Murphy Pulsation Dampener PD8100 Series User manual

Description
The PD8100 Series eliminates pointer flutter
on pressure indicating SWICHGAGE®devices
which are subject to pulsating pressure from
reciprocating pumps or compressors. It also
allows a close setting of high and low contact
points providing for more accurate pressure
indication and control of equipment.
The PD8100 Series decreases wear on geared
movements and increases the life of pressure
indicating instruments by eliminating exces-
sive gage strain and unnecessary movement.
A necessity which quickly pays for itself by
protecting any pressure indicating and control
instrument which is subject to pulsation.
PD8100 SERIES NOT FOR USE ON
OXYGEN OR LIQUID
OXYGEN APPLICATIONS.
Quality built with a large diameter valve stem
wheel for ease of adjustment with clearly printed
operating instructions. Machined from 1-3/8 in.
(35 mm) hex bar stock. A two degree taper on
valve and stem assure positive dampening.
Available in brass, carbon steel, 303 stainless
steel or 316 stainless steel to meet pressure
and environmental requirements with either
1/2 NPT or 1/4 NPT inlet connections.
Specifications
See “How to Order” section for available inlet
and outlet connections.
PD8183: All wetted parts are Brass. Rated to
3,000 psi (20.68 MPa) [206.80 bar].
PD8184: All wetted parts are Carbon steel.
Rated to 5,000 psi (34.47 MPa) [344.70
bar].
PD8185: All wetted parts are 303 stainless
steel. Rated to 10,000 psi (68.95 MPa)
[689.50 bar].
PD8190: All wetted parts are 316 stainless
steel. Rated to 10,000 psi (68.95 MPa)
[689.50 bar]. Meets NACE standard MR-
01-75 for direct exposure to H2S.
Operating Temperature:
-15 to 400°F (-26 to 204°C)
Shipping Weight (all models):
2 lbs.(0.9 kgs.)
Shipping Dimensions (all models):
4-3/4 x 4-3/4 x 3-1/4 in. (121 x 121 x 83 mm)
Warranty
A limited warranty on materials and workmanship
is given with this FW Murphy product. A copy of
the warranty may be viewed or printed by going to
www.fwmurphy.com/support/warranty.htm
PD-95145B
Revised 11-03
Catalog Section 55
(00-02-0125)
Pulsation Dampener
PD8100 Series
■
Used On Controllers, Instruments and
Recorders to Dampen Pressure Pulsation
■
Eliminate Gage Pointer Flutter
■
Aids In Providing More Accurate
Pressure Indication
■
Decreases Wear On Gage’s
Geared Movement
NOT INTENDED FOR USE AS A SHUTOFF VALVE
RUN
START
MURPHY SWICHGAGE
MURPHY SWICHGAGE
MURPHY SWICHGAGE
MURPHY SWICHGAGE
RUN
START
MURPHY SWICHGAGE
MURPHY SWICHGAGE
Eliminate pointer flutter
like this.
Make SWICHGAGE®instruments
and recorders operate like this.

PD-95145B page 2 of 2
DESCRIPTION (see drawing–right) PD8183 PD8184 PD8185 PD8190
AB
D
CE
G
H
FJ
INLET OUTLET
Service Parts
A. 1/2 NPT inlet x 1/4 NPT outlet*65-05-0104 65-05-0210 65-05-0204 65-05-1136
1/2 NPT inlet x 1/2 NPT outlet*65-05-0105 65-05-0212 65-05-0206 65-05-1135
B. Bonnet Fitting 65-05-0099 65-05-0209 65-05-0203 65-05-1139
C. Valve Stem 65-05-0175 65-05-0208 65-05-0202 65-05-1140
D. Packing Nut 65-05-0098 65-05-0211 65-05-0205 65-05-1137
E. Hand Wheel (with 10-32 nut) 55-00-0179 55-00-0179 55-00-0179 55-00-0179
F. Strainer Bushing Assembly†55-00-0174 55-00-0173 55-00-0175 55-00-0206
G. Molded Packing Gland 00-00-0936 00-00-0936 00-00-0936 00-00-0936
H. ‘O’ Ring Bonnet Seal 00-00-0302 00-00-0302 00-00-0302 00-00-0302
J. Stainless Steel Mesh Filter** 65-05-0214 65-05-0214 65-05-0214 65-05-0214
†Provided only for units with 1/4 NPT inlet.
*For 1/4 NPT inlet use with strainer bushing assembly.
**Provided in units with 1/2 NPT inlet.
How to Order
Base Model
PD8183
PD8184
PD8185
PD8190
Connection Size
1/4 x 1/4 = 1/4 NPT inlet x 1/4 NPT outlet
1/4 x 1/2 = 1/4 NPT inlet x 1/2 NPT outlet
1/2 x 1/2 = 1/2 NPT inlet x 1/2 NPT outlet
1/2 x 1/4 = 1/2 NPT inlet x 1/4 NPT outlet
PD8185 - 1/4 x 1/4
Shown at right, is a typical
MURPHYMATIC®compres-
sor panel featuring three
Pulsation Dampeners and
Murphy’s OPLFC gages.
The PD's are recommended
for use on piston pumps and
compressors to eliminate
pointer contact flutter
and gage wear.
FLOW
3-7/8 in.
(99 mm)
3 in.
(76 mm)
5-5/16 in.
(135 mm)
4-3/4 in.
(121 mm)
diameter
OPLFC
Mounting
Hole
PD8100
Series
Mounting
Hole
1/4 in. (6 mm) dia.
holes (3 pls.) on
5-13/64 in. (132 mm)
B.C.,120°apart,
clocking as shown
1/2 in.
radius
typical
2 in.
(51 mm)
1 in.
(25 mm)
Dimensions
Mounting for the OPLFC Pressure SWICHGAGE®and PD8100 Series
The PD8100 Series pulsation dampener is mounted directly below the OPLFC.
Precautions: Dope or use teflon tape on con-
nection threads. Do not block the inlet orifice.
