PowerView™PVM Series Gages
Features
•For modern electronic engines and
equipment using SAE J1939 Controller
Area Network
•Display SAE J1939 parameters broadcast
by the PowerView system.
•Cutting-edge, stepper motor technology
and robust functionality combined
•Microprocessor driven for high accuracy
•Simple installation and wiring design
The PowerView PVM Series gages are intelligent gages designed to display easy-to-read information
transmitted by the PowerView. The PVM gages communicate with the PowerView via a single RS485
twisted pair MODBUS ® RTU serial link. The gages can be daisy-chained using quick-connect
harnesses.
The major feature of the PVM gages is their balance between design and functionality. These modern
gages offer a selection of bezel styles and colors shown on page 3 of this document.
The PVM gages also include features such as a smooth stepper motor operation for the 270 ° sweep
pointer, an environmentally sealed case with two Amp Mini Universal Mate-N-Lok connectors molded into
the casing, and green LED back lighting. They are available for standard 2-1;16 in. (52 mm) and 3-3/8 in.
(86 mm) diameter hole sizes. In addition their plastic cases incorporate a “D” shape allowing panel
cutouts that eliminate gage rotation during installation.
PVM20 Series Models
• PVM20-A = Engine Oil Pressure
• PVM20-B = Coolant Temperature
• PVM20-C = Voltmeter
• PVM20-D = Percent Load at current RPM
• PVM20-E = Transmission Oil Pressure
• PVM20-F = Transmission Oil Temperature
• PVM20-G = Engine Oil Temperature
• PVM20-H = Hydraulic Oil Temperature
• PVM20-J = Percent Fuel Level
• PVM20-K = Boost Pressure
• PVM20-L = Exhaust Gas Temperature
• PVM20-M = Intake Manifold Temperature
• PVM20-N = Auxiliary Temperature
• PVM20-P = Auxiliary Pressure
• PVM20-T = Tachometer
PVM35 Series Models
• PVM35-T = Tachometer
• PVM35-S = Speedometer

Warranty - A limited warranty on materials and workmanship is given with this FW Murphy product. A copy of the warranty
may be viewed or printed by going to www.fwmurphy.com/support/warranty.htm
Specifications
PV101 Compatibility
Maximum supported: 5 PVM Gages
Maximum distance to last gage: 8.5 Meters
Power Supply Input Voltage
5V (4.5-5,.5.5 VDC minimum & maximum voltage)
Power Supply Operating Current (@ 5 VDC) =
PVM20, PVM35: 18 mA minimum; 80 mA maximum
Backlight Maximum Current: 60mA
Input: RS485 MODBUS®RTU data.
Output: Analog Readout.
Environmental
Operating Temperature: -40 to 185°F (-40°to 85°C)
Storage Temperature: -67 to 185°F (-55°to 85°C)
Environmental Sealed Enclosure:
Sealing: IP68, ±5 PSI (±34.4 kPa)
Case and Clamp Material: Polyester (PBT)
Lens Material: Polycarbonate
Bezel Material: Polyester (PBT)
Dial: White numerals over black background
Return-To-Zero Needle Movement: Not Available for PVM20
models.
Indicating Pointer: Stepper motor operation with 270°sweep
Gage Accuracy: Better than ±1.0% of scale
Maximum Panel Thickness: 3/8 inch (9.6 mm)
Connectors:
Amp Mini Universal Mate-N-Lok
Amp Plug P/N: 172338-1
Amp Socket P/N: 171639-1
Shipping Weight: 1 Lb. (450 g.)
Shipping Dimensions:
6 x 6 x 6 in. (153 x 153 x 153 mm)
Typical Gage Dimensions

Bezel Styles
PVM20 Series – 2 inch size gages
AB
A-20 Style A A-20 Style BB Low Profile SAE Style DB Low Curved Style
PVM35 Series – 3-1/2 inch size gages
AB
A-20 Style A A-20 Style BB Low Profile SAE Style DB Low Curved Style

How to Order
Wiring Harnesses and Accessories
For details see bulletin “ 0710179 – Wiring Harness Accessories for PVM Gages” .
