SmartMyk
Owner’s Guide

1.0
The mechanics
The microphone is manufactured from
polycarbon ABS, ensuring strength and
resilience even in extreme temperatures.
The barrel of the microphone houses
the metal resistance tube and the
microphone capsule.
The fully integrated shock mount
system is made of TPE synthetic
rubber which is weather resistant.
This is built into the body of the
microphone casing.
The electronic switches are also
weather resistant. The cold shoe
and camera attachment system
is manufactured with high quality
stainless steel.
2.0
The electronics
There are two switches on the rear
panel of the microphone. On the right
is the power switch marked 1 (ON) and
0 (OFF).
On the left is the amplier gain switch.
The amplier in the microphone has a
three position gain control. The centre
position is the normal setting where
the amplier provides a direct signal
to the camera. Moving the switch to
the left-hand side position boosts the
signal by +15dB. This is used with
cameras that have an adjustable gain
control and where it is preferable to
have increased gain at the input of
the camera to reduce noise from the
cameras amplier. The right position
selects a gain reduction off -15db.
This is used when the recorded source
is either extremely loud or an external
device is being used for recording.
Located between the switches is a
battery status indicator, which ashes
red to indicate that the amplier
is switched on and is in use. The
microphone will not operate without
the power switch being selected to
ON. To maximise the battery life it
is recommended to switch off the
amplier when the microphone is not
in use.
The team at My Myk Pty Ltd in Sydney Australia would like to
thank you for choosing the SmartMyk DSLR/Video camera
microphone.
SmartMyk has been designed for use with any DSLR or video
camera that is fitted with a flash shoe adaptor, more commonly
known as a hot shoe or cold shoe. Although the microphone was
designed as a solution for DSLR cameras, it works plugged into
any audio source.
SmartMyk |Owner’s Guide
Please ensure the AGC (Automatic
Gain Control) is switched off in
the camera menu to ensure the
microphone can operate to its
specied performance

3.0
The capsule
A Super Cardioid back electret capsule
with extremely good directional
properties enhanced with the
assistance of the resistant tube.
The manner in which the microphone
has been tuned with the tube makes it
an ideal microphone for recording dialog,
as it has a very clear and unmuddied
frequency response. The capsule is
tuned to minimise low frequency sounds
such as trafc rumble.
The battery
The battery can be found located in
the drawer on the side of the microphone
electronic housing. By opening the door
and pulling out the tray in a horizontal
motion, the battery is revealed and can
be easily removed by simply pushing
it out from the tray. The battery should
be placed in the battery holder with the
+ sign on the battery facing downward.
The battery is a standard 2032 button
cell battery readily available in most
supermarkets. The battery will offer
over 300 hours of continuous use.
4.0
The foam windsock
The windsock is manufactured from
reticulated polyurethane foam. The
sock is designed to minimize light wind
noise; however in high wind situations
it is recommended that a uffy wind
protector be tted. These are available
from many third party suppliers. The
outer size of the wind sock is 22mm in
diameter and 120 mm in length.
5.0
The cable
The cable utilizes a 3.5 TRS gold
plated connector which will plug into
the microphone input of most DSLR
and domestic video cameras. If your
camera requires a different input plug
there are many adaptors available on
the market. The cable is 150mm in
length which can be extended using
any 3.5mm extension cable.
6.0
Attaching the microphone to
the camera
The microphone is tted to the
camera by attaching it to the cold
shoe adaptor, usually found located
on the top of the viewnder section.
Carefully unscrew the knurled disc
on the thread under the microphone.
Position the square metal plate on
the bottom of the metal thread into
the cold shoe (Flashgun Adaptor) and
tighten the knurled disc down onto the
camera to secure the microphone to
the body of the camera. Next take the
3.5mm plug on the end of the audio
cable and connect the microphone into
the microphone input socket on the
camera. This socket is usually located
behind a rubberized ap on the side of
the camera body.
For suggestions on how to optimise
SmartMyk, please visit our web site
www.mymyk.com.
More information
For more information on any of our products, including warranty information,
please visit mymyk.com
