Mutable Instruments Ripples User manual

Installation
Ripples requires a -12V/+12V power
supply (2x5 pin connector). The red
stripe of the ribbon cable (-12V side)
must be oriented on the same side
as the “Red stripe” marking on the
module and on your power distribu-
tion board.
The module draws 35mA from both
the +12V and -12V supply rails.
Calibration
If necessary, adjust the trimmer on
the left side of the module so that
the tone emitted by the filter (when it
self-oscillates) tracks a CV sent to the
V/OCT CV input.
Online manual and help
The full manual can be found online at
mutable-instruments.net/modules/
ripples/manual
For help and discussions, head to
mutable-instruments.net/forum/
Please refer to the online manual
for detailed information regarding
compliance with EMC directives
Ripples
Liquid filter

AB
C
D E
4
Controls
A. Cutoff frequency.
B. Filter slope. The lower
position corresponds to a
12dB/octave slope (2-pole),
the upper position to a rounder
24dB/octave (4-pole). The BP
and LP outputs are affected.
C. Resonance. Goes up to
self-oscillation.
D. Input 1 level, with a tasty
analog soft-clipping.
E. FM Attenuverter. Adjusts
the amount and polarity of
frequency modulation from the
corresponding CV input.
Inputs and Outputs
1. Audio inputs. Input 1 goes
through a soft-clipping circuit,
while input 2 is always clean.
2. CV inputs for cutoff modula-
tion, resonance, cutoff modula-
tion with V/Oct tracking.
3. Voltage controlled gain for
the LP output.
4. HP, BP and LP filter out-
puts. The slope of the HP out-
put varies with the resonance.
1
2
3
1
