Murphy Single Set Point Switch OS77 Series User manual

OS77 Series Single Set Point Switch
Installation and Operation Instructions
OS-98001N
Effective 04-98
Section 20
00-02-0303
Description
The OS77 Series single set point speed switch is a compact, all-electronic,
speed sensing module. It is field adjustable and can be panel mounted via its
trip set point potentiometer.
Standard OS77 models provide a transistor output when tripped. Models with a
relay output are available.
The OS77 is used for protecting the engine from excessive or insufficient oper-
ating speeds. As the engine speed reaches the adjustable set point setting, the
OS77 will cause the engine to shutdown.
Models are available with Normally Open or Normally Closed circuit and
available recrank feature which inhibits starter re-engagement until the engine
speed is near zero RPM.
Specifications
Power Supply: Voltage: 7-28 VDC.
Maximum Current: 100 mA.
Frequency Signal:
Voltage, Magnetic Pickup Signal Models
• Minimum: 1.2 Vrms
• Maximum: 30 Vrms
Voltage, Distributor Ignition Models
• Minimum: 6 Vrms
• Maximum: 30 Vrms
Maximum Current, Magnetic Pickup Signal Models: 0.12 mA
Maximum Current, Distributor Ignition Models: 0.12 mA
Adjustment Range, Magnetic Pickup Signal Models: 1000-10,000 Hz
Adjustment Range, Distributor Ignition Models: 40-400 Hz
Reset Differential, Magnetic Pickup Signal Models
• Non-recrank model: 10 Hz Differential
• Recrank model: dropout 54 Hz
Reset Differential, Distributor Ignition Models
• Non-recrank model: 10 Hz Differential
• Recrank model: dropout 2.4 Hz
Output:
• Transistor Sink to Ground Resistive Load: 2 A, 28 VDC
• Relay Output Models: 5 A, 250 VAC
Adjustment: 270°–turn potentiometer
Temperature Range: -13° to 185°F (-25° to 85°C)
OS77 Module Dimensions
Please read the following information before installing. A visual inspection of this product for damage during shipping is recommended
before mounting. It is your responsibility to have a qualified person install this unit and make sure it conforms to NEC and local codes.
GENERAL INFORMATION
Installation Accessories
Hardware tools and optional equipment needed to install the OS77:
● Tools as needed for system mounting such as drill and screw driver
● 18 AWG wire for extension and hook up
● Wire termination tools and ring or spade wire termination.
● Voltmeter or test lamp for set up and adjustments.
®
FRANK W.
MFR.
WARNING
BEFORE BEGINNING INSTALLATION OF THIS MURPHY PRODUCT
✔Disconnect all electrical power to the machine.
✔Make sure the machine cannot operate during installation.
✔Follow all safety warnings of the machine manufacturer.
✔Read and follow all installation instructions.
OS77 Series
1
5
234
2-1/2 in.
(64 mm) 2-3/8 in. (60 mm)
2-1/8 in.
(54 mm)
Panel
Mounting
Hardware
Potentiometer
Locknut
Speed Adj.
Potentiometer
Speed Adj.
Potentiometer
Polycarbonate
enclosure
Terminal #5 used for
Relay output models
Positioning
post
Mounting Instructions
The OS77 module is designed to be mounted in a flat panel.
1. Drill the mounting holes as shown on the template included with the packing.
2. Insert the module from the back side of the panel (refer to schematic above).
3. Secure the OS77 module using the mounting hardware included.
Mounting Schematic

Setting the OS77 Series
The OS77 Series module must be fully installed and properly wired before
attempting any of adjustment steps. These adjustment steps must be per-
formed before the fine tuning can be accomplished and should be performed
for first time setup of the OS77.
Note for relay output models only (OS77R): The following instructions
assume terminal 5 is grounded. Relay contacts are between terminals 2& 5.
1 .Turn the “SPEED ADJ. ”potentiometer
fully clockwise (Detail 1).
2 .Remove the wire from terminal #2 of
the OS77 terminal block (Detail 2).
3 .Start engine and run at the highest
RPM desired. This is the RPM at
which the engine should be shut-
down if exceeded.
4 .Connect a Voltmeter or a test light
between terminals #1 (positive+) and
terminal #2 (negative) of the OS77 ter-
minal block. You should read no voltage
or the test lamp will be OFF.
5 .Slowly turn the “SPEED ADJ. ”
pot counter-clockwise and stop
the INSTANT the battery volt-
age is indicated on the meter
or the test light comes ON.
6 .Slowly turn “SPEED ADJ.”
pot clockwise about 1/8 of an
inch. Now, tighten the locknut
(bigger nut) on the SPEED
ADJ. pot without disturbing
the setting.
7 .Re-connect the wire to terminal
#2 on the OS77 terminal block.
This reconnects the SPEED
shutdown circuitry.
NOTE: If further adjustment (fine tuning) is needed: Turning the SPEED
ADJ. pot clockwise, RAISES the shutdown point. This allows the engine to
run at a HIGHER RPM. Turning the SPEED ADJ. counter-clockwise LOW-
ERS the shutdown point. This will shutdown the engine at a LOWER RPM.
Warranty
A two year limited warranty on materials and workmanship is
provided with this Murphy product. Details are available on
request and are packed with each unit.
HOOK UP AND ADJUSTMENTS
1234 5
OS77
+
+
–
–
B
Battery
To Starter
To
Starter
Key Switch
Pressure Temp.
Rack Puller
Hold coil
Fuel Valve
Ignition Coil
Pickup
518PH/518APH
IS
1234
OS77
+–
Battery
Pickup
169PH Magnetic Switch
1234
OS77
+–To Starter
Rack Puller
Hold coil
Fuel Valve
Ignition Coil
To Distributor
Ignition
R
G
NO NC
SW1 SW2
B
+–
B
Battery
To
Starter
Key Switch
Pressure Temp.
518PH/518APH
IS
R
G
NO NC
SW1 SW2
B
SB GC
*Applies to 518APH model.
***Applies to Relay output models only. B+ can be
switched on Relay output models if desired.
** Always use shielded cable.
**
*
**
*
5
5***
***
***
OS77 Module
Front View
Speed Adj.
Potentiometer
RaiseLower
Detail 1
OS77D Model Typical Wiring Diagram (Negative Ground Only)
OS77I Typical Wiring Diagram (Distributor Ignition Applications)
OS77I Typical Wiring Diagram (For Shutting Down Magneto Ignitions)
Wiring the OS77 Series
Detail 2
WARNING: BEFORE WIRING THE OS77 MAKE SURE THE
POWER SOURCE IS OFF AND EQUIPMENT IS STOPPED.
To Pickup
To Battery–
To Battery +
Light
Meter OR
+--
1234
OS77 Module
Back View
