FILTRATION & PROCESSING SOLUTIONS QL2 WATER FILTERS INSTALLATION AND OPERATION GUIDE
The Pentair®Everpure QL2-OCS2and QL2-2K Plus Water Filters reduce chlorine taste & odor. The QL2-OCS2and QL2-2K Plus
also reduce dirt and rust, and inhibit the formation of limescale which builds up on the brewer heating elements and in the
reservoir.
PROCEDURE
The following instructions provide for installation of a QL2-OCS2or QL2-2K Plus Filter regardless of whether or not the brewer is
already installed. The label on the OCS and QL2-2K Plus cartridges illustrates and explains the procedure for cartridge insertion
and removal from the filter head. The filter cartridge should be placed into the head after the system has been installed.
1. Install the QL2-OCS2or QL2-2K Plus as close to the brewer as possible. Do not connect this filter to any other equipment.
Connect only to the cold water line and do not expose it to high temperatures.
2. Select a location for the filter [nominally 4 x 4 x 13.5 inches long (10.1 x 10.1 x 34.2 cm) including a 2.5-inch (6.3 cm)
drop-down clearance for cartridge changes]. Write the installation date and anticipated cartridge replacement date in the
space provided on the cartridge label. The QL2-OCS2and QL2-2K Plus Cartridges should be replaced every 12 months or
after 1,500 gallons or 3,000 pots have been brewed, whichever occurs first.
3. If required, shut off the incoming water supply and relieve pressure in the tubing. Cut the tubing, allowing a 4-inch
(10.1 cm) space for the filter installation between the water supply and the brewer water inlet.
4. Install compression fittings into each port of the head. Use a good grade of pipe dope or plumber tape on the body threads.
Do not overtighten the fittings.
5. Slide compression nuts up the tubing (threads toward tubing ends). Slide a ferrule onto each tubing end (brass for copper
tubing, plastic for plastic tubing). Insert a tube insert into plastic tubing.
6. Position the QL2 head assembly so that the arrow shown on top of the head corresponds to the direction of water flow and
attach the incoming cold water supply to the inlet of the head.
7. Connect the filter outlet to the brewer water inlet line. Use compression or flare fittings to make water connections to
the brewer.
8. Mount the head to the wall using the screws and star washers provided.
9. Install the QL2-OCS2or QL2-2K Plus Cartridge into the head following the instructions on the cartridge label.
10. Turn on the water and check for leaks.
NOTE: The QL2-OCS2or QL2-2K Plus Cartridge must be flushed before use by running water through it at maximum flow for
five (5) minutes to purge the cartridge of air and establish precoat.
For installations in Massachusetts, the Commonwealth of Massachusetts Plumbing Code 248 CMR shall be adhered to.
Consult your licensed plumber for installation of the system.
QL2-OCS2Water Filter QL2-2K Plus Water Filter
EVERPURE®QL2OCS2& QL22K PLUS WATER FILTERS

2 QL2 WATER FILTERS INSTALLATION AND OPERATION GUIDE
FILTER SPECIFICATIONS
Rated Service Flow
(intermittent): 0.5 gpm, (1.9 Lpm)
Temperature: 35-100°F, (2-38°C)
Min./Max. Line Pressure: 10-125 psi (0.7-8.6 bar), non-
shock. Protect from
water hammer.
Capacity: 1,500 gallons (5,678 L)
NOTES
For Cold Water Use Only.
This drinking water system must be maintained in
accordance with the manufacturer’s instructions, including
the timely replacement of filter cartridges.
This product is intended for commercial use only. Home or
similar consumer use VOIDS THE WARRANTY.
Check for compliance with state and local laws and
regulations. Do not use with water that is microbiologically
unsafe or of unknown quality without adequate disinfection
before or after the system. Systems certified for cyst
reduction may be used on disinfected waters that may contain
filterable cysts.
The term "bacteriostatic" indicates that the system limits the
passage or growth of bacteria that may already exist in the
incoming water. It does not mean that the water leaving the
system is safer to drink than the water entering the system.
REPLACEMENT PARTS
Contact your local Pentair® Everpure®Dealer for filter
cartridges or system replacement parts.
Item
No. Description Part Number
1QL2 Head EV3063-32
2 OCS2Cartridge (6 pack) EV9618-07
22K-Plus Cartridge (6 pack) EV9612-66
3Mounting Screw EV3061-96
4Star Washer EV3062-04
5Mounting Bracket EV3055-34
6Bracket Screw EV3062-03
1
3
4
5
6
2
Systems Tested and Certified by NSF International against NSF/ANSI
Standards 42 and 53 for the reduction of:
Standard No. 42 — Aesthetic Effects
Bacteriostatic Effects (OCS2Only)
Chemical Reduction
Taste and Odor
Chlorine
Mechanical Filtration
Nominal Particulate Class I
Standard No. 53 — Health Effects
Mechanical Filtration
Cyst
Asbestos

3QL2 WATER FILTERS INSTALLATION AND OPERATION GUIDE

All Pentair trademarks and logos are owned by Pentair, Inc. or its affiliates. All other registered and unregistered trademarks and logos are the property of their
respective owners. Because we are continuously improving our products and services, Pentair reserves the right to change specifications without prior notice.
Pentair is an equal opportunity employer.
© 2014 Pentair Filtration Solutions, LLC. All Rights Reserved. EV3063-28 Rev C JL14
FILTRATION & PROCESSING SOLUTIONS
EVERPURESHURFLO WORLD HEADQUARTERS, 1040 MUIRFIELD DRIVE, HANOVER PARK, IL 60133 USA • WWW.EVERPURE.COM
800.942.1153 MAIN (US ONLY) • 800.942.1153 (US ONLY) • 630.307.3000 MAIN • 630.307.3030 FAX • CSEVERPUR[email protected] EMAIL
PENTAIR AUSTALIA/NEW ZEALAND, 1-21 MONASH DRIVE, DANDENONG SOUTH, VIC 3175, AUSTRALIA
1300.576.190 TEL • [e-mail] EMAIL
EVERPURESHURFLO CHINA, 21F CLOUD 9 PLAZA, NO 1118, SHANGHAI, 200052, CHINA
86.21.3211.4588 TEL • 86.21.3211.4580 FAX • [email protected] EMAIL
EVERPURESHURFLO INDIA, GREEN BOULEVARD, B-9/A, 7TH FLOOR - TOWER B SECTOR 62, NOIDA - 201301
91.120.419.9444 TEL • 91.120.419.9400 FAX • [e-mail] EMAIL
EVERPURESHURFLO EUROPE, PENTAIR WATER BELGIUM BVBA, INDUSTRIEPARK WOLFSTEE, TOEKOMSTLAAN, 30 B-2200 HERENTALS, BELGIUM
+32.(0).14.283.500 TEL • +32.(0).14.283.505 FAX • [e-mail] EMAIL
EVERPURESHURFLO JAPAN INC., HASHIMOTO MN BLDG. 7F, 3-25-1 HASHIMOTO, MIDORI-KU, SAGAMIHARA-SHI KANAGAWA 252-0143, JAPAN
81.(0)42.775.3011 TEL • 81.(0)42.775.3015 FAX • [e-mail] EMAIL
EVERPURESHURFLO SOUTHEAST ASIA, 390 HAVELOCK ROAD, #04-01, KING’S CENTRE, SINGAPORE 169662
65.6795.2213 TEL • FAX: [phone] FAX • [e-mail] EMAIL
EPA No. 002623-IL-002
LIMITED WARRANTY
COMMERCIAL WATER TREATMENT EQUIPMENT
You have just purchased one of the finest water treatment units made. As an expression of confidence in this product, Pentair Filtration
Solutions, LLC (“PFS”) offers the following product warranty. This product is warranted against material defects in materials and
workmanship to the original end-user when installed in accordance with the PFS specifications. The warranty period commences on the
date of purchase and is administered as follows:
For a period of ONE YEAR Replaceable elements (i.e., filter & water treatment cartridges)*
For a period of FIVE YEARS The entire system (excluding replaceable elements)
The unit must be used in operating conditions that conform to PFS’s recommended guidelines. This warranty will not apply if the unit
has been modified, repaired or altered by someone not authorized by PFS.
If a part described above is found to have a material defect in materials or workmanship within the specified warranty period, you
should notify Pentair®Everpure technical service at the phone number listed below. Any part found materially defective within the terms
of this warranty will be repaired or replaced (at PFS’s discretion) by your local dealer or Pentair Everpure technical service. You pay only
freight from our factory and local dealer charges. Any item repaired or replaced pursuant to this warranty will be covered under the
original warranty terms of the system.
PFS is not responsible for damage caused by accident, fire, flood, freezing, Act of God, misuse, misapplication, neglect, oxidizing agents
(such as chlorine, ozone, chloramines and other related components), alteration, installation or operation contrary to our printed
instructions, or by the use of accessories or components which do not meet PFS’s specifications. Refer to the specifications section in
the Installation and Operating manual for approved application parameters.
Our product performance specifications are furnished with each water treatment unit. TO THE EXTENT PERMITTED BY LAW,
EVERPURE DISCLAIMS ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR PARTICULAR PURPOSE; TO THE EXTENT REQUIRED BY LAW, ANY SUCH IMPLIED WARRANTIES ARE LIMITED IN
DURATION TO THE PERIOD SPECIFIED ABOVE FOR THE ENTIRE WATER TREATMENT UNIT.
As a manufacturer, we do not know the characteristics of your water supply or the purpose for which you are purchasing this product.
The quality of water supplies may vary seasonally or over a period of time, and your water usage rate may vary as well. Water
characteristics can also differ considerably if this product is moved to a new location. For these reasons, we assume no liability for
the determination of the proper equipment necessary to meet your requirements, and we do not authorize others to assume such
obligations for us. Further, we assume no liability and extend no warranties, express or implied, for the use of this product with a non-
potable water source or a water source which does not meet the conditions for use described in the owner’s guide or performance data
sheet for this product.
OUR OBLIGATIONS UNDER THIS WARRANTY ARE LIMITED TO THE REPAIR OR REPLACEMENT (AT PFS’S DISCRETION) OF THE
FAILED PARTS OF THE WATER TREATMENT UNIT, AND WE ASSUME NO LIABILITY WHATSOEVER FOR DIRECT, INDIRECT, INCIDENTAL,
CONSEQUENTIAL, SPECIAL, GENERAL OR OTHER DAMAGES.
Some states do not allow the exclusion of implied warranties or limitations on how long an implied warranty lasts, so the above
limitation may not apply to you. Similarly, some states do not allow the exclusion of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
*Warranty applies to material defects in materials & workmanship only.
