NAD CI 8-120 DSP User manual

AUDIO OUT
LR
MODEM USBLAN 4
LAN 3LAN 2LAN 1
DISPLAY USB USB
2 CHANNEL AUDIO OUT
UNBALANCED
RBALANCED LBALANCED
L
R
© NAD CI 8-120 DSP
© NAD CI 8-120 DSP
1.
®CI 8-120 DSP Multi-Channel Amplier
Quick Setup Guide
© NAD CI 8-120 DSP
x1/x2 x1/x2/x3/x4
GUIDELINE FOR NETWORK SETUP CONNECTION
This guideline is applicable to PC, MAC or smartphone control devices. Adapt the guidelines according to your
control device.
1 Use an Ethernet cable (not supplied) to connect CI 8-120’s LAN port to your Wired network or router.
IMPORTANT NOTES
• For wired connection to be established, ensure that a broadband router that supports Ethernet is setup and
available.
• Ensure that CI 8-120 and the control device (PC, Mac or smartphone device) are connected to the same network.
• Note the MAC ID listed below the rear panel LAN port as this information is needed when you identify the CI
8-120 from your network.
2 Power up your CI 8-120. The CI 8-120 will not communicate with the network when in Eco standby mode.
3 Use any network IP scanner to nd your CI 8-120’s Network ID (listed as the product name (NAD CI 8-120 DSP)
immediately followed by the last six digits in the MAC (Machine Access Control) address (example: NAD CI
8-120 DSP_123456). Note also the corresponding IP address assigned by the network.
4 Type the IP address into your control device’s web browser to access your CI 8-120’s User Interface (UI).
5 Congure your CI 8-120’s Identication, Input/Output, DSP and Settings parameters via User Interface.
FIRMWARE UPGRADE PROCEDURE
1 Upon gaining access to your CI 8-120’s User Interface, check immediately for any rmware update by selecting
“Check For Updates”from the “Settings”tab.
2 Follow the rmware upgrade prompt instructions to complete the upgrade process.
POWER OPTIONS
SETTING DESCRIPTION
Power button Press power button to set unit to operating or standby mode.
Always On Unit is always in operating mode. Shut down power by disconnecting unit’s AC plug from the mains power
source.
12V Trigger Presence or absence of +12V DC supply from compatible devices to rear panel +12V TRIGGER IN will
remotely switch the unit to operating or standby mode.
Signal Sense Unit will instantaneously turn from standby to operating mode if it senses any input signal (approximately
above 2 mV RMS input) applied through any of the GLOBAL or LINE INPUT sockets.
IMPORTANT
CI 8-120 factory default setting for Eco Mode is ON. With “Power Mode” set to “Signal Sense” and “Eco Mode” set
to “ON”, CI 8-120 will automatically go to Eco standby mode after 20 minutes of no active audio source input.
nadelectronics.com/product/ci-8-120-multi-channel-amplier
support.nadelectronics.com
© NAD CI 8-120 DSP
© NAD CI 8-120 DSP
© NAD CI 8-120 DSP
© NAD CI 8-120 DSP
© NAD CI 8-120 DSP
© NAD CI 8-120 DSP

©2019 NAD ELECTRONICS INTERNATIONAL, A DIVISION OF LENBROOK INDUSTRIES LIMITED
All rights reserved. NAD and the NAD logo are trademarks of NAD Electronics International, a division of Lenbrook Industries Limited.
No part of this publication may be reproduced, stored or transmitted in any form without the written permission of NAD Electronics International.
CI8-120DSP-QS-EN-v12 - 07/19
3.
© NAD CI 8-120 DSP
2.
x1/x2/x3/x4
+ -- +
STEREO
© NAD CI 8-120 DSP
© NAD CI 8-120 DSP
© NAD CI 8-120 DSP
© NAD CI 8-120 DSP
x1/x2/x3/x4
- +
BRIDGE
STANDBY AND CHANNEL LED STATUS INDICATORS
DESCRIPTION STANDBY LED STATUS CHANNEL LED 1-8 STATUS
Operating mode Blue If there is a signal, corresponding channel
LED is solid blue or no light if no signal.
Standby mode Amber O, no light
System reboot Flashing amber O, no light
Overvoltage or under voltage Red O, no light
AMP current error Red Corresponding channel LED is red.
AMP DC error Red Corresponding channel LED is red.
POWER CONSUMPTION AND HEAT OUTPUT
CONDITION
230V/50Hz 120V/60Hz
POWER
CONSUMPTION (W)
HEAT OUTPUT
(BTU/HR)
POWER
CONSUMPTION (W)
HEAT OUTPUT
(BTU/HR)
Eco Mode Standby Power at 8 ohms 0.5 1.7 0.5 1.7
Network Standby Power at 8 ohms 1 3.4 1 3.4
Idle power at 8 ohms 65 222 65 222
Output power at 8
ohms, all channels
driven
1/8 rated power 190 648 195 665
1/3 rated power 415 1416 420 1433
1/2 rated power 600 2048 610 2082
Full rated power 1125 3840 1270 4334
Output power at 4
ohms, all channels
driven
1/8 rated power 195 665 205 700
1/3 rated power 435 1485 445 1519
1/2 rated power 630 2150 645 2201
Full rated power 1290 4403 1355 4625
IMPORTANT
Visit nadelectronics.com/product/ci-8-120-multi-channel-amplier or support.nadelectronics.com for further information and assistance.
