaq iPAQPocket PC H3100
Series is a monochrome device. It
offers allthe features ofthe color
iPAQPocket PC H3600 Series, at a
very competitive price.
Easy expansion and customization
through Compaq ExpansionPack
System
• Thin, lightweight design with
backlit monochrome screen
• Microsoft
Pocket PC 2002
upgradeoption
• Audio record and playback –
Audio programs from the Web,
MP3 music, or voice notations
• Rechargeable battery that gives
up to 14hoursof battery life
• Protected by Compaq Services,
includinga One-yearLimited
Warranty — Certain restrictions
and exclusions apply. Consult the
CompaqCustomerSupport
Center for details.
QuickSpecs
Compaq iPAQ Pocket PC H3100 Series
DA-10680 World Wide — Version 16 — March 8, 2002
2
Standard Features
M
ODELS
Compaq iPAQ Pocket PC H3150
174003-001 – U.S. Commercial
Compaq iPAQ Pocket PC H3135 with CF Card Expansion Pack
174003-003 – U.S. Retail
Compaq iPAQ Pocket PC H3130
174003-011 – Australia/New Zealand
174003-021 – Europe (Norway, Denmark, Sweden, Finland)
174003-031 – U.K., Hong Kong, Singapore
174003-041 – Germany
174003-051 – France
174003-061 – Italy
174003-071 – Spain
174003-161 – Latin America
174003-AD1 – Korea
QuickSpecs
Compaq iPAQ Pocket PC H3100 Series
DA-10680 World Wide — Version 16 — March 8, 2002
3
Standard Features
Processor 206-MHz Intel
StrongARM SA-1110 32-bit RISC Processor
Memory 16-MB SDRAM, 16-MB Flash Memory
Interfaces Front Panel Buttons 5 buttons plus five-way joystick; (1 on/off and backlight button
and 4 customizable application buttons)
Navigator Button 1 Five-way joystick
Side Panel Recorder Button 1, Customizable
Bottom Panel Reset Switch 1
Stylus Eject Button 1
Infrared Port 1 (115 Kb/s)
Speaker 1
Light Sensor 1
Microphone 1
Communications Port 1 (with USB/Serial connectivity)
Stereo Audio Output Jack 1 (standard 3.5 mm)
Cradle Interfaces Connector 1
Cable 1 USB or Serial cable connects to PC
DC Jack connector for AC Adapter 1
Stylus Holder 2 holes on left and right front
Stabilizing Arm Release Button 1 Arms engage sides of Pocket PC when no Expansion Pack is
in use
Display 15 grayscale, semi-transmissive graphic STN (supertwist neumatic) LCD display
Power Supply 950 mAh Lithium Polymer, rechargeable in docking cradle or with AC Adapter
Estimated battery life: 14 hours
NOTE: Battery life will vary based on an estimated typical use pattern of an average user, the configuration of the
computer and the usage pattern of the individual user. Use of some attachments may significantly decrease
battery life.
Audio Capabilities Audio record and playback (play MP3 music or audio programs from the Web)
One-touch instant-record button (for voice memos)
Integrated speaker, stereo headphone jack
Integrated microphone
Ergonomic Design Features Instant-on/off and backlight
5-way joystick
Touch-sensitive display for stylus or fingertip
5 customizable application launch buttons – Calendar, Contacts, QStart, QMenu, and Recorder buttons
4 alarm settings
Speaker on front of unit
QuickSpecs
Compaq iPAQ Pocket PC H3100 Series
DA-10680 World Wide — Version 16 — March 8, 2002
4
Standard Features
Compaq Software Bundle Powered by Microsoft Windows
for Pocket PC and Microsoft ActiveSync
3.1
Included in the Operating System:
Calendar, Contacts, Tasks, Voice Recorder, Notes, Calculator, Solitaire, Pocket Excel, Pocket Word, Pocket Internet
Explorer, Inbox, File Explorer, Microsoft Reader for ebooks and audio books, Windows Media Player
Included in ROM:
QStart, QMenu, QUtilities (includes Compaq Flash Backup and Restore), Asset Viewer, Picture Viewer
Included on CD-ROM:
Pocket Asset Manager, Reference Guide (pdf format) and Virtual Tour, llium eWallet, Audible
ActiveSync 3.1, Microsoft Outlook
2000, Pocket Streets, Microsoft Transcriber, Internet Explorer 5.0
Operating System Microsoft Windows Powered Pocket PC
Service and Support One-year Limited Warranty, with Next Business Day replacement CarePAQin NA
QuickSpecs
Compaq iPAQ Pocket PC H3100 Series
DA-10680 World Wide — Version 16 — March 8, 2002
5
Options
Operating System Microsoft Pocket PC 2002 Upgrade
NOTE: Please visit: http://www.compaqordercenter.com/ipaq2002upgrade/ for available upgrades.
NOTE: This website is available in English only.
Expansion Packs CF Card Expansion Pack 170339-B21
PC Card Expansion Pack 170338-B21
Dual-Slot PC Card Expansion Pack 216198-B21
GSM/GPRS Wireless Data and Voice Pack 219936-B21
BluetoothWireless Pack with CF Card Slot 232568-B21
232568-002
232568-021
Style Packs Cover Pack 249707-B21
Color Style Pack with styli (Emerald Green, Sapphire Blue, Ruby Red) 224254-B21
Color Style Pack with styli (Amethyst Purple, Amber Orange, and Smoky Quartz) 224255-B21
Memory/Storage IBM Microdrivewith PC Card Adapter 217390-B25
CompactFlash (CF) 32-MB Memory Card 104703-004
CompactFlash (CF) 64-MB Memory Card 104703-003
NOTE: CF Card Expansion Pack required.
Power AC Adapter 402143-xxx
Auto Adapter 180743-B21
NOTE: Part numbers ending with xxx are specific to country.
Synchronization Serial Cradle 176482-B21
USB Cradle 176481-B21
USB Autosync Cable 191007-B21
Serial Autosync Cable 191008-B21
Communications WL110 Wireless PC Card (requires PC Card Expansion Pack) 191808-B21
56K V.90 CompactFlash Fax Modem (requires CF Card Expansion Pack) 148908-xxx
RS-232 Serial Cable 236251-B21
NOTE: Part numbers ending with xxx are specific to country.
iPAQnet Mobility Solutions
(U.S. only) One-year iPAQnet airtime (CDPD use for iPAQnet Mobile Internet only) and
Sierra Wireless AirCard 300 for Windows CE, and PC Card Expansion Pack 238712-001
One year iPAQnet airtime (CDPD use for iPAQnet Mobile Internet only) and
Sierra Wireless AirCard 300 for Windows CE 238711-001
Sierra Wireless AirCard 300 for Windows CE 238113-001
One year iPAQnet airtime – (CDPD use for iPAQnet Mobile Internet only) 237424-001
One year iPAQnet airtime – unlimited CDPD use on iPAQ Pocket PC 224257-001
Cases Executive Leather Case 170340-B21
Expandable Case 217883-B21
Sport Case, Moss 227256-B21
Sport Case, Marine 227255-B21
Sport Case, Sunshine 227257-B21
Sport Case, Black 170341-B21
Premier Leather Case 253504-B21
Zippered Leather Case 262207-B21
Rugged Case 230465-B21
Three-Pack of screen protectors 253517-B21
Other 3-Stylus Replacement Kit 176184-B21
Targus Stowaway Portable Keyboard for Compaq iPAQ Pocket PCs (English) 227262-B21
QuickSpecs
Compaq iPAQ Pocket PC H3100 Series
DA-10680 World Wide — Version 16 — March 8, 2002
6
Technical Specifications
Dimensions (Hx W x D) 5.1 x 3.3 x 0.62 in/12.95 x 8.38 x 1.57 cm
System Unit
Weight 0.36 lb/0.163 kg (including battery)
Operating Temperature 32° to 104°F/0° to 40°C
Operating Humidity 20% to 90%
Regulatory Marks Electrical FCC Class B, VCCI, CE, C-Tick,
Safety CE Marking, C-UL, NOM
RAM 16 MB
ROM (Flash) 16 MB
Number of grayscales 15
Monochrome Display
Resolution (W x H) 240 x 320
Dot Pitch 0.24 mm
Viewable Image (W x H) 2.35 in x 3.1 in (3.8 in diagonal); 5.96 cm x 7.87 cm (9.65 cm diagonal)
Display Type 15 grayscale, semi-transmissive graphic STN (supertwist neumatic) LCD display
Rechargeable Battery Battery Life Up to 14 hours, 950 mAh Lithium Polymer rechargeable battery
AC Adapter Dimensions (Hx W x D) 2.86 x 1.86 x 1.83 in/7.26 x 4.72 x 4.63 cm
Cord Length (approximate) 6 ft/1.83 m
Power Supply Ratings Voltage Range 100 to 240 V Switching
Input Current 0.3 A
Input Frequency 50 to 60 Hz
Output Voltage 5 VDC
Output Current 2 Amp
Compaq PCs use genuine Microsoft
Windows
www.microsoft.com/piracy/howtotell
©2002 Compaq Information Technologies Group, L.P. All rights reserved. Compaq, the Compaq logo, iPAQ, and
CarePAQ are trademarks of Compaq Information Technologies Group, L.P. in the U.S. and/or other countries. Intel,
and the Intel Inside Logo are trademarks of Intel Corporation in the U.S. and/or other countries. Microsoft, Windows
the Windows logos, Windows media, Outlook, and ActiveSync are trademarks of Microsoft Corporation in the U.S.
and/or other countries. Bluetooth is a trademark of Bluetooth SIG, Inc. in the U.S. and/or other countries. IBM
Microdrive is a trademark of IBM Corporation in the U.S. and/or other countries. All other product names mentioned
herein may be trademarks of their respective companies. The information in this publication is subject to change
without notice.
