Munters RBS 1TH Instruction manual

Manual for use and maintenance
RBS 1TH/2TH/3TH /4TH
Hanging Turkey Scale
Ag/MIS/ImGb-2875-01/23 Rev 1.0
P/N: 116902 Rev 1.0
RBS TH
Hanging
Bird Scales

© Munters AB, 2020 2
RBS 1TH, 2TH, 3TH, 4TH
Manual for use and maintenance
Rev 1.0; 02/2023
This manual for use and maintenance is an integral part of the apparatus together with the attached
technical documentation.
This document is destined for the user of the apparatus: it may not be reproduced in whole or in part,
committed to computer memory as a file or delivered to third parties without the prior authorization of the
assembler of the system.
Munters reserves the right to effect modifications to the apparatus in accordance with technical and legal
developments.

© Munters AB, 2020 3
Index
chapter page
1INTRODUCTION ------------------------------------------------------------------------------------------------------------------------------------------------- 4
1.1 Disclaimer------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 4
1.2 Introduction---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 4
1.3 Notes ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 4
2INTRODUCTION TO RBS TH-------------------------------------------------------------------------------------------------------------------------- 5
3PHYSICAL ASSEMBLY---------------------------------------------------------------------------------------------------------------------------------------- 6
3.1 Parts List------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ 6
3.2 Assemby Instructions------------------------------------------------------------------------------------------------------------------------------------------------------------------- 7
4RBS-1TH WIRING----------------------------------------------------------------------------------------------------------------------------------------------10
5RBS-2TH WIRING----------------------------------------------------------------------------------------------------------------------------------------------13
6RBS-3TH WIRING AND CALIBRATION----------------------------------------------------------------------------------------------------14
7RBS-4TH WIRING----------------------------------------------------------------------------------------------------------------------------------------------19
8WARRANTY ---------------------------------------------------------------------------------------------------------------------------------------------------------22

© Munters AB, 2020 4
1Introduction
1.1 Disclaimer
Munters reserves the right to make alterations to specifications, quantities, dimensions etc. for production
or other reasons, subsequent to publication. The information contained herein has been prepared by
qualified experts within Munters. While we believe the information is accurate and complete, we make no
warranty or representation for any particular purposes. The information is offered in good faith and with
the understanding that any use of the units or accessories in breach of the directions and warnings in this
document is at the sole discretion and risk of the user.
1.2 Introduction
Congratulations on your excellent choice of purchasing an RBS TH!
In order to realize the full benefit from this product it is important that it is installed, commissioned and
operated correctly. Before installation or using the unit, this manual should be studied carefully. It is also
recommended that it is kept safely for future reference. The manual is intended as a reference for
installation, commissioning and day-to-day operation of the Munters Controllers.
1.3 Notes
Date of release: July 2010
Munters cannot guarantee to inform users about the changes or to distribute new manuals to them.
All rights reserved. No part of this manual may be reproduced in any manner whatsoever without the
expressed written permission of Munters. The contents of this manual are subject to change without notice.

© Munters AB, 2020 5
2Introduction to RBS TH
The RBS Hanging Bird Scale support the following controllers.
•
RBS-1TH: AC-2000 SE or AC-2000
3G
•
RBS-2TH: RSC-2 SE
Figure 1: RBS-1TH Block Diagram Figure 2: RBS-2TH Block Diagram
•
RBS-3TH: Platinum, Platinum Pro, Trio,
or RSU-2
•
RBS-4TH: AC-2000 Plus
Figure 3: RBS-3TH Block Diagram Figure 4: RBS-4TH Block Diagram

© Munters AB, 2020 6
3Physical Assembly
3.1 Parts List
•One scale platform
•One metal cross
•Four metal hanging cables
•One shackle
•One load cell
•Four L shape frame bars + split pins
•Four safety pins
L shaped frame bars
+ split pins
Metal hanging cables
Metal cross
Shackl
Load Cell
Safety pins
Scale

© Munters AB, 2020 7
3.2 Assemby Instructions
1. Connect the four L shaped bars to the scale platform as follows:
a. Thread the four hanging metal cables from the bottom side of the four frame bars (the
bottom side is the side with the split pins) right up to the corner of the bar (Figure 5).
Figure 5
b. Insert each bar to the holes on the four corners of the scale platform and use the safety pin
to secure the bars in place.
c. Start with the first bar on any corner (Figure 6)
Figure 6
d. Continue with the second bar on the opposite side of the scale platform (Figure 7 and
Figure 8) and use the metal cross to connect the two bars in the middle.
Bottom side

© Munters AB, 2020 8
Figure 7 Figure 8
e. Connect bars 3 and 4 in the same manner (Figure 9 and Figure 10).
CAUTION Do not forget to use the safty pins!
Figure 9 Figure 10
f. Thread the hanging cables and the load cell on to the shackle and screw tightly.

© Munters AB, 2020 9
2. Place a hook measuring approximately 2.40 meter/7.3 feet above the ground.
If possible make it height-adjustable for changes in flock growth.
3. Hang the load cell in place.
4. The scale platform has a 3/8" hole for a pole that will prevent platform swinging.
CAUTION Insert the pole only after the scale is in place.
3\8"
hole

© Munters AB, 2020 10
4RBS-1TH Wiring
AC-2000 SE and AC-2000 3G controllers support up to two (2) RBS-1TH scales. Refer to the controller
manual for calibration instructions. Wire the:
•RBS-1TH to an RBS-1H box (Figure 12).
•RBS-1H box to a AC-2000 SE or AC-2000 3G Controller (Figure 13 and Figure 14).
Part Number
Description
908-99-00005
RBS-1H HANG
SCALE+230V POWER
SUPPLY BOX (AC2000
SE/3G)
CHICKEN/TURKEY
908-99-00024
RBS-1H HANG
SCALE+115V POWER
SUPPLY BOX (AC2000
SE/3G)
CHICKEN/TURKEY
Figure 11: RBS-1H Box
Number
Description
1
Red wire
2
White wire
3
Green
wire
4
Black wire
Figure 12: RBS-1H Box Wiring

© Munters AB, 2020 11
Figure 13: AC-2000 SE – RBS-1H Wiring

© Munters AB, 2020 12
Figure 14: AC-2000 3G – RBS-1H Wiring
CAUTION Ground the RBS-1H !
Number
Description
1 Controller Board
2 Scale ports expanded
3 RBS-1H Box
4 RBS-1H Box ports expanded
5 RBS-1H power ports expanded
6 Black wire
7 Red wire

© Munters AB, 2020 13
5RBS-2TH Wiring
RBS-2TH supports the RSC-2 Scale Center. Insert the RBS cables into the relevant RSC ports. Wire the
input power and computer inputs as shown in Figure 15.
Figure 15: RSC – RBS-2TH Wiring

© Munters AB, 2020 14
6RBS-3TH Wiring and Calibration
RBS-3TH supports the Platinum (Figure 16), Platinum Pro (Figure 17), Trio/Echo 2.0 (Figure 18), or RSU
(Figure 19) units.
Figure 16: Platinum– RBS-3TH Wiring

© Munters AB, 2020 15
Number
Description
1 Platinum Scale Card
2 Silo power supply
3 White wire (channel)
4 Green wire (+5V)
5 Red wire (channel)
6 Black wire (-5V)

© Munters AB, 2020 16
Figure 17: Platinum Pro – RBS-3TH Wiring

© Munters AB, 2020 17
Number
Description
Number
Description
1 Platinum Pro Scale Card 6 Black wire (-5V)
2 Scale Card Expanded 7 Silo power supply
3 White wire (channel) 8 Silo power supply expanded
4 Green wire (+5V) 9 Platinum Pro power supply
5 Red wire (channel) 10 Platinum Pro power supply expanded
Figure 18: Trio/Echo 2.0 – RBS-3TH Wiring

© Munters AB, 2020 18
Number
Description
Number
Description
1 Trio Scale Card 6 Black wire (-5V)
2 Scale Card Expanded 7 Red wire (+5)
3 White wire (channel) 8 Silo power supply
4 Green wire (+5V) 9 Silo power supply expanded
5 Red wire (channel)
Number
Description
1 RBS-3TH cable
2 White wire
3 Red wire
4 Black wire
5 Green wire
6 RSU Card
Figure 19: RSU – RBS-3TH Wiring

© Munters AB, 2020 19
7RBS-4TH Wiring
AC-2000 Plus can power two RBS-4TH units. No external power supply is required. Refer to the manual
for calibration instructions.
Wire the:
•RBS-4TH to an RBS-4H box (Figure 21)
•RBS-4H box to a AC-2000 Plus Controller (Figure 22)
Part Number
Description
908-99-00025
RBS-4H HANG
SCALE BOX
(AC2000 PLUS)
CHICKEN/TURKEY
Figure 20: RBS-4H Box

© Munters AB, 2020 20
Figure 21: RBS-4H Box Wiring
