MYE MWC-9 User manual

1
Operation Manual
MWC-9 900MHz Controller
MWC-9
Operation Manual
www.myeclubtv.com
manmwc9

2
CONTENTS
FCC Compliance Statement…………………..…………. 3
Canada Compliance Statement………………………….. 3
Specifications………………………………………….… 3
Controller Orientation (Front / Rear)…………………… 4
Keypad – Key Identification………………………….… 5
Main Features…………………………………………… 5
Display and Icon Identification…………….…………… 6
Programming - Near / Far Reception Setting…………… 6
Programming the Receiver Controller (Auto Programming)… 7
Programming the Receiver Controller (Manual Programming) 7
Attaching the Controller………………………………… 8
Intellijack…………………….………………………….. 9
Special Features…(FitP3)………………..………….….. 10
Special Features…(Auto Off)………………..…………. 10
Warranty Information…………..…………..….……..…. 11 /12

3
NOTE: This equipment has been tested and found to comply with the limits for a class B digital devise
pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in
a residential environment. This equipment generates, uses and can radiate radio frequency energy and if not installed and
used in accordance with the instruction manual may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the unit off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
•Reorient or relocate the receiver.
•Increase the separation between the equipment and the receiver.
•Connect the equipment to an outlet different from that which the receiver is connected.
•Consult your MYE dealer or experienced Radio / TV technician
FCC Compliance Statement
INDUSTRY CANADA COMPLIANCE STATEMENT
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Canada Compliance Statement
Parameter 900 MHz Receiver
Frequency Range 903.000 TO 926.0000 MHz
Input Sensitivity (20 dB SINAD) -85 dBm typical
Modulation FM Stereo deviation +/- 75KHz
Stereo Separation >25dB
Equalization BASS, FLAT,JAZZ, CLASSICAL
Audio Frequency Response 20 Hz to 13 kHz
Frequency Entry Scroll up/down.
Power 3.75 VDC TO +12VDC
SPECIFICATIONS
The MYE MWC-9 Receiver allows the user to watch and listen to any TV or other source connected to a
900MHz Transmitter. The user may also listen to the optional MYE FitP3 Music and Podcast Player when
docked. The MWC-9 can be powered directly from any standard CSAFE port using a MYE Entertainment
CSAFE cable or by an optional 9 VoltAC Adapter. Patent Pending
Product Description

4
UPPER LATCH
LOWER LATCH
UPPER LATCH
LOCKING SCREW
LOWER LATCH
LOCKING SCREW
CONTROLLER REAR VIEW
CONTROLLER FRONT VIEW
LCD DISPLAY
HEADPHONE JACK
ICON
HEADPHONE JACK
CONTROLLER KEYPAD
FITP3 PLAYER DOCK

5
MYE Wireless 900MHz TV Receiver
Model MWC-9
The MYE MWC-9 Receiver allows the user to watch and listen to any TV or other source
connected to a 900MHz Transmitter. The user may also listen to the optional MYE FitP3 Music
and Podcast Player when docked. The MWC-9 can be powered directly from any standard
CSAFE port using a MYE Entertainment CSAFE cable or by an optional 9 VoltAC Adapter.
Main Features:
FitP3 Button
Selects audio from the optional
FitP3 Player when FitP3 player is docked.
TV Button
Selects audio from TV’s connected to a
900MHz Transmitter
Channel Up/Down Buttons
Selects desired TV number
Volume Up/Down Buttons
Controls Volume Level Up and Down
Power Button
Turns Receiver ON/OFF
Mute
Mute ON or OFF
EQ Select
Select between 5 preset EQ tones:
Flat, Rock, Jazz, Classical & Bass
MWC-9 KEY IDENTIFICATION
FITP3 SELECT
CHANNEL UP
CHANNEL DOWN
FITP3 SKIP FORWARD
TV SELECT
VOLUME UP
VOLUME DOWN
EQ SETTING SELECT
MUTE
POWER ON / OFF
FITP3 PLAY / PAUSE
DISPLAY WINDOW

6
Programming - Far/Near Reception
This feature provides the ability to set the reception sensitivity of each MYE MWC-9 receiver
depending on the proximity between the receiver and transmitter.
Far Mode: (Default): The far mode is the most widely used and will accommodate the
majority of installations.
Near Mode: The near mode is used primarily in situations where the MWC-9 receiver is
positioned very close to one or more transmitters. The Near Mode is recommended when
receivers are installed between 1 and 5 feet from a transmitter.
Far / Near Mode
Note: The factory default is set to “Far” (HI).
To change to “Near” mode (LO):
1. Start with the MWC-9 in the OFF position.
2. With the unit OFF, press and hold the Volume UP button.
3. While holding the Volume UP button, press and release the POWER button.
4. Wait three seconds while continuing to hold Volume UP button until ‘LO’ is appears
on the display.
5. To revert back to Far mode simply follow steps 1-4 until “HI” appears on display.
DISPLY and ICON IDENTIFICATION
FAULTY
HEADPHONE
JACK
VOLUME
LEVEL
INDICATOR
CHANNEL
FITP3 MODE
SELECTED
CURRENT
CHANNEL
TRANSMITTER
TV MODE
SELECTED
MUTE “ON”
EQ PRESETS
FREQUENCY
DETECTED IN
AUTO PROGRAM
MODE

7
Programming
The MYE MWC-9 receiver must be programmed to detect and lock in the MYE
Entertainment transmitters as well as the other brands of transmitters listed below. The
MWC-9 features both “auto” and “manual” program modes. In the auto mode the MWC-9
will automatically search for and program in your transmitters. The manual mode provides
the ability to add or erase a specific transmitter channel or unwanted frequency caused by
spurious emissions or other local elements.
Auto Program Mode
1. Press Channel Down and Volume UP buttons simultaneously for three seconds until
“P-1” appears on the display.
2. Press the “>>” OR “<<” buttons to select one of the following program modes:
P-1 = MYE Entertainment 900MHz Transmitters
P-2 = Cardio Theater LCS 900MHz Transmitters
P-3 = Cardio Theater / Enercise xTV 900MHz Transmitters
P-4 = BroadcastVision 900MHz Transmitters
3. After selecting the Transmitter Mode, press the Play button to auto-scan and lock
transmitters.
4. Press the Channel UP or Channel Down buttons to determine all transmitters have
been locked in. NOTE: “PRESET” will appear in the display when a transmitter
channel is programmed.
5. To exit program mode press the EQ button. The display will blink briefly and the will
default to first transmitter channel programmed.
Manual Program Mode (Add or Delete Frequencies)
1. Press Channel Down and Volume UP buttons simultaneously for three seconds until
“P-1” appears on the display.
2. Press the “>>” OR “<<” buttons to select one of the following transmitter program
modes listed above.
3. Press the EQ button
4. Press CHANNEL UP/DOWN buttons to scroll through all transmitter channels.
5. To add or delete a transmitter channel press the “TV” button. NOTE: “PRESET” will
appear in the display when a transmitter channel is programmed.
6. To exit manual program mode press the EQ button. The display will blink briefly and
twill default to first transmitter channel programmed.

8
Attaching the Controller
1. Remove the rear mounting cup from the controller by loosening the two screws and
opening both metal latches on the back of the controller
2. Attach the rear mounting cup to the desired mounting location by either using the
secure clamp or traditional nylon wire ties. Secure Clamp- Insert screws (included)
3. Insert the Control power cable or CSAFE cable through the square opening of the
rear mounting cup. (PIC 3)
4. Connect the cable to the data port on the rear of the MYE Controller
5. Plug the power supply to an AC outlet or the CSAFE cable to an active CSAFE port.
6. Rotate the MYE Controller so it is vertical and position on the rear mounting cup
7. Lock the Controller in place by securing both metal clamps and tightening screws.
Shallow Cup with Secure Lock Mounting
PIC 3 Shallow Cup with Nylon Wire Tie Mounting
When CSAFE cables are required for power, USE only MYE Entertainment CSAFE cables with all
MYE Entertainment receiver controllers (900 MHz or FM). MYE Entertainment will not be
responsible for damage to controllers or CVE when alternate or other brand cables are used.

9
IntelliJack - Self Diagnostic Headphone Jack
The IntelliJack self diagnostic headphone circuit detects when the headphone jack has
failed or been damaged. When a faulty headphone jack is detected, a flashing “headphone”
icon appears in the LCD display. It will remain on until a new jack is installed and the icon
reset.
To Replace the Intellijack:
1. Loosen the two screws evenly on the bottom of the IntelliJack module and remove.
2. Carefully insert new IntelliJack module without bending contact pins.
3. Reset the Icon. Turn MYE Controller OFF then press and hold the “Power” button for
3-4 seconds. When the icon appears again release the Power button.
IMPORTANT NOTICE: Faulty headphones may trigger the fault headphone jack icon. It is
important to audibly test the headphone jack prior to replacement. If the headphone jack is
deemed OK simply follow step #3 above to reset the faulty headphone jack.

10
Special Features:
FitP3 Player Feature-
The MWC-9 controller has the ability to receive the MYE Entertainment FitP3 Player. Insert
the FitP3 Player into the FitP3 docking port. When the FitP3 Player is docked the MP3 Icon
illuminates in the LCD Window
The audio from the Controller, regardless of source will be directed to the headphone jack of
the FitP3 Player. The FitP3 Player can now be controlled through the use of the FitP3
Control Keys on your controller.
FitP3 Basic Functions-
Play & Pause
Back <<
Forward >>
Auto OFF Sensor-
The MYE Controller will monitor for the absence of vibration for 10 minutes. Should this
occur, the console will automatically power OFF saving energy and extending product
lifespan. This feature can be programmed enabled or disabled.
To Enable the Auto OFF Sensor:
1. Press the “Channel Down & Volume” buttons simultaneously for 3-5 seconds unit
the word “OFF” is displayed
2. Press the “TV” button to turn the feature ON or OFF
3. Press the “EQ” button to exit.

11
PLEASE READ THESE WARRANTY TERMS AND CONDITIONS CAREFULLY BEFORE USING YOUR MYE
ENTERTAINMENT PRODUCT. BY USING THE EQUIPMENT, YOU ARE CONSENTING TO BE BOUND BY THE
FOLLOWING WARRANTY TERMS AND CONDITIONS.
LIMITED WARRANTY
MYE ENTERTAINMENT (MYE) WARRANTS ALL NEW MYE PRODUCTS TO BE FREE FROM DEFECTS IN MATERIALS
AND MANUFACTURERS FOR THE WARRANTY PERIODS SET FORTH BELOW. THE WARRANTY PERIODS
COMMENCE ON THE INVOICE DATE OF THE ORIGINAL PURCHASE. THIS WARRANTY APPLIES ONLY AGAINST
DEFECTS DISCOVERED WITHIN THE WARRANTY PERIOD AND EXTENDS ONLY TO THE ORIGINAL PURCHASER OF
THE PRODUCT. PARTS REPAIRED OR REPLACED UNDER THE TERMS OF THIS WARRANTY WILL BE
WARRANTED FOR THE REMAINDER OF THE ORIGINAL WARRANTY PERIOD ONLY. TO CLAIM UNDER THIS
WARRANTY, THE BUYER MUST NOTIFY MYE OR YOUR AUTHORIZED MYE ENTERTAINMENT DEALER WITHIN
30 DAYS AFTER THE DATE OF DISCOVERY OF ANY NONCONFORMITY AND MAKE THE AFFECTED PRODUCT
AVAILABLE FOR INSPECTION BY MYE ENTERTAINMENT OR ITS SERVICE REPRESENTATIVE. MYE
ENTERTAINMENT PRODUCTS DEEMED DEFECTIVE BY A MYE ENTERTAINMENT REPRESENTATIVE WILL BE
ISSUED A RETURN AUTHORIZATION NUMBER. MYE ENTERTAINMENT WILL NOT ACCEPT RETURNS WITHOUT
A RETURN AUTHORIZATION NUMBER. MYE ENTERTAINMENT RESERVES THE RIGHT, AT THEIR OPTION, TO
REPAIR OR REPLACE THE PRODUCT AFTER VERIFICATION OF DEFECT. PRODUCT THAT FAILS AFTER THE
WARRANTY PERIOD EXPIRES WILL BE REPAIRED OR REPLACED AT THE CURRENT PART AND LABOR
PRICING AFTER AUTHORIZATION FROM THE CUSTOMER. REPAIRS ARE WARRANTED FOR 90 DAYS. MYE
ENTERTAINMENT’S OBLIGATIONS UNDER THIS WARRANTY ARE LIMITED AS SET FORTH BELOW:
WARRANTY PERIODS AND COVERAGE:
MYE ENTERTAINMENT TRANSMITTERS 3 YEAR PARTS, LABOR
MYE ENTERTAINMENT RECEIVERS 1 YEAR PARTS, LABOR
CONDITIONS AND RESTRICTIONS:
THIS WARRANTY IS VALID ONLY IN ACCORDANCE WITH THE FOLLOWING CONDITIONS:
THE WARRANTY APPLIES TO THE MYE ENTERTAINMENT PRODUCT ONLY 1) WHILE IT REMAINS IN THE
POSSESSION OF THE ORIGINAL PURCHASER AND PROOF OF PURCHASE IS DEMONSTRATED. 2) IT HAS NOT
BEEN SUBJECT TO ACCIDENT, MISUSE, ABUSE, IMPROPER SERVICE, MECHANICAL OR ELECTRICAL NON-MYE
ENTERTAINMENT AUTHORIZED MODIFICATION. 3) CLAIMS MADE WITHIN THE WARRANTY PERIOD.
THIS WARRANTY DOES NOT COVER DAMAGED OR FAILURE CAUSED BY ELECTRICAL WIRING NOT BEING IN
COMPLIANCE WITH ELECTRICAL CODES OR MYE’S OWNER MANUAL SPECIFICATIONS, OR FAILURES TO
PROVIDE REASONABLE AND NECESSARY MAINTENANCE AS OUTLINED IN THE OWNER’S MANUAL.
WARRANTIES OUTSIDE THE UNITED STATES AND CANADA MAY VARY. PLEASE CONTACT YOUR LOCAL
DEALER FOR DETAILS.
LIMITED WARRANTY SHALL NOT APPLY TO:
1) SOFTWARE UPGRADES.
2) NORMAL WEAR AND TEAR, CONSUMABLES AND COSMETIC ITEMS INCLUDING BUT NOT LIMITED TO
LABELS.
3) REPAIRS REFORMED ON MYE PRODUCTS MISSING ASERIAL NUMBER OR WITH A SERIAL TAG THAT HAS
BEEN ALTERED, REATTACHED OR DEFACED.
4) SERVICE CALLS TO CORRECT INSTALLATION OF THE PRODUCT OR INSTRUCT OWNERS ON HOW TO
USE THE PRODUCT.
5) PICK UP AND DELIVERY INVOLVING REPAIRS
6) ANY LABOR COSTS INCURRED BEYOND THE APPLICABLE LABOR WARRANTY PERIOD
7) THE USER IS CAUTIONED THAT CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE
MANUFACTURER OF THE PRODUCT COULD VOID THE USER’S AUTHORITY TO OPERATE THE PRODUCT.
WARRANTY

12
THE WARRANTIES PROVIDED HEREIN ARE THE EXCLUSIVE WARRANTIES GIVEN BY MYE ENTERTAINMENT AND
SUPERSEDE ANY PRIOR, CONTRARY OR ADDITIONAL REPRESENTATIONS, WHETHER ORAL OR WRITTEN. ANY
IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE THAT APPLY TO ANY PARTS DESCRIBED ABOVE ARE LIMITED IN DURATION TO THE PERIODS OF
EXPRESS WARRANTIES GIVEN ABOVE FOR THOSE SAME PARTS. MYE HEREBY DISCLAIMS AND EXCLUDES
THOSE WARRANTIES THEREAFTER. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. MYE ENTERTAINMENT ALSO HEREBY
DISCLAIMS AND EXCLUDES ALL OTHER OBLIGATIONS OR LIABILITIES, EXPRESS OR IMPLIED, ARISING BY LAW
OR OTHERWISE, WITH RESPECT TO ANY NONCONFORMANCE OR DEFECT IN ANY PRODUCT, INCLUDING BUT
NOT LIMITED TO: (A) ANY OBLIGATION, LIABILITY, RIGHT, CLAIM OR REMEDY IN TORT, WHETHER OR NOT
ARISING FROM THE NEGLIGENCE OF MYE OR ITS SUPPLIERS (WHETHER ACTIVE, PASSIVE OR IMPUTED); AND
(B) ANY OBLIGATION, LIABILITY, RIGHT, CLAIM OR REMEDY FOR LOSS OF OR DAMAGE TO ANY PRODUCT. THIS
DISCLAIMER AND RELEASE SHALL APPLY EVEN IF THE EXPRESSED WARRANTY SET FORTH ABOVE FAILS OF
ITS ESSENTIAL PURPOSE.
FOR ANY PRODUCT DESCRIBED ABOVE THAT FAILS TO CONFORM TO ITS WARRANTY, MYE ENTERTAINMENT WILL
PROVIDE, AT THEIR OPTION ONE OF THE FOLLOWING: 1) REPAIR, 2) REPLACEMENT OR 3) REFUND OF THE
PURCHASE PRICE.
MYE AND/OR ITS SUPPLIERS SHALL HAVE NO OBLIGATION OR LIABILITY, WHETHER ARISING IN CONTRACT
(INCLUDING WARRANTY), TORT (INCLUDING ACTIVE, PASSIVE, OR IMPUTED NEGLIGENCE AND STRICT
LIABILITY), OR OTHERWISE, FOR DAMAGE TO THE PRODUCT, PROPERTY DAMAGE, LOSS OF USE, REVENUE OR
PROFIT, COST OF CAPITAL, COST OF SUBSTITUTE PRODUCT, ADDITIONAL COSTS INCURRED BY BUYER (BY
WAY OF CORRECTION OR OTHERWISE) OR ANY OTHER INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, WHETHER RESULTING FROM NON-DELIVERY OR FROM THE USE, MISUSE OR INABILITY TO USE THE
PRODUCT. THIS EXCLUSION APPLIES EVEN IF THE ABOVE WARRANTY FAILS OF ITS ESSENTIAL PURPOSES
AND REGARDLESS OF WHETHER SUCH DAMAGES ARE SOUGHT FOR BREACH OF WARRANTY, BREACH OF
CONTRACT, NEGLIGENCE OR STRICT LIABILITY IN TORT OR UNDER ANY OTHER LEGAL THEORY.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES SO
THE ABOVE LIMITATION MAY NOTAPPLY TO YOU.
THIS WARRANTY GIVES SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE
TO STATE.
WARRANTY – cont.
MYE Entertainment LLC All Rights Reserved 2006
MYE Entertainment, LLC
25129 The Old Road
Suite 305
Stevenson Ranch, Ca. 91381
1-661-964-0217
www.myeclubtv.com
